User’s Guide

SN6507DGQEVM Low-Emissions 500 mA Push-Pull

Transformer Driver for Isolated Power Supplies

Evaluation Module

ABSTRACT

This user's guide describes the evaluation module (EVM) for TI’s SN6507 push-pull isolation transformer driver.

This EVM helps designers analyze and evaluate performance of the SN6507 device for quick development of

isolated power supplies.

In addition to the SN6507 device, this EVM contains a small form-factor transformer, simple rectifier circuit,

voltage regulator, and various adjustable options. These combinations simulate a complete isolated power

supply system suitable for many applications.

Table of Contents

1 Introduction.............................................................................................................................................................................2

2 Overview..................................................................................................................................................................................2

3 EVM Setup and Operation......................................................................................................................................................4

4 EVM Configuration Options...................................................................................................................................................5

5 Bill of Materials....................................................................................................................................................................... 8

6 EVM Schematic and PCB..................................................................................................................................................... 10

List of Figures

Figure 2-1. SN6507DGQEVM Radiated Emissions Sweep at Full Load per CISPR 32 Class B................................................ 3

Figure 3-1. Basic SN6507DGQEVM Operation...........................................................................................................................4

Figure 4-1. SN6507 Pinout.......................................................................................................................................................... 5

Figure 4-2. SN6507DGQEVM Top View......................................................................................................................................5

Figure 6-1. SN6507DGQEVM Schematic..................................................................................................................................10

Figure 6-2. SN6507DGQEVM Top PCB Layout.........................................................................................................................11

Figure 6-3. SN6507DGQEVM Bottom PCB Layout...................................................................................................................12

List of Tables

Table 4-1. LM317A (U1) Resistor Values for Common Regulated Output Voltages....................................................................6

Table 4-2. SN6507DGQEVM Jumper Configurations..................................................................................................................7

Table 5-1. SN6507DGQEVM Bill of Materials..............................................................................................................................8

Trademarks

All trademarks are the property of their respective owners.

www.ti.com Table of Contents

SLLU346 – APRIL 2022

Submit Document Feedback

SN6507DGQEVM Low-Emissions 500 mA Push-Pull Transformer Driver for

Isolated Power Supplies Evaluation Module

1 Introduction

This user's guide presents a typical laboratory setup used with this EVM.

CAUTION

Do not use this EVM for isolation voltage tests even though the isolated power transformer has

galvanic isolation protection of up to 2500 V. This EVM is designed for the evaluation of device

operating parameters only. If a high voltage (greater than 36 V) or a high load current (greater than

500 mA) is applied anywhere in the circuit, the EVM could be damaged.

Exceeding the specified input voltage range and applying loads outside the specified output range may cause

unexpected operation and irreversible damage to the EVM. If there is uncertainty as to the input voltage range,

power specifications, or about using a configuration that is or is not described in this user guide, please contact a

TI field representative or create a post on e2e.ti.com prior to connecting power.

2 Overview

The SN6507 evaluation module allows users to evaluate the performance and features of the SN6507 push-pull

isolation transformer driver in an isolated power supply application. This includes a transformer, rectifier circuit,

and an optional low-dropout (LDO) voltage regulator. The power supply input and isolated output is separated by

the isolation transformer which can be de-soldered and replaced with other push-pull transformers in 6-pin and

8-pin packages that fit on the PCB’s T1 footprint.

Isolated power supplies help block high voltages and prevent noise currents from entering isolated grounds and

interfering with or damaging sensitive circuitry. They are required to preserve an isolation barrier in systems

using isolated devices requiring discrete power supplies.

The complementary output signals (SW1 and SW2) from the SN6507 are ground-referenced, N-channel, power

switches that drive the primary side of the center-tapped transformer. The secondary side of the transformer

has its center-tap referenced to an isolated ground plane, and the complementary outputs are rectified through

a two-diode bridge. The break-before-make feature of the two driver outputs from the SN6507 ensures that

only one of the primary-side transformer windings is driven at a time. After being rectified, the DC voltage

is smoothed and routed to an unregulated output to power external loads up to 500 mA, or the LM317A

voltage regulator can be enabled using jumper J4. Once enabled, the regulator outputs a stable, regulated

+12-VDC output by default that can also be used to drive up to 500 mA load circuits. As configured by default,

the SN6507DGQEVM complies with the CISPR 32 Class B radiated emissions standard, as shown by the

measurement in Figure 2-1.

