Toro 137-9769 Manual de usuario

FormNo.3422-358RevB

TrimmerMountKit

ZMaster®3000,5000,or6000SeriesRidingMower

ModelNo.137-9769

InstallationInstructions

Safety

SafetyandInstructional

Decals

Safetydecalsandinstructionsare

easilyvisibletotheoperatorandare

locatednearanyareaofpotential

danger.Replaceanydecalthatis

damagedormissing.

decal117-0346

117-0346

1.Fuel-leakhazard—readtheOperator'sManual;donot

attempttoremovetherollbar;donotweld,drill,ormodify

therollbarinanyway.

8111LyndaleAvenueSouth

Bloomington,MN55420

Registeratwww.Toro.com.OriginalInstructions(EN)

PrintedintheUSA

AllRightsReserved*3422-358*B

Installation

PreparingtheMachine

NoPartsRequired

Procedure

1.Parkthemachineonalevelsurface.

2.Movethemotion-controlleverstotheNEUTRAL-LOCKposition.

3.Engagetheparkingbrake.

4.Shutofftheengineandremovethekey.

g037289

Figure1

AssemblingtheUpper

TrimmerMountAssembly

Partsneededforthisprocedure:

1Uppertrimmermountbracket

1Largestclamp

1Largebackerplate

2Carriagebolt(1/4x1-1/2inches)

2Flangenut(1/4inch)

Procedure

Assembletheuppertrimmermountassembly(Figure

2).

g249810

Figure2

1.Flangenut(1/4inch)4.Uppertrimmermount

bracket

2.Largebackerplate5.Carriagebolt(1/4x1-1/2

inches)

3.Largestclamp

InstallingtheSupport

Bracket

Partsneededforthisprocedure:

1Supportbracket

2Tubespacer

2Carriagebolt(3/8x3inches)

2Flangenut(3/8inch)

Procedure

1.Lowertherollbar.

2.Installthesupportbrackettotherightpostofthe

rollbarusing2tubespacers,2carriagebolts

(3/8x3inches),and2angenuts(3/8inch)as

showninFigure3.

3.Raisetherollbar.

g248751

Figure3

1.Supportbracket3.Tubespacer

2.Flangenut(3/8inch)4.Carriagebolt(3/8x3

inches)

ApplyingtheDecal

Partsneededforthisprocedure:

1Decal117-0346

Procedure

Ifdecal117-0346isappliedtotherightpostofthe

rollbaronyourmachineandthesupportbracketnow

coversthatdecal,applythenewdecaltotheinner,

lowersideoftherightpostoftherollbar(Figure4).

Note:Ifdecal117-0346isnotappliedtotheright

postoftherollbaronyourmachine,discardthedecal.

g249924

Figure4

1.Applythenewdecalhere.2.Existing,covereddecal

SecuringtheUpper

TrimmerMountAssembly

totheSupportBracket

Partsneededforthisprocedure:

2Carriagebolt(5/16x7/8inch)

2Flangenut(5/16inch)

Procedure

Securetheuppertrimmermountassemblytothe

supportbracketusing2carriagebolts(5/16x7/8inch)

and2angenuts(5/16inch)asshowninFigure5.

Note:Multiplemountingholelocationsareprovided

toadjustthemountingpositionofthetrimmerfor

clearance.

g249811

Figure5

1.Uppertrimmermount

assembly

3.Carriagebolt(5/16x7/8

inch)

2.Supportbracket4.Flangenut(5/16inch)

InstallingtheLower

TrimmerMountAssembly

Partsneededforthisprocedure:

1Lowertrimmermountassembly

2Carriagebolt(3/8x1inch)

2Flangenut(3/8inch)

Procedure

Installthelowertrimmermountassemblytothe

tie-downhookmountinglocationonthefront,right

sideoftheframeusing2carriagebolts(3/8x1inch)

and2angenuts(3/8inch)asshowninFigure6.

g249903

Figure6

1.Flangenut(3/8inch)3.Lowertrimmermount

assembly

2.Carriagebolt(3/8x1inch)

AssemblingtheTrimmer

MountBracket

Partsneededforthisprocedure:

1Trimmermountbracket

1Fist-mountplate

1Smallstclamp

1Smallbackerplate

4Flangenut(1/4inch)

2Carriagebolt(1/4x3/4inch)

2Carriagebolt(1/4x1-1/4inches)

Procedure

Assemblethetrimmermountbracket(Figure7).

g248809

Figure7

1.Flangenut(1/4inch)5.Carriagebolt(1/4x1-1/4

inches)

2.Smallbackerplate6.Trimmermountbracket

3.Smallstclamp7.Carriagebolt(1/4x3/4

inch)

4.Fist-mountplate

SecuringtheTrimmer

MountBrackettotheLower

TrimmerMountAssembly

Partsneededforthisprocedure:

2Carriagebolt(1/4x3/4inch)

2Flangenut(1/4inch)

Procedure

1.Fullylowerthemowerdeck.

2.Securethetrimmermountbracketassembly

tothelowertrimmermountassemblyusing2

carriagebolts(1/4x3/4inch)and2angenuts

(1/4inch)asshowninFigure8.

Note:Multiplemountingholelocationsare

providedtoadjustthemountingpositionofthe

trimmerforclearance.

g248811

Figure8

1.Trimmermountbracket3.Lowertrimmermount

assembly

2.Carriagebolt(1/4x3/4

inch)

4.Flangenut(1/4inch)

SecuringaTrimmertothe

MountAssemblies

NoPartsRequired

Procedure

Insertthehandleendofthetrimmerintothelargest

clampandthetrimmingendintothesmallstclamp.

Checkthetofthetrimmerforinterference,and

adjustthemountingholelocationsasrequiredfor

clearancetothemachine.

Notes:
