Transition Networks SM8TAT2SA Manual de instrucciones

33718 Rev. A https://www.transition.com Page 1of 255

SM8TAT2SA, SM16TAT2SA, and

SM24TAT2SA

Smart Managed Switches, 8-/16-/24-Port

Gigabit PoE+, 2-Port 100/1000 SFP

CLI Reference

33718 Rev. B

Transition Networks SMxTAT2SA CLI Reference

33718 Rev. B https://www.transition.com Page 2of 255

Trademarks

All trademarks and registered trademarks are the property of their respective owners.

used in any form or by any means (graphic, electronic or mechanical) without written permission from

Transition Networks. Printed in the U.S.A.

SMxTAT2SA Smart Managed Switches CLI Reference, 33718 Rev. B

Contact Information

Transition Networks

10900 Red Circle Drive

Minnetonka, MN 55343 USA

tel: +1.952.941.7600 | toll free: 1.800.526.9267 | fax: 952.941.2322

[email protected]om |techsupport@transition.com |customerse[email protected]

Revision History

Rev

Date

Description

3/8/17

Preliminary release for SMxTAT2SA at v1.00.

12/20/17

Update for FW v1.01.1209 which removes the show dms command.

Transition Networks SMxTAT2SA CLI Reference

33718 Rev. B https://www.transition.com Page 3of 255

CONTENTS

CONTENTS ..........................................................................................................................................................3

1 CLI Management .......................................................................................................................................4

1-1 LOGIN ........................................................................................................................................................ 5

1-2 OVERVIEW OF CLI COMMANDS...................................................................................................................... 5

2 CLEAR Commands................................................................................................................................... 10

3 CONFIGURE Commands ......................................................................................................................... 13

3-2 NO .......................................................................................................................................................... 80

3-3 QOS....................................................................................................................................................... 117

3-4 SNMP-SERVER ......................................................................................................................................... 120

3-5 SPANNING-TREE ....................................................................................................................................... 126

4 COPY Commands ................................................................................................................................... 131

5 DELETE Commands ................................................................................................................................ 133

6 DIR Commands ...................................................................................................................................... 134

7 DO Commands....................................................................................................................................... 135

8 DOT1x Commands ................................................................................................................................. 136

9 FIRMWARE Commands ......................................................................................................................... 139

10 NO Commands..................................................................................................................................... 140

11 PING Commands.................................................................................................................................. 143

12 RELOAD Commands............................................................................................................................. 145

13 SHOW Commands ............................................................................................................................... 146

14 TERMINAL Commands......................................................................................................................... 210

15 TRACEROUTE Commands .................................................................................................................... 211

16 CLI Command Summary ...................................................................................................................... 213

Transition Networks SMxTAT2SA CLI Reference

33718 Rev. B https://www.transition.com Page 4of 255

1 CLI Management

This manual documents CLI (Command Line Interface) commands for three similar models: SM8TAT2SA,

SM16TAT2SA, and SM24TAT2SA. The models differ mainly in port count. Model differences are noted where

applicable throughout this manual. A brief description of a typical connection is provided below:

□An-RJ-45 cable is used for connecting a terminal or terminal emulator to an RJ-45 port on the

SMxTAT2SA front panel to access the CLI.

□Attach an RJ-45 port on the switch’s front panel to the cable for CLI configuration.

□Attach the other end of the DB-9 cable to a PC running Tera Term or similar utility.

□At the “Tera Term New connection” menu, configure the parameters: Host: 192.168.1.77; History:

checked; Service: SSH; TCP port # 22; SSH version: SSG2; Protocol: UNSPEC.

Transition Networks SMxTAT2SA CLI Reference

33718 Rev. B https://www.transition.com Page 5of 255

1-1 Login

The command-line interface (CLI) is a text-based interface that you can access the CLI through either a direct

serial connection to the device or a Telnet session. The default username and password to login into the

switch are:

Username: admin

Password: admin

After you login successfully, the prompt displays as “<sys_name>#“ . This means you are an administrator

and have the highest privilege for setting the switch. If logged in as other than the administrator, the prompt

displays as “<sys_name>>”, which means you have guest privileges and are only allowed for setting the

system under the administrator. Each CLI command has its privilege level pre-assigned. See below.