Introduction www.ti.com

2SN6507DGQEVM Low-Emissions 500 mA Push-Pull Transformer Driver for

Isolated Power Supplies Evaluation Module

SLLU346 – APRIL 2022

Submit Document Feedback

Figure 2-1. SN6507DGQEVM Radiated Emissions Sweep at Full Load per CISPR 32 Class B

Use this EVM to evaluate electrical and timing parameters of the SN6507 device in different configurations.

Apply power to evaluate performance characteristics such as enable delay, rise and fall times, soft-start

duration, and power consumption for different load conditions. This EVM offers provisions for a wide range

of configurations, as detailed in Section 4.

www.ti.com Overview

SLLU346 – APRIL 2022

Submit Document Feedback

SN6507DGQEVM Low-Emissions 500 mA Push-Pull Transformer Driver for

Isolated Power Supplies Evaluation Module

3 EVM Setup and Operation

CAUTION

Note that this EVM is for operating-parameter evaluation only and not designed for isolation voltage

testing. Any voltage applied above the 36-V maximum recommended operating voltage or load

current applied above the 500-mA maximum recommended switching current of SN6507 may

damage the EVM.

SN6507DGQ is designed to sink a maximum amount of current up to 500 mA through its SW1

and SW2 pins and connect to up to 36 V inputs. Care must be taken to ensure transformer power

parameters are not exceeded if they are lower than SN6507 limits.

This section describes the setup and operation of the EVM for parameter-performance evaluation. The EVM is

configured for a 24 V input and an unregulated 15 V output. It comes with an SN6507DGQ unit installed in place

of U2 and a 24 V IN to 15 V, 500 mA OUT transformer in place of T1. This EVM can also be configured for

evaluation of various transformers and voltage input and output combinations by replacing the included push-pull

transformer device in place of T1. A list of recommended commercially available transformers is listed in the

SN6507 datasheet.

Figure 3-1 shows the basic setup of the EVM with an input power supply needed to evaluate device

performance. Power this Evaluation Module by connecting a voltage to VIN that is within the Recommended

Operating Range in the SN6507 device datasheet. Typical voltage levels for the VIN are 24 V and 12 V,

respectively. Both grounds of the EVM may be shorted together for evaluation. In practice, shorting the non-

isolated and isolated grounds would bypass the isolation barrier and is not recommended.

Figure 3-1. Basic SN6507DGQEVM Operation

EVM Setup and Operation www.ti.com

4SN6507DGQEVM Low-Emissions 500 mA Push-Pull Transformer Driver for

Isolated Power Supplies Evaluation Module

SLLU346 – APRIL 2022

Submit Document Feedback

4 EVM Configuration Options

The pin diagram of SN6507 in the DGQ package is shown in Figure 4-1.

EN/UVLO

VCC

GND

SW1

CLK

SS/ILIM

GND

SW2

DGQ PACKAGE

(TOP VIEW)

Thermal

Pad

(11)

Figure 4-1. SN6507 Pinout

The SN6507DGQEVM is designed for flexibility in evaluation of the SN6507 device by providing placeholder

options for several external components. The SN6507 pin-configurable options, snubber circuit components,

full-bridge output configurations, LDO output, and the isolation transformer itself may all be adjusted using

component-footprint and jumper provisions on this EVM. The transformer footprint, T1, is compatible with many

commercially-available push-pull isolation transformers. The EVM PCB is shown in Figure 4-2.

Figure 4-2. SN6507DGQEVM Top View

Details for the various configuration options of the SN6507 EVM are listed below.

