TFA 30.3018.10.IT Manual de usuario

WIRELESS 868 MHz TEMPERATURE

STATION

Instructions Manual

Cat. No. 30.3018.10.IT

Thank you for choosing this wireless temperature

station from TF .

BEFORE YOU USE IT

Pl as b sur to r ad th instruction manual

car fully.

This information will help you to familiarise yourself with

your new device, learn all of its functions and parts, find

out important details about its first use and how to operate

it, and get advice in the event of faults.

Following the instruction manual for use will prevent

damage to the device and loss of your statutory rights

arising from defects due to incorrect use.

W shall not b liabl for any damag occurring as a

r sult of not following th s instructions.

Pl as tak particular not of th saf ty advic !

Pl as look aft r this manual for futur r f r nc .

SCOPE OF SUPPLY:

• Temperature station (basic unit)

• Outdoor transmitter

• Instruction manual

FIELD OF OPERATION AND ALL OF THE

BENEFITS OF YOUR NEW TEMPERATURE

STATION AT A GLANCE:

• DCF-77 Radio controlled time with manual setting

options

• Time reception ON/OFF

• 12/24 hour display

• Hour and minute display

• Time zone option ±12hours

• Date and month calendar display

• Temperature display in degrees Celsius (°C) or

Fahrenheit (°F) selectable

• Indoor and outdoor temperature display with

MIN/M X recording

• Indoor humidity reading displayed as RH% with

MIN/M X recordings

• ll MIN/M X temperature recordings show date

and time received

• ll MIN/M X recordings can be reset

• Indoor comfort level indicator - happy or sad face

icons

• Can take up to two outdoor transmitters

• LCD contrast setting

• Low battery indicator

• Wireless transmission at 868 MHz

• Signal reception intervals at 4 seconds

• Wall mounting or table standing

FOR YOUR SAFETY:

• The product is exclusively intended for the field of

application described above. The product should

only be used as described within these instructions.

• Unauthorised repairs, modifications or changes to

the product are prohibited.

• The product is not to be used for medical purpose

or for public information, but is intended solely for

home use.

Caution!

Risk of injury:

• Keep this instrument and the batteries out of reach

of children.

• Batteries must not be thrown into the fire, short-

circuited, taken apart or recharged. Risk of

explosion!

• Batteries contain harmful acids. Low batteries

should be changed as soon as possible to prevent

damage caused by a leaking battery. Never use a

combination of old and new batteries together or

batteries of different types. Wear chemical-resistant

protective gloves and glasses when handling

leaked batteries.

! Important information on product saf ty!

• Do not expose the instrument to extreme

temperatures, vibration or shock.

• The outdoor transmitter is protected against splash

water, but is not watertight. Choose a shady and

dry position for the transmitter.

ELEMENTS

THE TEMPERATURE STATION

LCD

Display

Function

Keys

Foldable

stand

Hanging Hole

Battery Cover

THE OUTDOOR TRANSMITTER

• Remote transmission of

outdoor temperature to

temperature station by 868

MHz signal

• Wall mounting case

• Mounting at a sheltered place.

void direct rain and sunshine

HOW TO INSTALL AND REPLACE BATTERIES

IN THE TEMPERATURE TRANSMITTER

The temperature transmitter uses 2 x , IECLR3, 1.5V

batteries. To install and replace the batteries, please

follow the steps below:

1. Slide the battery cover downwards and remove.

2. Insert the batteries, observing the correct polarity

(see marking).

3. Replace the battery cover.

This socket is only for the

external probe. Do not

apply power plug to it.

Optional

external probe

HOW TO INSTALL AND REPLACE BATTERIES

IN THE TEMPERATURE STATION

The temperature station uses 2 x , IEC LR6, 1.5V

batteries. When batteries will need to be replaced, the low

battery symbol will appear on the LCD.

To install and replace the batteries, please follow the

steps below:

1. Insert finger or other

solid object in the

space at the bottom

center of the battery

compartment and lift

up to remove the

cover.

2. Insert batteries

observing the correct

polarity (see battery

compartment marking).

3. Replace battery cover.

Batt ry r plac m nt

• Replace the batteries when the battery symbol of

the temperature station appears near the indoor

temperature display.

• When the batteries of the transmitter are used up,

the low battery icon appears near the outdoor

temperature display.

Not :

In the event of changing batteries in any of the units, all

units need to be reset by following the setting up

procedures. This is because a random security code is

assigned by the transmitter at start-up and this code must

be received and stored by the temperature station in the

first three minutes of power being supplied to it.

SETTING UP:

WHEN ONE TRANSMITTER IS USED

1. First, insert the batteries in the transmitter

(see “How to install and r plac batt ri s

in th t mp ratur transmitt r” below).

2. Within 2 minutes of powering up the

transmitter, insert the batteries in the

Temperature Station (see “How to install

and r plac batt ri s in th t mp ratur

station” below). Once the batteries are in

place, all segments of the LCD will light up

briefly. Following the indoor

temperature/humidity and the time as 0:00

will be displayed. If these information are

not displayed on the LCD after 60 seconds,

remove the batteries and wait for at least 60

seconds before reinserting them. Once the

indoor data is displayed user may proceed

to the next step.

