Owner’s Manual

Models

TMGE24, TMGE36, TMGE48

This manual includes material related to installation,

use , cleaning, and care. Exploded view[s], as well

as any available parts list[s] and wiring diagram[s]

pertaining to the unit[s] covered by this manual are

also included.

This manual must be read and understood by all

persons using or installing this appliance. Contact

your Star dealer if you have any questions concerning

installation, use, or maintenance of this equipment.

DO NOT DISCARD THIS MANUAL.

Electric Griddle

2M-Z12971 •Rev. A •06.2016

TMGE36

LIMITED EQUIPMENT WARRANTY

All workmanship and material in Toastmaster products have a one (1) year limited warranty on parts and labor in the United States and Canada.

Such warranty is limited to the original purchaser only and shall be eﬀective from the date the equipment is placed in service. Toastmaster’s

obligation under this warranty is limited to the repair of defects without charge, by the factory authorized service agency or one of its sub-

agencies. Toastmaster will not assume any responsibility for loss of revenue. Models that are considered “portable” (see below) should be

taken to the closest Toastmaster service agency, transportation prepaid. On all shipments outside the U.S.A. and Canada, see the International

Warranty.

This warranty does not apply to any item that is disassembled or tampered with for any purpose other than repair by an authorized service

center or the service center’s sub-agency. This warranty does not apply if damage occurs from improper installation, misuse, wrong voltage,

wrong gas or operated contrary to the Installation and operating instructions. This warranty does not apply to “Special Products” but to regular

catalog items only. Toastmaster’s warranty on “Special Products” is six (6) months on parts and ninety (90) days on labor.

PARTS WARRANTY

Parts that are sold to repair out of warranty equipment are warranted for ninety (90) days. The labor to replace the part is NOT warrantied.

SERVICES AND EXPENSES NOT COVERED BY WARRANTY

• Travel time and mileage rendered beyond the 50-mile radius limit

• Mileage and travel time on “portable” equipment (see below)

• Labor to replace such items that can be replaced easily during

a daily cleaning routine (e.g., removable kettles on fryers, knobs,

grease drawers on griddles, etc.)

• Installation of equipment

• Cleaning of equipment

• Seasoning of griddle plates

PORTABLE EQUIPMENT

Star will not honor service bills that include travel time and mileage charges for servicing any products considered “portable” including items

listed below. These products should be taken to the Service Agency for repair:

• Specialty Food Warmers

• Sandwich Grills

• Pop-Up Toasters

• Accessories of any kind (e.g. Sneeze Guards, Manual Pumps, etc.)

• Heat Lamps

The foregoing warranty is in lieu of any and all other warranties expressed or implied and constitutes the entire warranty.

Should you require any assistance regarding the operation or

maintenance of any Toastmaster equipment; write, phone, fax

or email our Service Department. In all correspondence mention

the model number and the serial number of your unit, as well as

the voltage or type of gas you are using.

• Voltage conversions or gas conversions

• Pilot light adjustment

• Miscellaneous adjustments

• Thermostat calibration and bypass adjustment

• Resetting of circuit breakers, safety controls, or reset buttons

• Replacement of bulbs or fuses

• Repair of damage created during transit, delivery, or installation

or created by an act of God.

Business hours: 8:00 a.m. to 4:30 p.m. Central Standard Time

Telephone: 314-678-6303

Fax: 314-781-2714

Email: customerser[email protected]

Website: www.toastmastercorp.com

2M-Z12971 Rev A Owner’s Manual for Toastmaster TMGE Electric Griddles

TABLE OF CONTENTS

Warranty i

General Information and Installation 1–2

Phase Diagram 3

Daily Operation 4

Cleaning 4

Speciﬁcations 5

Exploded Views 6–7

Parts List 8-9

iii

NOTES

2M-Z21001 Rev- Owner's Manual for IRCS4 Impingement/Radiant Split-Belt Conveyor Toaster

2M-Z12971 Rev A Owner’s Manual for Toastmaster TMGE Electric Griddles

SAFETY SYMBOLS

These symbols are intended to alert the user to the

presence of important operating and maintenance

instructions in the manual accompanying the appliance.

