TRENDnet's TW100-BRF114U 4-Port Cable/DSL Firewall Router

with integrated USB Print Server allows users to easily and

securely share an Internet connection, files, virtually all types of

USB printers, and other resources. The router’s Stateful Packet

Inspection Firewall (SPI) protects against popular Denial of

Service attacks, while Multiple Web Patrol features allow parents

and Network Administrators to restrict internet access based on

clients' IP Addresses, Time/Date, URL Keywords, and Service

Types. The TW100-BRF114U’s integrated USB Print Server

allows users to transform a standalone USB Printer into a shared

network resource for increased cost-savings and productivity. An

intuitive web browser configuration makes configuring the

TW100-BRF114U quick and easy.

TW100-BRF114U

Cable/DSL 4-Port Firewall Router w/

USB Print Server

TW100-BRF114U

rev:07.18.2006

• Compliant with Windows 95/98/ME/NT/2000/XP, Unix, and Mac System

• Supports TCP/IP Printing Protocol with Peer to Peer Printing Method

• Supports of up to 100 (IPSec, L2TP, PPTP) Pass-Through Sessions Simultaneously

• Website Access Restriction using URL Keywords (50 entries)

• Provides Virtual Servers(40 entries) and Services Type Control

• Provides Access Control with User Define Services Types (70 entries)

• Provides Static Routing, Dynamic DNS Service and Multi-DMZ

• ALGs (Application Level Gateways) with Special Application Support (6 entries) and UPnP (Universal Plug & Play) Support

• Supports Network Address Translation (NAT/NAPT) and Stateful Packet Inspection (SPI) Firewall

• Real-Time Email Alert and Logs (Outgoing, Access Control & DoS Attacks)

• Easy Web Browser Configuration and Remote Management

• Flash Memory for Firmware Upgrade and Save/Restore Router Configuration

• 5-Year Warranty

FEATURES

BENEFITS

Easy Integration:

With the built-in 10/100Mbps Switch, you can integrate this device to any Ethernet/Fast Ethernet Network

Cost-Effectiveness:

Share the broadband Internet connection, saves router costs and account charges

Security:

Firewall Protection keeps hackers out

Performance:

Experience the high speed Internet access while reducing network traffic

Protocols

Security

Protocol

WAN

LAN

Printer Port

LED Indicators

LAN Ports

Power Adapter

Dimensions (L x W x H)

Weights

VPN Pass-Through

Printing Method

Temperature

Certifications

• IEEE 802.3 (10-Base T), 802.3u (100-Base TX)

• NAT, PPPoE, HTTP, DHCP, TCP/IP, UDP, PAP, CHAP, RIP1, RIP2, DDNS

• 141 x 100 x 27 mm (5.5x 3.9 x 1.06 inches)

• NAT Firewall, SPI Firewall

• PTP (Peer-to-Peer) over TCP/IP, LPD

• 1 x 10/100Mbps Port (Internet)

• 4 x 10/100Mbps Auto-MDIX Ports

• 1 x USB 1.1 Port

• 12V DC, 800mA

• URL Filter, Access Control, Password Protection, Email Alert and Logs

• Operating: 0° to 40° C (32° to 104° F) ; Storage: -10° to 70° C (14° to 158° F)

• Operating: 0° % ~ 80° % (non-condensing) ; Storage: 0°% ~ 95°% (non-condensing)

• CE, VCCI

• TCP/IP

• IPSec, PPTP, L2TP (100 Sessions)

• Unit: Power, Status, WAN

• Link/Act, 100

• 0.36 kg (12.8 oz.)

Humidity

Firewall

Standards

Hardware

Router

Print Server

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

Cable/DSL 4-Port Firewall Router w/ USB Print Server

TW100-BRF114U

RELATED PRODUCTS

TW100-BRV204

TW100-S4W1CA

TW100-BRV304

TW100-BRF114 Cable/DSL 4-Port Firewall Router

Cable/DSL VPN Firewall Router

DSL/Cable Broadband Router with 4-Port Switch

Cable/DSL Advanced VPN Firewall Router

ORDERING INFORMATION

To Order Please Call:

1-888-326-6061

3135 Kashiwa Street,Torrance, CA 90505 USA

Tel: 1-310-891-1100

Fax: 1-310-891-1111

Web:

Email: [email protected]

www.trendnet.com

NETWORKING SOLUTIONS

SPECIFICATIONS

Cable/DSL

Modem

Internet

Cable/DSL 4-Port Firewall Router with USB Print Server

(TW100-BRF114U)

(TE100-PCIWN)

Workstations with

Fast Ethernet Card

100Mbps

USB Printer

(TE100-PCIWN)

Server with

Fast Ethernet Card
