Texas Microsystems, Inc. P5000HX Series Manual de usuario
User’s Manual
Model P5000HX Series CPU
22875A
June 5, 1996
© Texas Microsystems
All Rights Reserved
Printed in USA
2 Model P5000HX Series CPU User’s Manual
Limited Warranty
(a)Texas Microsystems warrants that the goods sold by it hereunder will be free from
defects in materials or workmanship, under normal use and service, for a period of
two years from date of shipment. Said goods will meet the specifications in effect
at the time of manufacture. Texas Microsystems’ sole obligation under this warranty
shall be, at its option, to repair or replace, without charge, any defective component
part of such product, within a reasonable time period.
(b)Texas Microsystems shall not be liable under this warranty for (i) the goods that
Buyer alleges are defective and have been repaired or altered by someone other than
Texas Microsystems’ designated personnel or authorized representative, unless such
repair or alteration was effected pursuant to prior written approval of Texas
Microsystems, or (ii) where the Buyer fails to notify Texas Microsystems of any
alleged defect within the period of warranty, or (iii) where the Buyer fails to return
defective item to Texas Microsystems, in Houston, Texas, freight prepaid or (iv) where
equipment has been altered or damaged in any way which Texas Microsystems
reasonably determines to personally affect the performance and reliability, or where
the equipment has been subject to misuse, neglect or accident. The rights and
remedies granted to Buyer under this paragraph constitute Buyer’s sole and exclusive
remedy against Texas Microsystems, its officers, agents and employees for negligence,
inexcusable delay, breach of warranty, express or implied, or for any default
whatsoever relating to the condition of the product or Texas Microsystems’s duties to
eliminate any errors.
This warranty is in lieu of any other warranty, whether expressed, implied or
statutory, including, but not limited to, any warranty for fitness of purpose,
merchantability, or freedom from infringement or the like, and any warranty
otherwise arising out of any proposal, specifications or sample. Texas Microsystems
neither assumes nor authorizes any person to assume for it any other liability.
Every effort has been made to ensure that the information provided in this manual is
complete and accurate. However, technical inaccuracies or typographical errors may
be inadvertently included. Texas Microsystems assumes no responsibility for any
errors that may be contained in this document. Texas Microsystems makes no promise
to update or keep current the information contained in this document. Information in
this document, including product specifications, is subject to change without notice.
Model P5000HX Series CPU User’s Manual 3
Notice
This equipment has been tested and found to comply with the limits for a Class A
digital device pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference, in which case the user will be required to correct the interference at the
user’s own expense.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Changes or modifications not expressly approved by Texas
Microsystems could void the product warranty and the user’s
authority to operate the equipment.
This product also meets requirements for compliance with EN55022, Class B ITE.
All tradenames referenced are the service mark, trademark or registered trademark of the respective manufacturer.
4Model P5000HX Series CPU User’s Manual
CHAPTER 1 Introduction to the P5000HX Series
CPU 5
1.1 P5000HX Features 6
1.2 A PCI Discussion 8
CHAPTER 2 7 Steps to P5000HX Operation 11
2.1 Handling the P5000HX 12
2.2 Step 1 - Check Jumper Block Settings 14
2.3 Step 2 - Check Switch Settings 16
2.4 Step 3 - Connect Peripherals to Headers 18
2.5 Step 4 - Install the Board 26
2.6 Step 5 - Attach Peripherals to Connectors 28
2.7 Step 6 - Power-up the System 30
2.8 Step 7 - Run the Setup Utility 32
CHAPTER 3 P5000HX Service and Support 47
3.1 Installing Memory 48
3.2 General Maintenance 50
3.3 Customer Support 52
CHAPTER 4 Technical Data 55
4.1 Specifications 56
4.2 Connector Pinouts 58
4.3 Component Descriptions 66
Table of Contents
Model P5000HX Series CPU User’s Manual 5
CHAPTER 1 Introduction to the
P5000HX Series
CPU
Thank you for purchasing Texas Micro’s P5000HX Series
CPU. This chapter:
•introduces the primary features of the
P5000HX, and
•discusses the PCI backplane and PICMG.
If you wish to configure and install your P5000HX quickly
and you are familiar with P5000HX features and PCI con-
cepts, go directly to Chapter 2, then read this chapter at
your convenience.
1
Introduction to the P5000HX Series CPU
6 Model P5000HX Series CPU User’s Manual
1.1 P5000HX Features
The P5000HX The Texas Micro P5000HX:
•provides a 100/133/166/200 MHz, 64-bit
Pentium P54C processor,
•contains on-board PCI peripheral devices such
as SCSI and EIDE, and
•features 512 KByte flash memory and a CELP
socket for optional high-speed pipelined burst
SRAM modules (up to 512 KBytes).
Additional features
include... •Support for up to 256 MByte scaleable FPM
DRAM (chip set allows ECC using standard
SIMMs),
•One RS-232 serial port, one programmable
RS-232/422/485 serial port,
•a multi-function enhanced IEEE 1284 parallel
port,
•a floppy disk controller,
•an EIDE hard disk controller , and
•a PCI Bus-to-Fast and Wide SCSI Controller.
P5000HX Features
Model P5000HX Series CPU User’s Manual 7
FIGURE 1 P5000HX components
Introduction to the P5000HX Series CPU
8 Model P5000HX Series CPU User’s Manual
1.2 A PCI Discussion
Overview The P5000HX is designed to be used with either an ISA or
a PCI backplane. This section discusses the PCI Local Bus.
The PCI Local Bus The PCI Local Bus is a high-performance, 133 MB/sec,
32-bit bus with multiplexed address and data lines. It is
intended for use as an interconnect mechanism between
highly-integrated peripheral controller components, add-
in boards, and processor/memory systems.
Why the PCI Local
Bus? Graphics-oriented operating systems such as Windows
and OS/2 have created a data bottleneck between the pro-
cessor and its display peripherals in standard PC I/O
architectures. Moving peripheral functions with high-
bandwidth requirements closer to the system’s processor
bus can eliminate this bottleneck.
Substantial performance gains are seen with graphical
user interfaces (GUI’s) and other high-bandwidth func-
tions (i.e., full-motion video, SCSI, LANs, etc.) when a
“local bus” design is used.
The PCI Bridge The processor/cache/memory subsystem in a PCI system is
connected to PCI through a “PCI Bridge.” This bridge pro-
vides a low-latency path through which the processor may
directly access PCI devices mapped anywhere in the mem-
ory or I/O address spaces. It also provides a high-band-
width path, allowing PCI masters direct access to main
memory.
PICMG Texas Microsystems is a founding member of the PICMG
(PCI Industrial Computer Manufacturers Group), founded
to develop standards for PCI-based passive backplane sys-
tems. The P5000HX is fully PICMG-compliant.
A PCI Discussion
Model P5000HX Series CPU User’s Manual 9
FIGURE 2 A sample PCI backplane (Texas Micro’s 18-slot version)
Introduction to the P5000HX Series CPU
10 Model P5000HX Series CPU User’s Manual
This chapter covered...
•P5000HX features
•basic P5000HX components
•the PCI Local Bus and Bridge
•PICMG
Next...
The next chapter outlines the seven basic steps for
P5000HX configuration and installation.