THOROUGHLY INSPECT YOUR UNIT ON ARRIVAL

This unit has been tested for proper operation before leaving our plant to ensure delivery of your unit

in perfect condition. However, there are instances in which the unit may be damaged in transit. In the

event you discover any type of damage to your product upon receipt, you must immediately contact

the transportation company who delivered the item to you and initiate your claim with that company.

If this procedure is not followed, it may aﬀect the warranty status of the unit. If damage or loss is not

apparent until after equipment is unpacked, a request for inspection of concealed damage must be

made with carrier within 15 days. Please record the model number, serial number, voltage, and purchase

date in the area below at the time of receipt..

Model Number

Serial Number

Voltage

Purchase Date

MAINTENANCE AND REPAIRS

Contact your local authorized service agent for service or required maintenance. Please have the

information in the above ﬁelds ready when you call to ensure a faster service.

Using any part other than genuine Toasmaster factory supplied parts relieves the manufacturer of all

liability. Due to periodic changes in designs, methods, procedures, policies, and regulations, the

speciﬁcations contained in this document are subject to change without notice. Toastmaster reserves

the right to change product speciﬁcations and design without notice. Such revisions do not entitle the

buyer to corresponding changes, improvements, additions or replacements for previously purchased

equipment. While Toastmaster exercises good faith eﬀorts to provide information that is accurate,

we are not responsible for errors or omissions in information provided or conclusions reached as a result

of using the speciﬁcations. By using the information provided, the user assumes all risks in connection

with such use.

PLEASE REFER TO THE WARRANTY PAGE FOR SPECIFIC WARRANTY INFORMATION.

AUTHORIZED SERVICE AGENT LISTING

Reference the listing provided with the unit or for an updated listing go to the website or call customer

service to ﬁnd an agent.

Business hours: 8:00 a.m. to 4:30 p.m. Central Standard Time

Telephone: 314-678-6303

Fax: 314-781-2714

Email: customerservice@star-mfg.com

Website: www.toastmastercorp.com

Please visit www.starwebconnect.com/manuals.aspx for digital versions of any documents associated

with this unit.

GENERAL SAFETY INFORMATION

This equipment is designed and sold for commercial use only, and is intended for use by personnel

trained and experienced in its operation. This is not sold for consumer use in and around the home

nor for use directly by the general public in food service locations.

Before using your new equipment, read and understand all the instructions and labels associated

with the unit prior to putting it into operation. Make sure all people associated with its use understand

the units operation and safety before they use the unit.

GENERAL INSTALLATION INFORMATION

The unit is shipped fully assembled and ready to plug into a standard outlet speciﬁed for its voltage

and amp draw. If improper electrical supply can be determined through troubleshooting, contact

a qualiﬁed electrician prior to using the unit. Removal or replacement of the power cord or plug will

void the warranty. Should you require assistance, contact your local authorized service agent for any

service or required maintenance.

Set the unit so that the rear is 0.25 inches (6 mm) higher than the front using the adjustable feet.

Make certain the griddle has at least the minimum clearance on the sides and back as called out

on the nameplate of the unit.

Before using the unit for the ﬁrst time, ensure to clean the unit properly. Refer to the Cleaning

Procedure document for cleaning instructions.

ELECTRICAL CONNECTION

For your protection we recommend that a qualiﬁed electrician work on connecting this griddle.

He should be familiar with electrical installations and all electric codes. Proper connections and

power supply are essential for ecient performance. The external wiring should be in conduit

or an approved type of ﬂexible cable suitable for operation at the temperature indicated on the

wiring diagram for your unit, and of a proper size to carry the load. The supply circuit should be

properly fused and equipped with a means of disconnecting, as required by local electrical code.

The body of the griddle should be grounded.

Before making any electrical connection to this unit, check that the power supply is adequate for the

voltage, amperage, and requirements stated on the nameplate. This unit will be shipped ready to hard

wire. Make certain to disconnect the unit from the power source before installing or removing any parts.

Be absolutely sure that the ground connection for the receptacle is properly wired. Do not connect

equipment to power without proper ground connections. Improper grounding may result in personal

injury or fatality.

WIRING

Models may be wired for operation in the ﬁeld for either 1-phase or 3-phase power supplies by making

line connections at the junction box located at the rear of the unit as described on the phase diagram.

TMGE36 and TMGE48 models are recommended to be wired for 3-phase operation. TMGE48 models

are supplied with two junction boxes and can be wire to two (2) 8 kW lines or a single 16 kW line.

