Quick Reference Guide

MN 00505-QRG08-PRI

Printed in the USA 8/07

Customer Experience Center

1-800-331-4331 POWERED

!Aword about safe vehicle operations

This Quick Reference Guide is a summary of

basic vehicle operations. It contains brief

descriptions of fundamental operations so you

can locate and use the vehicle’s main

equipment quickly and easily.

The Quick Reference Guide is not intended as

asubstitute for the Owner’s Manual located

in the vehicle’s glove box. We strongly

encourage you to review the Owner’s Manual

and supplementary manuals so you will have

abetter understanding of the vehicle’s

capabilities and limitations.

Your dealership and the entire staff of Toyota

Motor Sales, U.S.A., Inc. wish you many years

of satisfied driving in your new Prius.

This Quick Reference Guide is not a full

description of Prius operations. Every

Prius owner should review the Owner’s

Manual that accompanies this vehicle.

Pay special attention to the boxed

information highlighted in yellow

throughout the Owner’s Manual.Each box

contains safe operating instructions to

help you avoid injury or equipment

malfunction.

All information in this Quick Reference

Guide is current at the time of printing.

Toyota reserves the right to make changes

at any time without notice.

2008

Prius

OVERVIEWBASIC VEHICLE OPERATION FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

Spare tire & tools

Tool location

Removing the spare tire

(1) Remove the luggage storage box.

(2) Loosen the bolt and remove it.

(3) Remove the jack box.

Refer to the “Owner’s Manual” for tire changing and

jack positioning procedures.

Wheel nut wrench Jack handle

Jack

Spare tire

(1)

(3)

(2)

OVERVIEWBASIC HYBRID VEHICLE OPERATION FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

INDEX

Item Page no.

BASIC HYBRID VEHICLE OPERATION

Hybrid Synergy Drive System 2

Keyless entry 6

Key fob 3

Parking & turning OFF the Hybrid System 9

Shifting 8

Smart Key system 4-5

Smart Key unlock functions

Turning the Hybrid System ON 7

OVERVIEW

Engine maintenance 15

Fuel tank door opener and cap 14

Hood release 15

Indicator symbols 12-13

Instrument cluster 12

Instrument panel 10-11

Light control-Instrument panel 14

Rear hatch 14

FEATURES/OPERATIONS

Air Conditioning/Heating 20-21

Audio 22-23

Clock 25

Cruise control 21

Cup and bottle holders 25

Garage door opener (HomeLink

)

Lights & turn signals 16

Luggage storage box 24

Parking brake 25

Power outlets 25

Seat adjustments-Front 18

Seat adjustments-Rear 18

Seats-Head restraints 18

Telephone controls (Bluetooth®)24

Tilt steering wheel 19

Window wipers & washers 17

Windows 19

SAFETY AND EMERGENCY FEATURES

Door locks 26

Doors-Child safety locks 26

Emergency flashers 27

Jump starting 28

Rear air vent 27

Seat belts 26

Seat belts-Shoulder belt anchor 26

Spare tire & tools 29

Tire Pressure Warning System 27

1Programmable by customer. For dealer-programmable

features, please visit your Toyota dealer.

2HomeLink®is a registered trademark of Johnson Controls, Inc.

OVERVIEW

BASIC HYBRID VEHICLE OPERATION FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

Master key Ignition key & wireless remote.

Mechanical key Fits into master key and can be

removed to manually lock/unlock driver door only.

Ignition key slot When inserting, push completely

in. When removing, gently pull; key will be pushed

out by a spring. DO NOT FORCE THE KEY.If it

cannot be removed, push it all the way in again,

then pull it out.

To remove or replace mechanical key Slide the

lock knob in the direction of the arrow.

Key fob

BASIC HYBRID VEHICLE

OPERATION

Master key

Mechanical key*

Ignition key

(key fob) slot

*Lock/Unlock the driver’s door only

Slide

Pull out

Hybrid Synergy Drive System

The Hybrid Synergy Drive System utilizes a computer

controlled gasoline engine and electric motor to

provide the most efficient combination of power for

the vehicle. To conserve energy, when the brakes

are applied, braking force generates electricity

which is then sent to the traction battery. In

addition, the engine shuts off when the vehicle is

stopped. The benefits are better fuel economy,

reduced vehicle emissions and improved

performance.

Note: Fuel consumption and energy information

of the Hybrid System are shown on the

multi-information display. Refer to this

screen for important driving information

and feedback to maximize energy

use/creation and conserve fuel.

Tips for improved fuel economy

-Ensure tire pressures are maintained at levels

specified in the Owner's Manual.

-If possible, link trips to reduce engine cold starts.

-Avoid driving at speeds that are higher than

necessary, especially on the highway.

-When possible, avoid sudden stops to maximize

regenerative braking energy.

-Minimize use of the Air Conditioning.

Refer to the Owner’s Manual for more details.

