Toslon TF740 Manual de usuario
1
Preface
As Yachting Electronic Co., Ltd is continuously improving this product, we retain the
right to make changes to the product at any time which may not be reected in this
version of the manual. Please contact your dealer if you require any further assistance.
It is the owner’s sole responsibility to install and use the instrument and transducers in a
manner that will not cause accidents, personal injury or property damage. The user of
this product is solely responsible for observing safe boating practices.
Sonar Performance
The accuracy of the sonar depth display can be aected by many factors, including the
type and location of the transducer and water conditions.
The choice, location, and installation of transducers are critical to the performance of
the system as intended. If in doubt, consult your local dealer.
To reduce the risk of misusing or misinterpreting this unit, you must read and under-
stand all aspects of this Installation and Operation Manual. We also recommend that
you practice all operations using the built-in simulator before using this unit on the
water.
Global Positioning System:
The Global Positioning System (GPS) is operated by the US Government which is solely
responsible for its operation, accuracy and maintenance. The GPS is subject to changes
which could aect the accuracy and performance of all GPS equipment anywhere in
the world, including this instrument.
Warnning: disassembly and repair of this electronic unit should only be performed
by authorized service personnel. Any modication of the serial number or attempt to
repair the original equipment or accessories by authorized individuals will void the
warranty.
We may nd it necessary to change or end our policies, regulations and special
oers at any time. We reserve the right to do so without notice. All features and
specications subject to change without notice.
2
Contents
Overview
Check the Content
Installation
Transducer Installation
GPS Receiver Instrallation
Antenna Installation
Connection
Powering
Using Instruction
Some warnnings
What’s on the display
Key Function
Quickly Operation
Start Using
Set HOME position
Save a waypoint
Go to target waypoint
Import KML
Go back
Menu Opertion
Basic
Sensivity
Surface Clarify
Fish ID. Sens
Background
Color Adjust
Color Style
Advanced Mode
Sonar
Depth Range
2
5
6
7
7
10
12
13
15
17
17
18
19
20
22
22
22
23
24
25
26
26
26
26
26
27
27
27
27
28
28
3
Sonar Gain
Load New Color
Overlap Data
Depth Oset
Temp. Oset
Shallow Alarm
GPS SETTINGS
GPS Filter
Distance Unit
Speed Unit
Time Zone
24-Hour Time
Sample Step
Arrive Alarm
Calibrate compass of display
Calibrate compass of boat
Autopilot
Wirling Test
Boat Type
Channels Reverse
Channel 1 Speed
Channel 2 Speed
Steering Sens.
System
Simulator
Backlight
Key Tone
Language
Baud Rage
Battery Alarm
Boat Vtg. Alarm
Default Settings
System Info.
Radio Bind
28
28
28
28
29
29
30
30
30
30
30
30
31
31
31
32
33
33
33
34
34
34
34
35
35
35
35
35
35
36
36
36
36
36
4
Update R-Boxes.
Quick Qperation
Quick Marker
Waypoint
Route
Go back
Set Home Pos.
Go to Home
Stop Autopilot
Clear Map
Import KML
Overlap Data
Specications
Warranty
Unit Care
FAQ (Frequenly Asked Questions)
36
38
38
39
40
41
41
41
41
41
41
42
43
44
45
46
5
Overview
TF740 is an ALL-IN-ONE Autopilot navigation and sonar system,
which was specially designed for all kinds of bait boats.
Push-Go Key (shortcut)
Pick Up Waypoint form Map
KML Import to Dene Lake Boundary
Two Propellers Boat Support
Propeller & Rudder Boat Support
Steering Sensitivity Adjustable
Built-in Lithium battery Charger
Hardware Gain Adjustable
Color Route to Indicate Depth (2D Map)
Advanced radio system (FHSS/DSSS)
What’s the advantage of TF740?
The TF740 was specially designed for bait boats. It was combined with wireless
Sonar, High Position accuracy GPS and Autopilot.
The advanced sonar features show you actual bottom condition and ish. The
autopilot function can automatically guide the boat to saved waypoint precisely,
which make it possible to use the boat under bad condition, such as night, heavy
fog, etc.
6
Check the content
3
1
2
15
15
14
14
45
12
12
13
13
11
11
10
10
6
7
89
1.Display
2. SonarBox-740w
3. Autopilot CCU740
4. XGPS 740
5. Transducer
6.Rubber for transducer
7. SonarBox extending cable
8. Power cable
9. Servo cable
10. Antenna for boat
11.Antenna for display
12. Bracket of GPS receiver
13. Screws (4pcs)
14. Valco
15. Antenna extending cable
7
Transducer Installation
1) for XBOAT730
Installation
Transducer
Mounting Instruction
Transducer Knob
Rubber
Screw down the 2 screws to
loose the battery support
1
take the knob and fake
transducer down
3
screw tight the knob
5installation was nished
6
hold the transducer(with
rubber) through the boat
4
loose the knob of xed fake
transducer by hand
2
8
2) for general bait boats ( like Carp Madness, Viper, etc)
For these bait boats, there is no transducer groove on the bottom housing. So, you
need to drill a hole on the boat bottom to x the transducer.
3) for bait boats of Carplounge/Waverunner/Vegaboat/Carp, etc
For these bait boats, there is a transducer groove on the boat bottom. So, you only need
to simply match the transducer to the boat with a rubber.
Transducer
Knob
Rubber
Transducer
Mounting Instruction
1) Choose a proper position
2) Drille a hole (14mm) on the
selected position.
3) Assemble the transducer
and rubber.
4) Hold the assembled
transduer and rubber through
the housing. Then use the knob
to screw tighten the transducer
from the inner housing.
5) The nished installation.
1
2
3 4 5
keep the sharp end the same
direction with head of
boat
9
4) for Anatec catamaran bait boat
For the boat, you only need simply match the transducer to the boat with the rubber
Transducer
Mounting Instruction
1) Take o the transducer
cover from the boat.
2) Assemble the transducer
and rubber.
3) Hold the assembled
transduer through the groove.
4) Use the knob to screw
tighten the transducer from
the inner housing.
5) The nished installation
1
2
3 4 5
keep the sharp end the same
direction with head of
boat
Transducer
Knob
Rubber
