Transcend Computer Drive Manual de usuario
User’s Manual
Portable Hard Drives
StoreJet
®
25
(Version 1.0)
Table of Contents
Introduction︱
︱︱
︱......................................................................................1
Features︱
︱︱
︱............................................................................................1
System Requirements︱
︱︱
︱.....................................................................2
Safety Precautions︱
︱︱
︱...........................................................................2
General Use................................................................................................................... 2
Backing up Data............................................................................................................ 2
Transporting.................................................................................................................. 2
Power............................................................................................................................. 2
Reminders..................................................................................................................... 2
Connecting to a Computer︱
︱︱
︱..............................................................3
One Touch Backup︱
︱︱
︱..........................................................................6
Disconnecting from a Computer︱
︱︱
︱....................................................7
Windows
...................................................................................................................... 7
Mac
®
OS......................................................................................................................... 7
Linux
®
............................................................................................................................ 8
Formatting the Hard Drive︱
︱︱
︱...............................................................9
Windows
®
XP................................................................................................................. 9
Windows
7/Vista........................................................................................................ 10
Mac
®
OS....................................................................................................................... 13
Linux
®
.......................................................................................................................... 15
Troubleshooting︱
︱︱
︱.............................................................................16
Specifications︱
︱︱
︱.................................................................................18
Recycling & Environmental Considerations︱
︱︱
︱...............................19
Three-year Limited Warranty︱
︱︱
︱........................................................20
1
Introduction︱
Congratulations on purchasing Transcend’s StoreJet 25.This rugged, ultra-portable, high speed
USB storage device is the perfect data management system for uploading, downloading, storing
and transferring your data. The compact StoreJet 25 is ideal for carrying your files, folders,
documents, photos, music and videos. In addition, the StoreJet 25 comes with very useful
software* that can increase your mobile productivity. This User’s Manual is designed to help you
get the most from your new device. Please read it in detail before using the StoreJet 25.
Note:
1. The SJ25 comes bundled with Transcend Elite, which enables the StoreJet’s One Touch
auto-backup button (available on select StoreJet models only). See the Elite Software User’s
Manual for details. The Transcend Elite software is also available for download at
www.transcend.com.tw/elite.
2. The StoreJet Format Utility only works in Windows—Please see the “Formatting the Hard
Drive” section of this manual for more information.
3.
To use the Mac OSX Time Machine function, please format the StoreJet drive to HFS+ first —
(see “Formatting the Hard Drive – Mac OS”)
Features︱
Advanced internal hard drive suspension system
Extra-large storage capacity
Sleek ultra portable design
Easy Plug and Play operation – no drivers required
USB powered – no external adapter necessary
Power saving sleep mode
One Touch Auto-Backup button (available only on select StoreJet models)
Includes Transcend Elite™ backup and security software
LED power / data transfer activity indicator
2
System Requirements︱
Desktop or notebook computer with a working USB port.
One of following Operating Systems:
USB 3.0 Models: USB 2.0 Models:
•
Windows
XP
•
Windows
XP
•
Windows
Vista
•
Windows
Vista
•
Windows
7
•
Windows
7
•
Linux
Kernel 2.6.31+
•
Linux
Kernel 2.4.2+
•
Mac
OS X 10.5+ (only USB 2.0 supported)
•
Mac
OS 9+
Safety Precautions︱
These usage and safety guidelines are IMPORTANT! Please follow them carefully.
General Use
•
Carefully unpack the contents of the StoreJet 25 package.
•
During operation, avoid exposing your StoreJet 25 to extreme temperatures above 55℃,
or below 5℃.
•
Do not drop your StoreJet 25.
•
Do not allow your StoreJet 25 to come in contact with water or any other liquids.
•
Do not use a damp/wet cloth to wipe or clean the exterior case.
oDo not store your StoreJet 25 in any of the following environments: Direct
sunlight
oNext to an air conditioner, electric heater or other heat sources
oIn a closed car that is in direct sunlight
oIn an area with strong magnetic fields or excessive vibration
•
If your Windows computer will not boot while StoreJet 25 is connected, please
disconnect the StoreJet 25 to your computer first and connect the StoreJet 25 after
starting Windows. Otherwise, refer to your computer's manual and change the BIOS
settings to instruct the computer to boot from a different device.
Backing up Data
•
Transcend does NOT take any responsibility for data loss, or damage during
operation. If you decide to store data on your StoreJet 25 we strongly advise that you
regularly backup the data to a computer, or other storage medium.
