Toa F-5 US Manual de usuario

[Operating Instruction]

PROFESSIONAL SOUND SPEAKER SYSTEM

Model F-5 us

The Toa F-5 is a full-range, bass-reflex type speaker ha ing a 4-inch

(10 cm) speaker with 10-watt power handling capacity. Small in size,

it can be easily mounted on the wall. Push terminals are pro ided on

the rear panel for high impedance applications. By changing the in-

ternal wire connection this speaker can also be used for low impe-

dance applications.

General description

Using the supplied wall mounting pattern for correct positioning, dri e two wood screws

or anchor bolts into the wall surface to a head height of less than 0.3" (8mm). Then insert

two fixing holes on the speaker's rear co er onto the screws or anchor bolts for mounting.

(The pattern is printed on a flap of the carton box containing this speaker.)

Wall

Less

than

0.3"

(8mm)

3" (76mm)

Less than 0.3" (8mm)

Precaution

The speaker weighs

3.5 Ibs (1.6 kg). When there is a

danger that the speaker falls,

reinforce the wall strength with

anchor bolts, etc.

The F-5 is factory-preset to 10 watts (490 ohms). Follow the instructions below to change

the wattage.

Remo e four screws on the rear and detach a baffle board from an enclosure.

Change the connection of a red input lead from the prewired tap to that of desired im-

pedance (wattage). In this e ent, tighten the connection.

To speaker unit (Red and black)

Red lead

Black lead

From input terminal

Do not change the connection

of black lead.

Impedance

Wattage

490 ohms

10W

980 ohms

5W

(The sound pressure le el of siren sound is 90 dB/m or more for any im-

pedance.)

For low impedance applications, remo e a red lead and a black lead

connecting between the matching transformer and speaker unit. Then

connect both leads from the input terminal directly to the speaker unit.

(Connect the red lead to " + " terminal of the speaker unit.)

T pe:

Rated input

power:

Nominal

impedance:

Output sound

pressure level:

Frequenc

response:

Speaker:

Ambient

temperature:

Material:

Dimensions:

Weight:

Bass reflex type

10 watts

490 ohms (10 watts)

980 ohms (5 watts)

88 dB/W/m

100 - 18000 Hz

4" (10 cm) dynamic speaker

–4°Fto +131°F

(–20°C to +55°C)

Polypropylene

7.76(W)×5.43(H)×5.98(D) inches

197(W)×138(H)×152(D) mm

3.5 Ibs

1.6 kg

When not using matching trans

Handling

capacit :

Impedance:

10W (continuous pink noise)

30W (continuous program)

8 ohms

Characteristic Diagram

(1W/1m in anechoic chamber, 1/3 octa e pink noise)

Toa Electric Co., Ltd.

KOBE, JAPAN

133-01-279-60

Installation

Changing the wattage

(impedance)

Specifications
