THOMSON Network Router Manual de usuario

Wireless Cable Gateway

User’s Guide

PC Link

Internet On/Off

ONLINE

PowerEth4. WLAN/USB DS

Eth2.

Eth1. Eth3.

DCW725 book file.indb 1DCW725 book file.indb 1 10/6/04 11:17:08 AM10/6/04 11:17:08 AM

CAUTION

Disconnect power before

servicing.

CAUTION

To ensure reliable operation and to prevent overheating, provide

adequate ventilation for this modem and keep it away from

heat sources. Do not locate near heat registers or other heat-

producing equipment. Provide for free air ﬂow around the cable

modem and its power supply.

CABLE INSTALLER:

This reminder is provided to call your attention to Article 820-40 of the National Electrical Code

(Section 54 of the Canadian Electrical Code, Part 1) which provides guidelines for proper grounding

and, in particular, speciﬁes that the cable ground shall be connected to the grounding system of the

building as close to the point of cable entry as practical.

DOCSIS compliant

This product was designed according to Data Over Cable Service Interface Speciﬁcations.

It will operate on any DOCSIS-compliant Hybrid Fiber Coax (HFC) cable system and offers DOCSIS

Baseline Privacy to promote secure Internet transactions.

Power cord Requirement

This product must be operated with the supplied line cord or with a line cord meeting

IEC227 H03 VV-F or IEC227 H03 VVH2-F having conductors with a cross-sectional area

not less than .75mm2.

Operating Information

Operating Temperature:0˚ - 40˚ C (32˚ - 104˚ F)

Storage Temperature:-30˚ to 65˚ C

If you purchased this product at a retail outlet, please read the following:

Product Registration

Please ﬁll out the product registration card that came with this product and return it immediately. Returning the card

allows us to contact you if needed.

Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here and record the

serial and model numbers in case you need them. The numbers are located on the back of the product.

Model No. ____________________________________ Serial No _____________________________________________

Purchase Date: _________________________________ Dealer/Address/Phone: _______________________________

Safety Information

DCW725 book file.indb 2DCW725 book file.indb 2 10/6/04 11:17:15 AM10/6/04 11:17:15 AM

Table of Contents

Chapter 1: Connections and Setup

Introduction ....................................................................................4

Wireless Cable Gateway Features .......................................................................... 4

What’s on the CD-ROM............................................................................................. 5

Computer Requirements ........................................................................................... 6

Wireless Cable Gateway Overview................................................6

Important Information .............................................................................................. 7

System Overview.............................................................................8

Understanding the Wireless Cable Gateway ...............................8

Your PC: Installing a PC Network Card ........................................9

Your PC: Installing a TCP/IP Stack ..............................................10

Your PC: Conﬁguring DHCP on a TCP/IP Stack on a PC ...........12

Conﬁguring Windows Me PCs.....................................................13

Conﬁguring Windows 2000 PCs .................................................14

Conﬁguring Windows XP PCs......................................................14

Connecting Your Devices .............................................................15

Activating the Wireless Cable Gateway.....................................15

Initialization ...............................................................................................................15

Mandatory User Conﬁguration ...................................................16

Chapter 2: Networking

Communications ..........................................................................19

USB MAC Address .......................................................................27

MAC and IP Addresses Summary ................................................28

DCW725 book file.indb 1DCW725 book file.indb 1 10/6/04 11:17:16 AM10/6/04 11:17:16 AM

Table of Contents

Chapter 3: Advanced Conﬁguration

Advanced User Conﬁguration......................................................29

Status Web Page Group...............................................................30

Software Web Page .................................................................................................30

Connection Web Page..............................................................................................31

Password Web Page ................................................................................................32

Event Log Web Page ................................................................................................33

Diagnostics Web Page .............................................................................................33

Network Basic Web Page Group .................................................34

WAN Web Page ........................................................................................................34

LAN and Computers Web Pages ..........................................................................35

Advanced Web Page Group .........................................................36

Options Web Page ...................................................................................................36

IP Filtering Web Page .............................................................................................37

MAC Filtering Web Page ........................................................................................37

Port Filtering Web Page .........................................................................................38

Forwarding Web Page .............................................................................................39

Port Triggers Web Page ..........................................................................................40

DMZ Host Web Page ...............................................................................................41

Routing Information Protocol Setup Web Page...............................................42

Firewall Web Pages Group...........................................................43

Web Content Filter and Parental Control Web Pages ...................................43

Time of Day Access Filter Web Page....................................................................44

Local Log and Remote Log Web Pages................................................................45

DCW725 book file.indb 2DCW725 book file.indb 2 10/6/04 11:17:17 AM10/6/04 11:17:17 AM

Table of Contents

Wireless Web Pages Group ..........................................................46