3. fter the batteries are inserted, the

temperature station will start receiving data

signal from the transmitter. The outdoor

temperature data (channel 1 and 2) should

then be displayed on the Temperature

station. If this does not happen after 2

minutes, the batteries will need to be

removed from both units and reset from step

4. In order to ensure sufficient 868 MHz transmission

however, the distance between the temperature

station and the transmitter should not be more than

100 meters (see notes on “Positioning” and “868

MHz R c ption”).

Not :

In the event of changing batteries of the units, ensure the

batteries do not spring free from the contacts. lways wait

at least 1 minute after removing the batteries before

reinserting, otherwise start up and transmission problems

may occur.

OPTIONAL CHANNEL 2 TEMPERATURE PROBE

When the temperature probe is connected to the

temperature transmitter, the temperature station will

always display the outdoor temperature transmitter data in

channel 1, and the temperature recorded from the probe

in channel 2.

If the probe on remote temperature sensor is

unplugged, the "probe channel" will show "---", the

temperature data from the transmitter will still be

displayed.

The temperature probe can be connected to the

temperature transmitter anytime. There is no need to

reset the units. The temperature station will automatically

detect the temperature probe and will display the

temperature probe data in channel 2.

WHEN MORE THAN ONE TRANSMITTER IS USED

1. User shall remove all the batteries from the

Temperature Station and transmitters, and wait 60

seconds.

2. Insert the batteries in the first transmitter.

3. Within 2 minutes of powering up the first

transmitter, insert the batteries in the Temperature

Station. Once the batteries are in place, all

segments of the LCD will light up briefly. Following

the indoor temperature/humidity and the time as

0:00 will be displayed. If these information are not

displayed on the LCD after 60 seconds, remove the

batteries from both units and wait for at least 60

seconds before reinserting them.

4. The outdoor temperature data from the first

transmitter (channel 1 and 2) should then be

displayed on the temperature station. lso, the

signal reception icon will be displayed. If this does

not happen after 2 minutes, the batteries will need

to be removed from both units and reset from step

5. If the temperature probe has been used, the

outdoor temperature from channel 2 will then be

displayed. Otherwise, the outdoor temperature will

display “---“.

Note: The temperature probe from the first sensor

will always occupy “channel 2”. Channel 2 can

only be used for the temperature probe. If you

choose not to use the temperature probe, channel

2 will display “---“.

5. Insert the batteries in the second transmitter as

soon as the outdoor temperature readings from the

first transmitter are displayed on the Temperature

Station.

Note : User shall insert the batteries into the

second transmitter within 45 seconds after the

temperature station displays the information of the

first transmitter. Or immediately after reception of

the first transmitter is finished

6. The outdoor temperature from the second

transmitter and the "channel 3" icon should then be

displayed on the temperature station. If this does

not happen after 2 minutes, the batteries will need

to be removed from all the units and reset from

step 1.

7. In order to ensure sufficient 868 MHz transmission

however, the distance between the temperature

station and the transmitter should not be more than

100 meters (see notes on “Positioning” and “868

MHz R c ption”).

DCF-77 RADIO CONTROLLED TIME

The time base for the radio-controlled time is a Cesium

tomic Clock operated by the Physikalisch Technische

Bundesanstalt Braunschweig which has a time deviation

of less than one second in one million years. The time is

coded and transmitted from Mainflingen near Frankfurt via

frequency signal DCF-77 (77.5 kHz) and has a

transmitting range of approximately 1,500 km. Your radio-

controlled temperature station receives this signal and

converts it to show the precise time in summer or

wintertime. The quality of the reception depends greatly

on the geographic location. In normal cases, there should

be no reception problems within a 1500km radius of

Frankfurt.

Once the outdoor temperature is displayed on the

temperature station, the DCF tower icon in the clock

display will start flashing in the upper left corner. This

indicates that the clock has detected that there is a radio

signal present and is trying to receive it. When the time

code is received, the DCF tower becomes permanently lit

and the time will be displayed.

DCF reception is done twice daily at 02:00 and 03:00 am.

If the reception is not successful at 02:00 am, then the

next reception takes place the next hour and so on until

06:00am, or until the reception is successful. If the

reception is not successful at 06:00 am, then the next

attempt will take place the next day at 02:00 am.

If the tower icon flashes, but does not set the time or the

DCF tower does not appear at all, then please take note

of the following:

Tabla de contenidos

Otros manuales de Termómetro de TFA

Manuales populares de Termómetro de otras marcas

Delton

Delton 981A Manual de usuario

Baker

Baker MM2P Manual de usuario

Tarmo

Tarmo 320281 Manual de usuario

Citizen

Citizen CTD 504 Manual de usuario

Vive

Vive DMD1010 Manual de usuario

Gotemp

Gotemp THB4002 Manual de usuario

GREISINGER

GREISINGER G 1202 Manual de usuario

Amprobe

Amprobe TMD-53W Manual de usuario

Trotec

Trotec BP10 Manual de usuario

Radiance instruments

Radiance instruments RT616 Series Manual de usuario

Eurolec

Eurolec IR151 Manual de usuario

Scaneo

Scaneo TS42B Manual de usuario

Sper scientific

Sper scientific 800043 Manual de usuario

Microlife

Microlife NC 200 Manual de instrucciones

Motorola

Motorola MBP69SN Guía de configuración

The MeatStick

The MeatStick The MeatStick Manual de usuario

Hama

Hama TH35-A Manual de usuario

Veridian Healthcare

Veridian Healthcare 09-349 Manual de usuario
