Trane TCONT900AC43UA Manual de usuario
69-1817-04
OWNER’S GUIDE
Pub No. 22-5211-02
TCONT900AC43UA Communicating,
Programmable Comfort Control
22-5211-02
2 69-1817—04
TABLE OF CONTENTS
Page Contents
3Features
4 Home Screen
6 Programming Your Heating and Cooling Schedule
14 Operating Your Comfort Control
21 Cleaning Your Comfort Control Screen
22 Reading Your Outdoor Temperature
26 Reading Your Inside Humidity Level
27 Controlling Your Inside Dehumidification Setting
29 Controlling Your Inside Humidification Setting
34 Advanced Settings
36 User Setup Menu
47 Error Codes
48 Frequently Asked Questions and Answers
49 Limited Five-Year Warranty
51 Customer Assistance
IMPORTANT
The Comfort Control has a touch screen interface. Touch keys appear, as necessary, to
complete tasks. Always press the keys with your fingertips. Sharp instruments like a pen or
pencil point can damage the Comfort Control.
22-5211-02
3 69-1817—04
FEATURES
•Large, Clear Display with Backlighting – current temperature, set temperature and time are
easy-to-read and all are displayed on the home screen.
•Menu Driven Programming – Guides you through the scheduling process, showing only
necessary information and choices on each screen.
•Ability to Select Multiple Days – allows you to easily customize the Comfort Control for your
unique schedule.
•Real-Time Clock – keeps time during power failure; automatically updates for daylight savings.
•Precise Temperature Control (+/- 1°F) (+/- .5°C) – reliable, consistent comfort.
•Multiple HOLD options – allows you to modify schedule indefinitely or for a specific time.
•Change Reminders – reminds you to service or replace the air filters and/or humidifier pad.
•Programmable Fan – increases air quality when combined with a whole-house air cleaner.
•Outdoor Temperature Indication – shows current outdoor temperature on the display to help
you plan outdoor activities.
NOTE: The home screen may differ slightly, depending on the heating and/or cooling system you
have and the Comfort Control settings for your system type.
22-5211-02
4 69-1817—04
HOME SCREEN
Key Description
SC
HE
D
H
O
L
D
C
L
OCK
SC
REE
N
M
O
R
E
T
U
E
AM
FAN
A
U
T
O
S
Y
S
TE
M
HEAT
Followin
g
Sc
h
edu
l
e
In
s
i
de
S
et T
o
M19952
FAN
SELECTS ON/AUTO/CIRC
SYSTEM
SELECTS EM. HEAT/HEAT/OFF/COOL/AUTO
SCHED
ENTERS SCHEDULING MODE
HOLD
SETS A PERMANENT HOLD AND
ACTIVATES VACATION HOLD
SCREEN
LOCKS OUT THE SCREEN TO ALLOW FOR CLEANING
CLOCK
SETS THE TIME FORWARD OR BACK
UP ARROW
RAISES TEMPERATURE SETTING
DOWN ARROW
LOWERS TEMPERATURE SETTING
MORE (SELECT MODELS)
SHOWS ADDITIONAL SYSTEM
INFORMATION
22-5211-02
5 69-1817—04
HOME SCREEN
Display Description
SC
HE
D
H
O
L
D
C
L
OCK
SC
REE
N
M
O
R
E
T
UE
AM
FAN
A
U
T
O
S
Y
S
TE
M
HEA
T
Followin
g
Sc
h
edu
l
e
In
s
i
de
S
et T
o
M19953
FAN
SHOWS FAN SETTING
T
UE
S
H
O
W
S
CU
RRENT DAY
O
F THE WEE
K
SYSTEM
SHOWS CURRENT SYSTEM POSITION
TIME
DISPLAY CURRENT TIME OF DAY,
HOLD TIME REMAINING OR NUMBER
OF VACATION DAYS REMAINING
IN
S
IDE TEMPERAT
U
R
E
S
H
O
W
S
THE
CU
RRENT IN
S
IDE TEMPERAT
U
R
E
SET TO TEMPERATURE
SHOWS THE CURRENT
SET TEMPERATURE
FOLLOWING SCHEDULE
SHOWS THE THERMOSTAT IS
FOLLOWING THE PROGRAMMED
SCHEDULE
22-5211-02
6 69-1817—04
PROGRAMMING YOUR HEATING AND COOLING SCHEDULE
Your Comfort Control can control up to four different schedule periods per day:
Wake – Period when you awaken and want your home at a comfortable temperature.
Leave – Period when you are away from home and want an energy-saving temperature.
Return – Period when you return home and want your home back to a comfortable temperature.
Sleep – Period when you are asleep and want an energy-saving temperature.
22-5211-02
7 69-1817—04
NOTE: Schedule times are in 15-minute intervals.
Preprogrammed Energy Star Settings
Table 1 shows default program settings. Visit the Energy Star web site at www.energystar.gov for
additional education and resources on programmable Comfort Controls.
Table 1. Energy Star Default Program Settings.
Schedule Period Time Setpoints Fan Setting
Heat Cool
Wake 6:00 AM 70°F (21°C) 78°F (25.5°C) Auto
Leave 8:00 AM 62°F (16.5°C) 85°F (29.5°C) Auto
Return 6:00 PM 70°F (21°C) 78°F (25.5°C) Auto
Sleep 10:00 PM 62°F (16.5°C) 82°F (27.8°C) Auto
22-5211-02
8 69-1817—04
EDITING SCHEDULE
1. Press Sched key.
2. Press Edit key.
SCHED HOLD CLOCK SCREEN
FRI
AM
PM
FAN
AUTO
SYSTEM
HEAT
Following
Schedule
Inside Set
M22445
SCHED
SCHED
HOLD
HOLD
CLOCK SCREEN
DONE WAKE LEAVE RETURN SLEEP CANCEL
MON TUE WED THU FRI SA SUN
AM
PM
PM
FAN
AUTO
SYSTEM
EM HEAT
HEAT
OFF
COOL
AUTO
CANCEL
PERIOD
HEAT
COOL
Following
Schedule
Inside Set
OK TO PICK MULTIPLE DAYS SCREEN LOCKED
M22553
EDIT
22-5211-02
9 69-1817—04
3. It is OK to pick multiple days. Select any combination of days to edit. These days are sched-
uled with the same times and temperatures. Check marks appear next to days selected.
4. Press Wake key. Once pressed, Wake flashes to show it is selected.
5. Press Up and Down keys to modify time and heat and cool temperatures from this screen.
NOTE: The Fan setting can be programmed for On, Auto, or Circ for each period selected. See
“Fan Schedule” on page 19 for more information.
DONE WAKE LEAVE RETURN SLEEP CANCEL
MON TUE WED THU FRI SAT SUN
AM
FAN
ON
AUTO
CIRC
CANCEL
PERIOD
HEAT
COOL
OK TO PICK MULTIPLE DAYS
M19955
22-5211-02
10 69-1817—04
6. Press Leave key and repeat step 5.
7. Press Return key and repeat step 5.
8. Press Sleep key and repeat step 5.
9. When complete, press Done key. “Saving Changes” appears on the screen to indicate
changes are being saved to the day(s) modified.
NOTE: To set a Program Schedule for the remaining days of the week, repeat steps 1-9.
Example: If Mon - Fri was selected first, go back and repeat steps 1-9 for Sat and Sun.
10. To exit schedule without saving changes, press Cancel key any time.
MON TUE WED THU FRI
SAVING
CHANGES
M19956
