Introduction

Thermo Fisher Scientific Smart-Vue Dry Contact Module Installation Guide 3

Introduction Congratulations and thank you for choosing the Thermo Scientific

Smart-Vue wireless monitoring end-point module. This manual covers

Smart-Vue end-point modules for use with dry contact devices.

This guide describes how to get your new Smart-Vue end-point module up

and running quickly. Detailed configuration instructions and software

settings are provided in the complete Thermo Scientific Smart-Vue Software

User Manual provided with your product.

Package contents • Smart-Vue wireless monitoring end-point module with battery – 3.6V

Lithium, 3600 mA (p/n SVU503-500-LSB) and attached 2-wire cable

to connect to the dry contact sensor

• Smart-Vue mounting kit with plastic holder, magnet, screws, cable ties

and plastic cable holders and Velcro®

• Documentation CD-ROM

Product overview The Smart-Vue dry contact wireless end-point module can be connected to

any industry-standard device with a dry contact output. Dry contact devices

do not generate any power. The Smart-Vue end-point module emits a low

current to detect whether the switch on the other device is open or closed.

Typical devices that provide a dry contact output include alarm units, door

open/close sensors, and switches. The Smart-Vue end-point module can be

configured to detect either a “normally closed” or “normally open” state to

correspond with the device to monitor. The Smart-Vue end-point module

indicates open or closed in large characters on its LCD display.

Main features • Configurable data logging, wireless transmission and alerts

• Automatic wireless set-up

• Wireless range indoors: 25-100 meters (82-328 ft); up to 400 meters

(1,312 ft) with 3 repeaters

• Operating temperature range for wireless end-point module: 0°C to

+50°C

What is a Smart-Vue wireless end-point module?

4 Smart-Vue Dry Contact Module Installation Guide Thermo Fisher Scientific

What is a Smart-Vue

wireless end-point

module?

Smart-Vue wireless end-point modules connect to remote devices (e.g.,

sensors) to monitor their status, transmitting information wirelessly to a

central database managed by Thermo Scientific Smart-Vue Server software.

Alerts can be sent automatically in case these readings indicate specific alarm

conditions configured in the software.

Figure 1. Smart-Vue wireless dry contact end-point module with 2-wire

cable

LCD display with

contact state, signal

and battery indicators

Push button

2-wire cable for

dry contact device

What is a Smart-Vue wireless end-point module?

Thermo Fisher Scientific Smart-Vue Dry Contact Module Installation Guide 5

Typical installation Smart-Vue end-point modules transmit remote readings and alerts to a PC

running Thermo Scientific Smart-Vue Server/Smart-Vue Client software

equipped with a wireless receiver. The receiver may also be located remotely

from the PC on a TCP/IP receiver installed directly on an Ethernet

network. Repeaters may be used when the wireless range between the

receiver and the Smart-Vue end-point module is too great to achieve a

strong signal. The diagram below shows these basic configurations:

Figure 2. Typical Smart-Vue wireless configurations

NOTE: Be sure to configure each end-point module (and repeater, if

applicable) to connect to one receiver only, as shown above in Figure 1. Any

given end-point module can only be read by one receiver.

Smart-Vue end-point modules for dry contact monitoring are generally

installed in a convenient location at room temperature.

Requirements and recommendations

6 Smart-Vue Dry Contact Module Installation Guide Thermo Fisher Scientific

Requirements and

recommendations For the purposes of this installation guide we assume that:

• Smart-Vue Server/Smart-Vue Client software is installed and configured

on your computer, and you have appropriate access rights to configure

devices.

• A Smart-Vue receiver is installed and functioning on your computer or

network.

General requirements

and recommendations • The personal computer (PC) running Smart-Vue Server software runs

continuously, 24/7/365, and should be connected to an Uninterruptible

Power Supply (UPS) that protects against power surges and provides

power to back up the PC and components.

• The AC adapter used for your serial receiver (if applicable) should also

be plugged into the UPS.

• The UPS is also recommended as a power backup for your

communication/network systems.

• Weekly manual system testing (e.g., temporarily remove a sensor to

verify the communications system is working) should be performed as

defined in your Standard Operating Procedure (SOP).

• Recommended maintenance and calibration procedures should be

followed.

• If you are storing cold products, Thermo Fisher Scientific recommends

use of a back-up cooling system (e.g., CO2or LN2) to maintain freezer

chamber temperature below the critical level should a power failure

occur. Contact your local sales representative for more information.

• Thermo Fisher Scientific recommends Installation and Operational

Qualifications (IQ/OQ) be performed before initial use.

• For timely notification of an emergency/alarm, it is critical to establish

primary, secondary and tertiary call-out procedures with escalation so

contact is not dependent on reaching one individual. Ideally, ultimate

contact is with a security department or company with 24/7

monitoring.

• End-point modules with internal sensors should not be placed in

cold-rooms.

• Please see the relevant product manuals for details on installing

Smart-Vue receivers and Smart-Vue Server/Smart-Vue Client software.

Where to find more information

Thermo Fisher Scientific Smart-Vue Dry Contact Module Installation Guide 7

Where to find more

information This guide leads you through basic installation steps to get you started with

your product. For more details, please see the Thermo Scientific Smart-Vue

Software User Manual. You may click on Help ==> User manual to open it

directly from within the Smart-Vue Client software.