Pin-configurations using RCs: Configuration options for pin-adjustable features of SN6507, including Enable,

UVLO, SW1/SW2 switching frequency (CLK), duty cycle control, slew rate adjustment, soft-start time, and

over-current protection limit can be found in the SN6507 data sheet. Corresponding component footprints on this

EVM are as follows:

• Ruv1 and Ruv2 correspond to RENT and RENB for UVLO and EN programming

www.ti.com EVM Configuration Options

SLLU346 – APRIL 2022

Submit Document Feedback

SN6507DGQEVM Low-Emissions 500 mA Push-Pull Transformer Driver for

Isolated Power Supplies Evaluation Module

• RDC is used for duty cycle control programming and is active when pins 2-3 of J13 are connected. If duty

cycle control is used, ensure a compatible transformer is placed in footprint T1 and output inductors with

sufficient inductance are populated in place of L1 (and L2 as needed)

• RCLK can be used to program the internal CLK and is active when pins 3-4 of J10 are connected

• RSR is used to adjust the slew rate of the switching pins, SW1 and SW2, and is active when pins 2-3 of J9

are connected

• Rilim is used to adjust the over-current protection limit of SN6507

• Css is used to adjust the soft start time of SN6507 during power-up

Transformer replacement: A 24 V IN to 15 V OUT transformer is included by default in place of T1. To evaluate

different transformers, de-solder this transformer and replace it with a 6-pin or 8-pin push-pull transformer that is

compatible with the T1 footprint.

Secondary-side snubber circuit: An RC snubber circuit of 100 Ω, 62pF is populated on R12, C15 and R13,

C16 by default to help minimize electromagnetic emissions. These components are optional, so they may be

replaced with other components or removed from the EVM and excluded from designs using the SN6507 device.

Primary-side snubber circuits: Primary-side snubber circuits can be placed using footprints for R10, C11 and

R11, C12 to further reduce emissions. Primary-side snubber circuit values can be calculated using the steps in

How to Reduce Emissions in Push-Pull Isolated Power Supplies (SLLA566).

Output rectifier: Diode placeholders D1, D2, D4, D5, and resistor R9 are included to allow system designers to

experiment with the different output topologies push-pull power supplies can support. D2 and D5 are populated

by default as this is the typical application topology, and some example output designs found in the SN6507 data

sheet can be configured on this EVM to achieve bi-polar or voltage-doubling outputs using the “-Vout” net by

populating D1 and D4 on the EVM. Make sure the output LDO, U1, is bypassed by disconnecting pins 1-2 of J4

if R9 is removed since the ISO_GND potential will be floating.

Ferrite bead options: To reduce emissions when power supply outputs are connected to long cables or have

high ringing, ferrites can be soldered in place of R15, R14, R6, R7, and R8. A ferrite with 1 kΩ impedance or

greater at 100 MHz like the Würth Elektroniks 742792662 is recommended.

Input-side transient protection: Provisions for a flat-clamp diode like TVS3300, U3, or a TVS diode like

SMAJ36A, D7, are included to protect the power supply input from external transients above the desired power

supply level.

Output-side transient protections: TVS diode placeholders D3 and D6 are included to protect the SN6507

output from external transients above the desired output power supply level.

LDO output: The included LM317A can be configured to change the regulated output voltage level by

connecting either of the R5x resistors using jumper J3. When configuring the LDO, ensure the LDO input voltage

is within the LDO’s recommended limits and high enough to support the desired output voltage level and the

dropout voltage of the LM317A. A regulated 15 V output can be configured by connecting pins 1-2 of J3, a

regulated 12 V output can be configured by connecting pins 2-3 of J3, or a custom output voltage value can be

configured by connecting pins 5-6 of J3 and changing R5C to a value which meets the desired output voltage

using Equation 1.

