TRENDnet TFC-110MM Manual de usuario

TRENDnet's TFC-110 series Fiber Media Converter transforms

10/100Base-TX UTP/STP media to 100Base-FX media and vice

versa. The 10/100Base-TX port auto-sense 10 or 100Mbps

connection speed, auto-negotiates half-/full-duplex mode, and auto-

selects MDI-X / MDI-II media type. This converter will give your

Switch/Hub the ability to interface with fiber connection over a

distance up to 2 km. With the optional 16-slot EIA-19" rack-mount

chassis; the TFC series converters are the perfect solutions for

various fiber media conversions for your network.

TFC-110MM

10/100Base-TX to 100Base-FX Multi-Mode

Fiber Converter with MT-RJ Connector

TFC-110MM

rev: 07.19.2010

• Compliant with IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX / 100Base-FX standards

• One 10/100Base-TX auto-negotiation RJ-45 port

• Auto-negotiation 10/100Mbps connection speed and Half/Full-duplex mode on TX port

• Auto MDIX for 10/100Base-TX port

• One 100Mbps fiber port with Multi-mode MT-RJ Connector

• Half / Full-Duplex mode selector on Fiber port

• Status LED indicators for Power, Link/Activity, Full-Duplex, and Speed

• Wall-Mountable

• Optional 19” system chassis with redundant power supply (TFC-1600), holds up to 16 TFC series Media Converters

• 5 year limited warranty

FEATURES

fiber

Supported Frame Size

Network Media

Wavelength

Protocol

Ports

Data Transfer Rate

Humidity

Temperature

• IEEE802.3 10Base-T, IEEE 802.3u 100Base-TX and 100Base-FX

• Standard Ethernet up to 1522-Byte

• Power, Link/Activity, Full-Duplex, and Speed

• 100Base-TX: Cat. 5, EIA/TIA-568 100-ohm UTP/STP, up to 100 meters.

• 100Base-FX: Multi-Mode fiber optic cable 50/125 or 62.5/125 µm, up to 2 Km.

• 1300nm

• 100Mbps (Half-Duplex), 200Mbps (Full-Duplex)

• Operating: 0° ~ 40° C (32° ~ 104° F) ; Storage: -25° ~ 70° C (-13° ~ 158° F)

• Operating: 10% ~ 90% ; Storage: 5% ~ 90% (non-condensing)

• CSMA/CD

• 1 x 10/100Base-TX and 1 x 100Base-FX

• 7.5VDC, 1.5A (7.2 watts max.)

Diagnostic LEDs

Power Adapter

Standards

Hardware

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

10/100Base-TX to 100Base-FX Multi-Mode Fiber Converter with

MT-RJ Connector

TFC-110MM

RELATED PRODUCTS

TFC-110MSC

TFC-110S60

TFC-1600 16-Slot Chassis System for TFC series Fiber Converter

10/100Base-TX to 100Base-FX Multi-Mode Fiber

Converter with SC-Type Connector

10/100Base-TX to 100Base-FX Single-Mode Fiber

Converter (100Km) with SC-Type Connector

ORDERING INFORMATION

To Order Please Call:

1-888-326-6061

SPECIFICATIONS

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email: [email protected]

www.trendnet.com

TFC-110MST

TFC-110S15

10/100Base-TX to 100Base-FX Multi-Mode Fiber

Converter with ST-Type Connector

10/100Base-TX to 100Base-FX Single-Mode Fiber

Converter (15Km) with SC-Type Connector

TFC-110S30 10/100Base-TX to 100Base-FX Single-Mode Fiber

Converter (30Km) with SC-Type Connector

TFC-110S60 10/100Base-TX to 100Base-FX Single-Mode Fiber

Converter (60Km) with SC-Type Connector
