Access5830™

Wireless Broadband System

USER MANUAL

[draft]

Access5830™ User Manual

Table of Contents

Overview 3

FCC Information 3

Warranty Information 3

Getting to Know Your Radio 4

Contents 4

Ethernet and Serial Ports 5

Antennas 5

AP/SU Operational Overview 5

Getting Started 7

Connections and Power 7

Basic Configuration 8

Opmode Concept 8

HTTP Browser Interface 9

Logging On to your Radio via Telnet. 9

Access Point Set Up and Configuration 10

AP System Information 10

AP Subscriber Unit Database 12

Subscriber Unit Set Up and Configuration 13

SU System Information 14

Establishing a Wireless Link 16

Access Point 16

Subscriber Unit 16

Association Concept (AP to SU communications) 16

Basic Diagnostics 17

Deployment 18

Site Selection 19

Site Survey 19

Channel Planning 19

Installation 20

SU Installation and Antenna Alignment 21

Link Test 22

Managing your Access5830 Network 22

Network Setup 22

Command Line Interface 22

Telnetting into remote SU 23

Managing AP from SU side of Network 23

Troublshooting 23

Specifications 24

Appendix 1 -- Access5830™ Command Line Interface (CLI) 25

Appendix 2 – HTTP Browser Interface 33

Access5830™ User Manual

Overview

This manual covers basic configuration and installation of the Access5830 Wireless Broadband System and

applies to the following radio part numbers:

M5830S-AP-60 Access Point with internal sectoral patch antenna

M5830S-SU Subscriber Unit with internal patch antenna

Note: The installation of the M5830S-SU requires professional installation due to FCC limits on output

power settings when using the 5.3 GHz U-NII band. Contact your sales person for more information

regarding the definition of “Professional Installation”.

FCC Information

This device complies with Part 15 of FCC Rules and Regulations. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference and (2) this device must accept any

interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant

to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses, and can radiate radio-frequency

energy and, if not installed and used in accordance with these instructions, may cause harmful interference

to radio communications. However, there is no guarantee that interference will not occur in any particular

installation. If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to correct the interference by one of

more of the following measures:

1) Reorient the antenna;

2) Increase the separation between the affected equipment and the unit;

3) Connect the affected equipment to a power outlet on a different circuit from that which the receiver is

connected to;

4) Consult the dealer and/or experienced radio/TV technician for help.

FCC ID: NCYM5830SAP

FCC ID: NCYM5830SSU

Canada: XXXXXXXXXX

IMPORTANT NOTE:

Intentional or unintentional changes or modifications must not be made unless under the express consent of

the party responsible for compliance. Any such modifications could void the user’s authority to operate the

equipment and will void the manufacturer’s warranty. To comply with FCC RF exposure requirements, the

following antenna installation and device operating configurations must be satisfied. The antenna for this

unit must be fixed and mounted on outdoor permanent structures with a separation distance of at least two

meters from all persons. Furthermore, it must not be co-located or operating in conjunction with any other

antenna or transmitter.

Warranty Information

Radios from Trango Broadband Wireless are warranted from one year from date of purchase. Please see

www.trangobroadband.com for complete description of warranty coverage and limitations

Access5830™ User Manual

Welcome!

Your Trango Broadband Access5830 radio system provides the latest innovations in high speed fixed

wireless broadband. The Access 5830 is a point-to-multipoint (PMP) system which provides network

connectivity at speeds up to 10 Mbps with a range of 10 miles or beyond depending on antenna

configuration. The Access5830 is unique in that it can operate in either the 5.8 GHz ISM band or the 5.3

GHz U-NII band.

The Access5830 system consists of two types of radios: Access Points (AP) and Subscriber Units (SU).

The AP will deliver wireless broadband service to one or more SU’s according to a proprietary polling

algorithm called SMARTPolling™. Each AP can associate with and deliver service to up to 512 SU’s.

With careful channel planning, (and adequate spacing and shielding) network operators can co-locate up to

22 AP’s at a single cell site.

The AP and SU conform to maximum radiated power limits as established by the FCC.

Band AP Max EIRP Approximate max range (AP to SU)

5.8 GHz ISM Band 36 dBm 6 Miles (allowing for 10 dB fade margin)

5.3 GHz U-NII Band 30 dBm 2 Miles (allowing for 10 dB fade margin)

In this document and within the radio configuration itself, the designators of “ISM” and “U-NII” are used

to distinguish between the two bands.

Getting to Know Your Radio

Contents

Each Access 5830 radio comes equipped with the radio itself, a power-over-Ethernet (POE) J-Box, an AC

adapter, and mounting hardware. The Access5830 AP (part # M5830S-AP-60) also comes with a serial

programming cable. Dual-polarized internal antennas are included within the radome of the AP and the

short range SU (Part #M5830S-SU).