VOUT = 1.25 V x (1+R5C/R4) + (50 uA x R5C) (1)

A table of calculated resistor values for R5C to achieve common voltage outputs is shown Table 4-1:

Table 4-1. LM317A (U1) Resistor Values for Common Regulated Output Voltages

Desired VOUT (V) R4 value (Ω) R5C value (Ω)

3.3 240 390

5 240 713

12 240 2044

15 240 2615

24 240 4326

EVM Configuration Options www.ti.com

6SN6507DGQEVM Low-Emissions 500 mA Push-Pull Transformer Driver for

Isolated Power Supplies Evaluation Module

SLLU346 – APRIL 2022

Submit Document Feedback

Table 4-1. LM317A (U1) Resistor Values for Common Regulated Output Voltages (continued)

Desired VOUT (V) R4 value (Ω) R5C value (Ω)

36 240 6609

Jumper configurations: Table 4-2 details the jumper configuration information of the SN6507DGQEVM.

Table 4-2. SN6507DGQEVM Jumper Configurations

Connection Label Function

J3 15 V, 12 V, ADJ. Connect pins 1-2, 2-3, or 5-6 of J3 to select the desired regulated output voltage of either 15

V, 12 V, or a custom value respectively between +VOUT_LDO and GND_OUT

J4 +VO_LDO_EN Connect this jumper to enable the regulated output LDO, U1

J5 +VOUT, GND_OUT A surface-mount 3x1 terminal block can be soldered onto this footprint for additional

measurement points of each labelled pad

J6 EN_H, EN_L Connect pins 1-2 of J6 to enable or pins 2-3 of J6 to disable SN6507 respectively. Do not

connect any pins of J6 if enable signals are controlling SN6507 using TP6 or if UVLO is

configured using Ruv1 and Ruv2

J7 NOTE Connect pins 1-2 of J7 to bypass output inductor L1 if duty cycle control is not used.

Disconnect these pins to use output inductor L1 for duty cycle control

J9 Default SR, ADJ. SR Connect pins 1-2 of J9 to use the default switching slew rate of SN6507 or connect pins

2-3 to adjust the slew rate using RSR. If J9 is completely disconnected, SN6507 will use its

default slew rate

J10 1 MHz, ADJ., CLK_IN Connect pins 5-6 of J10 for SN6507 to use the internal 1 MHz clock for switching SW1 and

SW2. Connect pins 3-4 of J10 to use an adjustable clock value based on the resistance of

RCLK. Connect pins 1-2 of J10 to use an external clock input connected to the test point

CLK_IN, described as SYNC Mode in Section 7.4.4 of the SN6507 datasheet.

J12 NOTE Connect pins 1-2 of J12 to bypass output inductor L2 if duty cycle control is not used.

Disconnect these pins to use output inductor L2 for duty cycle control

J13 DC_48%, DC_ADJ. Connect pins 1-2 of J13 to use the default switching duty cycle of SN6507 or connect pins

2-3 to adjust the slew rate using RDC. If J13 is completely disconnected, SN6507 will use its

default switching duty cycle

J14 -VOUT, GND_OUT A surface-mount 3x1 terminal block can be soldered onto this footprint for additional

measurement points of each labelled pad

www.ti.com EVM Configuration Options

SLLU346 – APRIL 2022

Submit Document Feedback

SN6507DGQEVM Low-Emissions 500 mA Push-Pull Transformer Driver for

Isolated Power Supplies Evaluation Module

5 Bill of Materials

Table 5-1 lists the bill of materials (BOM) for SN6507DGQEVM.

