Toro Pro Force Groundsmaster 3280-D Manual de usuario

FormNo.3434-904RevA

ProForce®DebrisBlowerMountingKit

Groundsmaster®3280-DTractionUnit

ModelNo.30493

InstallationInstructions

Installation

LooseParts

Usethechartbelowtoverifythatallpartshavebeenshipped.

ProcedureDescriptionQty.Use

1Nopartsrequired–Removethecuttingunitfromthelift

arms.

Bolt(3/8–16x1–3/4inches)2

Locknut(3/8–16inch)2

CVdriveshaft1

2Rollpin(3/16x2–1/4inches)1

ReplacetheCVshaft.

Bolt(1/2–13x3/4inches)2

Lockwasher(1/2inch)2

Flatwasher(9/16x1–3/8inches)2

Hairpincotter2

Clevispin(5/16x1–22/25inches)2

Supportrod2

Bolt(1/2–13x1inch)2

Clevispin2

Bolt(3/8–16x1–3/4inches)2

Locknut(3/8–16inch)2

Rollpin(3/16x2–1/4inches)1

Attachmentframe1

Mounttheattachmentframetothelift

arms.

Drive-shaftassembly1

Rollpin1

Bolt(5/16x1-3/4inches)2

4Locknut(5/16inch)2

Installthedriveshafttotheblower

gearboxshaft.

Mountingplate1

Bolt(1/2x1-1/4inches)4

5Locknut(1/2inch)4

Installthemountingplatetothedebris

blowerframe.

Debris-blowerassembly1

Lockingpin1

6Hairpincotter1

Mounttheblowertothetractionunit.

Consolewiringharness1

Blowerwiringharness1

Cabletie10

Switch1

Fuse1

Fuseblock1

Routethewireharness.

8111LyndaleAvenueSouth

Bloomington,MN55420

Registeratwww.T oro.com.OriginalInstructions(EN)

PrintedintheUSA

AllRightsReserved*3434-904*A

Important:Ensurethatthetractionunithas5

weights(partnumber24-5790-01)installedbefore

installingthemountingkit.

Note:Iftheunitdoesnothaveliftarms,installthe

followingbeforeproceeding:

•117–0806LeftLiftArmAssembly

•117–0800RightLiftArmAssembly

Thiskitincludestherequiredpinsformountingthe

armstotheGroundsmaster3280-D.

•2ofpart98-2330

•2ofpart3272-24

RemovingtheCuttingUnit

fromtheLiftArms

NoPartsRequired

Procedure

1.Positionthemachineonlevelsurface,lowerthe

cuttingunittotheoor,movetheliftlevertothe

FLOATposition,shuttheengineoff,andengage

theparkingbrake.

2.Removetheboltandwashermountedtothetop

ofeachheight-of-cutrod(Figure1).

g029538

Figure1

1.Liftarm7.Hairpincotter

2.Castor-armbracket8.Height-of-cutcollar

3.Height-of-cutrod9.Clevispin

4.Lift-armpads10.Hairpincotter

5.Thrustwashers11.Bolt

6.Clevispin

3.Removethehairpinandclevispinsecuringthe

height-of-cutcollartotheheight-of-cutrodon

therearofthecuttingunit(Figure1).

4.Removetheheight-of-cutcollar.

Note:Youwillusethesecomponentstoinstall

theattachmentframe.

5.Removethehairpincottersandclevispins

securingtheliftarmstothecastorarmbrackets

(Figure1).

Note:Youwillusethesecomponentstoinstall

theattachmentframe.

6.Rollthecuttingunitawayfromthetractionunit,

separatingthemaleandfemalesectionsofthe

PTOshaft.

DANGER

DonotstarttheengineandengagethePTO

leverwhenthePTOshaftisnotconnectedto

thegearboxontheattachment.

IftheenginestartsandthePTOshaftrotates,

seriousinjurycouldresult.

ReplacingtheCVShaft

Partsneededforthisprocedure:

2Bolt(3/8–16x1–3/4inches)

2Locknut(3/8–16inch)

1CVdriveshaft

1Rollpin(3/16x2–1/4inches)

Procedure

1.Removetheexistingdriveshaftfromthe

machine.

2.PlacethenewCVdriveshaftinthelocationof

theoldoneandsecureitwith2bolts(3/8–16x

1–3/4inches),2locknuts(3/8–16inch),anda

rollpin(3/16x2–1/4inches).

g029541

Figure2

1.Existingdriveshaft4.Bolt(3/8–16x1–3/4

inches)

2.CVdriveshaft5.Rollpin(3/16x2–1/4

inches)

3.Locknut(3/8–16inch)

3.Torquetheboltsandlocknutsto51to65N⋅m

(38to48ft-lb).

4.GreasetheCVshaftatallrecommendedgrease

points;refertoyourattachmentOperator’s

Manual.

