Dyna-Glo DGL260SNP Manual de usuario
1
Rev. 03/05/21
17-INCH PORTABLE
TABLETOP GAS GRIDDLE
Model #DGL260SNP / DGL260SNP-D
/ DGL260CNP / DGL260CNP-D
ATTACH YOUR RECEIPT HERE
Serial Number _____________________________ Purchase Date ______________________
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-877-447-4768, 8:00 a.m. – 4:30 p.m., CST, Monday – Friday
Français p. XX
Español p. XX
Français p. 21
Español p. 41
2
Table of contents
Assembler/Installer: This manual contains important information necessary for the proper
assembly and safe use of this appliance. Read and follow all warnings and instructions before
assembling and using this appliance. Leave these instructions with the consumer.
Consumer/User: Follow all warnings and instructions when using this appliance.
Retain these instructions for future reference.
Safety......................................................................................................................3
Package Contents ....................................................................................................5
Overview.................................................................................................................6
Inial Commissioning ..............................................................................................7
AssemblyInstrucons............................................................................................. 7
Use .........................................................................................................................8
Cleaning ..................................................................................................................13
Troubleshoong ......................................................................................................16
Warranty.................................................................................................................18
Replacement Parts List ...........................................................................................20
....................................................................................................... Table of contents
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open ame.\
3. If odor continues, keep away from the appliance
and immediately call your local re department.
1. Never operate this appliance unattended.
2. Never operate this appliance within 10 feet (3 m) of any structure, combustible material or
other gas cylinder
3. Never operate this appliance within 25 feet (7.5 m) of any ammable liquid.
4. Never allow oil or grease to get hotter than 400°F or 200°C, if the temperature exceeds
400°F (200°C) or if oil begins to smoke, immediately turn the burner or gas supply OFF.
5. Heated liquids remain at scalding temperatures long after the cooking process. Never
touch cooking appliance until liquids have cooled to 115°F (45°C) or less.
6. If a re should occur, keep away from the appliance and immediately call your re
department. Do not attempt to extinguish an oil or grease re with water.
Failure to follow these instructions
could result in re, explosion, or burn
hazard which could cause property
damage, personal injury or death.
DANGERDANGER
DANGER
DANGER Failure to follow these instructions could result in re, exsplosion or burn
hazard which could cause property damage, personal injury or death.
3
CAUTION
Please read and understand this entire manual before attempting to assemble, operate or install
the product. If you have any questions regarding the product, please call customer service at:
1-877-447-4768, 8:00a.m. - 4:30 p.m., CST, Monday – Friday.
• DO NOT use this product for anything other than its intended purpose. It is NOT intended for
commercial use. It is NOT intended to be installed or used in or on a recreational vehicle and/
or boat.
• In the event of an oil or grease re, do not attempt to extinguish with water. Immediately call
the re department. A Type BC or ABC re extinguisher may, in some circumstances contain
the re.
• This appliance is for outdoor use only in well-ventilated areas. DO NOT operate it in a building,
garage or any other enclosed area, or under overhead construction.
• A minimum clearance of 10 ft (3048 mm) to combustible material is required on the front, sides
and back. It is very important to always maintain proper clearances to combustibles.
• DO NOT obstruct the ow of combustion air/or ventilation air for the appliance.
• When cooking, the griddle must be on a level, stable noncombustible surface in an area clear
of combustible material, including long or dry grass.
• Before each use check that no dead leaves or debris are under the appliance.
• Store this appliance in a dry, protected location.
• The use of alcohol, prescription or nonprescription drugs may impair the user’s ability to
properly assemble and safely operate this appliance.
• Allow the griddle to cool to 115°F (45°C) before moving or storing. Use caution when lifting and
moving the appliance to avoid back strain or back injury. DO NOT move the appliance while it
is in use.
SAFETY
4
SAFETY
• Do not place the griddle under overhead
combustible construction or awnings.
Minimum clearance from sides and
back of unit to combustible construction,
10 ft (3048mm) from sides and back.
NOTE: The installation must conform with
local codes or, in the absence of local codes,
with either the National Fuel Gas Code,
ANSI Z223.1/NFPA 54, Natural Gas and
Propane Installation Code, CSA B149.1, or
Propane Storage and
Handling Code, B149.2.
CAUTION
• DO NOT store or use this appliance near gasoline or other combustible liquids or where other
combustible vapors may be present.
• DO NOT use this appliance as a heater.
• DO NOT leave the appliance unattended while in use. Keep children and pets away from the
appliance at all times.
• This appliance will be hot during and after use. Use insulated oven mitts or gloves for protection
from hot surfaces or splatter from cooking liquids.
• Make sure that the orice of each control valve properly mates with the burner mixing tube by
visual observation. Please refer to maintenance section.
• Allow the griddle and its components to cool completely before conducting any routine cleaning
or maintenance.
• This griddle is designed only to be used with a 1 lb 16.4 oz disposable propane cylinder with a
CGA #600 connection. Cylinder must be marked “propane”.
• A propane cylinder not connected for use should not be stored in the vicinity of the griddle or
any other appliance. DO NOT store spare propane cylinder within 10 ft. (3 m) of the griddle.
propane cylinder must be stored outdoors, out of reach of children. DO NOT store propane
cylinder in a building, garage or any other enclosed area.