CONNECT/PLUG UNIT INTO DEDICATED AC LINE WITH APPROPRIATE AMPERAGE/VOLTAGE AS

SPECIFIED ON THE NAMEPLATE OF THE UNIT.

DO NOT IMMERSE OR LET THE UNIT STAND IN WATER.

DO NOT HOSE DOWN THE UNIT OR THE TABLE/COUNTER IF THE UNIT IS ON THE TABLE/COUNTER.

KEEP AWAY FROM RUNNING WATER.

2M-Z21001 Rev- Owner's Manual for IRCS4 Impingement/Radiant Split-Belt Conveyor Toaster

2M-Z12971 Rev A Owner’s Manual for Toastmaster TMGE Electric Griddles

PHASE DIAGRAM

POWER MUST BE REMOVED FROM THE UNIT BEFORE ATTEMPTING REPAIR OR SERVICE.

MAKE CERTAIN TO CHECK ALL CONNECTIONS THOROUGHLY BEFORE RESTORING POWER TO THE UNIT.

THE INFORMATION BELOW IS REFERENCED FROM DIAGRAM 2M-Z21072.

DAILY OPERATION

GRIDDLE CARE

It takes very little time and eort to keep the griddle

attractive and performing at top eciency. If grease

is permitted to accumulate, it forms a viscous residue

and then carbonizes, making it extremely dicult to

remove. To prevent this condition, the following

suggestions for cleanliness should be followed.

i. After each use, scrape the griddle with a scraper

or ﬂexible spatula to remove excess grease and food

and maneuver it into the grease chute. If there is an

accumulation of burned on grease and/or food, the

griddle should be thoroughly scoured and reseasoned.

Use pumice or griddle stone while the griddle is warm.

Do not use steel wool because of the danger of steel

slivers getting into the food

ii. Daily use a clean cloth and a good non-abrasive

cleaner to clean the stainless steel body of the

griddle is recommended. Wipe the polished front

with a soft cloth so not to scratch the ﬁnish.

iii. At least once a day, remove the grease drawer and

wash it using the same process as an ordinary cooking

utensil. The drawer is removed by pulling forward until

it is released from its track.

SEASONING THE GRIDDLE HEATING SURFACE

Clean the griddle surface thoroughly. After the griddle

has been thoroughly cleaned, it should be seasoned to

prevent food from sticking. Before using and after each

thorough scouring, season the griddle heating surface

in the following manner.

i. Turn the temperature control dials to 350°F (177°C).

ii. Using a clean cloth, not a spatula, spread a thin ﬁlm

of cooking oil over the griddle cooking surface. This

ﬁlm should remain on the hot griddle surface for half

an hour.

iii. Remove the excess oil and wipe clean.

iv. Apply another ﬁlm of cooking oil over the hot cooking

area for another half hour and again remove excess

oil and wipe clean. The griddle surface should now

be ready for use.

TEMPERATURE CONTROL

The temperature controls are combination “ON/OFF”

switches and thermostats. Turning the dial knob

automatically maintains the selected heat range.

There is one thermostat for every twelve [12] inch

(305 mm) wide section that operate independently.

COOKING

Set the thermostat dial knob at the desired temperature.

After a short pre-heating period, the thermostat will

automatically maintain the selected temperature.

IDLING

During idle periods, to save on operating costs, lower

the temperature setting of the thermostat to about

250°F (121°C). It is not necessary to maintain cooking

temperature during idle periods, as the griddle can

quickly be reheated to the desired temperature.

SIGNAL LIGHTS

Each thermostat has its own signal light which

indicates when the unit’s control knob is not

in the o position.

GREASE PAN

The grease pan on the front is hot and contains hot

grease. Take care when removing and emptying the

tray. The tray should be checked and emptied on

a regular basis.

2M-Z21001 Rev- Owner's Manual for IRCS4 Impingement/Radiant Split-Belt Conveyor Toaster

2M-Z12971 Rev A Owner’s Manual for Toastmaster TMGE Electric Griddles

SPECIFICATIONS

TMGE36 shown

MODEL HEIGHT WIDTH

[A]

DEPTH APPROX. SHIP

WEIGHT

APPROX. WEIGHT

INSTALLED

TMGE24 15.3 in.

(389 mm)

24 in.

