Apollo User Manual

Version: 1.2

R&D Department, Shanghai TopXGun Robotics Co., Ltd

Apollo User Manual

Content

1. Objective.................................................................................................................................3

1.1Audience............................................................................................................................ 3

1.2Agreement..........................................................................................................................3

2. About Software....................................................................................................................... 3

2.1. Functional Features..........................................................................................................3

2.2. New Characteristics......................................................................................................... 4

2.3. Technical Support............................................................................................................ 4

3. Hardware Environment...........................................................................................................4

3.1. Preparation for Installation.............................................................................................. 4

3.2 Hardware Installation........................................................................................................5

4. Software Environment............................................................................................................ 5

4.1 Software List.....................................................................................................................5

4.2 Software Installation.........................................................................................................6

4.3 Software Operation...........................................................................................................7

4.4 Software Development..................................................................................................... 7

5 Common Problems.................................................................................................................. 7

5.1 Connect the serial interfaces of Apollo with USB, but a question mark is displayed at

the COM interface.................................................................................................................. 7

5.2 HDMI of Apollo can’t be used......................................................................................... 7

5.3 Meanings of indicator lamps of Apollo’s OS................................................................... 8

5.4 Can 4G SIM cards be inserted into and pulled out of 4G card slots of Apollo without

powering off?..........................................................................................................................8

5.5 4G of Apollo is automatically started without electrification. Then, how to make

automatic connection of 4G possible just by powering on?................................................... 8

5.6 How to configure for automatic startup of CAN without electrification?........................8

5.7 Packet loss is caused when gigabit network is accessed to Apollo.................................. 8

5.8 Changes to IP upon Each Startup of Apollo..................................................................... 9

5.9 Regular manual cleaning will be necessary when the space and files for saving log files

are too large............................................................................................................................ 9

5.10 How to upgrade AOS in case of failed upgrade?.........................................................9

Apollo User Manual

1 Objective

Apollo User Manual (hereinafter referred to as the Manual) intends to introduce Apollo

system to users and help users rapidly install and apply the system.

1.1Audience

This manual is written in hope of application and testing of Apollo and development

personnel who have known something about Linux and ROS. This manual is a basic tutorial for

users who don’t know a lot about computers.

1.2 Agreement

According to this manual, you are assumed to generally know about computers. This is an

online user manual, which is more complete and prompt. With the iterative release of new

versions, subsequent manuals might more or less deviate from this manual. In this case, you are

supposed to operate according to the latest online user manual.

2 About Software

2.1. Functional Features

Apollo, as brain of unmanned aerial vehicles (UAVs), has powerful computing capability,

many interfaces and 4G networking capability. With Linux operating system and integrated with

TopXGun SDK, Apollo makes it more convenient to develop application scenarios of UAVs and

brings more potential of UAVs into play.

Powerful computing capability

Using Freescale i.MX6 processor, Apollo is composed of 4 ARM Cortex-A9 processors and

its dominant frequency is up to 1.2GHZ. With 2GBDDR3 memory and 16GB EMMC, ithas

powerful computing capability. In addition, Apollo uses a STM32F103 MCU ascoprocessorfor

interacting with powerful real-time equipment, in order to ensure real-time performances of the

whole system.

Support of numerous interfaces

With many interfaces, Apollo is used for managing and controlling airbone equipment (e.g.

Apollo User Manual

task load, sensors and control modules).

High-speed networking capacity

With built-in high-speed 4G modules, Apollo is applicable to China Mobile,ChinaTelecom

and China Unicom. By 4G, users can perform extremely remote control, cluster control and

remote real-time monitoring of UAVs, in order that UAVs can really become online smart

platforms.

Convenient development environment

Apollo, equipped with Linux operating system and integrated with TopXGun SDK, is very

convenient for developing airborne applications and software. Furthermore, Apollo is equipped

with ROS and Qianxun Si SDK, making it convenient for developing applications and software

for UAVs.

Low power consumption

The power consumption of Apollo. In starting 4G communications, the maximum power

consumption is 8W. Without 4G, the maximum power consumption is only 5W. With fan-free heat

dissipation structure, Apollo is more reliable.

