TP-Link TD-8811B Manual de usuario

TD-8811/TD-8811B

External ADSL2+ ROUTER

Specifications are subject to change without notice. is a registered

trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are

trademarks or registered trademarks of their respective holders.

No part of the specifications may be reproduced in any form or by any means or used to

make any derivative such as translation, transformation, or adaptation without permission

CO., LTD.

FCC STATEMENT

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

•Consult the dealer or an experienced radio/ TV technician for help.

This device complies with part 15 of the FCC Rules. Operation is subject to the following

two conditions:

1) This device may not cause harmful interference.

2) This device must accept any interference received, including interference that

may cause undesired operation.

CE Mark Warning

This is a class B product. In a domestic environment, this product may cause radio

interference, in which case the user may be required to take adequate measures.

Package contents

The following contents should be found in your box:

¾One TD-8811/TD-8811B External ADSL2+ ROUTER

¾One AC power Adapter for TD-8811/8811B External ADSL2+ ROUTER

¾One Resource CD for TD-8811/TD-8811B External ADSL2+ ROUTER, including:

•This User Guide

•Quick installation Guide Program

•Other Helpful Information

•USB driver

¾Quick installation Guide

¾One RJ45 cable

¾Two RJ11 cable

¾One ADSL splitter (only available for TD-8811)

¾One USB cable

)Note:

If any of the above items are damaged or missing, please contact the retailer from whom

you purchased the TD-8811/TD-8811B External ADSL2+ ROUTER for assistance.

COMMENT

Chapter 1. Product Overview ....................................................................1

1.1 Product main specification .............................................................................1

1.2 Supporting protocol........................................................................................1

1.3 Transmit data-rate..........................................................................................2

1.4 ATM property..................................................................................................2

1.5 System support ..............................................................................................2

1.6 Working environment .....................................................................................2

1.7 Electric parameter..........................................................................................2

Chapter 2. Hardware Installation Guide....................................................3

2.1 System requirement .......................................................................................3

2.2 LED explanation.............................................................................................3

2.3 Rear-panel......................................................................................................4

2.4 Hardware installation procedures...................................................................4

Chapter 3. System Configuration..............................................................5

3.1 Computer Configuration.................................................................................5

3.2 Login...............................................................................................................7

3.3 Web Setup......................................................................................................9

3.4 Software Dial................................................................................................18

3.5 USB Configuration........................................................................................19

Chapter 4: Advantage management setup................................................22

Appendix A: FQA.........................................................................................23

Appendix B: Default Configuration............................................................24

Appendix C: Contact Information...............................................................25

TD-8811/8811B External ADSL2+ ROUTER

Chapter 1. Product Overview

The TP-LINK TD-8811/TD-8811B External ADSL2+ ROUTER is the latest product designed and

manufactured by TP-LINK TECHNOLOGIES CO., LTD. With TP-LINK’s excellent circuit design

and high quality production, we guarantee its high performance, great stability and easy to use.

The TD-8811/TD-8811B is a complete plug-and-play solution. With standard Ethernet interface, it

can be directly connected to any 10M/100M Ethernet devices, support Auto-MDI/MDIX.

The TD-8811/TD-8811B not only uses html (web mode through Ethernet port) to configure the

router but also uses external utility software, too. You can download it from our website

(http://www.tp-link.com).

1.1 Product main specification

¾High speed and asymmetrical data transmit mode, provides safe and exclusive bandwidth

¾Supports All ADSL2+ industrial standards

¾Compatible with all mainstream DSLAM (CO)

¾Firmware upgradeable

¾Provides integrated access of internet and route function which face to SOHO users

¾Advanced DMT modulation and demodulation

¾Real-time Configuration and device monitoring

¾Quick response semi-conductive surge protection circuit, provides reliable ESD and

surge-protect function

1.2 Supporting protocol

- G.992.1 (G.dmt) - Annex A/B

- G.992.2 (G.lite) - Annex A/B

- ANSI T1.413

- G.992.3 (ADSL2) - Annex A/B compliant

- G.992.5 (ADSL2+) Annex A/B compliant

- ADSL dual latency (fast path and interleaved path)

- I.432 ATM physical layer compliant

-Supports RFC2364 (PPPoA)

-Supports RFC2516 (PPPoE)

-Supports RFC1483 (EoA) (Bridged *and route)

-Supports RFC1577 (IPoA)

)Note:

1) TD-8811 supports Annex A, TD-8811B supports Annex B

2) “*” Needs the third-party software.