OVERVIEW

BASIC HYBRID VEHICLE OPERATION FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

BASIC HYBRID VEHICLE OPERATION

Locking operation

Front door Rear hatch

Smart Key system (if equipped)

Carrying a Smart Key allows the vehicle to be

locked, unlocked and the Hybrid System engaged

without handling the key.

Push

Smart Key unlock functions

(if equipped)

The Smart Key unlocking function can be

programmed to operate in three different modes

when Smart Key is activated. In all modes, grasping

the front passenger door handle will unlock all

doors.

-To unlock driver side door only, grasp driver side

handle.

-To unlock all doors, grasp any door handle except

rear doors.

-To unlock driver side door or hatch independently,

grasp the handle.

Refer to the Owner’s Manual for more information

on this feature, and how to change modes.

Smart Key system cancel switch

NOTE: To conserve battery power, turn the Smart Key

system “OFF” when not using the vehicle for prolonged

periods of time. For more battery saving information,

refer to the Owner’s Manual for more details.

ON OFF

Push

Unlocking operation

Front door

NOTE: After unlocking, if a door is not opened

within 30 seconds, all doors will relock for safety.

Refer to your Owner’s Manual and the following

section of this guide for Smart Key unlocking

programmable options.

Rear hatch

BASIC HYBRID VEHICLE OPERATION

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

BASIC HYBRID VEHICLE OPERATION

Insert key.*

Depress the brake pedal and push the “POWER”

button briefly and firmly.

The “READY” light will blink. After a few

seconds, when the light remains ON and a beep

sounds, you may begin driving.

Note: The brake pedal must be depressed to turn

the Hybrid System on.

* It is not necessary to insert the ignition key (key

fob) if Smart Key system is installed and activated.

Turning the Hybrid System ON

Changing operation modes

Pressing “POWER” without depressing the brake

pedal while the Hybrid System is OFF will change

the operation mode in succession from:

Start function

ACCESSORY

OFF

Accessories such as the radio

will operate.

Ignition is on; Hybrid System is not

engaged.

All systems OFF.

Panic button

Push and hold

Keyless entry

Locking operation

Unlocking operation

NOTE: After unlocking, if a door is not opened within

30 seconds, all doors will relock for safety.

Push

Push ONCE: Driver door

TWICE: All doors

OVERVIEW

BASIC HYBRID VEHICLE OPERATION FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

BASIC HYBRID VEHICLE OPERATION

When the vehicle is at a complete stop, keep

brake pedal depressed and push Park button

above the shift lever.

Push the “POWER” button to turn off the system.

Fully depress the parking brake.

Remove the key fob if inserted.*

Information

In some instances when the engine starts, and/or on a

short trip after the engine is stopped, the engine

water pump may continue operating for a short time.

This is a standard operation of the vehicle to ensure

optimum performance and shouldn’t be a concern.

WARNING: If the “POWER” button is held for longer

than three seconds while the vehicle is moving, the

Hybrid System will shut off.

*It is not necessary to insert the ignition key (key

fob) if Smart Key system is installed and activated.

Shifting

Park button

Shift lever

Brake pedal must be depressed when shifting to or

from the Park position. If brake is not applied, a

beep will sound and the vehicle cannot be shifted.

NOTE: The shift lever will always return to its

original position after shifting. ALWAYS CONFIRM

SHIFT POSITION BY CHECKING INDICATOR SYMBOLS

ON THE INSTRUMENT CLUSTER.

*The engine brake is the equivalent of downshifting.

Shift to “B” when engine braking is desired (i.e.

downhill driving, coasting to a stop, etc.).

Park button

Reverse (buzzer sounds)

Neutral

Drive

Engine brake

Shift position

Parking & turning OFF the Hybrid System

OVERVIEW

BASIC HYBRID VEHICLE OPERATION FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

OVERVIEW

Headlight, turn signal and front fog light1controls

Wiper and washer controls

“POWER” button

Clock

“AUDIO” switch (multi-information display control)

“CLIMATE” switch (multi-information display control)

Multi-information display

“DISPLAY” switch (multi-information display control)

“INFO” switch (multi-information display control)

Mph or km/h button

Trip meter reset

Emergency flasher button

Audio system

12V DC Power outlet

Park button

Electronic shift lever

Ignition key (key fob) slot

Cruise control1

Tire Pressure Warning System reset

Smart Key system cancel1

Steering wheel climate control

Instrument panel light control

Steering wheel audio control

1If equipped

2For details, refer to the Navigation System

Owner’s Manual.

Instrument panel

With navigation system1, 2

Without navigation system

BASIC HYBRID VEHICLE OPERATION

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

OVERVIEW

Headlight indicator

Low engine oil pressure warning1

Service indicators and reminder

Speedometer

Fuel gauge

Odometer and two trip meters

Instrument cluster

Driver seat belt reminder1

(alarm will sound if speed is over 12 mph)

Front passenger seat belt reminder1

(alarm will sound if speed is over 12 mph)

Brake system warning1

Charging system warning1

Low fuel level indicator1

Anti-lock Brake System warning1

Malfunction/Check Engine indicator1

Indicator symbols

Master warning1

High coolant temperature warning1

Open door warning1

Airbag SRS warning1

1For details, refer to “Service reminder indicators and warning buzzers-- --

Instrument cluster” Section 5-2, 2008 Owner’s Manual.

