Touch Dynamic CS-200 Manual de usuario
CS-200
Point-of-Sale
HardwareSystem
User Manual
Revision v1.3 December 2009
2
Copyright 2007 Oct. ~
All Rights Reserved
Manual Version 1.3
Part Number:
The information contained in this document is subject to change without notice.
We make no warranty of any kind with regard to this material, including, but not limited to, the
implied warranties of merchantability and fitness for a particular purpose. We shall not be
liable for errors contained herein or for incidental or consequential damages in connection
with the furnishing, performance, or use of this material.
This document contains proprietary information that is protected by copyright. All rights are
reserved. No part of this document may be photocopied, reproduced or translated to another
language without the prior written consent of the manufacturer.
TRADEMARK
Intel®, Pentium® and MMX are registered trademarks of Intel® Corporation. Microsoft® and
Windows® are registered trademarks of Microsoft Corporation.
Other trademarks mentioned herein are the property of their respective owners.
3
Safety
IMPORTANT SAFETY INSTRUCTIONS
1. To disconnect the machine from the electrical power supply, turn off the power switch
and remove the power cord plug from the wall socket. The wall socket must be easily
accessible and in close proximity to the machine.
2. Read these instructions carefully. Save these instructions for future reference.
3. Follow all warnings and instructions marked on the product.
4. Do not use this product near water.
5. Do not place this product on an unstable cart, stand, or table. The product may fall,
causing serious damage to the product.
6. Slots and openings in the cabinet and the back or bottom are provided for ventilation to
ensure reliable operation of the product and to protect it from overheating. These
openings must not be blocked or covered. The openings should never be blocked by
placing the product on a bed, sofa, rug, or other similar surface. This product should
never be placed near or over a radiator or heat register or in a built-in installation unless
proper ventilation is provided.
7. This product should be operated from the type of power indicated on the marking label.
If you are not sure of the type of power available, consult your dealer or local power
company.
8. Do not allow anything to rest on the power cord. Do not locate this product where
persons will walk on the cord.
9. Never push objects of any kind into this product through cabinet slots as they may
touch dangerous voltage points or short out parts that could result in a fire or electric
shock. Never spill liquid of any kind on the product.
CE MARK
This device complies with the requirements of the EEC directive
2004/108/EC with regard to “Electromagnetic compatibility” and
2006/95/EC “Low Voltage Directive”.
FCC This device complies with part 15 of the FCC rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause
undesired operation.
4
CAUTION ON LITHIUM BATTERIES
There is a danger of explosion if the battery is replaced incorrectly. Replace only with the
same or equivalent type recommended by the manufacturer. Discard used batteries
according to the manufacturer’s instructions.
LEGISLATION AND WEEE SYMBOL
2002/96/EC Waste Electrical and Electronic Equipment Directive on the treatment, collection,
recycling and disposal of electric and electronic devices and their components.
The crossed dustbin symbol on the device means that it should not be disposed of with other
household wastes at the end of its working life. Instead, the device should be taken to the
waste collection centers for activation of the treatment, collection, recycling and disposal
procedure.
To prevent possible harm to the environment or human health from uncontrolled waste
disposal, please separate this from other types of wastes and recycle it responsibly to
promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or
their local government office, for details of where and how they can take this item for
environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the
purchase contract.
This product should not be mixed with other commercial wastes for disposal.
5
Revision History
Changes to the original user manual are listed below:
Version Date Description
1.0 2007 December Initial release
1.1 2007 March System disassembly updated
1.2 2007 October
Cover page update
Wall mount bracket installation
Connector Pin Definition update
1.3 2009 December Drivers installation removed from manual
6
Table of Contents
1. Item Checklist .............................................................................................................................................................7
1.1 Standard Items......................................................................................................... 7
2. System View.................................................................................................................................................................8
2.1 Front View................................................................................................................ 8
2.2 Rear View................................................................................................................. 8
2.3 System Drawing....................................................................................................... 9
4. Peripherals Installation............................................................................................................................................11
4.1 Biometric Magnetic Stripe Reader Installation.........................................................11
4.2 Cash Drawer Installation.........................................................................................11
4.3 Customer Display Installation................................................................................. 13
4.4 Second Display Installation.................................................................................... 14
4.5 Wall Mount Bracket Installation.............................................................................. 15
5. System Disassembly..................................................................................................................................................16
5.1. Removing the Base Cover .................................................................................... 16
5.2. Replacing the HDD ............................................................................................... 17
5.4. Replacing the Power Supply................................................................................. 17
5.5. Replacing the RAM............................................................................................... 18
Appendix A: Specification............................................................................................................................................19
Appendix B: Jumper Settings......................................................................................................................................21
Appendix C: BIOS Setting...........................................................................................................................................27
Appendix D: Drivers Installation................................................................................................................................30
7
1. Item Checklist
Take the system unit out of the carton. Remove the unit from the carton by holding it by
the foam inserts. The following contents should be found in the carton:
1.1 Standard Items
a. Driver CD
b. Power Cable
Note: The power cord type various according to different country and region.
8
2. System View
2.1 Front View
2.2 Rear View
Note: The maximum current that can be drawn from each COM port is 500 mA.
CD-ROM
(option) USB 1 & 2 Power Button
VGA
COM3
KB/Mouse LAN
Cash Drawer
Power USB 24V
Power USB 12V
COM2
COM1
LPT COM4 Line-In Line-Out
9
2.3 System Drawing
Item Description
1 Front Bezel
2 Touch Panel
3 LCD Panel
4 LCD Chassis
5 Main Board
6 Inverter
7 MSR Function Board
8 Touch Bridge Board
9 Thermal Module
10 LCD Cover Assembly
11 MSR Dummy Door
12 CPU / RAM Door
10
Item Description
13 CD-ROM
14 Base Front Cover
15 Front I/O Board
16 CD-ROM Guide Bracket
17 Side Cover
18 Power Supply
19 Rear I/O Board
20 Base Cover Bracket
21 Base Cover
