Toro 04295 Manual de usuario

FormNo.3401-934RevA

LEDLightandWirelessHourMeterHarnessKit

2012andAfterGreensmaster®800,1000,1600,Flex™1800,or

2100SeriesMower

ModelNo.04295

InstallationInstructions

ContactyourAuthorizedToroDistributorformoreinformation.

ThisproductcomplieswithallrelevantEuropeandirectives;fordetails,pleaseseetheseparateproductspecicDeclarationof

Conformity(DOC)sheet.

WARNING

CALIFORNIA

Proposition65Warning

ThisproductcontainsachemicalorchemicalsknowntotheStateofCaliforniato

causecancer,birthdefects,orreproductiveharm.

LooseParts

Usethechartbelowtoverifythatallpartshavebeenshipped.

ProcedureDescriptionQty.Use

1Nopartsrequired–Preparethemachine.

2Nopartsrequired–Removethecontrol-panelcover(1800

or2100seriesmachines).

Flangeheadscrew2

Voltageregulator1

Mountingbracket1

3Wireharness1

Assemblethevoltageregulator.

4Cabletie2Routethewireharness.

5Rockerswitch1Connectthewireharness.

6Nopartsrequired–FinishtheLEDlightandwirelesshour

meterharnesskitinstallation.

7Nopartsrequired–InstallthewireharnesstotheLEDlight

kitand/orwirelesshourmeterkit.

8111LyndaleAvenueSouth

Bloomington,MN55420

Registeratwww.Toro.com.OriginalInstructions(EN)

PrintedintheUSA

AllRightsReserved*3401-934*A

PreparingtheMachine

NoPartsRequired

Preparingan800,1000,or1600Series

Machine

1.Ensurethereel-driveleverisintheREEL-DRIVEOFF

position;refertotheOperator’sManual.

2.Movethemachinetoalevelsurfaceandsetthe

traction-drivelevertotheTRACTION-DRIVENEUTRAL

position;refertotheOperator’sManual

3.SetthethrottlecontroltotheSLOWpositionandset

theOn-OffswitchtotheOFFposition;refertothe

Operator’sManual.

4.Settheparkingbrake;refertotheOperator’sManual.

5.Disconnectthespark-plugwirefromtheterminalof

thesparkplug(Figure1).

Figure1

1.Spark-plugwire

Preparingan1800or2100Series

Machine

1.Ensurethetractionandreeldriveengagementleveris

intheREEL-DRIVEOFFposition;refertotheOperator’s

Manual.

2.Movethemachinetoalevelsurfaceandsetthe

tractionandreeldriveengagementlevertothe

TRACTION-DRIVENEUTRALposition;refertothe

Operator’sManual.

3.SetthethrottlecontroltotheSLOWpositionandset

theOn-OffswitchtotheOFFposition;refertothe

Operator’sManual.

4.Settheparkingbrake;refertotheOperator’sManual.

5.Disconnectthespark-plugwirefromtheterminalof

thesparkplug(Figure2).

Figure2

1.Spark-plugwire

RemovingtheControl-Panel

Cover(1800or2100Series

Machines)

NoPartsRequired

Procedure

1.Removethe4ange-headscrews(1/4x1/2inch)that

securethecontrol-panelcovertothesupportbracket

ofthehandlebar(Figure3).

Figure3

1.Control-panelcover3.Supportbracket(handle

bar)

2.Flange-headscrew(1/4x

1/2inch)

2.Movethecontrol-panelcoverupandforwardfromthe

controlpanel,andremovethecoverfromthemachine

(Figure3).

Note:Retaintheange-headscrewsandcontrol-panel

coverforassemblyin6FinishingtheLEDLightand

WirelessHourMeterHarnessKitInstallation(page

10).

AssemblingtheVoltage

Regulator

Partsneededforthisprocedure:

2Flangeheadscrew

1Voltageregulator

1Mountingbracket

1Wireharness

AssemblingtheVoltageRegulator,

MountingBracket,andWireHarness

1.Alignthegroundterminalandtheslotsinthevoltage

regulatortotheholesinthemountingbracket(Figure

4).

Figure4

1.Flangeheadscrew3.Voltageregulator

2.Groundterminal4.Mountingbracket

2.Assembletheterminalandregulatortothebracket

with2angeheadscrews(Figure4).

3.Torquetheangeheadscrewsto283to395N∙cm(25

to35in-lb).

4.Connectthe3-pinconnectorofthewireharnesswith

the3-socketconnectorofthevoltageregulator(Figure

5).

Note:Ensurethattheconnectorsarefullyseatedand

thelatchoftheconnectorssnaptogethersecurely.

Figure5

1.3-pinconnector(wire

harness)

2.3-socketconnector

(voltageregulator)

AssemblingtheVoltageRegulatorand

MountingBrackettotheMachine

1.Preparethemachineforinstallationofthevoltage

regulatorandmountingbracketbyperformingthe

following:

•800,1000,or1600seriesmachine

A.Atthebackoftheengine,removethecabletie

thatsecuresthewireharnessfortheinterlock

moduletothewire-harnessbracket(Aof

Figure7).