Performance................................................................................................................46

Authentication...........................................................................................................46

Privacy..........................................................................................................................47

802.11b/g Basic Web Page ....................................................................................47

802.11b/g Privacy Web Page .................................................................................49

802.11b/g Advanced Web Page ............................................................................53

802.11b/g Access Control Web Page ...................................................................55

Determining WiFi MAC Address............................................................................56

Bridging Web Page ...................................................................................................58

Chapter 4: Additional Information

Troubleshooting ............................................................................59

Front of the Unit ..........................................................................60

Back of the Unit ...........................................................................61

Description of Jacks .................................................................................................61

Detailed Explanation of Jacks ....................................................62

Care and Cleaning ........................................................................63

Service Information......................................................................63

FCC Declaration of Conformity and Industry

Canada Information ....................................................................64

Product Speciﬁcations .................................................................65

DCW725 book file.indb 3DCW725 book file.indb 3 10/6/04 11:17:17 AM10/6/04 11:17:17 AM

Chapter 1: Connections and Setup

Illustrations contained in this document are for representation only.

4 Chapter 1

Introduction

Wireless Cable Gateway Features

Thank you for purchasing the DCW725 Wireless Cable Gateway. This device delivers the highest

performance in data over cable technology. Ideal for home and small business users, this easy-

to-use communication device offers reliable connectivity as well as remarkable data transfer

rates – up to 600 times faster than a 56K dial-up modem. Once the DCW725 is activated, you are

online to enjoy real-time 3D animation, video conferencing, and perform other data intensive

tasks.

The Wireless Cable Gateway provides high-speed, reliable and secure transport capabilities and

is designed with DOCSIS upgrade ability for both DOCSIS 1.0, 1.1, and 2.0. The gateway offers

anti-spooﬁng functions, resulting in greater subscriber privacy and higher system availability.

Advanced features such as WLAN IEEE 802.11b/g, NAT, Firewall, VPN pass through and

CableHome are also available now and can be conﬁgured.

DCW725 book file.indb 4DCW725 book file.indb 4 10/6/04 11:17:18 AM10/6/04 11:17:18 AM

Chapter 1 5

Chapter 1: Connections and Setup

What’s on the CD-ROM

If you connect a PC using the USB port on your gateway, you’ll need the USB drivers found on the

CD-ROM.

CD-ROM Contents:

• Electronic copy of this user’s guide (.pdf format)

• Adobe Acrobat Reader — application you can load to read .pdf format, if you don’t have it

loaded already

• USB drivers — required if connecting by USB

DCW725 book file.indb 5DCW725 book file.indb 5 10/6/04 11:17:18 AM10/6/04 11:17:18 AM

6 Chapter 1

Chapter 1: Connections and Setup

Computer Requirements

• USB 1.0 or 1.1 (PC only), Ethernet (10/100), 802.11b or g

• A TCP/IP network protocol for each machine

• A network cable with RJ-45 connector for Ethernet connection

• Microsoft Internet Explorer 4.0 or later, or Netscape Navigator 4.0 or later. (5.0 and 4.7 or

later, respectively, are strongly recommended.)

• Windows Me, 2000, or XP for USB

Wireless Cable Gateway Overview

Cable Internet Service Requirements

• cable company that offers DOCSIS-compliant Internet services

Computer Internet

Wirelesss Cable Gateway Cable Company

What the Wireless Cable Gateway Does

The Digital Wireless Cable Gateway serves as a two-way high-speed bridge between your personal

computer and a cable Internet Service Provider (ISP). It converts information that originates from

the Internet or your computer into electronic messages that can be transported over the same

wires your cable company uses to transport video signals.

What the Wireless Cable Gateway Needs to Do Its Job

• The Right Cable Company: Make sure your cable company provides data services that use

cable TV industry-standard DOCSIS technology.

HPNA

WLAN

Power

Test

USB

Full/Col

100/10

Link/Act

Receive

Send

Ready

Link/Act Cable Modem

1 2 3 4

DCW725 book file.indb 6DCW725 book file.indb 6 10/6/04 11:17:18 AM10/6/04 11:17:18 AM

Chapter 1 7

Chapter 1: Connections and Setup

• The Internet Service Provider (ISP): Your cable company provides you access to an Internet

Service Provider (ISP). The ISP is your gateway to the Internet. It provides you with a pipeline

to access Internet content on the World Wide Web (WWW).

Check with your cable company to make sure you have everything you need to begin; they’ll

know if you need to install special software or re-conﬁgure your computer to make your

cable Internet service work for you.

Contact Your Local Cable Company

You will need to contact your cable company to establish an Internet account before you can

use your gateway. You should have the following information ready (which you will ﬁnd on the

sticker on the gateway) :

• The serial number

• The model number

• The Media Access Control (MAC) address

Record your information here:

Serial Number:__________________________

Model Number: _________________________

MAC Address:___________________________

S.N.

