Thor Kitchen HRF3603F Manual de usuario

HRF3603FMODEL:

Contents

Safety and warning information…........2

Installing your new appliance………....8

Description of the appliance….......….11

Display controls…………………...…..12

Using your appliance……………....... 14

Helpful hints and tips……………… 15

Cleaning and care……………………16

Troubleshooting………………………17

Disposal of the appliance……………18

For your safety and correct usage before installing and first

using the appliance, read this user manual carefully, including

its hints and warnings. To avoid unnecessary mistakes and

accidents, it is important to make sure that all people using the

appliance are thoroughly familiar with its

operation and safety features. Save these instructions and be

sure that they remain with the appliance if it is moved or sold,

so that anyone using it throughout its life, will be properly

informed on its usage and safety notices.

For the safety of life and property, keep the precautions of

these user's instructions as the manufacturer is not

responsible for damages caused by omission.

This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities,

or lack of experience and knowledge, unless they have been

given supervision or instruction concerning use of the

appliance by a person responsible for their safety.

Children should be supervised to ensure that they

do not play with the appliance.

Keep all packaging away from children as there is risk of

suffocation.

If you are discarding the appliance, pull the plug out of the

socket, cut the connection cable (as close to the appliance

as you can) and remove the door to prevent children playing

from suffering an electric shock or from closing themselves

inside it.

If this appliance, featuring a magnetic door seals, is to

replace an older appliance having a spring lock (latch) on the

door or lid, be sure to make the spring lock unusable before

you discard the old appliance. This will prevent it from

becoming a death trap for a child.

General safety

WARNING —This appliance is intended to be used in

single family residential usage.

WARNING — Do not store explosive substances such as

aerosol cans with a flammable propellant in this appliance.

WARNING — If the supply cord is damaged, it must be

replaced by the manufacturer, its service agent or similarly

qualified persons in order to avoid a hazard.

WARNING — Keep ventilation openings, in the appliance

enclosure or in the built-in structure, clear of obstruction.

WARNING — Do not use mechanical devices or other

means to accelerate the defrosting process, other than those

recommended by the manufacturer.

WARNING — Do not damage the refrigerant tubing.

WARNING — Do not use electrical appliances inside the

food storage compartments of the appliance, unless they are

of the type recommended by the manufacturer.

WARNING — The refrigerant and insulation blowing gas are

flammable. When disposing of the appliance, do so only at

an authorized waste disposal centre. Do not expose to

flame.

WARNING —When positioning the appliance, ensure the

supply cord is not trapped or damaged.

WARNING —Do not locate multiple portable socket-outlets

or portable power supplies at the rear of the appliance.

Refrigerant

The refrigerant isobutene (R600a) is contained within the

refrigerant circuit of the appliance, a natural gas with a high

level of environmental compatibility, which is nevertheless

flammable. During transportation and installation of the

appliance, ensure that none of the components of the

refrigerant circuit becomes damaged.

The refrigerant (R600a) is flammable.

WARNING — Refrigerators contain refrigerant andgases in

the insulation. Refrigerant and gases must be disposed of

professionally as they may cause eye injuries or ignition.

Ensure that tubing of the refrigerant circuit is not damage

prior to proper disposal.

Replacing the illuminating lamps

WARNING—The illuminating lamps must not be replaced by

the user! If the illuminating lamps is damaged, contact the

customer helpline for assistance.

This warning is only for refrigerators that contain illuminating

lamps.

WARNING:risk of fire

If the refrigerant circuit should be damaged:

-Avoid opening flames and sources of ignition.

-Thoroughly ventilate the room in which the appliance is

situated.

ADVERTENCIA:

Daily use

Do not store flammable gass or liquids in the appliance,

There is a risk of an explosion.

Do not operate any electrical appliances in the appliance

(e.g.electric ice cream makers,mixers etc.).

When unplugging always pull the plug from the mains

socket,do not pull on the cable.

Do not place hot items near the plastic components of this

appliance.

Electrical safety

1.The power cord must not be lengthened.

