Tiiwee PIR Motion Sensor TWPIR02
User Manual
Copyright © 2019 Tiiwee. All rights reserved. This manual or any portion thereof may not be reproduced or used in any manner whatsoever.
ENGLISH
Tiiwee PIR Motion Sensor TWPIR02
(For indoor use only)
For Tiiwee Home Alarm System
Introduction
Congratulations with your Tiiwee passive infrared detector (PIR). It is compatible
with the components of the Tiiwee Home Alarm System and can be wirelessly
connected to all Tiiwee 433 MHz Alarm Units (available separately).
This sensor applies digital dual-core fuzzy logic control processing technology and
intelligent analysis algorithms to prevent false alarms. It also features various
settings to adjust the PIR sensor to your personal situation.
Important: This sensor has been programmed to respect a 5 second delay
between 2 signals. This is intentional and will save battery power.
contents
1 x Tiiwee PIR sensor TWPIR02 for Tiiwee Home Alarm System
3 x batteries, 1.5V AAA-type, alkaline
1 x ball-joint mount
2 x screws
1 x instructions for use
Copyright © 2019 Tiiwee. All rights reserved. This manual or any portion thereof may not be reproduced or used in any manner whatsoever.
Product Overview and activation
Open the back panel to insert the batteries. Please respect the correct
polarity. Now, close the back panel again. Slide the ball joint in place until it
locks in place and attach the wall mount on the ball joint. Your PIR sensor is
now ready to be installed on the mount.
General installation guidelines
Avoid positions that are close to a window, air conditioners, fluorescent
lights, heaters, refrigerators, stoves, and direct sunlight and other places
where temperature would change rapidly and air flow is high. If there are
two detectors in the same detecting range, please adjust the position to
avoid interference and false alarms.
Copyright © 2019 Tiiwee. All rights reserved. This manual or any portion thereof may not be reproduced or used in any manner whatsoever.
Attach the detector to the bracket, and change the detecting angle and
distance by adjusting the installation height and the bracket. It is advised
to install the device at a height of approximately 2 meters.
IMPORTANT: The Infrared detector is sensitive to a human’s vertical
movement. It is less sensitive to horizontal movements. Therefore, it is
advised to aim the device at a 90 degrees’ angle to a person’s walking
direction.
Test
1. After the installation, turn the switch to ON. Now, walk or move in front
of the PIR sensor at a distance between 3 and 6 meters.
Copyright © 2019 Tiiwee. All rights reserved. This manual or any portion thereof may not be reproduced or used in any manner whatsoever.
2. The Indicator light should light up once. Note the 5 second delay
between 2 signals. This is normal and intentional to save battery power.
3. If needed, adjust the detector angle to get the desired detection range.
When the detector indicator flashes
•LED flashes once: A signal is detected and the detector sends a
signal to the Alarm unit.
•LED continuously on: Low-voltage indication, please change the
battery as soon as possible.
Connecting the PIR Sensors to an Alarm Siren
This PIR sensor is compatible with the Tiiwee Home Alarm System.
Connect it wirelessly with one of the 433 MHz Alarm Units.
IMPORTANT: The instructions for pairing the PIR sensor with the Tiiwee
Home Alarm System are included with the Alarm units or can be
consulted on our website www.tiiwee.com or one of our Youtube
channels.
Advanced features
The Tiiwee PIR sensor is equipped with some additional features to allow
you to adjust the device to your specific needs. In order to access these
functions, remove the screw at the top of the sensor. Then separate the 2
parts (front and back part) by using an appropriate device (screw driver
i.e.). Now you can see the circuit board with the 2 switches.
Copyright © 2019 Tiiwee. All rights reserved. This manual or any portion thereof may not be reproduced or used in any manner whatsoever.
1. The Indicator light can be switched off to save battery power (“LED
OFF position). Off course, in this mode an alarm signal will still be
sent to the Alarm Unit or the PIR Motion Sensor Alarm. However,
please note that the low battery indication is switched off in this
setting.
2. A waiting time of 5 minutes between detections can be set saving
battery power (“5 Min” vs “5s” switch). The 5-minute waiting
period can be used when your PIR sensor is meant to result in a
strong Siren alarm. This mode however is not advised when you
selected a Chime sound setting on your Alarm unit.