MODEL:

MAC:

XXXXXXXXXXXXXX

DCWXXX

009064XXXXXX

Please verify the following with the cable company:

• The cable service to your home supports DOCSIS-compliant two-way modem access.

• Your Internet account has been set up.

• You have a cable outlet near your PC and it is ready for cable modem service.

Note: It is important to supply power to the modem at all times. Keeping your modem plugged in will keep it

connected to the Internet. This means that it will always be ready when you are. To disconnect your computer

from the Internet, use the ON/OFF button to put the modem in standby mode.

Important Information

Your cable company should always be consulted before installing a new cable outlet. Do not

attempt any rewiring without contacting your cable company ﬁrst.

DCW725 book file.indb 7DCW725 book file.indb 7 10/6/04 11:17:18 AM10/6/04 11:17:18 AM

8 Chapter 1

Chapter 1: Connections and Setup

System Overview

The Wireless Cable Gateway is connected between your cable company and the PCs within your

home, as pictured previously in the Wireless Cable Gateway Overview. The connection to the cable

company is made by a coaxial cable, and is referred to as the WAN (Wide Area Network) side of

your Wireless Cable Gateway. The connections to your PCs are made by your choice of several

standard home networking methods: Ethernet, USB, or 802.11b Wireless, and are referred to as the

LAN (Local Area Network) side of your Wireless Cable Gateway. Multiple PCs can use any or all of

the LAN side connections simultaneously to share your single cable company connection, up to a

maximum of 254 PCs total.

Unlike a simple hub or switch, the gateway’s setup consists of more than simply plugging

hardware together. You’ll need to conﬁgure your networked PCs to accept the IP addresses the

gateway assigns them (if applicable), and you will also need to conﬁgure the gateway with

settings provided by your cable company.

Understanding the Wireless Cable Gateway

Connections

Fig. 1

DCW725 book file.indb 8DCW725 book file.indb 8 10/6/04 11:17:19 AM10/6/04 11:17:19 AM

Tabla de contenidos

Otros manuales de Enrutador de red de THOMSON

THOMSON

THOMSON TG608 Guía de seguridad

THOMSON

THOMSON SpeedTouch 605 Manual de usuario

THOMSON

THOMSON SpeedTouch 610 Manual de instrucciones

THOMSON

THOMSON SpeedTouch 608 WL Manual de usuario

THOMSON

THOMSON Speedtouch 600 Series Manual de usuario

THOMSON

THOMSON SPEEDTOUCH 605S Guía de seguridad

THOMSON

THOMSON SpeedTouch Manual de usuario

THOMSON

THOMSON Technicolor TG582n Manual de usuario

THOMSON

THOMSON SpeedTouch 605 Manual de usuario

THOMSON

THOMSON GRASS VALLEY Profile XP PVS3000 Manual de usuario

THOMSON

THOMSON SpeedTouch 210i Manual de usuario

THOMSON

THOMSON TG585 V7 Instrucciones de uso

THOMSON

THOMSON SpeedTouch 610 Manual de usuario

THOMSON

THOMSON SpeedTouch 608 Manual de instrucciones

THOMSON

THOMSON SpeedTouch 716 Manual de usuario

THOMSON

THOMSON TG585 V8 Guía de seguridad

THOMSON

THOMSON Wireless Business DSL Routers... Manual

THOMSON

THOMSON TG585 Manual de usuario

Manuales populares de Enrutador de red de otras marcas

Allnet

Allnet ALL0333AU Manual de usuario

HomeSeer

HomeSeer HT-SEL Manual de usuario

Sercomm

Sercomm Genesis OC3505D Manual de usuario

Billion

Billion BIPAC 5102 Series Manual de usuario

TP-Link

TP-Link TD-8817 Manual de usuario

Motorola

Motorola MR1900 Manual de usuario

Digi

Digi IX14 Manual de usuario

Cisco

Cisco NCS 540 Manual

XAVi

XAVi X8821e Manual de usuario

BEC

BEC 6200WZL Manual de usuario

MikroTik

MikroTik hAP ac3 Series Manual de usuario

Korenix

Korenix JetNet 5428G Series Manual de usuario

NETGEAR

NETGEAR FS526T - Switch Manual de usuario

Korenix

Korenix JetNet 5710G Series Manual de usuario

Automated Logic

Automated Logic ZN551 Manual del propietario

Cisco

Cisco ASR 1000 Series Manual del operador

EnGenius

EnGenius ESR-9710 Manual de usuario

Cisco

Cisco 805 Series Instrucciones de funcionamiento y seguridad
