Trane TAYSTAT 370 Manual de usuario

OWNER’S GUIDE

69-1247-1

Electronic Thermostats

TAYSTAT 370, 371, 380

Pub. No. 22-5184-01

69-1247—1

FEATURES

The Trane Co. sells comfort systems. Comfort is achieved

through matching the correct equipment and controls. This

thermostat is designed to provide the maximum comfort

for your needs. Some of the basic offerings are:

•Simple and easy to use. The ▲ and ▼ keys make it

easy for you to change your temperature setting.

•Large digital display. You can easily read the current

room temperature at a glance.

•No need for batteries. atteries are not required

because your temperature settings are held perma-

nently in memory.

3Pub. No. 22-5184-01

69-1247—1

SETTINGS

Setting SYSTEM and FAN S itches

System and fan settings are controlled by using

SYSTEM and FAN switches located on the bottom of

the thermostat case.

Note: When the TAYSTAT 380 is used with two-stage

heating equipment, there is an air flow change

when the stage change occurs.

Pub. No. 22-5184-01

69-1247—1

First set the SYSTEM s itch:

Cool: Normal setting for months when your home

needs cooling (air conditioning). Digital display

shows a snowflake when cooling is on.

Off: oth heating and cooling are off.

Heat: Normal setting for months when your home

needs heating. Digital display shows a flame

when heating is on.

FAN

Auto On

FAN

SWITCH M10273

Then set the FAN s itch:

Auto: Normal setting for most homes. Some systems

may delay the fan turning on and off with the

equipment.

On: The fan runs continuously. Use for improved air

circulation and air quality.

SYSTEM

Cool Off Heat

SYSTEM

SWITCH

M16376

5Pub. No. 22-5184-01

69-1247—1

Displaying Temperature Setting

NOTE: Your temperature setting can be set anywhere

from 50° to 99°F (10° to 37°C).

The temperature setting and the room temperature display

separately. The ▼ indicator points to Set when the

temperature setting displays, and to Room when the room

temperature displays. The thermostat displays room

temperature unless ▲ or ▼ is pressed.

1. To display the temperature setting on the digital

display, press either the ▲ or ▼ key once.

Set Room

INDICATOR

M18441

Pub. No. 22-5184-01

69-1247—1

Changing Temperature Setting

1. To lower the temperature setting, press the ▼ key.

When in the heating mode, lowering the temperature

at night or during the day can lower your energy

costs.

2. To raise the temperature setting, press the ▲ key.

When in the cooling mode, raising the temperature

before you leave for work or school also lowers your

energy costs.

Set Room

M18442

Set Room

M18443

7Pub. No. 22-5184-01

69-1247—1

CAUTION

Equipment Damage Haza d.

Can cause pe manent damage to the comp es-

so o othe equipment.

To avoid possible equipment damage, do not

operate cooling when outside temperature is below

50°F (10°C). See equipment manufacturer

instructions. To avoid possible compressor

damage, allow the compressor to remain off for

five minutes before restarting.

Pub. No. 22-5184-01

69-1247—1

TROUBLESHOOTING GUIDE

Symptom Action

Heating or

Cooling will not

come on.

Check that the SYSTEM switch on

the thermostat is set to Heat

or Cool.

Check if the circuit breaker is

tripped—reset the circuit

breaker.

Check if the fuse is blown—

replace the fuse.

Check for air movement at the

Check power to the heating or

cooling equipment.

Temperature

setting is too

warm or cool.

Adjust the temperature by

pressing either the ▲ or ▼ key.

9Pub. No. 22-5184-01

69-1247—1

LIMITED WARRANTY

Lo Voltage Room Thermostats

This warranty is extended by American Standard Inc., to

the original purchaser and to any succeeding owner of the

real property to which the The mostat is originally affixed,

and applies to products purchased and retained for use

within the U.S.A. and Canada.

If any part of your The mostat fails because of a manu-

facturing defect within one year from the date of the

original purchase, Warrantor will furnish, without charge, a

new thermostat. Any local t anspo tation, elated

se vice labo and diagnosis calls a e not included.

Pub. No. 22-5184-01

69-1247—1

This warranty does not cover failure of your The mostat if

it is damaged while in your possession or if the failure is

caused by unreasonable use. In no event shall Warrantor

be liable for incidental or consequential damages. In no

event shall any implied wa anty of me chandise o

fitness fo use exceed the te ms of the limited

wa anty stated above.

Some states do not allow limitations on how long an

implied warranty lasts or do not allow the exclusion or

limitation of incidental or consequential damages, so the

above limitation may not apply to you. This warranty gives

you specific legal rights, and you may also have other

rights which vary from state to state.