Username: admin <tab>

Password: admin <Enter>

SM16TAT2SA

1-2 Overview of CLI Commands

The CLI is divided into several modes. If you have enough privilege to run a particular command, you may run

the command in the correct mode. To see the commands of the mode, enter a “?” (question mark) after the

system prompt, then all commands will be listed in the screen. The command modes are listed below:

Command Modes

Mode

Prompt

Command Function in this Mode

exec

<sys_name>#

Display current configuration, diagnostics, and

maintenance

config

<sys_name>(config)#

Configure features other than those below

Config-if

<sys_name>(config-interface)#

Configure ports

Config-if-vlan

<sys_name>(config-if-vlan)#

Configure static vlan

Config-line

<sys_name>(config-line)#

Line Configuration

Config-ipmc-profile

<sys_name>(config-impc-profile)#

IPMC Profile

Config-snmp-host

<sys_name>(config-snmp-host)#

SNMP Server Host

Config-stp-aggr

<sys_name>(config-stp-aggr)#

STP Aggregation

Config-dhcp-pool

<sys_name>(config-dhcp-pool)#

DHCP Pool Configuration

Config-rfc2544-profile

<sys_name>(config-rfc2544-profile)#

RFC2544 Profile

Transition Networks SMxTAT2SA CLI Reference

33718 Rev. B https://www.transition.com Page 6of 255

Commands reside in the corresponding modes could run only in that mode. If you want to run a particular

command, you just change to the appropriate mode. The command modes are organized as a tree, starting in

exec mode. The following table explains how to change from one mode to another.

Change Between Command Modes

Mode

Enter Mode

Leave Mode

exec

config

Configure terminal

exit

config-interface

Interface <port-type> <port-type-list>

exit

config-vlan

Interface vlan <vlan_list>

exit

Idle timeout Message

Warning: Idle timeout. The session will be closed.

After the session times out, you must log back in again. Press the Enter key to display the Username prompt.

SM16TAT2SA#

Warning: Idle timeout. The session will be closed.

<Enter>

Username: admin

Password:

SM16TAT2SA#

Transition Networks SMxTAT2SA CLI Reference

33718 Rev. B https://www.transition.com Page 7of 255

1-3 Global CLI Commands

To see the commands of the current mode, type a question mark (?) after the prompt to list all available

commands for that mode.

SM16TAT2SA# ?

! Comments

clear Reset functions

configure Enter configuration mode

copy Copy from source to destination

delete Delete one file in flash file system

diagnostics diagnostics

dir Directory of all files in flash file system

exit Exit from the CLI

find-switch Turn on and off all LED light 3 times in 15 seconds

firmware firmware

logout Exit from EXEC mode

more Display file

ping Send ICMP echo messages

reload Reload system

show Show running system information

ssl Setup SSL certificate

terminal Set terminal line parameters

traceroute Trace the route to HOST

SM16TAT2SA#

Transition Networks SMxTAT2SA CLI Reference

33718 Rev. B https://www.transition.com Page 8of 255

ExitExit from Config mode to EXEC mode.

Syntax: exit

Parameter: None.

Example:

SM16TAT2SA(config)# exit

SM16TAT2SA#

? (Help)

Help may be requested at any point in a command by entering a question mark '?'. If nothing matches,

the help list will be empty and you must back up until entering a '?' shows the available options.

Two styles of help are provided:

1. Full help is available when you are ready to enter a command argument (e.g. 'show ?') and describes

each possible argument.

2. Partial help is provided when an abbreviated argument is entered and you want to know what

arguments match the entry (e.g. show pr?).

Syntax: ?

Parameter: None.

Example:

SM16TAT2SA# ?

