Tovertafel Pixie

Assembly instructions

NL - orginal assembly instructions

August 2023

UK Assembly instructions

NL Montagehandleiding

DE Installationshandbuch

FR Manuel de montage

SE Monteringsanvisningar

NO Monteringsveiledning

DK Samlevejledning

3August 2023•Assembly instructions

Tovertafel Pixie

Assembly instructions

Contents

1. Introduction 4

1.1. Intended use 4

1.2. Important before you begin playing 4

1.3. Assistance 4

1.4. Explanation of the symbols used 5

2. Safety instructions 5

2.1. Parts supplied 6

3. Assembling the Tovertafel Pixie 7

3.1. Checking the package contents 7

3.2. Assembling the Tovertafel Pixie 7

4. EC declaration 15

5. Legal information 15

6. Disposal or recycling 15

•Assembly instructions August 2023

1. Introduction

The Tovertafel Pixie is very easy to assemble. These instructions will lead you through the assembly process

step-by-step.

Carefully read the user manual before you start using the Tovertafel Pixie. Pay particular

attention to the safety instructions in order to guarantee that the Tovertafel Pixie functions

correctly.

Caution

• Risk of product damage. Do not remove the contents of the box until mentioned in the assembly instructions.

The packaging is part of the assembly process.

1.1. Intended use

The Tovertafel Pixie is an interactive projection

system that projects games on ceilings, walls or

tables.

The Tovertafel Pixie may not be mounted, moved or

operated by people with limited physical, sensory

or intellectual capacities, or a lack of experience

and/or knowledge, unless they are being supervised

by a person who is responsible for their safety or

who issues them instructions.

The Tovertafel Pixie is only intended for indoor use.

The Tovertafel Pixie is intended for maximum 2

players.

1.2. Important before you begin

playing

If the instructions in the assembly instructions or

user manual are not complied with and/or the Pixie

is used for purposes other than those described in

the manual, the product guarantee will lapse and

we will not accept any liability.

We recommend that you save the original

packaging in case you might need to return the

Pixie.

1.3. Assistance

We are continuously developing

the product. It is possible that

some functions in this guide dier

and have been improved in the

meantime. For the latest

information and extensive

support, please see

my.tover.care/pixie or scan the

QR code to go to the website.

Are you having problems assembling or using the

Tovertafel Pixie? If so, please get in touch with our

service team.

Service team:

+31 (0)85 303 4819

support@tover.care

www.tover.care/pixie

Address:

Tover B.V.

Hamburgerstraat 28a

3512 NS Utrecht

The Netherlands

Did you purchase the Tovertafel Pixie via one of our

local distributors? In that case, get in touch with

that distributor for service questions. See our

website my.tover.care/articles/contact.

5August 2023•Assembly instructions

1.4. Explanation of the symbols used

Reference to a choice that you can

make to a step.

Warning Indicates a hazardous

situation. Failure to follow the safety

instructions may result in death or

serious injury.

Caution Indicates a hazardous

situation. Failure to follow the safety

instructions may result in minor to

moderate injury.

Remark represents information that

should be regarded as important but

which has no connection with injury.

Tip represents useful information.

2. Safety instructions

Safety during use is only guaranteed if assembly has

been carried out correctly in a technical sense and

in accordance with the assembly instructions. You

are personally responsible for damage caused by

improper assembly.

Read the safety instructions

described in the user manual

before starting assembly.

•Assembly instructions August 2023

2.1. Parts supplied

Risk of product damage. Do not remove the contents of the box until mentioned in the assembly instructions.

The packaging is part of the assembly process.

1. Remote control

2. 1× battery CR2032

3. Lid

4. Allen key 2.5 mm

5. Yellow power cable 5 m (NB: type, colour and length vary per country)

6. Base in box

7. Yellow cover with cable

8. Frame components in box

9. Box with user manual and assembly instructions

A. Screw type A (round head, length 8 mm)

B. Screw type B (round head with flange, length 10 mm)

7August 2023•Assembly instructions

3. Assembling the Tovertafel Pixie

3.1. Checking the package contents

Check that all components are present during assembly (see chapter 2.1.Parts supplied) and that there is no

visible damage to the components. If components are missing or damaged, please contact Tover B.V. or one of

our approved distributors (see chapter 1.3. Assistance) and wait to use the Tovertafel Pixie until Tover has

provided further instructions.

3.2. Assembling the Tovertafel Pixie

Step 1:

1. Find a good, open space on the floor to assemble the Tovertafel Pixie.

2. Open the box.

Step 2:

1. Remove the cardboard section containing manuals, accessories and assembly material from the

packaging and place it within reach.

2. Remove the top piece of foam from the packaging and place it on the floor so that it can be used to protect

the yellow cover.

4You can also place a cloth or a rug to prevent scratches.

•Assembly instructions August 2023

Step 3:

Remove the yellow cover and the frame (in the rectangular packaging) from the box simultaneously, and

immediately place the yellow cover on the piece of white foam or on a rug.

2Risk of product damage. Never pull the wire between the frame and the yellow cover.

Step 4:

1. Open the cardboard around the frame.

2. Thread the wire through the components of the frame.

9August 2023•Assembly instructions

Step 5:

1. Slide the 3 components of the frame into each other while you carefully guide the wire through them.

2. Align the assembly holes with each other.

3. Manually screw the frame components together using 4× screw type A.

4Use the enclosed Allen key.

2Remark

• Risk of product damage. The Tovertafel Pixie has not been designed for assembly with electrical tools; the

power of the electrical tools can damage the product. Only use manual tools for assembly.

Step 6:

1. Li the base out of the packaging.

4Leave the cardboard around the base during assembly. This makes the base easy to assemble and

prevents it from rolling away.

2. Place the base straight in front of the frame.

3. Thread the wire into the base.

4. Slide the frame components into each other.

5. Align the assembly holes with each other.

6. Manually screw the frame to the base using 2× screw type A.

4Use the enclosed Allen key.

2Remark

• Risk of product damage. The Tovertafel Pixie has not been designed for assembly with electrical tools; the

power of the electrical tools can damage the product. Only use manual tools for assembly.

•Assembly instructions August 2023

Step 7:

Remove the cardboard around the base by folding down the lips at the side.

Step 8:

1. Pull and tighten the wire via the bottom of the base.

2. Roll up the wire so that it fits inside the cavity.

3. Insert the plug into the plug port. Push the plug until you hear a click.
