Thermo Scientific TruNarc Manual de usuario

Thermo Scientific

TruNarc

User Guide

110-00056-02

TruNarc is a registered trademark of Thermo Fisher Scientific Inc. in the United States.

Thermo Fisher Scientific Inc. provides this document to its customers with a product

purchase to use in the product operation. This document is copyright protected and any

reproduction of the whole or any part of this document is strictly prohibited, except with the

written authorization of Thermo Fisher Scientific Inc.

The contents of this document are subject to change without notice. All technical

information in this document is for reference purposes only. System configurations and

specifications in this document supersede all previous information received by the purchaser.

Thermo Fisher Scientific Inc. makes no representations that this document is complete,

accurate or error-free and assumes no responsibility and will not be liable for any errors,

omissions, damage or loss that might result from any use of this document, even if the

information in the document is followed properly.

This document is not part of any sales contract between Thermo Fisher Scientific Inc. and a

purchaser. This document shall in no way govern or modify any Terms and Conditions of

Sale, which Terms and Conditions of Sale shall govern all conflicting information between the

two documents.

Thermo Scientific TruNarc User Guide 1

Contents

Preface

Contacting Us ............................................................................................5

Safety Notices.............................................................................................6

Eye Safety...................................................................................................8

Chapter 1 Getting Started

TruNarc Analyzer Front Diagram ..............................................................9

TruNarc Analyzer Side and Bottom Diagrams..........................................10

Carrying Case Contents............................................................................11

Positioning the Self Check Standard.........................................................11

Turning the TruNarc Analyzer On and Off .............................................12

Activating the Laser ..................................................................................13

Opening and Closing the Access Door .....................................................14

Recharging the Battery .............................................................................14

Setting the Date, Time, and Time Zone...................................................15

Using the Wall Plug Adapters...................................................................15

Chapter 2 Performing a Scan

Follow Safe Scanning Practices .................................................................17

How to Get a Good Scan .........................................................................19

Performing a Self Check...........................................................................19

Best Practices for Scanning .......................................................................22

Performing a Scan ....................................................................................24

Understanding Scan Results .....................................................................25

Viewing Stored Scan and Self Check Results ............................................27

Chapter 3 Using the Solution Kit (Type H)

How the Solution Kit (Type H) Works....................................................29

Preparing for a Solution Kit (Type H) Scan .............................................30

Performing a Solution Kit (Type H) Scan ................................................30

Interpreting the Scan Result .....................................................................33

Scanning Black Tar Heroin ......................................................................34

Disposing of Used Test Sticks and Vials ...................................................34

Contents

2TruNarc User Guide Thermo Scientific

Chapter 4 Using the TruNarc Admin Software

Key Parts of the Main Window................................................................ 36

Renaming Columns................................................................................. 37

Changing the Order of Columns ............................................................. 37

Entering Text into Columns.................................................................... 37

Synchronizing Data with the TruNarc Admin Software........................... 38

Searching for Scan Results by Key Words ................................................ 38

Searching for Scan Results by Date .......................................................... 39

Deleting Scan Results from the TruNarc Analyzer ................................... 39

Viewing and Printing Reports.................................................................. 40

Customizing the Report Logo.................................................................. 41

Exporting Scan Results ............................................................................ 42

Viewing the TruNarc Analyzer Library .................................................... 42

Changing the TruNarc Analyzer Time..................................................... 43

Changing the TruNarc Analyzer Language .............................................. 43

Viewing the Admin Software Version Number ........................................ 44

Editing Your TruNarc Admin Account Information................................ 44

Reviewing the TruNarc Admin Operator Training.................................. 44

Chapter 5 Maintenance and Getting Help

Getting Reachback Support ..................................................................... 45

Cleaning the Nose Cone and Self Check Standard................................... 46

Cleaning and Decontaminating the TruNarc Analyzer ............................ 46

Ordering Solution Kit (Type H) Test Sticks and Ethanol Vials ............... 46

Locating the TruNarc Analyzer Serial Number ........................................ 46

Purchasing Scan Credits........................................................................... 47

Transferring Scan Credits to One or More TruNarc Analyzers ................ 49

Checking Whether Scan Credits Were Transferred.................................. 50

Returning the TruNarc Analyzer for Service ............................................ 50

Chapter 6 TruNarc Safety Features

Qualifications for Operators .................................................................... 51

Overview ................................................................................................. 51

Scan Ready Screen ................................................................................... 52

Scan Delay Option .................................................................................. 52

Timeout Feature ...................................................................................... 53

Vial Holder.............................................................................................. 53

Contents

Thermo Scientific TruNarc User Guide 3

Appendix A Regulatory Statements and Warranty

Laser and Electrical Safety Labels..............................................................55

Chemical Safety Labels.............................................................................55

WEEE Compliance ..................................................................................56

WEEE Konformität..................................................................................56

Conformité DEEE ...................................................................................56

Limited Warranty.....................................................................................57

Contents

4TruNarc User Guide Thermo Scientific

Thermo Scientific TruNarc User Guide 5

Preface

The Thermo Scientific™ TruNarc™ analyzer is a 785-nm Raman

spectrometer used for the rapid identification of suspected narcotics.