2If this light flashes, see “Cruise control” Section 2-4, 2008 Owner’

sManual.

3For details, refer to “Transmission” Section 2-1, 2008 Owner’s Manual.

Driving ready light

Engine oil replacement reminder1

Turn signal indicator

Headlight high beam indicator

Cruise control indicator2

Slip indicator

Hybrid System warning1

Vehicle Stability Control warning1

Traction battery warning1

Electric power steering system

warning1

Smart Key system warning1

Automatic headlight leveling system warning1

Running mode position indicator3

Automatic Air Conditioner indicator

Recirculate mode indicator

Windshield airflow indicator

Rear window and outside rearview mirror

defoggers indicator

Hybrid vehicle immobilizer/Theft deterrent

system indicator

Low Tire Pressure Warning1

Front passenger occupant classification

indicator

BASIC HYBRID VEHICLE OPERATION

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

Hood release

Engine maintenance

Windshield washer fluid tank

Engine oil filler cap

Engine coolant reservoir

Engine oil level dipstick

Note: Regularly scheduled maintenance, including

oil changes, will help extend the life of

your vehicle and maintain performance.

Please refer to the “Owner’s Warranty

Information Booklet,” “Scheduled

Maintenance Guide” or “Owner’s Manual

Supplement.”

Pull up latch and

raise hood

Pull

Rear hatch

Pull

NOTE: Tighten until one click is heard. If the cap is

not tightened enough, Check Engine “ ” indicator

may illuminate.

NOTE: MAINTAIN GASOLINE IN THE TANK AT ALL

TIMES. SERIOUS DAMAGE TO THE HYBRID

SYSTEM CAN OCCUR IF THE VEHICLE RUNS

OUT OF GASOLINE.

Fuel tank door opener and cap

Turn

Driver seat Pull up

Store

OVERVIEW

To open the rear hatch, grasp the handle and pull up.

Light control-Instrument panel

Brightness

control

Otros manuales para PRIUS 2008

Tabla de contenidos

Otros manuales de Automóvil de Toyota

Toyota

Toyota Supra 1990 Manual de usuario

Toyota

Toyota 2010 Tundra Manual de usuario

Toyota

Toyota Avalon Hybrid 2015 Manual de usuario

Toyota

Toyota '07Camry_U Guía de instalación

Toyota

Toyota 2009 Camry Manual de usuario

Toyota

Toyota 2009 4Runner Manual de usuario

Toyota

Toyota PRIUS 50 2020 Series Manual de usuario

Toyota

Toyota AVALON 2005 Manual de usuario

Toyota

Toyota AVALON 2005 Manual de usuario

Toyota

Toyota Prius 2007 Manual de usuario

Toyota

Toyota Cruiser 07 FJ Manual de usuario

Toyota

Toyota 4RUNNER BROCHURE 2011 Manual de usuario

Toyota

Toyota Tacoma 2012 Manual de usuario

Toyota

Toyota TACOMA 2022 Manual de usuario

Toyota

Toyota Avalon 2006 Manual de usuario

Toyota

Toyota LAND CRUISER Manual de usuario

Toyota

Toyota AVALON Manual de usuario

Toyota

Toyota Corolla 2022 Manual de usuario

Toyota

Toyota '01 AVALON U Manual de instrucciones

Toyota

Toyota AVALON HYBRID Manual de usuario

Toyota

Toyota Prius 2007 Manual de usuario

Toyota

Toyota GR Supra 2023 Manual de funcionamiento

Toyota

Toyota Corolla guide Manual de usuario

Toyota

Toyota COROLLA MATRIX 2009 Manual de usuario

Manuales populares de Automóvil de otras marcas

CITROËN

CITROËN DS4 DSign Manual de usuario

Lexus

Lexus 2015 CT 200h Manual de usuario

Cadillac

Cadillac CTS 2008 Manual de usuario

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manual de usuario

Porsche

Porsche Boxster S Manual de usuario

GMC

GMC 2010 Savana 1500 Cargo Manual de usuario

KIAM

KIAM SPORTAGE 2014 Manual de lista de piezas

GMC

GMC 2013 Terrain Instrucciones de montaje

GMC

GMC T-Series 1999 Manual de usuario

Mercury

Mercury 1998 Mystique Manual de usuario

Mercury

Mercury 2007 Mariner Manual de usuario

Mazda

Mazda 2007 Mazdaspeed 3 Guía

Mazda

Mazda 2014 CX-5 Manual de usuario

GMC

GMC Chevrolet Express 2022 Manual de usuario

GMC

GMC 1997 Jimmy Manual de usuario

Chevrolet

Chevrolet 2012 Malibu Manual de usuario

Cadillac

Cadillac 2010 Escalade Manual de usuario

Skoda

Skoda FABIA RS - ANNEXE 118 Manual de usuario