Radio (AP or SU)

J Box (Power over Ethernet Injector)

Serial Programming Cable

(AP Only)

Power Supply (120 VAC – 20 VDC)

Mounting Hardware

Access5830™ User Manual

Ethernet and Serial Ports

At the bottom of the Access5830 are two access ports: a twist-on weatherproof cable port for RJ-45

Ethernet (and POE), and an access cover (with two screws) for RJ-11 serial port. Most configuration and

management tasks can be performed through the Ethernet jack. The access cover also contains a small

window which reveals three LEDs. These LEDs provide RF link-status information and will be discussed

later in this text.

Antennas

The Access5830 AP and SU each include dual polarized patch antennas built in behind the plastic radome

cover. These antennas can be electronically switched between horizontal (H) or vertical (V) polarization.

AP/SU Operational Overview

The Access5830 AP is a sophisticated broadband wireless device that provides a host of comprehensive

tools and functions. The AP resides at the center of the point-to-multipoint (PMP) network and performs

all management functions including the allocation of bandwidth allocation for all associated SU’s. As

such, we refer to The Access5830 is an “AP-Centric” system.

One of the major advantages of the Access5830 system is the ability of the AP to handle multiple

SU connections and share the 10 Mbps data throughput very efficiently. Bandwidth allocation is

managed by the AP’s SMARTPolling algorithm according to provisioning rules set up by the

system administrator.

The AP unit acts as a hub in a star configuration wireless multipoint network supporting up to 512

subscriber units. The AP unit, hardwired to a network point of presence, polls each subscriber

unit SU in a round robin format to determine if the SU has data to transfer. The SU only transmits

the data “upstream” to the AP when the AP gives authorization via a “transmit grant”. The SU

parses every “downstream” data packet from the AP and identifies packets intended for it.

In order for an SU to communicate with an AP, the system administrator must first add the MAC

address and ID number of the SU to the user database in the AP.

APs and SUs look identical. The only way to

tell them apart is by the model number printed

on the backside product label. This label also

contains the MAC ID of the radio as well as the

serial #.

Access5830™ User Manual

When power is first applied to a properly installed SU, it will scan all the channels in its scantable,

searching for an AP that is sending transmit grants for this particular SU. The SU will then stop

on that channel and respond to the AP using maximum RF power. Before the AP can add the SU

to the polling list, it must authenticate the SU by verifying the MAC address, and performing a

ranging operation to the SU. This process involves sending a special command to the SU and

getting an instantaneous reply from the SU.

Upon successfully locating and ranging the SU, The AP will then add the SU to the normal polling

list and level the RF transmit power level from the SU to set a good signal-to-noise ratio at the AP.

The AP uses several parameters to determine how often each SU is polled for data, and the

conditions of any data transfer, as follows:

1) Committed Information Rate (CIR)

2) Maximum Information Rate (MIR)

3) Priority

4) Poll response timeout

All the above parameters are set in the AP by the system administrator and cannot be controlled at

the SU. It should also be noted that the MAC table located in the AP is dynamic and stores up to

2000 entries. There is no limitation on the number of IP addresses or hardware devices that an

individual SU may have physically connected to it.

Access5830™ User Manual

Getting Started

First unpack your AP and at least one SU. It is recommended that novice users first provision and test the

radios on the bench before deploying in the field.

Connections and Power

Note: Connection and powering of radios is the same for AP’s and SU’s.

• Connect a Cat-5 (straight through) Ethernet cable (we recommend shielded twisted pair) between

the ODU (out door unit) port of the J-box and the RJ-45 connector on the radio. Note that this

cable will carry power over Ethernet (PoE). See appendix for PoE pinout diagram for this J-Box

to radio connection.

• If connecting to a COMPUTER, use a Cross-Over Ethernet cable from the NET port of the J-box

to the computer’s Ethernet port.

If connecting to a HUB, SWITCH, or ROUTER, use a Straight-Thru cable.

• Plug the AC adapter into an AC outlet.

POWER ODU

POWER

ODUNET

LED Indicates

power to J-Box

LED Indicates

power to Radio

AP or SU

AC Power

CAT-5

Straight-Thru

Cable

20 V

Power

Supply

Network

CAT-5

Use cross-over

cable if to PC

Power over Ethernet

J-Box

Use straight-thru cable

if to hub, switch

or router

Both green LED’s on the J-box should be lit, indicating power is present at the J-box as well as the radio.

You are now ready to configure the radio via the Ethernet port.

Access5830™ User Manual

Note: If you cannot access the radio management functions via the Ethernet port, use the Serial

Programming cable (supplied with AP) and attach to RJ-11 located behind access cover on bottom of radio.

Basic Configuration

The Access5830 can be configured using either the Command Line Interface (CLI) or the Web Browser

(HTTP) interface. Although both methods are comprehensive and powerful, the CLI method provides

slightly more functionality. Regardless of which method is chosen, it is important to gain a good

understanding of the major CLI commands available. The entire CLI Command Set Reference is available

in a separate document. This user manual focuses on the CLI for radio configuration and management.

