Topfield TF 6000 PVR ES Manual de usuario

TOPFIELD

TF 6000 PVR ES

User Guide

Digital Satellite Receiver

Personal Video Recorder

Contents iii

Contents

1 Introduction 1

1.1 Features ............................... 1

1.2 Controlling the digital receiver .................. 2

1.2.1 The front panel ....................... 4

1.2.2 The remote control ..................... 5

1.3 What is common interface? .................... 8

2 Setup 9

2.1 Unpacking .............................. 9

2.2 Safety precautions ......................... 9

2.3 Rear panel connections ....................... 11

2.4 Connecting up your digital receiver ............... 12

2.4.1 Connecting the antenna .................. 13

2.4.2 Connecting to your television .............. 14

2.4.3 Connecting to your video cassette recorder ....... 17

2.5 Switching on for the ﬁrst time ................... 17

2.5.1 Inserting batteries in the remote control ......... 17

2.5.2 Powering on and checking picture ............ 18

iv Contents

3 Preference Settings 19

3.1 Language settings .......................... 19

3.2 Video and audio settings ...................... 21

3.2.1 Television standard .................... 21

3.2.2 Colour model ........................ 21

3.2.3 Video cassette recorder .................. 22

3.2.4 Television aspect ratio ................... 22

3.2.5 High deﬁnition television ................. 23

3.2.6 Video scaling ........................ 24

3.2.7 Audio mode ........................ 24

3.3 Local time setting .......................... 24

3.4 Parental control ........................... 25

3.5 Adjusting the on-screen display .................. 28

3.6 To turn on the time shift feature .................. 28

3.7 To use MediaHighway programme guide ............ 28

4 Service Search 30

4.1 Searching broadcasting services .................. 30

4.1.1 Conﬁguring LNB settings ................. 30

4.1.2 Conﬁguring DiSEqC 1.2 settings ............. 33

4.1.3 Conﬁguring USALS settings ............... 34

4.1.4 Searching services ..................... 36

4.2 Copying services .......................... 38

4.3 Resetting to factory settings .................... 39

5 Daily Usage 40

5.1 Volume control ........................... 40

5.2 Watching television ......................... 40

5.2.1 The services list ....................... 40

5.2.2 The favourite services list ................. 43

Contents v

5.2.3 Viewing programme information ............ 44

5.2.4 Selecting audio tracks ................... 45

5.2.5 Selecting subtitle tracks .................. 45

5.2.6 Viewing teletext ...................... 45

5.3 Viewing electronic programme guide .............. 46

5.4 Watching multifeed programme ................. 47

5.5 Using time shift ........................... 47

5.6 Using picture in picture ...................... 49

6 Listing Services 50

6.1 Editing the services list ....................... 50

6.2 Editing the favourite list ...................... 52

6.3 How to use on-screen keyboard .................. 54

6.4 Transferring receiver data ..................... 54

6.5 Editing channel data on your computer ............. 55

6.5.1 Editing satellite and transponder list .......... 57

6.5.2 Editing television and radio services list ........ 59

6.5.3 Editing favourite list .................... 60

7 Recording and Playing 62

7.1 Recording a programme ...................... 63

7.1.1 Instant recording ...................... 63

7.1.2 Timer recording ...................... 65

7.1.3 Scheduling recordings using the programme guide . . 68

7.1.4 Recording a time-shifted programme .......... 68

7.1.5 Recording a pay service programme ........... 69

7.2 File archive ............................. 70

7.2.1 To delete a recording .................... 70

7.2.2 To sort recordings ..................... 70

7.2.3 To lock a recording ..................... 71

vi Contents

7.2.4 To rename a recording ................... 71

7.2.5 To make a new folder ................... 71

7.2.6 To move a recording to another folder .......... 71

7.3 Playing back a recording ...................... 72

7.3.1 To navigate using the progress bar ............ 72

7.3.2 To play in slow motion .................. 73

7.3.3 To play in fast motion ................... 73

7.3.4 To make a bookmark .................... 74

7.3.5 To play back a recording repeatedly ........... 74

7.3.6 To play back recordings in sequence ........... 75

7.3.7 To play back a scrambled recording ........... 75

7.4 Copying a recording ........................ 76

7.5 MP3 playback ............................ 76

7.6 Transferring recording ﬁles .................... 77

7.7 Formatting the hard disk ...................... 79

8 Accessing to The Digital Receiver via The Internet 80

8.1 Conﬁguring the router ....................... 81

8.1.1 To access within the local area network ......... 81

8.1.2 To access on the level of the Internet ........... 82

8.2 Conﬁguring the network settings on the digital receiver . . . . 84

8.3 Accessing the web server ..................... 85

8.4 Accessing the FTP server ...................... 87

9 Topﬁeld Application Program 89

10 Firmware Update 91

10.1 Checking the ﬁrmware information ............... 91

10.2 From your computer via USB port ................ 92

10.3 From your computer via RS-232 port ............... 93

10.4 From another digital receiver via RS-232 port .......... 93

10.5 Over the air ............................. 94

Contents vii

Index 96

Chapter 1

Introduction

The TF 6000 PVR ES digital receiver is fully compliant with the

international Digital Video Broadcasting (DVB) standard, and

thus is able to receive digital broadcasts of that standard. For

its operation you need an antenna, which must be installed

appropriately.

NOTE

In general we equate a channel with a frequency. Unlike ana-

logue broadcasts, however, digital broadcasts are not all as-

signed to their own frequencies; instead, multiple television

broadcasts are transmitted through a single frequency. The fre-

quency in digital broadcasting is usually called transponder. To

reduce confusion in this manual, the word

service

is preferably

used than

channel

as a term to indicate one television or radio

broadcast.

1.1 Features

The TF 6000 PVR ES digital receiver has the following features:

•

Supports DiSEqC 1.0, DiSEqC 1.1, DiSEqC 1.2 and US-

ALS.

2 Introduction

• Can store up to 5000 television and radio services.

• You can edit the services list.

•

You can create favourite lists of your favourite services.

•

You can view information about the current television or

radio programme.

•

Has an electronic programme guide that provides an

overview of scheduled programmes.

•

You can update the ﬁrmware of the digital receiver to the

latest version which would be provided by the manufac-

turer.

•

You can record one broadcasting service while you are

currently watching another.

•

The large storage capacity of the built-in hard disk drive

allows you to record up to about 60 hours of television

—in case of 250 gigabytes— in excellent picture and sound

quality.

•

Time shift is a special technical feature available on the

TF 6000 PVR ES. You can pause the programme you are

watching and resume it again at a later time. Then

you can quickly go to whatever part of the current pro-

gramme by fast foward or backward search.

1.2 Controlling the digital receiver

You can operate the digital receiver with the remote control

and the buttons on the front panel.

NOTE

When the digital receiver is off but plugged into a wall outlet,

we say that it is in standby mode; on the other hand, when it is

on, it is in operation mode. Even when you are not using the
