Transcend StoreJet 25M3 Manual de usuario

User’s Manual

2.5" External Hard Drive

StoreJet®25M3

(Version 1.0)

Table of Contents

Introduction︱......................................................................................1

Package Contents︱............................................................................1

Features︱............................................................................................2

System Requirements︱.....................................................................2

Safety Precautions︱...........................................................................3

General Use.................................................................................................................... 3

Backing up Data............................................................................................................. 3

Transporting .................................................................................................................. 3

Power.............................................................................................................................. 3

Reminders...................................................................................................................... 4

Product Overview︱............................................................................4

Connecting to a Computer︱..............................................................5

Disconnecting from a Computer︱....................................................8

Windows®....................................................................................................................... 8

Mac®OS.......................................................................................................................... 9

Linux®............................................................................................................................. 9

Formatting the Hard Drive︱...............................................................9

Windows® XP................................................................................................................ 10

Windows®7/Vista......................................................................................................... 11

Mac®OS........................................................................................................................ 14

Linux®........................................................................................................................... 16

Troubleshooting︱.............................................................................17

Specifications︱.................................................................................19

Transcend Limited Warranty︱........................................................20

Introduction︱

Congratulations on purchasing Transcend’s StoreJet 25M3.This rugged, ultra-portable, high

speed USB storage device is the perfect data management system for uploading, downloading,

storing and transferring your data. With its shock-resistant design, huge storage capacity and

real-world transfer speeds up to 3X faster than USB 2.0 (in USB 3.0 mode), the compact StoreJet

25M3 is ideal for carrying your files, folders, documents, photos, music and videos. In addition, the

StoreJet 25 comes with very useful software* that can increase your mobile productivity. This

User’s Manual is designed to help you get the most from your new device. Please read it in detail

before using the StoreJet 25.

*Note: The StoreJet Elite software only works in Windows—please see the Software User's Manual for details

Package Contents︱

The StoreJet 25 package includes the following items:

StoreJet®25M3

USB 3.0 Cable

USB Power Cable

Quick Start Guide

Warranty Card

Features︱

SuperSpeed USB 3.0 compliant and backwards compatible with USB 2.0

Durable anti-shock silicone outer shell

Advanced internal hard drive suspension system

Connection bandwidth up to 5Gbits per second

Extra-large storage capacity

Sleek ultra portable design

Easy Plug and Play operation – no drivers required

USB powered – no external adapter necessary

Power saving sleep mode

One Touch Auto-Backup button

Includes StoreJet Elite backup and security software

Multicolor LED indicator (power, data transfer, & USB 2.0/3.0 connection type)

System Requirements︱

Desktop or notebook computer with a working USB port.

One of following Operating Systems:

•Windows®XP

•Windows®Vista

•Windows®7

•Linux®Kernel 2.6.31 or later

•Mac®OS X 10.4 or later (only USB 2.0 currently supported)

Safety Precautions︱

These usage and safety guidelines are IMPORTANT! Please follow them carefully.

General Use

•Carefully unpack the contents of the StoreJet 25 package.

•During operation, avoid exposing your StoreJet 25 to extreme temperatures above 55℃,

or below 5℃.

•Do not drop your StoreJet 25.

•Do not allow your StoreJet 25 to come in contact with water or any other liquids.

•Do not use a damp/wet cloth to wipe or clean the exterior case.

oDo not store your StoreJet 25 in any of the following environments: Direct

sunlight

oNext to an air conditioner, electric heater or other heat sources

oIn a closed car that is in direct sunlight

oIn an area with strong magnetic fields or excessive vibration

•If your Windows computer will not boot while StoreJet 25 is connected, please

disconnect the StoreJet 25 to your computer first and connect the StoreJet 25 after

starting Windows. Otherwise, refer to your computer's manual and change the BIOS

settings to instruct the computer to boot from a different device.

Backing up Data

•Transcend does NOT take any responsibility for data loss, or damage during

operation. If you decide to store data on your StoreJet 25 we strongly advise that you

regularly backup the data to a computer, or other storage medium.

•To ensure Super-Speed USB 3.0 data transfer rates when using your StoreJet 25,

please make sure that your computer has the relevant drivers and hardware to support

USB 3.0. If you are unsure about how to check this, please consult the user’s manual of

your computer, motherboard, or USB 3.0 interface card for USB 3.0 driver information.