2. Make sure that the power plug is not crushed or damaged.

A crushed or damaged power plug may overheat and cause a

fire.

3. Make sure that you can access the main plug of the

appliance.

4. Do not pull the main cable.

5. If the power plug socket is loose, do not insert the power

plug. There is a risk of electric shock or fire.

6.You must not operate the appliance without the interior

lighting lamp cover.

7.The fridge is only applied with power supply of single phase

alternating current of 115V/60Hz. If fluctuation of voltage

in the district of user is so large that the voltage exceeds the

above scope, for safety sake, be sure to apply A.C. Automatic

voltage regulator of more than 350W to the fridge. The fridge

must employ a special power socket instead of common one

with other electric appliances. Its plug must match the socket

with ground wire.

It is dangerous to alter the specifications or modify this

product in any way.

Any damage to the cord may cause a shortcircuit, fire, and/or

electric shock.

Do not place food products directly against the air outlet on

the rear wall.

Store pre-packed frozen food in accordance with the frozen

food manufacture’s instructions.

The appliances manufactures storage recommendations

should be strictly adhered to.Refer to relrelevant instructions

for storage.

Do not place carbonated or fizzy drinks in the freeze

compartment as it creates pressure on the container,which

may cause it to explode,resulting in damage to the

appliance.

Frozen food can cause frost burns if consumed straight from

the freezer compartment.

Do not place the appliance in direct sunlight.

Keep buring candles,lamps and other items with naked

flames away from the appliance so that do not set the

appliance on fire.

The appliance is intended for keeping food stuff and/or

beverages in normal household as explained in this

instruction booklet The appliance is heavy.Care should be

taken when moving it.

Do not remove nor touch items from the freezer

compartment if your hands are damp/wet,as this could cause

skin abrasions or frost/freezer burns.

Never use the base,drawers, doors etc. to stand on or as

supports.

Frozen food must not be refrozen once it has been thawed

out.

Do not consume ice popsicles or ice cubes straight from

the freezer as this can cause freezer burn to the mouth

and lips.

To avoid items falling and causing injury or damage to

the appliance, do not overload the door racks or put too

much food in the crisper drawers.

caution!

Care and cleaning

Adequate air circulation should be around the appliance,

lacking this leads to overheating. To achieve sufficient

ventilation, follow the instructions relevant to installation.

Wherever possible the back of the product should not be too

close to a wall to avoid touching or catching warm parts

(compressor, condenser) to prevent the risk of a fire, follow

the instructions relevant to installation.

The appliance must not be locate close to radiators or

cookers.

Make sure that the mains plug is accessible after the

installation of the appliance.

Service

Any electrical work required to do the servicing of the

appliance should be carried out by qualified electrician or

competent person.

This product must be serviced by an authorized Service

Center, and only genuine spare parts must be used.

1)If the appliance is Frost Free.

2)If the appliance contains freezer compartment.

Installation Important!

For electrical connection carefully, follow the instructions

given in this manual.

Unpack the appliance and check if there are damages on it.

Do not connect the appliance if it is damaged. Report

possible damages immediately to the place you bought it. In

this case retain packing.

It is advisable to wait at least four hours before connecting

the appliance to allow the oil to flow back in the compressor.

Before maintenance, switch off the appliance and disconnect

the mains plug from the mains socket.

Do not clean the appliance with metal objects, steam

cleaner, ethereal oils, organic solvents or abrasive

cleansers.

Do not use sharp objects to remove frost from the appliance.

Use a plastic scraper.

Installing your new appliance

Ventilation of appliance

Before using the appliance for the first

time, you should be informed of the

following tips.

In order to improve efficiency

of the cooling system and save

energy, it is necessary to maintain

good ventilation around the appliance

for the dissipation of heat. For this

reason, sufficient clear space should

be available around the refrigerator.

Suggest :It is advisable for there to be

at least 50-70mm of space from the

back to the wall, at least 100mm from

its

top,at last 100mm from its side to the

wall and a clear space in front to allow

the doors to open 145°. As shown in

following diagrams.

Note:

the climate class showed in the table

below.