Designed for law enforcement organizations, this handheld narcotics

identification system analyzes most substances through sealed packaging and

provides clear, definitive results. Using the companion TruNarc Admin

software, results may be uploaded to a computer, and reports may be

generated for every scan.

This guide describes how to scan substances with the TruNarc analyzer,

interpret scan results, use the TruNarc Admin software to set up and manage

a database of results, purchase scan credits, and maintain the instrument.

This guide includes a Safety section, Chapter 6, that describes the safety

features of the TruNarc. These safety features were designed to address the

inherent danger associated with clandestine (Clan Labs). Be sure to review

these features before using TruNarc in this environment.

Contacting Us

Telephone USA 1-800-374-1992

International +1-978-642-1100

Email [email protected]

Website www.thermoscientific.com/trunarc-support

Mail 2 Radcliff Road, Tewksbury, MA 01876

PPreface

6TruNarc User Guide Thermo Scientific

Safety Notices

The TruNarc analyzer is designed to be used in a typical field environment

and is therefore considerably more rugged than a laboratory instrument.

However, the user should recognize that this is a precision scientific

instrument. Abuse and mistreatment of the TruNarc analyzer may lead to

degraded performance or premature failure.

CAUTION

The TruNarc analyzer is not designed to be intrinsically safe, and the user

should take the necessary precautions when using the analyzer.

CAUTION

Do not use the TruNarc analyzer unless you have been trained in its use.

CAUTION

The TruNarc analyzer incorporates a laser diode that emits a maximum

350-mW beam at 785 nm. A 9-mm focal length lens is used to concentrate the

energy on a sample. The beam diameter at the plane of the focal lens is

approximately 9.6 mm.

CAUTION

CAUTION: This instrument is certified as a Class IIIB laser product to the

requirements of the U.S. Federal Product Performance Standard for Laser

Products contained in the regulations of 21 CFR Sub-Chapter “J” except for

deviations pursuant to Department of Health and Human Services issued Laser

Notices. The TruNarc analyzer also complies with IEC 60825-1 Ed. 2(2007).

CAUTION

Exposure to Class IIIB levels of laser energy can be hazardous. Avoid exposure

to the beam. Exposure to specular (mirror-like) reflections should also be

avoided. Never point the TruNarc analyzer at anyone. In the absence of a

workplace safety standard or requirements, refer to the American National

Standard ANSI Z136.1 for the safe use of lasers or the International Standard

IEC 60825-14 user's guide for guidance on identifying and controlling hazards

associated with laser use. Calculations performed in accordance with the

recommended practices of ANSI Z136.1 and IEC 60825-1 give a Nominal

Ocular Hazard Distance (NOHD) of approximately 14 inches (35 cm) from the

sample point of the lens and an estimated optical density (OD) greater than 3.

CAUTION

Exposure to levels of laser energy above the maximum permissible exposure

(MPE) can be harmful to the eye. The MPE for this analyzer is 1.48 mW/cm2.

The emitted energy must travel a minimum distance of 14 inches (35 cm)

before its concentration is below the MPE for normal viewing. This distance is

defined as the hazard zone. With proper use, exposure to levels above the

MPE can be avoided. Avoid exposure to the beam.

Preface P

Thermo Scientific TruNarc User Guide 7

CAUTION

Use administrative controls, engineering controls, and/or laser safety glasses

to avoid exposure to laser radiation within the 14-inch (35 cm) hazard zone. Use

laser safety eyewear of an optical density (OD) greater than 3 at 785 nm.

14-inch (35 cm)

hazard zone

CAUTION!

CAUTION

Do not operate the TruNarc analyzer if the laser aperture is cracked. When the

laser aperture is cracked, the instrument’s laser beam is collimated rather than

divergent, and the laser is no longer safe to operate under any circumstances.

The laser aperture is most likely to crack when you drop the instrument. To

check for cracks, turn the instrument off, remove the nose cone, and check the

integrity of the laser aperture. If the laser aperture is cracked, take the

instrument out of service and contact Thermo Fisher Scientific Customer

Support.

