TP-Link Archer C5 Pro Manual de usuario

AC1350

Wireless Dual Band

Gigabit Router

Archer C5 Pro

Upgrade to Fast AC Wi-Fi and

gigabit connections

450 + 867 Mbps

Dual Band Wi-Fi

Gigabit

Ports Beamforming Remote

Management

EasyMesh

Beamforming for Better Corverage

Beamforming technology detects the location of your connected devices

and concentrates the Archer C5 Pro's Wi-Fi towards them to create

stronger overall connections.

Archer C5 Pro Regular Router

TP-Link AC1350 Wireless Dual Band Gigabit Router Archer C5 Pro

Highlights

MU-MIMO for 2 x Faster Connections

MU-MIMO technology serves up to two devices at once, reducing wait time,

increasing Wi-Fi throughput for every device, and making each stream more

ecient.

Traditional Router

Sends data to one device at a time

Archer C5 Pro

Simultaneously sends data to multiple devices

EasyMesh

Compliant with WFA EasyMesh and provide a simple way to install and

congure multiple AP networks. Enables devices to work together and

provide an adaptive network of extended and uniform coverage, bringing

added exibility to both consumers and service providers.

TP-Link AC1350 Wireless Dual Band Gigabit Router Archer C5 Pro

Support Agile ACS

Support TP-Link 's Agile ACS solution, helping ISPs to realize remote

management, especially by its Auto-Conguration, Dynamic Service

Provisioning and Auto rmware upgrade.

ISP Support Center

Pro-active Problem Resolution

Diagnostics Information

Notication Information

ACS Server Broadband

TR-069 Remote

Management

(TR-181/TR-098/TR-143)

Agile ACS

Auto-Conguration &

Dynamic Service

Provisioning

Instance Response

Satellite

Gataway

WAN

Highlights

Faster Wi-Fi for More Device

2.4GHz and 5GHz bands run at fast AC1350 Wi-Fi speeds to deliver more

bandwidth and support more devices in your home.

Gigabit Ethernet

Enjoy fast, reliable wired connections for gaming and streaming in the best quality.

867Mbps 5GHz

450Mbps 2.4GHz

TP-Link AC1350 Wireless Dual Band Gigabit Router Archer C5 Pro

Ethernet Ports

Reset

WPS/Wi-Fi

On/O

Power

On/O

Power

Internet

Access

Service

Provider Site

v1.2 pro

Ethernet Switch

OLT GPON SFU

Network

Infrastructure

DSLAM/CMTS DSL/Cable

Modem

Archer C5 Pro

WAN/LAN

CPE

2.4 G 5 G

Connected Home

Smart Home

Home

Application

Laptop Mobile Phone TV

IP Camera IoT

HFC

Fiber

RJ45 Cable

Internet

TP-Link AC1350 Wireless Dual Band Gigabit Router Archer C5 Pro

Application Diagram

· Active Defense – Protect your home network with rewalls and

wireless encryption

· Multi-SSID – Provides dierent wireless access for dierent

applications and services

· Access Control – Establish a whitelist or blacklist to allow or

block certain devices from accessing the internet

· Parental Control – Manage when and how connected devices

can access the internet

· Intuitive Web UI – Ensure quick and simple installation without

hassle

· Fast Encryption – Quickly connect devices to Wi-Fi at the

push of a button without entering the password

Ease of Use Security

Features

Reliability

· Ultimate Wireless Speed – 450Mbps Wi-Fi speed on 2.4GHz

and 867Mbps Wi-Fi speed on 5GHz meet your daily internet

needs

· MU-MIMO – Simultaneously transfer data to multiple devices

for 2× faster

· Support 802.11 ac – Provide a data transfer rate 3 times

faster than 802.11n for each stream

· IPTV – Support IGMP Proxy/Snooping, Bridge and Tag VLAN

to optimize IPTV streaming

TP-Link AC1350 Wireless Dual Band Gigabit Router Archer C5 Pro

Hardware

· Ethernet Ports: 4*10/100/1000Mbps LAN Ports, 1*10/100/1000Mbps WAN Port

· Buttons: Reset Button, Power On/O Button, WPS/Wi-Fi On/O Button

· Antennas: 4 Fixed Omni Directional Antennas

· External Power Supply: 12V/1A

· Dimensions (W x D x H): 9.1 × 5.7 × 1.4 in (230 × 144 × 35 mm)

Software

Wireless

· Wireless Standards: IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz

· Frequency: 2.4GHz and 5GHz

· Signal Rate:

5GHz: Up to 867Mbps

2.4GHz: Up to 450Mbps

· Wireless Function: Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Schedule,

Wireless Statistics, AP mode

· Mesh Technology: WFA EasyMesh

· Wireless Security: 64/128-bit WEP, WPA / WPA2, WPA-PSK/ WPA2-PSK encryption

Specications

· WAN Type: Multi- EWAN, Dynamic IP, Static IP, PPPoE, PPTP, L2TP

· DHCP: Server, DHCP Client List, Address Reservation

· Port Forwarding: Virtual Server, Port Triggering, UPnP, DMZ

· VPN Passthrough: PPTP, L2TP, IPSec

· VPN Server: PPTP, OpenVPN

· Dynamic DNS: DynDns, NO-IP

· Access Control: Parental Control, Local Management Control, Host List, White List,

Black List

· Firewall Security: DoS, SPI Firewall, IP and MAC Address Binding

· Protocols: IPv4, IPv6

· Management: Access Control, Local Management, Remote Management, TR-069,

TR-098, TR181, TR-111, TR143

· APP Management: Tether

TP-Link AC1350 Wireless Dual Band Gigabit Router Archer C5 Pro

Specications

· System Requirements

Microsoft Windows 10/8.1/8/7/Vista/XP/2000/NT/98SE, MAC OS,

NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome

20.0, Safari 4.0, or other Java-enabled browser, Cable or DSL Modem

Subscription with an internet service provider (for internet access)

· Package Contents

Wireless Router Archer C5 Pro

Power Adapter

RJ45 Ethernet Cable

Quick Installation Guide

· Certication

CE, RoHS

· Environment

Operating Temperature: 0℃~40℃(32℉~104℉)

Storage Temperature: -40℃~70℃(-40℉~158℉)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing

Others
