TP-Link TL-WPA2220 Manual de usuario

www.tp-link.com

TL-WPA281 V3

Features：

Description：

300Mbps AV200 WiFi

Powerline Extender

Wi-Fi Clone Button simplies your Wi-Fi conguration

and helps build a seamless unied home network

HomePlug AV standard providing up to 200Mbps high

speed data transmission over a home’s existing electrical

wiring, ideal for lag-free HD or 3D video streaming and

online gaming

Extend 300Mbps Wireless connections to previously

hard-to-reach areas of your home and oce

Two Ethernet ports allow your TVs, game consoles, or PCs

connect to the Internet

Up to 300-meter range over the household power circuit

Easy-to-install, just plug in, pair and play

128-bit AES encryption easily at a push of "Pair" Button

Supports IGMP managed multicast IP transmission,

optimizing IPTV streaming

TP-LINK 300Mbps AV200 WiFi Powerline Extender TL-WPA281 V3 extends your Internet connection to every room of the house

through your home’s existing electrical circuitry. The TL-WPA281 V3 features a Wi-Fi Clone Button enabling Super Range Exten-

sion, which means it can automatically copy the SSID and Password of your router. In this way, TL-WPA281 V3 simplies your

Wi-Fi conguration and allows for seamless roaming within your home network.

Package:

300Mbps AV200 WiFi Powerline Extender

TL-WPA281 V3

2-meter RJ-45 Ethernet Cable * 2

Quick Installation Guide

Resource CD

www.tp-link.com

Specifications：

Specifications are subject to change without notice. TP-LINK is a registered trademark of TP-LINK Technologies Co., Ltd. Other brands and product names are

trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any

Diagram:

Hardware Features

Standards and Protocols

Interface

Plug Type

Button

LED Indicator

Dimensions ( W x D x H )

Power Consumption

Range

Software Features

Modulation Technology

Encryption

Others

Certications

System Requirements

Environment

HomePlug AV, IEEE802.3, IEEE802.3u, IEEE802.11b/g/n

10/100Mbps Ethernet Ports

Pair, Reset, Wi-Fi/Wi-Fi Clone

PWR, PLC, ETH, Wi-Fi/Wi-Fi Clone

3.7 x 2.1 x 1.6 in. (94 × 54 × 40mm)

<6W

300 Meters over electrical circuit

OFDM (PLC)

Powerline Security:

128-bit AES

Wireless Security:

WEP, WPA/WPA2, WPA-PSK/WPA2-PSK Encryption

CE, FCC, RoHS

Windows 8/7/Vista/XP/2000, Mac OS, Linux*

Operating Temperature: 0°C~40°C (32°F~104°F)

Storage Temperature: -40°C~70°C (-40°F~158°F)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing

* Utility supports Windows 8/7/Vista/XP/2000 operating system for the present.

TL-WPA2220300Mbps AV200 WiFi Powerline Extender

UNIFIED HOME NETWORK

Room 1 Room 2

SSID: abc

Password: 123

SSID: abc

Password: 123

Ethernet Cable

Electrical Wire

Router Game

console Laptop

TL-PA2010 TL-WPA281 V3

*The Powerline Adapters need to be connected in the same electrical circuit.

Router

TL-PA2010

TL-WPA281 V3

*The Powerline Adapters need to be connected in the same electrical circuit.

PLUG & PLAY WITH TP-LINK WI-FI CLONE!

PASSWORD

SSID

PASSWORD

SSID

PASSWORD

SSID

PASSWORD

SSID

PASSWORD

SSID

PASSWORD

WPS

> Plug in TL-WPA281 V3 near your router.

> Press the Wi-Fi Clone button on TL-WPA281 V3.

> Press the WPS button on your router.

That’s it! Now TL-WPA281 V3 has copied your router’s SSID and

Password and you can enjoy a unied home network!