MountingtheAttachment

FrametotheLiftArms

Partsneededforthisprocedure:

2Bolt(1/2–13x3/4inches)

2Lockwasher(1/2inch)

2Flatwasher(9/16x1–3/8inches)

2Hairpincotter

2Clevispin(5/16x1–22/25inches)

2Supportrod

2Bolt(1/2–13x1inch)

2Clevispin

2Bolt(3/8–16x1–3/4inches)

2Locknut(3/8–16inch)

1Rollpin(3/16x2–1/4inches)

1Attachmentframe

Procedure

1.Insertasupportrodintoeachendoftherear

tubeontheattachmentframe(Figure3).

Note:Makesurethethroughholeispositioned

atthetop.

2.Looselyattachthebottomofeachsupportrod

totheattachment-frametubewithabolt(1/2–13

x1inch),alockwasher(1/2inch),andaat

washer(9/16x1–3/8inches)asshowninFigure

3.Positiontheattachmentframeunderthelift

arms.

4.MovetheliftlevertotheFLOATposition.Pusha

liftarmdownuntiltheholesintheliftarmlineup

withtheholesintheattachment-framebrackets

andthesupportrodscanbeinsertedintothe

liftarmpads(Figure3).

5.Securetheliftarmtotheattachmentframe

bracketswithaclevispin(Figure3).

6.Inserttheendofthehairpincotterintotheslot

intheattachmentframebrackettabtoretainthe

clevispin(Figure3).

g029543

Figure3

Rightliftarmshown

1.Bolt(1/2–13x3/4inches)7.Bolt(1/2–13x1inch)

2.Lockwasher(1/2inch)8.Clevispin

3.Flatwasher(9/16x1–3/8

inches)

9.Hairpincotter

4.Height-of-cutcollar10.Liftarm

5.Clevispin(5/16x1–22/25

inches)

11.Attachmentframe

6.Supportrod

7.Repeattheprocedureontheoppositeliftarm.

8.Startthetractionunitandraisetheattachment

frame.

9.Pushdownontherearoftheattachmentframe

andinsertthesupportrodsthroughthelift-arm

pads.

10.Installtheheight-of-cutcollarsontothesupport

rodsandsecurethemwiththeclevispinsand

hairpincotters(Figure3).

Note:Positiontheheadofclevispintowardthe

frontoftheattachmentframe.

11.Torquetheboltssecuringthesupportrodstothe

bottomoftheattachment-frametubeto75N⋅m

(102ft-lb)asshowninFigure3.

12.Installabolt(1/2–13x3/4inches),alockwasher

(1/2inch),andaatwasher(9/16x1–3/8

inches)tothetopofeachsupportrod(Figure3).

13.Turnoffthetractionunit.

14.AttachtheCVshafttotheshaftandsecure

itwitharollpin(3/16x2–1/4inches),2bolts

(3/8–16x1–3/4inches),and2locknuts(3/8–16

inch).

15.Torquetheboltsandlocknutsto37to44N⋅m

(27to33ft-lb).

InstallingtheDriveShaftto

theBlowerGearboxShaft

Partsneededforthisprocedure:

1Drive-shaftassembly

1Rollpin

2Bolt(5/16x1-3/4inches)

2Locknut(5/16inch)

Procedure

1.Removethecabletiesecuringthedriveshaft

totheshippingcrate.

2.Slidethedriveshaftontothegearboxshaft.

g023911

Figure4

1.Rollpin(3/16x1–1/2

inches)

4.Bolts(5/16x1–3/4inches)

2.Safetychain5.Locknuts(5/16inch)

3.Driveshaft6.Gearboxshaft

3.Alignthemountingholesinthegearboxshaft

withtheholesinthedriveshaftandslidethem

together.

4.Securethemwitharollpin(Figure4).

5.Securethedriveshafttothegearboxshaftwith

2bolts(5/16x1–3/4inches),2locknuts(5/16

inch),andarollpin(3/16x1–1/2inches)as

showninFigure4.

6.Torquetheboltsandlocknutsto18to25N⋅m

(175to225in-lb).

7.Removethecabletiethatholdsthedriveshaft

together.

8.Securethesafetychaintotheblowerframe

(Figure4).

InstallingtheMounting

PlatetotheDebrisBlower

Frame

Partsneededforthisprocedure:

1Mountingplate

4Bolt(1/2x1-1/4inches)

4Locknut(1/2inch)

Procedure

1.Removetheboltssecuringthemountingplate

tothecrate(Figure5).

g021682

Figure5

1.Mountingplate

2.Installthemountingplatetothedebrisblower

framewith4bolts(1/2x1-1/4inch)and4

locknuts(1/2inch)asshowninFigure6.

Note:Usethelowersetofholesoneachside

ofthemountingplatewheninstallingtheplate.

3.Torquetheboltsto92to113N⋅m(68to82ft-lb).

g021677

Figure6

1.Mountingplate3.Locknut(4)

2.Bolt(4)

MountingtheDebrisBlower

totheTractionUnit

Partsneededforthisprocedure:

1Debris-blowerassembly

1Lockingpin

1Hairpincotter

Procedure

1.Removeanyattachmentfromthefrontofthe

machine.