This appliance performs well within

It may not work properly if being

left at a temperature above or below

the indicated range for a long period.

908mm

650mm

765mm

1410mm

120°

Leveling of appliance

For sufficient leveling and air

circulating in the lower rear section of

the appliance, the bottom feet may

need to be adjusted.

●

To allow the doors to self-close, tilt

the top backwards by about 10mm.

Stand your appliance in a dry place to

avoid high moisture.

Keep the appliance out of direct

sunlight，rain or frost. Stand the

appliance away from heat sources

such as stoves, fires or heaters.

●

≤10mm

You can adjust them manually by

hand or by using a suitable spanner.

●

100

50~70

properly, a water pressure should be

required.

-the maximum inlet water pressure

is 862kPa;

-the minimum inlet water pressure

is 207kPa.

Water filters are not included on your

new appliance, to help promote better

health, you may need to purchase

a water purifying system to do that.

In order for the ice maker to operate

The water connection must be made by

a qualified plumber. Operation outside

the water pressure range may cause

malfunction, severe and damaging

water leaks.

Under normal conditions, a 200cc

(5.75 oz.) cup can be fill in about

10 seconds.

If the refrigerator is installed in

an area with low water pressure

(blow 30 psi),you can install a booster

pump to compensate for the low pressure.

1. Power drill and 1/4’’ drill bit.

2. 1/2’’ or adjustable wrench.

3. Flat blade and Philips head screwdrivers.

4.You may find these items sold as a kit

at local hardware store.

5. These items are provided with your fridge.

Please check your fridge drawer to find them.

1.First ,shut off the main water supply.

2.Using the power drill and a 1/4’’ drill

bit drill into the cold water line and

connect the saddle-type shutoff valve.

3.Connect 1/4’’ extension tubing to shutoff

valve outlet.

4.Flush the tubing .Turn the main water

supply on and flush out the tubing until

the water is clear.Then , shut the water off

at the water valve after about quart of water

has been flushed through the tubing.

5.Connect the extension tubing line with

the line on the back of the fridge via the

coupler .Fully insert the extension tubing

into the coupler, and then insert the clip

onto the coupler to lock up the tubing.

Do the same with the other end. After both

clips are inserted ,check the line to make

sure it is held firmly by the clip.

Ensure that water line does not get

pinched or bent when installing. This can

result in improper water flow through the

line and will affect the functionality of

the fridge.

6.Turn the water on and check for leakage.

Ensure that water line does not get

Ensure that water line does not getEnsure that water line does not getEnsurethat water line does not getEnsurethat water line does not getEnsure that water line does not getEnsurethat water line does not getEnsurethat water line does not get

Use only the new tubings supplied with the

refrigerator. Old tubing should not be used.

After connected to the water supply line,

please open the water value to flush the

filter for 5 minutes before use.

The initial dark discoloration of water is

normal.

It is normal that there will be a sound that

exhaust comes out from the appliance when

you connect the water line to the appliance

and press the lever of the dispenser for

the first time.

The water line must be connected to the

cold water pipe. If it is connected to the

hot water pipe, it may cause the purifier

to malfunction.

Avoid contamination of pipes during

installation.

Connect to potable supply only.

Filled with the potable water only.

The water line must be connected to the

The water line must be connected to theThe water line must be connected to theThe water line must be connected to theThe water line must be connected to theThe water line must be connected to theThe water line must be connected to theThe water line must be connected to the

Avoid contamination of pipes during

Avoid contamination of pipes duringAvoid contamination of pipes duringAvoid contamination of pipes duringAvoid contamination of pipes duringAvoid contamination of pipes duringAvoid contamination of pipes duringAvoid contamination of pipes during

Connect to potable supply only.

Connect to potable supply only.Connect to potable supply only.Connect to potable supply only.Connect to potable supply only.Connect to potable supply only.Connect to potable supply only.Connect to potable supply only.

Filled with the potable water only.

Filled with the potable water only.Filled with the potable water only.Filled with the potable water only.Filled with the potable water only.Filled with the potable water only.Filled with the potable water only.Filled with the potable water only.