2
Transporting
•
Do not pack the StoreJet 25 into luggage without proper padded support. Other items in
your luggage may damage the drive during travel if it does not have proper protection.
•
Avoid squeezing or compressing the StoreJet 25.
•
Do not place objects on top of your StoreJet 25.
Power
•
The StoreJet gets its power directly from your computer’s USB port. However, the power
supplied by the USB ports on some older computers does not meet the stable 5V DC
power requirements of the StoreJet. If your StoreJet does not function properly upon
connecting it to your computer, please plug BOTH ENDS of the USB Y-cable into your
computer.
Both ends of the USB Y-cable should be
connected to provide ample power to the
StoreJet
The Power Cable can provide additional
power for the StoreJet 25 if necessary
(SJ25M3 / SJ25D3)
•
Use only the USB cable that came with the StoreJet 25 to connect it to a computer, and
always ensure that the cable you are using is in good condition. NEVER use a cable that
is frayed or damaged.
•
Ensure nothing is resting on the USB cable and that the cable is not located where it can
be tripped over or stepped on.
Reminders
Always follow the procedures in the “Disconnecting from a Computer” section to remove the
StoreJet from your computer.
3
Connecting to a Computer︱
1.
Plug the small end (1) of the USB cable into the StoreJet 25.
2.
Plug BOTH large ends (2) and (3) of the USB cable into an available USB 2.0 or USB 3.0 port
on your desktop or notebook computer.
NOTE:Always plug both large ends of the Y-cable into your computer. If only one
USB port is available, please connect the data transfer end (2) of the Y-cable
(compatibility not guaranteed).
(SJ25M3 / SJ25D3)
USB Cable
Power
Connector
Micro / Mini
USB Connector USB 2.0 / 3.0
Connector
4
3.
A new Local Disk drive with a newly-assigned drive letter will appear, and a Removable
Hardware icon will appear on the Windows System Tray. The StoreJet 25’s internal hard
drive comes pre-formatted to FAT32, which is compatible with most computer systems,
including Windows, Mac, Linux, and more.
•Computers running Windows and Mac OS will automatically detect and install the StoreJet 25. To use
USB 3.0, please ensure your computer has all necessary USB 3.0 drivers installed, and make sure you
plug the USB Cable into the correct port on your computer (USB 3.0 ports are usually color-coded to
differentiate them from USB 2.0)
•Linux users may have to configure the StoreJet 25 manually. To do this, first create a directory for the
StoreJet 25 (Example: mkdir /mnt/storejet). Then, mount the StoreJet 25 (Example: mount –a –t
msdos /dev/sda1 /mnt/Storejet)
5
Note: (D:) and (G:) above are example drive letters; the letter in your "My Computer" window may differ
Note: “New Volume” is an example drive. The drive name on your Mac computer may differ
4.
Once connected, you can use the StoreJet 25 as an external hard drive to transfer data to and
from your computer. Simply drag and drop files or folders onto the Local Disk,Volume,or
drive letter that represents the StoreJet 25.
NOTE:
To ensure Super-Speed USB 3.0 data transfer rates when using your
StoreJet 25, please make sure that your computer has the relevant
drivers and hardware to support USB 3.0. If you are unsure about how
to check this, please consult the user’s manual of your computer,
motherboard, or USB 3.0 interface card for USB 3.0 driver information.
6
One Touch Backup︱
︱︱
︱
(Select StoreJet models only)
To enable the One Touch auto-backup button, you must first run the preloaded Transcend Elite
software (located in the Transcend Elite directory of your StoreJet). Once you have successfully
created a Backup Task within Transcend Elite, you can then use the StoreJet’s One Touch
auto-backup button to instantly backup and synchronize your data (download the Transcend Elite
User’s Manual at www.transcend.com.tw/elite for detailed instructions on how to use the software).
7
Disconnecting from a Computer︱
︱︱
︱
NEVER disconnect the StoreJet from a Computer when its LED is flashing.
Windows
1. Select the Hardware icon on the system tray.
2. The Safely Remove Hardware pop-up window will appear. Select it to continue.
3. A window will appear stating, “The ‘USB Mass Storage Device’ device can now be safely
removed from the system.”
WARNING! To prevent data loss, always use this procedure to remove the StoreJet
from Windows
®
.
Mac
®
OS
Drag and drop the Disk icon that represents your StoreJet 25 into the Trashcan. Then unplug your
StoreJet 25 from the USB port.