2.Movethetractionunitintopositionbehindthe

attachmentadapter.

3.Raisethetractionunitadapterintothe

attachmentadapter.

Note:Ifthejackstandisraisedslightlyhigher

thanthecastors,theadapteriseasiertoinstall.

4.Insertthelockingpinthroughtheadaptersand

secureitwithahairpincotter(Figure7).

g023910

Figure7

1.Lockingpin2.Hairpincotter

5.Installthedriveshafttothequick-attachframe

byslidingthequickcouplerontotheshaft

(Figure8).

g021678

Figure8

1.Driveshaft2.Quick-attach-frameshaft

6.Securethesafetychaintothequick-attach

frame(Figure8).

RoutingtheWiringHarness

Partsneededforthisprocedure:

1Consolewiringharness

1Blowerwiringharness

10Cabletie

1Switch

1Fuse

1Fuseblock

Procedure

1.Routetheconsole-wiringharnessalongthelift

frameandthroughthemachine.

2.Plugtheconnectorintothefuseblock(Figure9).

g029724

Figure9

1.Fuse5.Ground

2.Fuseblock6.Tofuseblock

3.Switch7.Toattachment

4.Switchconnector

3.Plugthefuseintothefuseblock(Figure9).

Note:Iftherearenoopenslotsintheexisting

fuseblock,usetheadditionalfuseblock

providedinthekit.

4.Connecttheground-ringterminaltotheground

block(Figure9).

5.Removetheknockoutplugfromthecontrol

panel,placetheswitchinthehole,andconnect

theconsole-wiringharnesstotheswitch(Figure

10).

g029725

Figure10

1.PTOswitch—bloweron/off3.Switch

2.Knockoutplug

6.Usecabletiestosecuretheconsole-wiring

harnesstothemachineandtheliftarm(Figure

11).

g029763

Figure11

1.Console-wiringharness3.Blower-wiringharness

2.Harnessconnectors

7.Plugtheblower-wiringharnessintothechute

motor,thenconnectittotheconsole-wiring

harness(Figure11).

8.Securetheblower-wiringharnesstothe

attachmentframeusingcableties.

ProductOverview

Controls

g029764

Figure12

1.PTOswitch—bloweron/off2.Right/leftblower-chute

control

Tabla de contenidos

Otros manuales de Accesorios para cortadoras de césped de Toro

Toro

Toro 04480 Manual de usuario

Toro

Toro 23508 Manual de instalación y funcionamiento

Toro

Toro 04295 Manual de usuario

Toro

Toro Groundsmaster 4500-D Manual

Toro

Toro RECYCLER 59291 Manual de usuario

Toro

Toro 78496 Manual de usuario

Toro

Toro 07921 Manual de usuario

Toro

Toro 126-8379 Manual de usuario

Toro

Toro 140-5605 Manual de usuario

Toro

Toro 78537 Manual de usuario

Toro

Toro Grandstand 139-1529 Manual de usuario

Toro

Toro 140-4310 Manual de usuario

Toro

Toro Sand Pro 3040 Manual de usuario

Toro

Toro Wheel Horse 78361 Manual de usuario

Toro

Toro Z-Master Manual de usuario

Toro

Toro Reelmaster 5010- H Manual de usuario

Toro

Toro Groundsmaster 4500-D Manual de usuario

Toro

Toro Super Recycler 115-8416 Manual de usuario

Toro

Toro 137-5001 Manual de usuario

Toro

Toro 132-6960 Manual de usuario

Toro

Toro 108-2639 Manual de usuario

Toro

Toro 110-2025 Manual de usuario

Toro

Toro 78534 Manual de usuario

Toro

Toro E-Z Vac 79346 Manual de usuario

Manuales populares de Accesorios para cortadoras de césped de otras marcas

Ariens

Ariens 891008 Manual de usuario

Rover

Rover 108 - 109 Manual de usuario

Snapper

Snapper 1690047 Manual de usuario

Scag Power Equipment

Scag Power Equipment GC-F4 Manual de usuario

RHINO

RHINO 800 Manual de usuario

Exmark

Exmark Quest 126-7506 Manual de usuario

Snapper

Snapper 1685167 Manual de usuario

Cub Cadet

Cub Cadet 19B70029100 Manual de usuario

Stihl

Stihl AMK 043.1 Manual de usuario

MTD

MTD 753-0873 Manual

Bush Hog

Bush Hog RG60 Manual de usuario

Land Pride

Land Pride RCF2760 Manual de usuario

Simplicity

Simplicity 211 Manual de usuario

Exmark

Exmark ULTRAVAC QUICK DUMP SYSTEM Manual de usuario

Excel

Excel Two Bag Catcher Manual de usuario

Textron

Textron Jacobsen Pro12 DFS Manual de usuario

Ryobi

Ryobi AC018130 Manual de usuario

Snapper

Snapper 4544 Guía de configuración
