thomann Achat 110 MA Manual de usuario
Achat 110 MA
active
full-range speaker
user manual
Musikhaus Thomann
Treppendorf 30
96138 Burgebrach
Germany
Telephone: +49 (0) 9546 9223-0
E-mail: [email protected]
Internet: www.thomann.de
15.07.2015, ID: 230511 (V2)
Table of contents
1 General information................................................................................................................................. 4
1.1 Further information........................................................................................................................... 5
1.2 Notational conventions.................................................................................................................... 6
1.3 Symbols and signal words............................................................................................................... 6
2 Features.......................................................................................................................................................... 8
3 Installation.................................................................................................................................................... 9
3.1 Tips on handling speakers............................................................................................................ 10
3.2 Installation.......................................................................................................................................... 11
3.3 Connections....................................................................................................................................... 15
4 Connections and operating elements........................................................................................... 16
5 Technical specifications....................................................................................................................... 18
6 Plug and connection assignment.................................................................................................... 22
7 Protecting the environment.............................................................................................................. 25
Table of contents
Achat 110 MA
3
1 General information
This manual contains important instructions for the safe operation of the unit. Read and follow
the safety instructions and all other instructions. Keep the manual for future reference. Make
sure that it is available to all those using the device. If you sell the unit please make sure that
the buyer also receives this manual.
Our products are subject to a process of continuous development. Thus, they are subject to
change.
General information
active full-range speaker
4
1.1 Further information
On our website (www.thomann.de) you will find lots of further information and details on the
following points:
Download This manual is also available as PDF file for you to download.
Keyword search Use the search function in the electronic version to find the topics of
interest for you quickly.
Online guides Our online guides provide detailed information on technical basics
and terms.
Personal consultation For personal consultation please contact our technical hotline.
Service If you have any problems with the device the
customer service will gladly assist you.
General information
Achat 110 MA
5
1.2 Notational conventions
This manual uses the following notational conventions:
The letterings for connectors and controls are marked by square brackets and italics.
Examples: [VOLUME] control, [Mono] button.
1.3 Symbols and signal words
In this section you will find an overview of the meaning of symbols and signal words that are
used in this manual.
Letterings
General information
active full-range speaker
6
Signal word Meaning
WARNING! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in death or serious
injury if it is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
Warning signs Type of danger
Warning – suspended load.
General information
Achat 110 MA
7
2 Features
Special features of this device:
nConnections: XLR/1/4" combo socket for signal input, XLR mounting plug for signal output
nVolume control
nSwitchable low-cut filter to eliminate low frequencies
nPower supply switch
n36 mm pole flange on the bottom
nM10 rigging points
nBlack textured coating
nOptionally available accessories:
– Vertical bracket the box pro Achat 110M U-bracket (item no. 258813: black)
– Safety rope Stairville Safety 80 cm / 4 mm / 15 kg (item no. 328043)
Features
active full-range speaker
8
3 Installation
Unpack and carefully check that there is no transportation damage before using the unit. Keep
the equipment packaging. To fully protect the device against vibration, dust and moisture
during transportation or storage use the original packaging or your own packaging material
suitable for transport or storage, respectively.
Create all connections while the device is off. Use the shortest possible high-quality cables for
all connections. Take care when running the cables to prevent tripping hazards.
Installation
Achat 110 MA
9
3.1 Tips on handling speakers
We recommend you to set up the speakers in a way, that the sound signals can reach the audi‐
ence unobstructedly. It will often be helpful to mount the speakers on tripods. Thus, the sound
will be evenly spread with maximum range throughout the audience area.
Always use high grade cable to connect your equipment. Otherwise you won't reach max‐
imum sound quality.
If you notice distortion during operation, the active speaker is overloaded. This may perma‐
nently damage the device. Always reduce the volume as soon as you hear distortion.
Installation
active full-range speaker
10