TD-8811/8811B External ADSL2+ ROUTER

1.3 Transmit data-rate

¾Max download data-rate: 24Mbps

¾Max upload data-rate: 1Mbps

¾Max line length: 6Km

1.4 ATM property

¾AAL0, AAL5, OAM, RM, and raw cell types supported

¾Direct hardware support for 4 Receive VCs, with additional RX VCs and TX VCs supported in

software

¾Full 24-bit Virtual Path Identifier (VPI) and Virtual Circuit Identifier (VCI)

1.5 System support

¾Support PVC

¾Support NAT、DHCP and so on

¾Support IEEE 802.3、IEEE 802.3u

¾Support 10Base-T/100BASE-TX full-duplex or half duplex Ethernet

¾Support Auto-MDIX

¾Support USB 1.1 device interface

1.6 Working environment

¾Operating temperature: 0 ~40℃℃

¾Storage temperature: -40 ~70℃℃

¾Humidity: 10%~90% (non-condensing)

1.7 Electric parameter

¾Adaptor power Output: 9VAC/0.8A, 50Hz or 60 Hz

¾Power consumption: 4W Maximum

TD-8811/8811B External ADSL2+ ROUTER

Chapter 2. Hardware Installation Guide

The TD-8811/TD-8811B maintains three separate interfaces, one Ethernet, one USB interface

and one ADSL interface. The Router should not be located where it will be exposed to moisture or

excessive heat. Place the Router in a location where it can be safely connected to the various

devices as well as to a power source.

2.1 System requirement

Confirm your computer has been installed with networking interface card (NIC) before connecting

ADSL2+ ROUTER to your computer, with the operating system supporting the TCP/IP protocol.

2.2 LED explanation

The front panel of ADSL2+ ROUTER includes one power indicator (RED) and five function

indicators (GREEN), as explained in chart 1-1:

Indicator Description Status Function Details

Power Power On

Off

Power OK

Power fail

Act Data

Off

There is data transmitting or receiving on WAN

port

No data is transmitting or receiving on WAN port

Alarm Mistake

Off

There is a mistake when ADSL is transmitting

data or receiving data

ADSL works normally

ADSL ADSL

status

Slow flash

Quick flash

Self-detecting when power up

Connecting to the telecom network

Connection to telecom network is OK

LAN Ethernet

Off

Flash

LAN port works normally

Connection on LAN port is abnormal

Data is transmitting or receiving on LAN port

USB

USB status

Off

Flash

Connection to telecom network is OK

Connection on USB port is abnormal

Data is transmitting or receiving

Chart 1-1

TD-8811/8811B External ADSL2+ ROUTER

2.3 Rear-panel

¾ON/OFF: Turn on/off the ADSL2+ Router’s power.

¾POWER (9VAC/0.8A input): please do not use any unknown power adapter, otherwise your

ADSL2+ Router may be damaged.

¾RESET (reset default): Press the reset button, then turn on the Router's power (keep the

button pressed) for at least three seconds, it will restore the settings to the default factory

configuration.

¾LAN: Connect with your computer’s NIC.

¾USB: Connect with your computer’s USB interface

¾LINE (WAN): Connect to the MODEM Port of Splitter or connect the telephone line.

2.4 Hardware installation procedures

The procedure to install the Router can be described in the following steps:

First Step: Connect the MODEM port of Splitter with the LINE port of the TD-8811/TD-8811B

ADSL2+ ROUTER by telephone line.

Second Step: Connect category 5 cable with RJ45 jacks to ADSL2+ Router’s LAN port and your

computer’s NIC. Or connect USB cable to ADSL2+ Router’s USB port and your computer’s USB

interface.

Third Step: Plug one end of the AC Power Adapter into the Power jack on the Ethernet ADSL2+

Router and the other end to a standard electrical outlet.

Last Step: Check the line connection to see if everything is ready. Power up finally.

TD-8811/8811B External ADSL2+ ROUTER

Figure 2-1

Chapter 3. System Configuration

3.1 Computer Configuration

1. Connect the cable according to Chapter 2, turn on the power.

2. Change the IP address of your PC（Figure 3-1）: Open TCP/IP Properties of the LAN card in

your PC, enter the IP address as 192.168.1.* (* is any value between 2 to 254, Network mask

is 255.255.255.0, Gateway is 192.168.1.1, DNS address is the value provided by ISP).