Mode Setting
The factory settings are “5s” and “Led On”. This means that the sensor will
respect a 5-seconds waiting time between 2 signals and that the LED
Copyright © 2019 Tiiwee. All rights reserved. This manual or any portion thereof may not be reproduced or used in any manner whatsoever.
indicator light will always flash if movement is detected. These are the most
commonly used settings.
1. If both switches are set to the ON position as shown in picture 1, the
LED will flash each time a movement is detected. After each signal, a 5
second waiting time is set as a standard to allow a person to pass
without triggering a signal continuously.
2. If the top switch is set to Off the detector will respect a 5-minute delay
before it will become active again. This is a power saving mode. This
setting can perfectly be used with a loud alarm (which will sound
continuously and loud). A Chime setting on the Alarm unit is not advised
with this delay.
3. If the lower switch is set to Off, the Led light will not flash each time a
signal is detected. This can be convenient for saving battery power.
4. If both switches are in the Off position as shown in Figure 2, the PIR
sensor will respect a 5-minute interval between 2 different signals nor will
the LED window flash.
Low-voltage Reminder Function: The indicator light will be continuously
on when the voltage of the PIR is lower than 2.4V unless its light has been
switched off by setting the internal switches.
Copyright © 2019 Tiiwee. All rights reserved. This manual or any portion thereof may not be reproduced or used in any manner whatsoever.
Detection Range Characteristics
Technical Features
Power: The PIR sensor is powered through 3 x AAA 1.5V alkaline batteries
or by an external 5V/1A DC power supply connected through the micro-
USB port. The batteries can stay inside the sensor whilst the external
power supply is connected and in use. They will work as a power backup in
case of 220V power failure. The power adaptor is not included in the
product.
Specifications
Standby Current: <50uA
Working Current:<20mA
Detecting Range: 4-8 m/110 degrees angle
Wireless Distance: 100m ( Open Area )
Wireless Frequency: 433MHz
Housing Material: ABS
Working Humidity: <80%
Detector Size: 106x67x45mm
Copyright © 2019 Tiiwee. All rights reserved. This manual or any portion thereof may not be reproduced or used in any manner whatsoever.
DEUTSCH
Tiiwee PIR Bewegungsmelder TWPIR02
(Für den inneren Gebrauch)
For Tiiwee Home Alarm System
Einführung
Wir beglückwünschen Sie zum Kauf des Tiiwee PIR (Passiv Infrarot)
Bewegungsmelders. Der Sensor ist ein Teil des Tiiwee Home Alarm Systems und
kompatibel mit allen Tiiwee 433 MHz Alarmeinheiten (separat verfügbar).
Der Sensor nutzt die sogenannte "Dual-Core Fuzzy Logic Control Technologie" und
intelligente Analyse-Algorithmen, um Falschalarme zu vermeiden. Der Sensor hat
darüberhinaus verschiedene Einstellmöglichkeiten, um ihn an persönliche
Situationen anzupassen.
WICHTIG: Der Sensor ist mit einer 5 Sekunden Pause zwischen zwei Signalen
programmiert. Dies ist gewollt und dient dem Sparen von Batterie-Leistung.
Was wird geliefert?
1 x Tiiwee PIR Bewegungsmelder TWPIR02 für das Tiiwee Home Alarm System
3 x Batterien, 1.5V AAA, alkalisch
1 x Kugelgelenk-Montageplatte
2 x Schrauben
1 x Gebrauchsanleitung
Copyright © 2019 Tiiwee. All rights reserved. This manual or any portion thereof may not be reproduced or used in any manner whatsoever.
Produktübersicht und Aktivierung
Öffnen Sie den Bewegungsmelder auf der Rückseite und setzen Sie die Batterien
ein. Achten Sie auf die korrekte Polarität. Setzen Sie die Abdeckplatte wieder auf
und verbinden Sie den Sensor mit den Montagekomponenten. Ihr PIR Bewegungs-
melder ist nun fertig für die Montage.
Installationshinweise
Vermeiden Sie Positionen in der Nähe von Fenstern, Klimaanlagen,
fluoreszierendem Licht, Heizungen und anderen Wärmequellen, Kühlschränken,
Kochfeldern und direktem Sonnenlicht - Stellen, an denen plötzliche
Temperaturschwankungen und hohe Luftströme auftreten können. Falls Sie zwei
PIR Bewegungsmelder im gleichen Bereich installiert haben, achten Sie bitte auf
deren Ausrichtung, um Interferenzen und Falschalarme zu vermeiden.