• Disconnect the cylinder when appliance is not in use.
• While the griddle is not in use, the gas must be turned off at the supply cylinder.
• Do not use the griddle if the burner fails to light or fails to remain lit. Under such conditions, gas
should be turned off and the fuel cylinder should be disconnected.
• Use in high wind conditions that result in poor burner operation such as blowing out and aring
should be avoided. If repositioning the appliance does not improve operation under such wind
conditions, the appliance should be turned off.
• Read and follow all warnings and instructions before assembling and using the appliance.
WARNING
10 ft
3048mm
10 ft
3048mm
5
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
AFirebox Assembly 1
B Grease Cup 1
C Knob 1
D Leg 2
ERegulator Assembly 1
E
D
A
B
C
6
ASSEMBLY INSTRUCTIONS
1. First, remove pre-assembled four
M6x12 screws from rebox assembly (A), then
attach leg (D) to rebox assembly (A) used
removed screws.
2. Assemble the knob (C) and grease cup (B). 2
1
D
D
A
ACB
7
ASSEMBLY INSTRUCTIONS
3. Assemble the regulator assembly (E).
NOTE: Hand tighten rmly ONLY. DO NOT
over tighten.
4. Hand-tighten the propane cylinder to the
regulator assembly.
3
4
E
Must not be removed on the “X”
8
USE
CHECKING FOR LEAKS
After all connections are made, check all connections and ttings on the propane cylinder valve, and
regulator assembly for leaks with a water and soap solution.
To prevent re or explosion while testing for a leak:
• Always perform leak test prior to lighting the griddle.
• Do not smoke while testing for a leak.
• Always perform leak tests outdoors in a well-ventilated area.
• Do not use any source of ame while testing for leaks.
• Do not use the griddle until any and all leaks are corrected.
• If you are unable to correct a leak, disconnect the propane supply and call a gas appliance service
dealer.
PERFORM LEAK TEST
• Prepare leak test solution by 50/50 ratio of liquid dish soap and water.
Total solution required is approximately 2 - 3 ounces (70 - 90 ml).
Put leak test solution in a spray bottle.
• Ensure the control knob is in the O OFF position.
• Connect the regulator assembly to the gas supply.
• Spray leak test solution on all gas carrying connections and ttings. Presence of bubbles at areas
of applied test solution indicates a gas leak. If leaks are detected or you smell or hear gas, shut off the
gas supply valve immediately and repair or replace the defective part. Do not use the griddle until
all leaks are corrected.
WARNING
ALL INSTRUCTIONS AND SAFEGUARDS ON THIS PAGE MUST BE FOLLOWED TO
PREVENT FIRE, DAMAGE AND/OR INJURY.
CAUTION
Only use the regulator assembly provided! If a replacement is necessary, please call
our customer service center. Do not use replacement parts that are not intended for this griddle.
9
USE
CONNECTING GAS CYLINDER
The propane gas supply cylinder to be used must be constructed and marked in accordance with the
Specications for LP Gas Cylinders of the U.S. Department of Transportation (D.O.T.) or the National
Standard of Canada, CAN/CSA-B339, Cylinders, Spheres and Tubes for Transportation of Dangerous
Goods; and Commission, as applicable; and provided with a listed overlling prevention device.
Use only a 1 lb 16.4 oz disposable propane cylinder with a CGS #600 connection. Cylinder must be
marked “propane”. The gas cylinder should not be dropped or handled roughly!
If the appliance is not in use, the gas cylinder must be disconnected. Storage of an appliance indoors
is permissible ONLY if the cylinder is disconnected and removed from the appliance. Cylinders must
be stored outdoors out of the reach of children and must not be stored in a building, garage or any
other enclosed area. Your cylinder must never be stored where temperatures can reach over 125°F.
Place dust cap on cylinder valve outlet whenever the cylinder is not in use. Only install the type of
dust cap on the cylinder valve outlet that is provided with the cylinder valve. Other types of caps or
plugs may result in leakage of propane.
Before connection, be sure that there is no debris caught in the outlet of the gas cylinder, inlet of the
regulator assembly or in the outlet of the burner and burner ports. Connect regulator assembly and
hand-tighten rmly. Disconnect the propane cylinder from the regulator assembly when the griddle is
not in use.
DO NOT obstruct the ow of combustion air and ventilation air to the griddle. The propane cylin-
der must be arranged for vapor withdrawal and equipped with a listed overlling prevention device.
Please use the proper cylinder orientation to provide vapor withdrawal.
CAUTION
a. Do not store a spare propane cylinder under or near this appliance.
b. Never ll the cylinder beyond 80 percent full.
c. If the information in (a) and (b) is not followed exactly, a re causing death or serious
injury may occur.
10
USE
WARNING
ALL INSTRUCTIONS AND SAFEGUARDS ON THIS PAGE MUST BE FOLLOWED TO
PREVENT FIRE, DAMAGE AND/OR INJURY.
WARNING
In the connection process, make sure:
• the regulator assembly inlet connector mates with the cylinder valve outlet properly, safely and rmly.