2.2. New Characteristics

Following functions are added in this launch:

Access to FCUs: it is applicable for accessing TopXGun M2 FCU to Apollo and controlling

it.

External control: Integrating serial Interfaces, USB, OTG, CAN, ethernet, PWM and GPIO

general control modules makes it convenient for rapid connection and functional extension

between the system and the peripheral equipment.

Data transmission: applicable to transmission via bluetooth, networking cables, USB, 4G and

radios for wireless data transmission.

Operation scheduling: applicable to mapping/surveying and power patrolling.

2.3. Technical Support

For details about technical support, refer to the official website of TopXGun:

http://www.topxgun.com/col-contact.html

3. Hardware Environment

3.1. Preparation for Installation

For details about preparation for installation, please refer to the quick guide supplied together

with Apollo as gift.

Apollo User Manual

3.2 Hardware Installation

4. Software Environment

4.1 Software List

SN Type Document Name Specifications

1 Apollo System

Firmware

aos-0.1.1-nx001.apsw Apollo Operating System

2 apl-engine-1.2.3-r1.imx6qsabresd.rpm Apollo engines provide

waypoint-related tasks

3 apl-fcu-1.2.2-r1.imx6qsabresd.rpm Apollo interacts with FCU

to obtain UID, configured

Apollo User Manual

Apollo Application parameters and telemetry

data for the units

4 apl-iocu-1.2.0-r1.imx6qsabresd.rpm Apollo is used for setting

GPIO and PWM outputs

as modes of operation for

M1 and M8

5 apl-mapping-1.2.0-r1.imx6qsabresd.rpm Apollo is used for

mapping, surveying and

shooting

6 Apollo IOCU firmware APOLLO_IOCU_0000_FA_2018040801_U_1.

1.firmware

Apollo controls firmware

that interacts with

peripheral equipment in

terms of input and output

4.2 Software Installation

Notes: For following operations, installations can be installed in computers with

Windows system.

1. Connect data cables of OTG to their interfaces via Apollo, and the other end to the USB

interface of PC;

2. Electrify Apollo and wait for some time (about 20s), so that drive lettersofApollo

appear on PC;

3. Copy files to be installed or updated to drive letters of Apollo. When several documents

are copied together, Apollo will install and update them in succession;

4. Reboot Apollo. Then, the system will be installed automatically.

5. After installation, a file suffixed “DONE” can be seen in the drive letter of Apollo. This

means the installation has been completed. If the installation fails, a file suffixed failed

will appear.

The successful installation is shown as follows:

The failed installation is shown as follows:

Apollo User Manual

6. By entering cat /etc/aos-version into the XShell terminal, current version of AOS can be

viewedasshowninthefollowingfigure:

4.3 Software Operation

Apollo systems and software can be powered on and run automatically once Apollo is

electrified.

4.4 Software Development

For secondary software development based on Apollo operating system, please refer to the

manual on Apollo development for details.

5 Common Problems

5.1 Connect the serial interfaces of Apollo with USB, but a question mark is displayed

at the COM interface

1) Whether drivers have been installed correctly

Solution:

a) Whether corresponding software has been correctly installed to drive the operating

system

b) Connect a computer to the FCU to check if the ports are numbered inside the equipment

manager

c) Switch off the power and resume operation

2. Check whether USB data cables are damaged

Solution:

a) Replace data cables to resume operations

3. Problems with operating systems of computers

Solution:

a) In view that some streamlined third-party operating systems lack files, we recommend

genuine or pure operating systems

5.2 HDMI of Apollo can’t be used

HDMI is disabled on a default basis for Apollo products. If necessary, please contact official

after-sales service specialists of TopXGun

Apollo User Manual

5.3 Meanings of indicator lamps of Apollo’s OS

These indicator lamps are reserved to be used by customers and not uniformly defined.

5.4 Can 4G SIM cards be inserted into and pulled out of 4G card slots of Apollo

without powering off?

4G SIM cards of Apollo can’t be inserted into and pulled out of the slots without powering

off for the time being. To insert and pull out 4G SIM cards, please power the Apollo off first.

5.5 4G of Apollo is automatically started without electrification. Then, how to make

automatic connection of 4G possible just by powering on?