The CLI is accessible via telnet session (through Ethernet port) or via the serial port using Hyper-terminal.

If you would like to use the Hyperterminal via PC serial port, use settings 8-N-1 Flow control: None.

Opmode Concept

Before logging on to a radio, it is important to understand the “opmode” concept of the Access5830. AP’s

can be in one of two opmodes; “OFF” opmode, or “AP” opmode. When in “OFF” opmode the radio is not

radiating RF energy, and it is not attempting to associate with SU’s. “AP” opmode is the normal operating

mode of the AP which is used when radiating RF energy and associating with SU’s.

Similarly, SU’s have two opmodes: “SU” opmode or “OFF” opmode.

Opmode is important to understand for the following reason:

You can log onto an AP via Ethernet port (telnet or http browser) regardless of Opmode. However, you

can only log onto an SU (via the Ethernet port) when it is in Opmode “OFF”. Factory default opmode is

“SU”, however, while booting, the SU will wait 30 seconds before entering opmode “SU”. During this 30

second window, you can log onto the SU while it is in opmode “OFF”. Once you log onto the SU, the

progression to opmode “SU” will stop, and the unit will remain in opmode “OFF”. If accessing the SU via

the serial programming cable, you can log onto the unit weather it is in opmode “OFF” or opmode “SU”.

Also, certain commands, such as the site survey command (ssurvey) and the SU RSSI command (ssrssi)

can only be performed while the radio is in opmode “OFF”. See Appendix 1 Command Set Reference l for

a complete listing of commands, and the appropriate opmode(s) for each command.

Access5830™ User Manual

HTTP Browser Interface

The HTTP browser interface is an easy-to-use configuration and management tool. In order to use the

browser interface – simply connect the radio to a PC, and type the radio’s IP address into the web browser

(i.e. Microsoft Internet Explorer). This will bring up a logon screen.

Type the password (default trango) and continue. This will bring up a screen similar to the following:

For more information on the HTTP browser interface, please see Appendix 3, or refer to the online

HELP button on the browser screen.

Logging On to your Radio via Telnet.

Open a command prompt (DOS) session on your PC. Open a Telnet session by typing

telnet [ip address of radio]

You will be greeted with current hardware and firmware information and prompted for a password. Type

in the password and press enter.

All Trango radios (AP and SU) come factory pre-configured with a default IP address

192.168.100.100. The default password is trango.

Prior to deployment you will want to change the password and assign a unique IP address to each radio.

Access5830™ User Manual

Access Point Set Up and Configuration

It is recommended to set up the AP prior to setting up the SU’s.

In the process of configuring the AP, you will:

1. Review and modify basic system information such as Base ID, RF Channel, etc.

2. Add SU’s to the Subscriber Unit Database (SUDB).

Logon to the AP and to receive a comprehensive snapshot of the system’s status, type the command

sysinfo. The result appear similar to:

Many of these parameters can be changed by the user. A description of each of these changeable

parameters, along with the related command is shown in the table below. Please note that in order to save

any changes to persistent storage, you must type the command: updateflash systemsetting. If you do not

update the flash, settings will be reset after reboot.

AP SYSINFO PARAMETERS AND RELATED COMMANDS

Parameter Description Related CLI Command

Device ID Mac ID of AP N/A

Base ID Specifies the cell or cluster that

the AP belongs to. Base ID is

one of three key pieces of

information, along with active

channel, and subscriber database

information for the link

establishment between the AP

and SU’s

set baseid <baseid>

Tabla de contenidos

Manuales populares de Receptor de otras marcas

Garmin

Garmin GA 23 Manual de usuario

Aiphone

Aiphone PS-12F Manual de usuario

IMES

IMES TCS-01CA-PMI Manual de usuario

BWI Eagle

BWI Eagle AIR-EAGLE SR Manual

AMIMON

AMIMON AMN12310 WHDI Manual de usuario

Dual

Dual DMCPA79BT Instrucciones de funcionamiento

Sound Associates

Sound Associates SA652P Manual de usuario

Sherwood

Sherwood NewCastle R-772 Manual de usuario

Audio

Audio A10-RX Series Manual de usuario

AllSee

AllSee PushShare PSRV1.1 Manual de usuario

DEMAG

DEMAG DRC-DR D2 Manual de usuario

Teleco

Teleco TVRCL868A02 Manual de usuario

Bosch

Bosch RF3222E Manual de usuario

Kramer

Kramer 631R Manual de usuario

Xpress

Xpress xmc10 Manual de usuario

JVC

JVC KD-MR1BTS Manual de usuario

Omega Engineering

Omega Engineering UWTC-REC3 Manual de usuario

e-survey

e-survey E300 Pro Manual de usuario
