Topfield TF3200IR Manual de usuario

The User’s Manual

Please read this UserÕs Manual carefully.

The menu structure and specification can be changed without notice.

Digital Satellite Receiver

With Irdeto Embedded.

TOPFIELD

TF3200IR

This symbol indicates “dangerous voltage”

inside the product that presents a risk of

electric shock or personal injury.

This symbol indicates

important instructions

accompanying the product.

CAUTION

RISK ELECTRIC SHOCK

Do NOT OPEN

CAUTION: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,

DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE

INTRODUCTION 4

CONTENTS 5

FEATURES 5

FRONT/ REAR PANELS 6

1) FRONT PANEL 6

2) REAR PANEL 6

REMOTE CONTROL UNIT(RCU) 8

GETTING STARTED 12

FUNCTION GUIDE 13

MENU OPERATIONS 16

1) SYSTEM SETTING 17

2) ORGANIZING CHANNEL 27

3) ORGANIZING FAVORITES 29

4) INSTALLATION 30

5) INFORMATION 40

6) Irdeto Access 41

7) GAME 43

TROUBLE SHOOTING(Q & A) 45

SPECIFICATIONS 46

TABLE OF CONTENTS

Please do not insert metal or alien substance into the slots

for the Modules and Cards.

In doing so can cause damage to the STB and reduce its life span.

WARNING

WARNING Warning WARNING Warning WARNING

Please read the following recommended safety precautions carefully for your safety.

MAINS SUPPLY : 90-250V AC 50/60 Hz.

OVERLOADING : Do not overload wall outlets, extension cords or adapters

as these can result in fire or electrical shock.

LIQUIDS : Keep liquids away from the STB.

The apparatus shall not be exposed to dripping or splashing and

that no objects filled with liquids, such as vases, shall be placed

on the apparatus.

SMALL OBJECTS : Coins or other small objects must be kept away from the IRD

as they can fall through the ventilation slots of the IRD and

cause serious damage.

CLEANING : Disconnect the IRD from the wall socket before cleaning it.

Use a dry cloth lightly dampened(no solvents) to clean

the exterior of the IRD.

VENTILATION : Do not block the decoder’s ventilation slots.

Ensure that a free airflow is maintained around the IRD.

NEVER stand the IRD on soft furnishings or carpets.

Do not use or store the IRD where it is exposed to direct

sunlight or near a heater. NEVER stack other electronic

equipment on top of the IRD.

ATTACHMENTS : Do not use any attachments that are not recommended as these

may cause hazards or damage the equipment .

CONNECTION TO THE SATELLITE DISH LNB :

Disconnect the IRD from the mains before connecting or

disconnecting the cable from the satellite dish.

FAILURE TO DO SO CAN DAMAGE THE LNB.

SERVICING : Do not attempt to service this product yourself.

Refer all serving to qualified service agents.

LIGHTNING : It is recommended that the IRD should remain connected at all

times to the mains supply and satellite dish (except when

working on the LNB). However, the manufacturer’s

instructions for safeguarding other equipment connected to the

IRD, i, e, TV set, must be followed during lightning storms.

LNB and the modem telephone line are essential.

EARTHING : The LNB cable must be earthed to the system earth for

the satellite dish.

LOCATION : Locate the IRD indoor place properly to prevent lightening,

raining and direct sunlight.

INTRODUCTION

Thank you for purchasing the Digital Satellite Receiver (STB).

This Digital Satellite Receiver is fully compliant with the international DVB standard

and thus transmits digital images, sounds, information guides and teletext directly

to your TV through the satellite. Now you can comfortably see and receive digitally

transmitted music, news, movie and sports satellite broadcasts in your office or at your

home.

In the Channel Search section, both the automatic channel search method and the

manual Search mode are provided. Also it supports DiSEqC 1.2 and USALS enabling

you to move your antenna in order to focus your preferred satellite. You can save

up to 2500 and 1500 Radio channels and work around with the Favorite, Lock,

Delete, Move and Sort functions. The Menu is very modern and supports different

languages. All functions can be carried out using the remote control and some of the

functions can also be carried out using the front panel.