1. Log in to the No.3 serial interface of Apollo with terminal management tools (e.g. XShell) and

confirm that 0.1.1 is the version of Apollo system. Enter following command line:

cat /etc/aos-version

2. Add following command line to #!bin/bash of /etc/rc5.d/S50app-run.sh, and restart Apollo after

saving:

rm /home/flier/.4g-log

source /etc/4g-connect.sh > /home/flier/.4g-log &

5.6 How to configure for automatic startup of CAN without electrification?

1. Log in to the No.3 serial interface of Apollo with terminal management tools (e.g. XShell) and

confirm that 0.1.1 is the version of Apollo system. Enter following command line:

cat /etc/aos-version

2. Add following command line to #!bin/bash of /etc/rc5.d/S50app-run.sh, and restart Apollo after

saving:

ip link set can0 up type can bitrate 1000000 triple-sampling on

5.7 Packet loss is caused when gigabit network is accessed to Apollo

In this case, set the Apollo network interface cards under the 100M mode. Steps shall be taken as

follows:

1. Log in to the No.3 serial interface of Apollo with terminal management tools (e.g. XShell) and

confirm that 0.1.1 is the version of Apollo system. Enter following command line:

cat /etc/aos-version

2. Input following commands and power on to boot scripts

sudo vi /etc/rc5.d/S50app-run.sh

3. Add following command line to the second row and restart Apollo after saving the command

line

Apollo User Manual

ethtool -s eth0 speed 100 duplex full autoneg off

5.8 Changes to IP upon Each Startup of Apollo

In this case, static IP of Apollo shall be configured. Steps shall be taken asfollows:

1. Log in to the No.3 serial interface of Apollo with terminal management tools (e.g. XShell) and

confirm that 0.1.1 is the version of Apollo system. Enter following command line:

cat /etc/aos-version

2. Input following commands and open the control scripts

sudo vi /etc/network/interfaces

3.Add following content to scripts and save them.

auto eth0:0

iface eth0:0 inet static

address 10.10.10.10

netmask 255.0.0.0

4. Apollo will recognize the static IP of 10.10.10.10 on a default basis through above

configurations

5.9 Regular manual cleaning will be necessary when the space and files for saving log

files are too large.

1. Log in to the No.3 serial interface of Apollo with terminal management tools (e.g. XShell) and

confirm that 0.1.1 is the version of Apollo system. Enter following command line:

cat /etc/aos-version

2. Input following command line to delete logs

rm -rf ~/.ros/log/*

5.10 How to upgrade AOS in case of failed upgrade?

To upgrade AOS, it is necessary to update Apollo loader at first. In this case, steps shall be taken

as follows:

1. Copy “aloader-0.1.3-nx001.alsw” to Apollo through USB drives or networks;

2. Mount loader drives:

sudo mount /dev/mmcblk3p2 /media/mmcblk3p2/

3. Delete the old loader:

sudo rm /media/mmcblk3p2/* -rf

4. Load the new loader:

sudo tar xvf aloader-0.1.3-nx001.alsw -C /media/mmcblk3p2/

5. Renovate magnetic disks:

sync

Tabla de contenidos

Manuales populares de Controladores de otras marcas

Digiplex

Digiplex DGP-848 Instrucciones de funcionamiento

YASKAWA

YASKAWA SGM series Manual de usuario

Sinope

Sinope Calypso RM3500ZB Manual de usuario

Isimet

Isimet DLA Series Style 2 Manual de instalación

LSIS

LSIS sv-ip5a Manual de usuario

Rockwell Automation

Rockwell Automation 1769-L31 Manual de usuario

Airflow

Airflow Uno hab Manual de usuario

ABB

ABB ACS580-01 drives Manual de usuario

Panasonic

Panasonic GM1 Series Manual de usuario

Emerson

Emerson SW93 Manual de usuario

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manual de usuario

Panasonic

Panasonic FP? Positioning Unit RTEX Manual de usuario

Samson

Samson Type 5824 Manual de servicio

Alpha IP

Alpha IP MIOB 21001 Manual de usuario

Siemens

Siemens OpenAir GMA 1 Series Manual de usuario

Surecom

Surecom SR-629 Manual de usuario

Fishman

Fishman TriplePlay Manual de usuario

Regulus

Regulus SRS1 T Manual de usuario