CAUTION

There are no user-serviceable components inside the TruNarc analyzer. The

connector compartment door may be opened, but do not open the protective

enclosure or modify the electronics within. All service operations must be

performed by Thermo Fisher Scientific or an authorized service agent of Thermo

Fisher Scientific. Any attempt by the user to open the TruNarc analyzer will

render the warranty null and void.

CAUTION

WARNING: Use of controls, adjustments, or performance of procedures other

than those specified herein or those specified by the manufacturer's personnel

may result in a hazardous condition.

CAUTION

Follow your organization's procedure and regulations for the handling of

unknown substances. WARNING: Scanning a thermally sensitive material

contained in a tightly sealed vessel (e.g., capped jar or vial) with the TruNarc

analyzer may cause a pressure build up and subsequent explosion of the

vessel.

PPreface

8TruNarc User Guide Thermo Scientific

Eye Safety

CAUTION

The Solution Kit (Type H) holds vials of ethanol. These vials are used in the

testing procedure. Ethanol is categorized as a hazardous good and a flammable

substance. Consult the Materials Safety Data Sheet (MSDS) on ethanol for

detailed safety information. You will find a copy of the MSDS inside the box in

which the Solution Kit (Type H) is packaged. Be sure to check shipping

regulations and requirements before shipping the Solution Kit (Type H) or

transporting it on an airplane. Do not ship broken or leaking ethanol vials.

CAUTION

Do not point the instrument at the eyes of other people.

CAUTION

Do not look at the laser aperture when the laser is on. Keep your eyes outside

the laser’s Hazard Zone of approximately 14 inches (35 cm), measured from the

laser’s aperture.

Tabla de contenidos

Otros manuales de Instrumento de medición de Thermo Scientific

Thermo Scientific

Thermo Scientific RadEye G20-ER Manual de usuario

Thermo Scientific

Thermo Scientific 20-35-NM-F Manual de usuario

Thermo Scientific

Thermo Scientific Orion AquaMate 8000 UV-Vis Manual de usuario

Thermo Scientific

Thermo Scientific Polysonics SX30 Manual de usuario

Thermo Scientific

Thermo Scientific Russell RL060C Manual de usuario

Thermo Scientific

Thermo Scientific Odalog L2 Series Manual de usuario

Thermo Scientific

Thermo Scientific Orion Star Manual de usuario

Thermo Scientific

Thermo Scientific Russell RL060P Manual de usuario

Thermo Scientific

Thermo Scientific 48i Manual de usuario

Thermo Scientific

Thermo Scientific Orion AquaMate UV-Vis Manual de usuario

Thermo Scientific

Thermo Scientific SENTINEL RadEye G Manual de usuario

Thermo Scientific

Thermo Scientific Multiskan Sky Manual de usuario

Thermo Scientific

Thermo Scientific Oakton pH 450 Manual de usuario

Thermo Scientific

Thermo Scientific Scientific AquaSensors DataStick Manual de usuario

Thermo Scientific

Thermo Scientific 20 GENESYS Manual de usuario

Thermo Scientific

Thermo Scientific 48iQTL Manual de usuario

Thermo Scientific

Thermo Scientific Applied Biosystems SeqStudio Genetic... Manual de usuario

Thermo Scientific

Thermo Scientific 43iQTL Manual de usuario

Thermo Scientific

Thermo Scientific MIRAN 205B Series Manual de usuario

Thermo Scientific

Thermo Scientific Eutech TN-100 Manual de usuario

Thermo Scientific

Thermo Scientific AutoXP Manual de usuario

Thermo Scientific

Thermo Scientific AquaSensors AV38 Manual de usuario

Thermo Scientific

Thermo Scientific Orion 2117HL Manual de usuario

Thermo Scientific

Thermo Scientific Evolution One Series Manual de usuario

Manuales populares de Instrumento de medición de otras marcas

Suaoki

Suaoki D40 Manual de usuario

Elster

Elster BK-G1.6 Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manual

Duratool

Duratool D03128 Manual de usuario

Vega

Vega VEGAPULS 65 Manual de usuario

Tonghui

Tonghui TH2618B Manual de usuario

Tenmars

Tenmars TM-801 Manual de usuario

MSR

MSR 145 Manual de usuario

TPS

TPS WP-82 Manual de usuario

ELMETRON

ELMETRON CP-511 Manual de usuario

PCB Piezotronics

PCB Piezotronics 003C30 Manual de usuario

Tenma

Tenma 72-10465 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag 50 Especificaciones técnicas

Siemens

Siemens SITRANS F Coriolis FCT030 Manual de lista de piezas

KLINGER

KLINGER CMF V Series Manual de usuario

EXFO

EXFO FTB-2 Manual de operación y mantenimiento

Keysight

Keysight M8290A Manual de usuario

ADTEK

ADTEK MW-5 Manual de usuario