The STB is easy to use and adaptable for future advances. Please be aware that new

software may change the functions of the STB.

If you have any difficulties concerning the operation of your STB, please refer to the

relevant section of this manual, including the ‘Troubleshooting’. This Manual will

provide you with useful information on using the STB.

INTRODUCTION

Please ensure that the following items are included with the STB.

1) Remote control unit

2) Batteries (size AAA)

3) User’s Guide (this document)

Fully Compliant to DVB

Antenna/LNB control

- 22KHz mode On/Off

- Automatic FEC Detection

- DiSEqC 1.0 & 1.2 compatible & USALS

Satellite/Channel support

- 2500 TV channels, 1500 Radio channels storable

- Automatic channel search

Video/Audio

- Automatic PAL/NTSC selection

- Multi-lingual Audio support

- Multi-lingual Subtitle support

OSD (On Screen Display) support

- 256 color support.

- Multi-lingual menu text support.

- GMT and Time Offset support

- 10 favorite channel groups support

- Page Up/Page Down available on your channel list

- PIG ( Picture In Graphic ) support

Teletext

- Software emulation mode with always VBI insertion mode on.

Games are embedded.

CONTENTS

FEATURES

CONTENTS / FEATURES

- STANDBY

The power button of STB (ON / Stand by)

2)Rear Panel

FRONT / REAR PANELS

FRONT/REAR PANELS

- CHANNEL

The channel buttons are to change channels.

- LED

STANDBY

REMOTE

TV / SAT

FRONT / REAR PANELS

LNB IN

Connects the satellite antenna cable.

LNB OUT

Use it to connect to another STB.

RS232

Upgrades the STB Program & software.

TV SCART

Connects the TV SCART

VIDEO INPUT

Video input (YELLOW).

AUDIO-LEFT INPUT

Audio input (WHITE).

AUDIO-RIGHT INPUT

Audio input (RED).

RF OUT

Connects the TV.

RF IN

Connects the TV antenna.

FRONT/REAR PANELS

REMOTE CONTROL UNIT

VOL

/LIST VOL

REMOTE CONTROL UNIT (RCU)

Switches the STB between Operation and

Standby mode.

Returns to the previous menu and the screen.

Enables/ Disables the Audio.

Selects the TV or Radio service channels

and individual menu options.

Displays the Menu on screen or returns to

previous menu from submenu.

Displays the EPG (Electronic Program

Guide) on screen only when available.

Tunes to the next or previous service.

Services up or down through the available

services.

Adjusts the volume (Increase/Decrease).

VOL VOL

Displays Channel List on screen. Selects the item in the menu mode.

Displays the program information box on the screen and removes it.

REMOTE CONTROL UNIT (RCU)

Changes the terrestrial TV and Satellite mode.

Selects LEFT/RIGHT/MONO/STEREO sound function.

Selects the subtitle language list for the current service.

Enables the teletext with software emulation.

Displays the favorite channel list.

Displays and alters the UHF setting in menu.

Selects the previously viewed channel.

Selects the TV/Radio mode.

REMOTE CONTROL UNIT

INSTALLATION

1) Connection to TV and Hi-Fi

1-2) Connection to the TV using the RF cable.

Connect a terrestrial antenna to RF IN socket on

the STB.

Connect one end of the RF cable to the

RF OUT socket on the STB. Connect

the other end to the ANT IN socket on the TV.

INSTALLATION (Connection)

1-1) Connection to the TV with the SCART

Cable.

Connect one end of the SCART cable to

the TV SCART socket on the STB and

the other end to a SCART socket on the

TV.

First, connect both the satellite antenna and the TV line to the STB and switch the

power on.

In this manual there are some of the most common ways to connect the equipment:

TV and STB.

There are several ways of connecting the STB to the existing Audio/TV system.

We recommend using one of the following setups.

If you have problems with your connections and need help, contact your dealer or

Service Provider.