Installation

procedure The procedure described here assumes that Smart-Vue Server/Smart-Vue

Client software is installed on your computer, and that your Thermo

Scientific wireless receiver is configured and ready to use.

Getting started Wiring the Smart-Vue end-point module to a dry contact device

Connect the 2-wire cable extending from the Smart-Vue end-point module

to the appropriate output on the device where you are measuring the

open/closed status.

For dry contact devices, it is important to establish whether they are

configured for “normally open” (status is considered normal if the contact is

detected as “open”) or “normally closed” (status is considered normal if the

contact is detected as “closed”).

When working with “normally open” devices, the Smart-Vue tests emit a

small charge to test the current loop. If the loop is open, the device’s status is

considered normal. If the loop is closed, an alarm is sent. However, an alarm

will not be sent if the cable between the Smart-Vue end-point module and

the device is cut, as the loop will still be open just as for a “normally open”

condition and the cut cable will not be detected. When working with a

device configured for “normally closed”, the Smart-Vue end-point module

will send an alarm if the cable is cut.

Placing your Smart-Vue

end-point module for

best performance

For optimal operation, follow these recommendations when physically

placing your device:

• Do not place the end-point module within 40 cm (16 inches) of another

module.

• Make sure the wireless end-point module is not placed on an electrical

conduit or cable tray (such as for computer network cables).

• For best results, place the end-point module so that it faces the general

direction of the receiver antenna.

• Keep about 20 cm (8 inches) of clear space around the end-point

module. A module that is “stuck” between two refrigerators may not

communicate effectively.

Otros manuales para Smart-Vue

Tabla de contenidos

Otros manuales de Equipo de laboratorio de Thermo Scientific

Thermo Scientific

Thermo Scientific Microm HM355S Manual de usuario

Thermo Scientific

Thermo Scientific A 40B Manual de usuario

Thermo Scientific

Thermo Scientific QuantStudio 1 Guía de inicio rápido

Thermo Scientific

Thermo Scientific Finnpipette F1 Manual de usuario

Thermo Scientific

Thermo Scientific PDM3700 Manual de usuario

Thermo Scientific

Thermo Scientific TCF-32 Manual de usuario

Thermo Scientific

Thermo Scientific SPD131DDA Manual de usuario

Thermo Scientific

Thermo Scientific Barnstead EASYpure RODI 1332 Series Manual de usuario

Thermo Scientific

Thermo Scientific Sorvall LYNX 4000 Manual de usuario

Thermo Scientific

Thermo Scientific SORVALL RC-5C PLUS Manual de usuario

Thermo Scientific

Thermo Scientific Forma 8602 Instrucciones de funcionamiento

Thermo Scientific

Thermo Scientific 3721 Instrucciones de funcionamiento

Thermo Scientific

Thermo Scientific Orion 2001FC Manual de usuario

Thermo Scientific

Thermo Scientific Sorvall T3 Manual de usuario

Thermo Scientific

Thermo Scientific 495 Series Manual de usuario

Thermo Scientific

Thermo Scientific MAXQ SHKE435HP Instrucciones de funcionamiento

Thermo Scientific

Thermo Scientific Sorvall Legend X1 Manual de usuario

Thermo Scientific

Thermo Scientific MaxQ SHKE420HP Instrucciones de funcionamiento

Thermo Scientific

Thermo Scientific STANDARD Series Manual de usuario

Thermo Scientific

Thermo Scientific Fisher Scientific Fisherbrand GT1R... Manual de usuario

Thermo Scientific

Thermo Scientific 3920 Manual de usuario

Thermo Scientific

Thermo Scientific KingFisher Flex Manual de usuario

Thermo Scientific

Thermo Scientific TRACE 1300 Manual de usuario

Thermo Scientific

Thermo Scientific MaxQ SHKA4000 Manual de usuario

Manuales populares de Equipo de laboratorio de otras marcas

Qiagen

Qiagen DML 3000 Manual de usuario

Queensgate

Queensgate NANOSCAN OP400 Manual de programación

Conviron

Conviron GEN1000-GE Manual de usuario

Parr Instrument

Parr Instrument 4560 Manual de instrucciones

IKA

IKA IC control Manual de usuario

Integra

Integra DOSE IT Manual de usuario

Agilent Technologies

Agilent Technologies 5800 ICP-OES Manual de usuario

Endress+Hauser

Endress+Hauser Cleanfit CPA875 Manual de usuario

NI PXI-5422 Manual

Collomix

Collomix Aqix Manual de usuario

SPEX SamplePrep

SPEX SamplePrep 6875 Freezer/Mill Series Manual de usuario

Ocean Insight

Ocean Insight FLAME-NIR+ Manual de usuario

Parker

Parker ALIGN-MG-NA Manual de usuario

BD 644787 Manual de usuario

DENTAURUM

DENTAURUM Compact Megaplus Manual de usuario

Biuged Laboratory Instruments

Biuged Laboratory Instruments BGD 626 Manual de usuario

VWR

VWR SAS Super IAQ Manual de usuario

illumina

illumina MiSeqDx Manual de usuario
