Tiger Electronics Pokemon Camera Manual de usuario

GETTING STARTED

1. Film Counter Window

2. Shutter Button

3. Built-In Flash

4. Rewind Knob

5. On/Off Switch

6. Camera Lens

7. Flash Ready Light

8. Viewfinder

9. Rewind Release Button

10. Film Advance Wheel

11. Battery Compartment(Bottom of camera)

12. Film Compartment Door Tab

13. Film Loading Compartment

BATTERY INSTALLATION

To open the battery compartment cover, push the

cover in the direction of the arrow (1) marked on the

outside of the cover. Lift the cover to insert the

battery (2).

Insert1xAA/LR6battery(notincluded),makingsure

to align the “+” and “-” signs as shown (3). Return

thebatterycompartmentcovertoitsoriginalposition.

CAUTION

- DO NOT MIX OLDAND NEW BATTERIES.

- DO NOT MIXALKALINE, STANDARD OR RECHARGEABLE

BATTERIES.

- BATTERY INSTALLATION SHOULD BE DONE BY AN ADULT.

- NON-RECHARGEABLE BATTERIESARE NOTTO BE RECHARGED.

- RECHARGEABLE BATTERIES ARE TO BE REMOVED FROM THE

TOY BEFORE BEING CHARGED (IF REMOVABLE).

- RECHARGEABLEBATTERIESARE ONLYTO BE CHARGED UNDER

ADULT SUPERVISION (IF REMOVABLE).

- ONLY BATTERIES OF THE SAME OR EQUIVALENT TYPEAS

RECOMMENDED ARE TO BE USED.

- BATTERIESARETOBE INSERTEDWITHTHE CORRECT POLARITY.

- EXHAUSTED BATTERIES ARE TO BE REMOVED FROM THE TOY.

- THE SUPPLY TERMINALSARE NOT TO BE SHORT-CIRCUITED.

CHOOSING FILM

Thiscameraaccepts standard 35mm (135mm) film with up to36exposures.

Suggest to use ISO 400 film.

LOADING THE FILM

1. Move the film compartment door tab to the

right to open the film compartment door.

2. Insert the film cartridge into the left side of the

filmcompartment. Makecertainthefilm cartridge

fits securely or the film will not advance.

3. Pull out the film cartridge leader from the

cartridge and insert the tip of the film into the

slot of the take-up spool. The take-up spool is

locatedontherightsideofthefilmcompartment.

Turn the manual film wheel so the slot for the

film is facing up. Make certain the film leader

fits completely into the slot before proceeding.

The second or third lower perforation on the film

must lock onto the small tab on the edge of the slot.

4. Turn the film advance wheel to the right until it

stops turning. Make certain that the upper

perforations on the film are properly aligned with

the film wheel between the two filcompartments.

If the film advance wheel does not stop, the film

has not been loaded properly.

5. Press the shutter button once and turn the film

advance wheel again to make certain the film

has wound onto the take up spool properly.

6. Close the film compartment door. Press the

shutter button and turn the film advance wheel

until the number “1” appears in the film counter

window.

POKÉMON BORDER

ThePokémonborderwillappear on each phototaken

with this camera. The border will look like the photo

on the right.

CARRYING STRAP

Place the strap around your wrist. The strap does

not need to be tightened or secured to the wrist.

Placing the strap on the wrist prevents the camera

from falling out of your hands should it be accidently hit.

Carry the camera using the strap to avoid pressing

anybuttons. Becareful not to hit the camera against

any hard objects or it will cause damage to the

camera or lens.

SHUTTER BUTTON

The shutter button must be pressed down each time you take a picture.

Press the button and a slight “click” will be heard to indicate the camera has

taken a picture.

Ages 5 and Up

CAMERA

ON-OFF

21 43

8 10

CAMERA

Instruction Manual

CAMERA

Instruction Manual

IMPORTANT NOTES:

1. The shutter button will not take another picture if the film advance wheel

was not advanced when the previous picture was taken.

2. Theshutter button will not function whenthe film has reached the endof

the film cartridge. Make certain the number of exposures in the film

counter window matches the exposures on the film.

VIEWFINDER

To take a picture, look through theviewfinderlocated

in the middle on the back of the camera.

TURNING ON THE CAMERA WITH BUILT-IN FLASH

Turn ON the camera by sliding the switch to the ON

position. When the “Flash Ready Light” goes on,

the camera is ready to take a picture.