Figure6

Figure7

1.Cabletie(r-treeanchor)4.Stud(fueltank)

2.Wire-harnessbracket5.Flange-headbolt(10-24x

3/8inch)

3.Nut6.Interlockmodule

B.Removethe2nutsthatsecurethewire-harness

brackettotheengine(AofFigure7)

C.Removetheange-headbolt10-24x3/8

inchthatsecurestheinterlockmoduletothe

wire-harnessbracket(Figure7).

Note:Younolongerneedthewire-harness

bracket.

•1800or2100seriesmachine—Atthebackofthe

engine,removethe2nutsthatsecurethetankto

theengine(Figure9).

Figure8

1.Fueltank3.Stud(fueltank)

2.Nut

2.Alignthegroundterminalofthewireharnesswiththe

leftholeshortangeofthemountingbracketforthe

voltageregulatorasshowninFigure9.

Figure9

1.Groundterminal(wire

harness)

3.Nut

2.Stud(fueltank)4.Mountingbracket(voltage

regulator)

3.Aligntheholesintheshortangeofthemounting

bracketforthevoltageregulatorwiththerearstuds

ofthefueltank(Figure9).

4.Assemblethemountingbracketandgroundterminal

totheenginewiththe2nutsthatyouremovedinstep

1(Figure9).

5.Torquethenutsto9.7to12.0N∙m(86to106in-lb).

RoutingtheWireHarness

Partsneededforthisprocedure:

2Cabletie

Procedure

1.Routethewireharnessfromthemountingbracketto

thelefthandlebar(Figure10andFigure11).

Figure10

800,1000,or1600SeriesMachine

1.Console3.Cableties

2.Wireharness4.Lefthandlebartube

Figure11

1800or2100SeriesMachines

1.Lefthandlebar3.Wireharness

2.Supportbracket(handle

bar)

4.Cableties

2.Routethewireharnessalongthelefthandlebarand

acrossthesupportbracketofthehandlebars(Figure

11).

3.Securethewireharnesswith2cabletiesasshownin

Figure10andFigure11.

ConnectingtheWireHarness

Partsneededforthisprocedure:

1Rockerswitch

ConnectingtheWireHarnesstothe

Engine

1.Locatetheengine-alternatorharnessattherearsideof

theenginecase(Figure12).

Note:Theengine-alternatorharnesshas2wireswith

singlesocketconnectors.

Figure12

1.Bulletconnectors(wire

harness)

2.Socketconnectors

(engine-alternator

harness)

2.Connectthe2bulletconnectorsofthewireharness

tothe2socketconnectorsoftheengine-alternator

harness(Figure12).

IdentifyingtheElectricalConnectors

•Usethe3-socketconnectorwheninstallingtheoptional

Wireless-HourMeterKit(Figure13andFigure14).

•Usethe2-socketconnectorlightharnessinterconnect

wheninstallingtheoptionalLEDLightKit(Figure13

andFigure14)

Figure13

800,1000,or1600SeriesMachine

1.2-socketconnector

(LED-lightharness

interconnect—usewith

theoptionalLEDLightKit)

3.10-socketconnector(light

switch)

2.3-socketconnector(hour

meter—usewiththe

optionalWirelessHour

MeterKit)

Figure14

1800or2100SeriesMachines

1.10-socketconnector(light

switch)

3.2-socketconnector

(LED-lightharness

interconnect—usewith

theoptionalLEDLightKit)

2.3-socketconnector(hour

meter—usewiththe

optionalWirelessHour

MeterKit)

InstallingtheLightSwitch(800,1000,

1600SeriesMachines)

1.Removetheknock-outplugatthetopleftareaforthe

console(AFigure15).

Figure15

1.Knock-outplug(console)3.10-socketconnector(wire

harness—LightKitand

HourMeterWireHarness

Kit)

2.2-positionrockerswitch

2.Pullupthe10-socketconnectorofthewireharness

fromthelightkitandhourmeterwireharnesskit

throughtheopeninginthecontrolpanel(Figure15).

3.Connectthe10-pinconnectorofthe2-positionrocker

switchintothe10-socketconnectorofthelightkitand

hourmeterkit(Figure15).

Note:Ensurethattheconnectorsarefullyseatedand

thelatchoftheconnectorssnaptogethersecurely.

4.Aligntheswitchsothatthenotchinthebodyofthe

switchistowardtheleftsideofthecontrolpanel

(Figure16).

Figure16

1.Opening(controlpanel)3.Notch(body—rocker

switch)

2.2-positionrockerswitch4.Leftsideofthecontrol

panel

5.Inserttheswitchintotheopeninginthecontrolpanel

untiltheswitchsnapssecurelyintothepanel(Figure

16).

InstallingtheLightSwitch(1800or

2100SeriesMachines)

1.Removetheplugfromtheopeningattheleftfaceof

thecontrolpanel(Figure17).

Figure17

1.Plug3.2-positionrockerswitch

2.Opening(controlpanel)4.10-socketconnector(wire

harness—LightKitand

HourMeterWireHarness

Kit)

2.Pullupthe10-socketconnectorofthewireharness

fromthelightkitandhourmeterwireharnesskit

throughtheopeninginthecontrolpanel(Figure17).

