TRENDnet TEW-PC16 Manual de usuario

TEW-PC16

11Mbps Wireless

PCMCIA Network Card

User’sGuide

Rev 1.1

Regulatory Compliance

FCC Warning

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interfer-

ence in a residential installation. This equipment generates, uses and

can radiate radio frequency energy and, if not installed and used in ac-

cordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

?? Reorient or relocate the receiving antenna.

?? Increase the separation between the equipment and receiver.

?? Connect the equipment into an outlet on a circuit different from that

to which the receiver is connected.

?? Consult the dealer or an experienced radio/TV technician for help.

You are cautioned that changes or modifications not expressly ap-

proved by the party responsible for compliance could void your

authority to operate the equipment.

FCC Radiation Exposure Statement

This equipment complies with FCC radiation exposure limits set forth for

an uncontrolled environment.

This equipment should be installed and operated with minimum distance

20cm between the radiator & your body.

Wireless LAN card user’sguide

CE Mark Warning

This is a Class B product. In a domestic environment, this product may

cause radio interference, in which case the user may be required to take

adequate measures.

About this Guide

This User’s Guide describes how to install and operate your Wireless

LAN card. Please read this guide before installing the product.

This guide includes the following topics:

?? Product description, features and specifications.

?? Hardware installation procedures.

?? Software installation procedures.

?? Troubleshooting procedures.

Preface

iii

Table of contents

CHAPTER 1...................................................................................................................1

Introduction 1

Features...........................................................................................................1

What is Wireless LAN?..................................................................................2

LAN Modes......................................................................................................3

Notes on wireless LAN configuration........................................................4

CHAPTER 2...................................................................................................................5

Hardware installation 5

What’s in the package..................................................................................5

Hardware description...................................................................................5

Inserting the Wireless LAN card .................................................................6

Status LEDs.....................................................................................................7

Ejecting the Wireless LAN card...................................................................7

CHAPTER 3...................................................................................................................9

Driver installation for Windows and Linux 9

Driver installation for Windows 95............................................................9

Driver installation for Windows 98..........................................................16

Driver installation for Windows 2000.....................................................19

Driver installation for Windows NT 4.0 ..................................................24

Driver Installation for Windows ME........................................................29

Driver installation for Linux.....................................................................31

CHAPTER 4.................................................................................................................34

Using the Wireless Utility 34

Installation in Windows.............................................................................34

Using the Wireless Utility...........................................................................42

APPENDIX A...............................................................................................................46

Troubleshooting 46

Q&A for Windows environments...............................................................46

APPENDIX B...............................................................................................................48

Specifications...............................................................................................48

Chapter 1

Introduction

Thank you for purchasing the Wireless LAN card. This high-speed

Wireless LAN card provides you with an innovative wireless net-

working solution. The Card is easy to set up and use. With this

innovative wireless technology, you can share files and printers on

the network—without inconvenient wires! Now you can carry the

LAN in your pocket!

Features

?? Wire-free access to networked resources from anywhere beyond

the desktop

?? Low interference & high susceptibility guarantee reliable perform-

ance

?? Delivers data rate up to 11 Mbps

?? Dynamically shifts between 11, 5.5, 2, and 1 Mbps network speed,

based on signal strength for maximum availability and reliability of

connection

?? Allows users move between Access Points without resetting their

connection configuration

?? Antenna is built into the card with LEDs indicating Power and

Link

?? Uses 2.4GHz frequency band, which complies with worldwide re-

quirement

?? Supports most popular operating systems: Window

95/98/2000/NT 4.0/ME and Linux

?? Ensures great security by providing the Wired Equivalent Privacy

(WEP) defined in the IEEE 802.11 standard

Wireless LAN card user’sguide

What is Wireless LAN?

Wireless Local Area Network (WLAN) systems offer a great

number of advantages over traditional wired systems. WLANs are

flexible and easy to setup and manage. They are also more eco-

nomical than wired LAN systems.

Using radio frequency (RF) technology, WLANs transmit and re-

ceive data through the air. WLANs combine data connectivity with

user mobility. For example, users can roam from a conference

room to their office without being disconnected from the LAN.

Using WLANs, users can conveniently access shared information,

and network administrators can configure and augment networks

without installing or moving network cables.

WLAN technology provides users with many convenient and cost

saving features:

?? Mobility: WLANs provide LAN users with access to real-

time information anywhere in their organization, providing

service opportunities that are impossible with wired net-

works.

?? Ease of Installation: Installing is easy for novice and ex-

pert users alike, eliminating the need to install network

cables in walls and ceilings.

?? Scalability: WLANs can be configured in a variety of to-

pologies to adapt to specific applications and installations.

Configurations are easily changed and range from peer-to-

peer networks suitable for a small number of users to full

infrastructure networks of thousands of users roaming over

a broad area.

—Introduction

LAN Modes

Wireless LANs can be configured in one of two ways:

Ad-hoc

Networking Also known as a peer-to-peer network, an ad-hoc

network is one that allows all workstations and com-

puters in the network to act as servers to all other

users on the network. Users on the network can

share files, print to a shared printer, and access the

Internet with a shared modem. However, with ad-hoc

networking, users can only communicate with other

wireless LAN computers that are in the wireless LAN

workgroup, and are within range.

Infrastructure

Networking Infrastructure networking differs from ad-hoc network-

ing in that it includes an access point. Unlike the ad-

hoc structure where users on the LAN contend the

shared bandwidth, on an infrastructure network the

access point can manage the bandwidth to maximize

bandwidth utilization.

Additionally, the access point enables userson a

wireless LAN to access an existing wired network,

allowing wireless users to take advantage of the

wired networks resources, such as Internet, email,

file transfer, and printer sharing.

Infrastructure networking has the following advan-

tages over ad-hoc networking:

?? Extended range:each wireless LAN computer

within the range of the access point can com-

municate with other wireless LAN computers

within range of the access point.

?? Roaming:the access point enables a wireless

LAN computer to move through a building and

still be connected to the LAN.

?? Wired to wireless LAN connectivity: the access

point bridges the gap between wireless LANs

Wireless LAN card user’sguide

and their wired counterparts.

Notes on wireless LAN configuration

When configuring a wireless LAN (WLAN), be sure to note the

following points:

?? Optimize the performance of the WLAN by ensuring that

the distance to Access Points is within the transmission

range. In most buildings, WLAN cards operate within a

range of 100 ~ 300 feet, depending on the thickness and

structure of the walls.

?? Radio waves can pass through walls and glass but not metal.

If there is interference in transmitting through a wall, it may

be that the wall has reinforcing metal in its structure. Install

another access point to circumvent this problem.

?? Floors usually have metal girders and metal reinforcing

struts that interfere with WLAN transmission.

This concludes the first chapter. The next chapter deals with the

hardware installation of the Wireless LAN card.
