TRENDnet TEW-421PC Manual de usuario

TEW-421PC

TEW-423PI

Quick Installation Guide

Table of Contents

Version 12.28.2006

English .....................................................................................................

Troubleshooting ........................................................................................

1. Before You Start

2. .....................................................................................

................................................................................

How to Install

3. Using the Wireless Adapter ..............................................................

System Requirements

Application

32-bit CardBus Type II Card slot (TEW-421PC)

32-bit PCI 2.2 slot (TEW-423PI)

CD-ROM Drive

CPU: 300MHz or above

Memory: 256MB RAM or above

Windows XP/2000/ME/98SE

TEW-421PC/TEW-423PI

Utility & Driver CD-ROM

Quick Installation Guide

Package Contents

1. Before You Start

English

54Mbps Wireless

Workstation with

Wireless PCI Adapter

(TEW-423PI)

Cable/DSL

Modem

Internet

Workstation with

Wireless USB 2.0 Adapter

(TEW-429UB)

54Mbps

Wireless Firewall Router

(TEW-432BRP)

802.11g

Notebook with

Wireless PC Card

(TEW-421PC)

2. How to Install

English

1. Insert the Utility & Driver CD-

ROM into your computer's CD-

ROM Drive and then click Install

Utility.

2. Follow the InstallShield Wizard

instructions and then click Finish.

Important! DO NOT install the PCI adapter or PC Card in the computer until

instructed to do so.

For Windows Users

TEW-421PC

4. Insert PC Card firmly into an

available PC Card slot on the

notebook PC and then turn ON the

computer and wait until the

Windows desktop appears.

3. Shutdown your computer.

English

TEW-423PI

8. Insert PCI Card firmly into an

available PCI Card slot on the

desktop PC, attach the included

antenna, and then turn ON the

computer and wait until the

Windows desktop appears.

6. Shutdown your computer.

7. Open your computer's case.

5. Go to Step 9.

9. Drivers will install automatically.

Windows XP/2000

Note: For installation instructions for Windows 98SE and ME, refer to the User

Guide on the Utility and User Guide CD-ROM.

Your installation is now complete.

English

3. Using the Wireless Adapter

1. On the bottom right-hand corner of

the screen, double-click on the

wireless LAN Configuration

utility icon

2. Click Site Survey.

Wireless configuration is now complete.

For detailed information regarding the TEW-421PC/ 423PI configuration

and advanced settings, please refer to the User's Guide included on the Utility

& Driver CD-ROM or TRENDnet's website at www.trendnet.com

TEW-

Note: If you are running Windows XP, you need to disable Wireless Zero

Configuration. Please refer to question 4 of the Troubleshooting section.

3. Click the SSID that matches your

wireless access point and then

click Connect.

Q1:

A1:

Q2:

A2:

Q3:

A3:

Q4:

A4:

Q5:

A5:

I inserted the TEW-421PC/TEW-423PI CD-ROM into my computer's CD-ROM Drive and

the installation menu does not appear automatically. What should I do?

If the installation menu does not appear automatically, click Start, click Run, and type

D:\Autorun.exe where "D" in "D:\Autorun.exe" is the letter assigned to your computer's

CD-ROM Drive, and then press the ENTER key on your keyboard.

I completed all the steps in the quick installation guide, but my card is not connecting to

my access point. What should I do?

First, verify that the Network Name (SSID) matches your wireless router or access

point's Network Name (SSID). Second, check your TCP/IP properties to ensure that Obtain

an IP address automatically is selected. Third, open the Wireless Client Utility icon, click

Site Survey and then click refresh to check and see if there are any available wireless

networks listed.

Windows is unable to recognize my hardware. What should I do?

First, make sure your computer meets the minimum requirements as specified in

Section 1 of this quick installation guide. Second, you must complete the installation of the

wireless configuration utility (as described in Section 2) before connecting the Wireless

Adapter to your computer. Third, connect the Wireless Adapter to a different PCI/PC Card

slot on your computer.

I cannot open the wireless configuration utility. What should I do?

First, access your device manager to make sure the adapter is installed properly. If you

see a networking device with a yellow question mark or exclamation point, you will need to

reinstall the device and/or the drivers. To access your device manager, right-click My

Computer, click Properties, under the Hardware tab click Device Manager. Second, if you

are running Windows XP, you need to disable wireless zero configuration. Go to Control

Panel -> Network Connections. Right click on the Wireless Network Connection icon

and select Properties. Click on the Wireless Networks tab and uncheck Use windows to

configure my wireless settings. Then click OK.

How do I install the drivers on Windows 98SE or ME?

Please refer to the User's Guide included on the Driver CD-ROM.

If you still encounter problems or have any questions regarding the TEW-421PC/TEW-423PI,

please refer to the User's Guide included on the Utility & Driver CD-ROM or contact Trendnet's

Technical Support Department.

Troubleshooting

NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV

INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS

EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO

OPERATE THE EQUIPMENT.

ADVERTENCIA

En todos nuestros equipos se mencionan claramente las caracteristicas del adaptador de

alimentacón necesario para su funcionamiento. El uso de un adaptador distinto al

mencionado puede producir daños fisicos y/o daños al equipo conectado. El adaptador

de alimentación debe operar con voltaje y frecuencia de la energia electrica domiciliaria

existente en el pais o zona de instalación.

TEW-421PC: 0950-04-2375

TEW-423PI: 0949-04-2375

Certifications

This equipment has been tested and found to comply with FCC and CE Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference received. Including interference that may cause undesired

operation.

Waste electrical and electronic products must not

be disposed of with household waste. Please

recycle where facilities exist. Check with you Local

Authority or Retailer for recycling advice.

Este equipamento opera em caráter secundário, isto é, não tem

direito a proteção contra interferência prejudicial, mesmo de estações

do mesmo tipo, e não pode causar interferência a sistemas operando

em caráter primário.

Product Warranty Registration

Please take a moment to register your product online.

Go to TRENDnet’s website at http://www.trendnet.com

TRENDnet Technical Support

US Canada

24/7 Tech Support

Toll Free Telephone: 1(866) 845-3673

Europe (Germany France Italy Spain Switzerland UK)

English/Espanol - 24/7

Francais/Deutsch - 11am-8pm, Monday - Friday MET

English/Espanol - 24/7

Francais/Deutsch - 11am-8pm, Monday - Friday MET

Worldwide

Telephone: +(31) (0) 20 504 05 35

Toll Free Telephone: +00800 60 76 76 67

. . . . .

20675 Manhattan Place

Torrance, CA 90501

USA