! Comments

clear Reset functions

configure Enter configuration mode

copy Copy from source to destination

delete Delete one file in flash file system

diagnostics diagnostics

dir Directory of all files in flash file system

exit Exit from the CLI

find-switch Turn on and off all LED light 3 times in 15 seconds

firmware firmware

logout Exit from EXEC mode

more Display file

ping Send ICMP echo messages

reload Reload system

show Show running system information

terminal Set terminal line parameters

traceroute Trace the route to HOST

SM16TAT2SA#

Transition Networks SMxTAT2SA CLI Reference

33718 Rev. B https://www.transition.com Page 9of 255

logout

Exit from EXEC mode. You must log back in.

Syntax:

logout

Parameter:

none

Example:

SM16TAT2SA# logout

end Go back to EXEC mode.

Syntax:

end

Example:

SM16TAT2SA# configure terminal

SM16TAT2SA(config)# end

SM16TAT2SA#

Transition Networks SMxTAT2SA CLI Reference

33718 Rev. B https://www.transition.com Page 10 of 255

2 CLEAR Commands

Table : Clear Commands

Command Function

access-list Access list

ip Clear DHCP Relay statistics

lldp Clear LLDP statistics for one or more given interface

logging Syslog

mac MAC Address Table

spanning-tree Execute protocol migration check on interfaces

statistics Clear statistics for one or more given interface

lldp

Clears LLDP statistics.

Syntax

Clear lldp statistics

Parameters

global Clear global counters

interface Interface

EXAMPLE

SM16TAT2SA# clear lldp?

lldp Clear LLDP statistics for one or more given interface

SM16TAT2SA# clear lldp ?

statistics Clear LLDP statistics

SM16TAT2SA# clear lldp statistics ?

global Clear global counters

interface Interface

SM16TAT2SA# clear lldp statistics global ?

<cr>

SM16TAT2SA# clear lldp statistics interface ?

GigabitEthernet GigabitEthernet

* All ports

SM16TAT2SA# clear lldp statistics interface GigabitEthernet ?

<port_list> Port List S/X-Y,Z (1/1-18)

SM16TAT2SA# clear lldp statistics interface GigabitEthernet 1/3-7

Otros manuales para SM8TAT2SA

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cambiar de Transition Networks

Transition Networks

Transition Networks SM24TAT4GPA Manual de usuario

Transition Networks

Transition Networks SISPM1040-582-LRT Manual de usuario

Transition Networks

Transition Networks SISTM10xx-162-LR(T) Manual de usuario

Transition Networks

Transition Networks 1005 Manual de usuario

Transition Networks

Transition Networks E-TBT-HB-0402 Manual de usuario

Transition Networks

Transition Networks SM8TAT2SA Manual de usuario

Transition Networks

Transition Networks SESPM1040-541-LT Series Manual de usuario

Transition Networks

Transition Networks E-MUX-SA05 Manual de usuario

Transition Networks

Transition Networks E-TBT-HB-0400 Manual de usuario

Transition Networks

Transition Networks SM12DP2XA Manual de usuario

Transition Networks

Transition Networks SM24-100SFP-AH Manual de usuario

Transition Networks

Transition Networks SM TAT4X Series Manual de usuario

Transition Networks

Transition Networks SM24DP4XA Manual de usuario

Transition Networks

Transition Networks StackMaster SMHB-E-FL-12 Manual de usuario

Transition Networks

Transition Networks LANMaster T8-FL Manual de usuario

Transition Networks

Transition Networks Milan MIL-SM8002TG Manual de usuario

Transition Networks

Transition Networks SM24DPa Manual de usuario

Transition Networks

Transition Networks SM24DPB Manual de usuario

Transition Networks

Transition Networks mil-sm8dpa Manual de usuario

Transition Networks

Transition Networks SISPM1040-382-LRT Manual de usuario

Transition Networks

Transition Networks SISPM1040-582-LRT Manual de usuario

Transition Networks

Transition Networks STACKMASTER TR SMHB-TR-16 Manual de usuario

Transition Networks

Transition Networks SISPM1040-3 L Series Manual de usuario

Transition Networks

Transition Networks LAN MASTER 33022.B Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