Transporting

•Do not pack the StoreJet 25 into luggage without proper padded support. Other items in

your luggage may damage the drive during travel if it does not have proper protection.

•Avoid squeezing or compressing the StoreJet 25.

•Do not place objects on top of your StoreJet 25.

Power

•The StoreJet 25 is powered directly via a computer USB port. However, the power

supplied by the USB port on some older computers is below the 5V DC required to

power the StoreJet 25. If your StoreJet does not function properly upon connecting it to

your computer, please use the included USB Power Cable.

The Power Cable can provide additional power for the

StoreJet 25 if necessary

•Use only the USB 3.0 cable that came with the StoreJet 25 to connect it to a computer,

and always ensure that the cable you are using is in good condition. NEVER use a cable

that is frayed or damaged.

•Ensure nothing is resting on the USB cable and that the cable is not located where it can

be tripped over or stepped on.

Reminders

Always follow the procedures in the “Disconnecting from a Computer” section to remove the

StoreJet from your computer.

Product Overview︱

A Power Cable DC-IN

B Micro USB 3.0 Port

C One Touch Auto-Backup Button

Connecting to a Computer︱

The StoreJet 25M3 can be connected to your computer using either USB 2.0 or USB 3.0. To get

the best performance results from your drive, we recommend using the USB 3.0 interface

(currently not supported on Mac computers).

Micro USB 3.0

Connector

USB 2.0 / 3.0

Connector

USB 3.0 Cable

StoreJet 25M3 Micro USB port USB 2.0 Port USB 3.0 Port

1. Plug the micro USB end (1) of the USB cable into the StoreJet 25M3.

2. Plug the rectangular end (2) of the USB cable into an available USB 2.0 or USB 3.0 port on

your desktop or notebook computer.

3. If necessary, plug in the USB Power Cable.

Connecting the USB Power Cable

NOTE:

On some older computers, the power supplied by the USB port might not meet the 5V DC requirement.

If you have power-related problems, please be sure to use the included USB Power Cable.

(1) (2)

1. Unplug the USB 3.0 Cable from your computer.

2. Connect the round-shaped end (1) of the USB Power Cable to the DC IN jack on the

StoreJet 25

3. Plug the rectangular end (2) into any available USB port (USB 2.0 or 3.0) on your desktop

computer, notebook or netbook.

4. Reconnect the USB 3.0 Cable.

4. When the StoreJet 25 is successfully connected to a computer, its LED will light up (USB2.0

and USB3.0 have different colors of illumination to indicate connection type). In Windows, a

new Local Disk drive with a newly-assigned drive letter will appear, and a Removable

Hardware icon will appear on the Windows System Tray. The StoreJet 25’s internal hard

drive comes pre-formatted to FAT32, which is compatible with most computer systems,

including Windows, Mac, Linux, and more.

•Computers running Windows and Mac OS will automatically detect and install the StoreJet 25M3. To use

USB 3.0, please ensure your computer has all necessary USB 3.0 drivers installed, and make sure you

plug the USB Cable into the correct port on your computer (USB 3.0 ports are usually color-coded to

differentiate them from USB 2.0)

•Linux users may have to configure the StoreJet 25 manually. To do this, first create a directory for the

StoreJet 25 (Example: mkdir /mnt/storejet). Then, mount the StoreJet 25 (Example: mount –a –t

msdos /dev/sda1 /mnt/Storejet)

Note: (D:) and (G:) above are example drive letters; the letter in your "My Computer" window may differ

Note: “New Volume” is an example drive. The drive name on your Mac computer may differ

5. Once connected, you can use the StoreJet 25 as an external hard drive to transfer data to and

from your computer. Simply drag and drop files or folders onto the Local Disk,Volume,or

drive letter that represents the StoreJet 25.

6. If you have installed the bundled StoreJet elite software, you can press the StoreJet 25’s One

Touch “Backup Button” to instantly backup your data (see the StoreJet elite Software User’s

Manual for details).

Note: One Touch Auto-Backup Button

Disconnecting from a Computer︱

NEVER disconnect the StoreJet from a Computer when its LED is flashing.

Windows®

1. Select the Hardware icon on the system tray.

2. The Safely Remove Hardware pop-up window will appear. Select it to continue.
