FormNo.3404-625RevA

10GallonFuelTankKit

ProForce®DebrisBlower

ModelNo.130-4371

InstallationInstructions

WARNING

CALIFORNIA

Proposition65Warning

ThisproductcontainsachemicalorchemicalsknowntotheStateofCaliforniato

causecancer,birthdefects,orreproductiveharm.

RemovingtheFuelTank

NoPartsRequired

Procedure

1.Parkthemachineonalevelsurface,shutofftheengine,

chockthewheels,disconnectthebattery,andremove

thekeyfromtheignitionswitch.

2.Allowtheenginetocool,thendrainthefueltank.

Note:Disposeoffuelproperly.Recycleaccording

tolocalcodes.

3.Restarttheengineandrunituntilitstops.

4.Choketheengine.Startandruntheengineuntilitwill

notstart.

5.Disconnectthefueltankhosesfromthemachineand

discardthem(Figure1).

Note:Retainthehoseclamps.

6.Removethefastenersandstrapssecuringthefueltank

tothemachineanddiscardthemalongwiththetank

(Figure1).

7.Disconnecttheremaininghosesfromthecarbon

canister(Figure1).

Note:Retainthehoseclamps.

8.Removethebatterycoverandbattery(Figure1);refer

toyourOperator’sManual.

9.Removethecarboncanisteranddiscardit(Figure1).

Figure1

1.Batterycover3.Fuel-tankhoses

2.Carboncanister4.Fueltank

8111LyndaleAvenueSouth

Bloomington,MN55420

Registeratwww.Toro.com.OriginalInstructions(EN)

PrintedintheUSA

AllRightsReserved*3404-625*A

Installingthe10GallonTank

NoPartsRequired

Procedure

1.Drill4holes(3/8inch)intheexistingfueltanktrayas

showninFigure2.

Figure2

1.2.18cm(0.86inch)3.2.03cm(0.80inch)

2.Drillhere.4.2.79cm(1.10inches)

2.Attachthenewfuel-tanktraytotheexistingfuel-tank

trayandsecureitwith4ange-headbolts(5/16inch)

and4angenuts(5/16inch)throughtheholesinthe

tray(Figure3).

Figure3

1.Flangenut(5/16inch)3.Newfuel-tanktray

2.Flange-headbolt(5/16

inch)

3.Attachthecarbon-canisterbrackettotheframeusing2

bolts(1/4inch)and2angenuts(1/4inch)asshown

inFigure4.

Note:Ifthebracketdoesnotperfectlylineupwith

theexistingholes,widenthemslightlyusinga7cm

(0.281inch)drillbit.

Figure4

1.Flangenut(1/4inch)3.Bolt(1/4inch)

2.Carbon-canisterbracket

4.Securethecarboncanistertothecarbon-canister

bracketusingthecanisterstrapand2carriageboltsand

angenuts(3/8inch)asshowninFigure5.

Figure5

1.Carbon-canisterbracket4.Canisterstrap

2.Flangenut(3/8inch)5.Carboncanister

3.Carriagebolt

5.Attachthepadstothefuel-tankstraps(Figure6).

Figure6

1.Newfuel-tankstraps3.Newfueltank

2.Pad4.Flangenut(1/4inch)

6.Securethenewfueltanktothefuel-tanktrayusingthe

strapsand4angenuts(1/4inch)asshowninFigure6.

7.Attachthehoseadapterandshorthosetotheinline

fuellterandsecureittothebottomofthecarbon

canister(Figure7).

Figure7

1.Shorthose3.Inlinefuel-lterhose

2.Hoseadapter

8.Attachthe1.6m(65inch)hosetothefueltankand

fuellterusingthepreviouslyremovedhoseclampsas

showninFigure8.

Note:Ensurethatthehoseisroutedthroughthehole

intheframe.

Figure8

1.Fuellter3.1.5m(61inch)fuelhose

2.Carboncanister4.1.6m(65inch)fuelhose

9.Attachthe1.5m(61inch)hosetothefueltankand

carboncanisterusingthepreviouslyremovedhose

clampsasshowninFigure8.

Note:Shortenthehoseifitistoolongforyour

machine.

10.Attachtheventlinehosetothecarboncanisterusing

thepreviouslyremovedhoseclamp(Figure9).

Figure9

1.Ventlinehose

11.Snapthetieclipontothesideofthefuel-tanktrayand

securethe2fuel-tankhosestoit(Figure10).

Figure10

1.Tieclip

12.Installthepreviouslyremovedbatteryandconnectit

tothemachine;refertoyourOperator’sManual.

13.Installthebatterycover.