(610 mm)

28.3 in.

(719 mm)

175 lb.

(79.4 kg)

147 lb.

(66.7 kg)

TMGE36 15.3 in.

(389 mm)

36 in.

(914 mm)

28.3 in.

(719 mm)

262 lb.

(118.8 kg)

221 lb.

(100.2 kg)

TMGE48 15.3 in.

(389 mm)

48 in.

(1.22 m)

28.3 in.

(719 mm)

350 lb.

(158.8 kg)

295 lb.

(133.8 kg)

MODEL TOTAL

VOLTS 1Φ AMPS 3Φ AMPS

3Φ AMPS

TMGE24 6/

208/

240

28.8/

33.3

14.4/

16.7

25/

28.9

14.4/

16.7

TMGE36 9/

208/

240

43.3/

25/

28.9

25/

28.9

25/

28.9

TMGE48 12/

208/

240

57.8/

66.7

38.2/

44.2

25/

28.9

38.2/

44.2

15.3 in.

(389 mm)

1.1 in.

(28 mm) 4 in.

(102 mm)

3.3 in.

(84 mm) 0.7 in.

(18 mm) 5 in.

(127 mm)

7.3 in.

(185 mm)

28.3 in.

(719 mm)

4.1 in.

(104 mm)

26 in.

(660 mm)

21 22 16

FRONT—PANEL AND CONTROLS

RIGHT SIDE—PANELS

TMGE36 shown

LEFT SIDE—PANELS

TMGE36 shown

Otros manuales para TMGE24 -

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Plancha de Toastmaster

Toastmaster

Toastmaster A710 Manual de usuario

Toastmaster

Toastmaster TG15W Manual de usuario

Toastmaster

Toastmaster TMEG15W/B Manual de usuario

Toastmaster

Toastmaster TG21WL TG21WCAN Manual de usuario

Toastmaster

Toastmaster TECG7324 Manual de usuario

Toastmaster

Toastmaster Free-Standing Models 7224 Manual de usuario

Toastmaster

Toastmaster ACCU-MISER AM24 Hoja de especificaciones

Toastmaster

Toastmaster TECG732467 Manual de usuario

Toastmaster

Toastmaster TMEG21W Manual de usuario

Toastmaster

Toastmaster 7072WH13 Manual de operación

Toastmaster

Toastmaster TG21W Manual de usuario

Toastmaster

Toastmaster TM-201GR Manual de usuario

Toastmaster

Toastmaster TMGM36 - Manual de usuario

Toastmaster

Toastmaster TMGE24 - Manual de usuario

Toastmaster

Toastmaster TMGM24 - Manual de usuario

Toastmaster

Toastmaster TMDG2400 Manual de usuario

Toastmaster

Toastmaster TECG732467 Manual de usuario

Toastmaster

Toastmaster AACU-MISER AM24SS Hoja de especificaciones

Toastmaster

Toastmaster TMDG2400T Manual de usuario

Toastmaster

Toastmaster TMDG24 Manual de usuario

Manuales populares de Plancha de otras marcas

Proctor-Silex

Proctor-Silex 25340 Manual de usuario

New House Kitchen

New House Kitchen NH33-C Manual de usuario

Magikitch'n

Magikitch'n 24 Manual de usuario

Black Stone

Black Stone 1650 Manual de usuario

Anvil

Anvil FTA7116 Manual de usuario

Presto

Presto 07030 Manual de usuario

Pit Boss

Pit Boss PB2BGT1 Manual

Dyna-Glo

Dyna-Glo DGL260SNP Manual de usuario

Char-Broil

Char-Broil 19952085 Manual de usuario

APW Wyott

APW Wyott HMG-2424 Manual de usuario

Pit Boss

Pit Boss Ultimate Griddle PB2BGD2 Manual de usuario

Airxcel

Airxcel Suburban Elite SOP-1005A Manual de usuario

Keating Of Chicago

Keating Of Chicago MIRACLEAN PRE-2000 Manual de usuario

Nexgrill

Nexgrill 720-0786A Manual de usuario

Outwell

Outwell FH-3047C Manual de usuario

Rankam

Rankam Member's Mark GR2298901-MM-02 Guía de referencia rápida

Black Stone

Black Stone 1972 Manual de usuario

Star

Star Ultra Max 760TA Manual de usuario
