IMPORTANT: As there are different versions of each rig depending on your
region, please ensure that you are using the correct instruction set. The
part number below should match the part number labeled on your box
4
If you have any issues, please contact us at support@trakracer.com
Part # Description QTY Check
BOX #: TR120-BLK-PART1
PS-780-R Prole strip, 780mm Red 2
PS-500-R Prole strip, 500mm Red 2
PS-460-R Prole strip, 460mm Red 2
AL-120-780 Aluminum Prole, 40x120x780mm 2
AT-120-780 Aluminum Prole (Threaded), 40x120x780mm 2
BOX #: TR120-BLK-PART2
CC-01 Cable Management clips 10
BC-40 Bracket, Corner with Cap, 40x40 8
BA-120-BLK Bracket, Anodized corner, 40x120, Black 6
EC-120 End Cap, 40x120 4
EC-40 End Cap, 40x40 4
FR-01 Feet, Rubber 4
LP-120 Logo Plate, TR120 1
NS-M8 T-Nut (Spring), M8 24
NS-M8 T-Nut (Spring), M8 16
NS-M6 T-Nut (Spring), M6 8
AL-120-580 Aluminum Prole, 40x120x580mm 1
AT-120-500 Aluminum Prole (Threaded), 40x120x500mm 2
AT-120-580 Aluminum Prole (Threaded), 40x120x580mm 1
AL-40-460 Aluminum Prole, 40x40x460mm 2
SH-M8-16 Screw (Hex), M8x16 24
SB-M6-12 Screw (Button), M6x12 4
SH-M8-20 Screw (Hex), M8x20 12
SH-M8-20 Screw (Hex), M8x20 16
SH-M6-20 Screw (Hex), M6x20 4
SH-M8-35 Screw (Hex), M8x30 12
SS-01 Seat Slider 1
TK-M8 Tool Kit, M8 1
BCH-120 Chicane Connector, 120mm 2
WF-M8 Washer (Flat), M8 20
WL-M8 Washer (Lock), M8 28
TR120-BLK-PART1
TR120-BLK-PART2
TR120-BLK PARTS LIST
*NOTE: Extra hardware may be included as spare parts
INCLUDED TOOLS
6mm Ball End Hex Key
13mm Spanner