It takes approximately 8 seconds for the flash to

charge after each use. The flash ready light will go

on when the flash is ready.

IMPORTANT NOTE:

Remember to turn OFF the camera when not in use to protect the lens.

TAKING A PICTURE

1. Install new batteries for best results

2. Load the film

3. Turn on the camera and wait until the flash ready light is on

4. Look into the viewfinder

5. Press down on the shutter button

6. Turn the film advance wheel clockwise to advance the film

Congratulations - you have taken a picture using the Pokémon Camera!

FOR BEST RESULTS

1. Turn on the camera and wait for the flash to be charged.

2. Hold the camera steady. If necessary, place the camera on a stable

surface.

3. Press the shutter button gently so the camera does not move.

4. Don’t forget to turn the film advance wheel each time you take a picture.

5. Monitor the film counter window and do not take any pictures when the

number in the window matches the film exposures on the film.

UNLOADING THE FILM

When the film counter window matches the film

exposures on the film, the film cartridge must be

rewound and removed.

To rewind the film, press the rewind release button,

unfoldtherewindcrank,and turn the crankclockwise.

When the film is almost completely rewound, there

will be slight tension against the crank. Continue to turn the crank until the

tension is released and the entire film is wound onto the film cartridge.

Open the film compartment, remove the film and bring the film to a film

processing center.

CAUTION DEFAULT OR DAMAGE

If a part of your game is damaged or something has been left out, DO NOT

RETURN THE GAME TO THE STORE. The store doesn’t have replace-

ment parts. Instead, write to us at:

TIGER ELECTRONICS, LTD. REPAIR CENTER

980 Woodlands Parkway,

Vernon Hills, Illinois 60061, U.S.A.

In your note, mention the name of your game, the game’s model number,

and tell us briefly what the problem is. Also include sales slip, date, place of

980 Woodlands Parkway, Vernon HIlls, Illinois 60061, USA.

www.tigertoys.com

PRINTED IN CHINA

Licensed Product

Official

CREATURES, GAME FREAK.

TM & ® are trademarks of Nintendo.

892010001IWTI-02

AMERA

ON-OFF

90-DAY LIMITED WARRANTY

Tiger Electronics, Ltd. (Tiger) warrants to the original consumer purchaser

of this product that the product will be free from defects in materials or

workmanship for 90 days from the date of original purchase. This

warranty does not cover damages resulting from accident, negligence,

improper service or use or other causes not arising out of defects in

materials or workmanship.

During this 90-day warranty period, the product will either be repaired or

replaced (at Tiger’s option) without charge to the purchaser, when

returned with proof of the date of purchase to either the dealer or to Tiger.

Product returned to Tiger without proof of the date of purchase or after the

90-day warranty period has expired, but prior to one year from the original

date of purchase, will be repaired or replaced (at Tiger’s option) for a

service fee of U.S.$10. Payments must be by check or money order

payable to Tiger Electronics, Inc.

The foregoing states the purchaser’s sole and exclusive remedy for

any breach of warranty with respect to the product.

All product returned must be shipped prepaid and insured for loss or

damage to:

Tiger Electronics, Ltd. Repair Dept.

980 Woodlands Parkway,

Vernon Hills, Illinois 6006l, U.S.A.

The product should be carefully packed in the original box or other

packing materials sufficient to avoid damage during shipment. Include a

complete written description of the defect, a check if product is beyond

the 90-day warranty period, and your printed name, address and

telephone number.

THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES AND NO

OTHER REPRESENTATIONS OR CLAIMS OF ANY NATURE SHALL

BE BINDING ON OR OBLIGATE TIGER IN ANY WAY. ANY IMPLIED

WARRANTIES APPLICABLE TO THIS PRODUCT, INCLUDING

WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A

PARTICULAR PURPOSE, ARE LIMITED TO THE NINETY (90) DAY

PERIOD DESCRIBED ABOVE. IN NO EVENT WILL TIGER BE LIABLE

FOR ANY SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES

RESULTING FROM POSSESSION, USE, OR MALFUNCTION OF THIS

TIGER PRODUCT.

Some states do not allow limitations as to how long an implied warranty

lasts and/or exclusions or limitations of incidental or consequential

damages, so the above limitations and/or exclusions of liability may not

apply to you. This warranty gives you specific rights, and you may also

have other rights which vary from state to state.

For more information about Tiger Electronics, our products and

special promotions, please visit our Web Site at: www.tigertoys.com