3.Connectthe10-pinconnectorofthe2-positionrocker

switchintothe10-socketconnectorofthelightkitand

hourmeterkit(Figure17).

Note:Ensurethattheconnectorsarefullyseatedand

thelatchoftheconnectorssnaptogethersecurely.

4.Aligntheswitchsothatthenotchinthebodyofthe

switchistowardthefrontofthecontrolpanel(Figure

18).

Figure18

1.Opening(controlpanel)3.Notch(body—rocker

switch)

2.2-positionrockerswitch4.Frontofthecontrolpanel

5.Inserttheswitchintotheopeninginthecontrolpanel

untiltheswitchsnapssecurelyintothepanel(Figure

18).

FinishingtheLEDLightand

WirelessHourMeterHarness

KitInstallation

NoPartsRequired

InstallingtheControl-PanelCover

(1800or2100SeriesMachines)

1.Alignthekey-holeslotinthecontrol-panelcoverover

thetractionandreeldriveengagementlever(Figure19).

Figure19

1.Tractionandreeldrive

engagementlever

3.Flange-headscrews(1/4

x1/2inch)

2.Key-holeslot

(control-panelcover)

4.Supportbracket(handle

bar)

2.Aligntheholesinthesideofthecontrol-panelcover

withtheholesinthesupportbracketforthehandle

bars(Figure19).

3.Installthecontrol-panelcovertothesupportbracket

withthe4ange-headscrews(1/4x1/2inch)thatyou

removedinstep1of2RemovingtheControl-Panel

Cover(1800or2100SeriesMachines)(page3).

4.Torquetheange-headscrewsto5.2to6.8N∙m(46

to60in-lb).

ConnectingtheSpark-PlugWire

Connectthespark-plugwiretotheterminalofthesparkplug

asshowninFigure2of1PreparingtheMachine(page2).

InstallingtheWireHarness

totheLEDLightKitand/or

WirelessHourMeterKit

NoPartsRequired

Procedure

•RefertotheinstallationinstructionsinyourLEDLight

KittoinstallthewireharnessfortheLEDlighttothe

wireharnessoftheLEDLightandWirelessHourMeter

HarnessKit.

•RefertotheinstallationinstructionsinthemyTurf™

WirelessHourmeterSystemreferenceguidetoinstallthe

hourmetertothewireharness.

Otros manuales de Accesorios para cortadoras de césped de Toro

Toro

Toro Greensmaster 3320 TriFlex Manual de usuario

Toro

Toro 03217 Manual de usuario

Toro

Toro 140-3508 Manual de usuario

Toro

Toro 132-6114 Manual de usuario

Toro

Toro Z Master Commercial 2000 Series Manual de usuario

Toro

Toro 03484 Manual de usuario

Toro

Toro 132-6960 Manual de usuario

Toro

Toro 78496 Manual de usuario

Toro

Toro 111-8010 Manual de usuario

Toro

Toro 04553 Manual de usuario

Toro

Toro 31101 Groundsmaster 360 Manual de usuario

Toro

Toro 125-5180 Manual de usuario

Toro

Toro 117-3600 Manual de usuario

Toro

Toro 134-5389 Manual de usuario

Toro

Toro Z Master 500 Series Manual de usuario

Toro

Toro 120-3290 Manual de usuario

Toro

Toro 144-1848 Manual de usuario

Toro

Toro 78514 Manual de usuario

Toro

Toro Groundsmaster 4700-D Manual de usuario

Toro

Toro Recycler 126-8701 Manual de usuario

Toro

Toro Reelmaster 5010- H Manual de usuario

Toro

Toro 04480 Manual de usuario

Toro

Toro 140-9347 Manual de usuario

Toro

Toro 03638 Manual de usuario

Manuales populares de Accesorios para cortadoras de césped de otras marcas

Ariens

Ariens 891008 Manual de usuario

Rover

Rover 108 - 109 Manual de usuario

Snapper

Snapper 1690047 Manual de usuario

Scag Power Equipment

Scag Power Equipment GC-F4 Manual de usuario

RHINO

RHINO 800 Manual de usuario

Exmark

Exmark Quest 126-7506 Manual de usuario

Snapper

Snapper 1685167 Manual de usuario

Cub Cadet

Cub Cadet 19B70029100 Manual de usuario

Stihl

Stihl AMK 043.1 Manual de usuario

MTD

MTD 753-0873 Manual

Bush Hog

Bush Hog RG60 Manual de usuario

Land Pride

Land Pride RCF2760 Manual de usuario

Simplicity

Simplicity 211 Manual de usuario

Exmark

Exmark ULTRAVAC QUICK DUMP SYSTEM Manual de usuario

Excel

Excel Two Bag Catcher Manual de usuario

Textron

Textron Jacobsen Pro12 DFS Manual de usuario

Ryobi

Ryobi AC018130 Manual de usuario

Snapper

Snapper 4544 Guía de configuración