Table 5-1. SN6507DGQEVM Bill of Materials

Designator Quantity Value Description Package Reference Part Number Manufacturer

C1, C5, C14 3 0.1 uF CAP, CERM, 0.1 uF, 100 V,+/- 10%, X7R, AEC-Q200

Grade 1, 0603

603 GCJ188R72A104KA0

MuRata

C2 1 10 uF CAP, CERM, 10 uF, 35 V, +/- 10%, X5R, 0805 805 C2012X5R1V106K08

5AC

TDK

C3, C13 2 10 uF CAP, CERM, 10 uF, 100 V, +/- 10%, X7S, 2220 C5750X7S2A106K230

TDK

C4 1 1 uF CAP, CERM, 1 µF, 100 V,+/- 10%, X7R, 1206 1206 12061C105KAT2A AVX

C7, C8, C17 3 10 uF CAP, CERM, 10 uF, 50 V, +/- 10%, X7R, AEC-Q200

Grade 1, 1210

1210 UMJ325KB7106KMH

Taiyo Yuden

C10, C19 2 0.1uF CAP, CERM, 0.1 uF, 50 V, +/- 10%, X7R, 0603 603 C1608X7R1H104K08

0AA

TDK

C15, C16 2 62 pF Ceramic Capacitor for Automotive 62 pF ±1% 100VDC

X8G 0603 Paper T/R

603 GCM1885G2A620FA1

Murata

Css 1 2.2 uF CAP, CERM, 2.2 uF, 10 V, +/- 10%, X7R, 0805 805 GRM21BR71A225KA

01L

MuRata

D2, D5 2 200 V, 2 A Silicon Germanium (SiGe) rectifier CFP3

Package 2.8 A 200 V 58 pF

CFP3 PMEG200G20ELRX Nexperia

H1, H2, H3, H4 4 Bumpon, Hemisphere, 0.44 X 0.20, Clear Transparent Bumpon SJ-5303 (CLEAR) 3M

J1, J2, J8, J11 4 Conn Term Block, 2POS, 3.5 mm, TH 11x8.5x7.3 mm 1751248 Phoenix Contact

J3, J10 2 Header, 2.54 mm, 3x2, Gold, SMT Header, 2.54 mm, 3x2, SMT TSM-103-01-L-DV Samtec

J4, J7, J12 3 Header, 2.54 mm, 2x1, Gold, SMT Header, 2.54 mm, 2x1, SMT 61000218321 Wurth Elektronik

J6, J9, J13 3 Header, 2.54 mm, 3x1, Gold, SMT Header, 2.54 mm, 3x1, SMT M20-8770342 Harwin

L1, L2 2 33 µH 33 µH Shielded Molded Inductor 500 mA 1.33Ohm

Max 1212 (3030 Metric)

SMT2_3MM0_3MM0 74438335330 Wurth

LBL1 1 Thermal Transfer Printable Labels, 0.650" W x 0.200"

H - 10,000 per roll

PCB Label 0.650 x 0.200 inch THT-14-423-10 Brady

R1, R6, R7, R8, R14,

R15, R16, Rclk

8 0 Ohms Jumper 0.125 W, 1/8 W Chip Resistor 0805

(2012 Metric) Automotive AEC-Q200 Thick Film

805 RMCF0805ZT0R00 Stackpole

Electronics

R2 1 10k RES, 10 k, 5%, 0.1 W, 0603 603 RC0603JR-0710KL Yageo

Bill of Materials www.ti.com

8SN6507DGQEVM Low-Emissions 500 mA Push-Pull Transformer Driver for Isolated Power Supplies

Evaluation Module

SLLU346 – APRIL 2022

Submit Document Feedback

Table 5-1. SN6507DGQEVM Bill of Materials (continued)

Designator Quantity Value Description Package Reference Part Number Manufacturer

R3 1 10k RES, 10 k, 5%, 0.125 W, AEC-Q200 Grade 0, 0805 805 ERJ-6GEYJ103V Panasonic

R4 1 240 240 Ohms ±0.1% 0.2W, 1/5W Chip Resistor

0603 (1608 Metric) Automotive AEC-Q200, Pulse

Withstanding Thick Film

603 ERJ-PB3B2400V Panasonic

R5A 1 2.61k RES, 2.61 k, 1%, 0.1 W, 0603 603 RC0603FR-072K61L Yageo

R5B 1 2.05k RES, 2.05 k, 1%, 0.1 W, 0603 603 RC0603FR-072K05L Yageo

R9 1 0 RES, 0, 5%, 0.1 W, 0603 603 RC0603JR-070RL Yageo

R12, R13 2 100 100 Ohms ±5% 0.2W, 1/5W Chip Resistor 0603 (1608

Metric) Automotive AEC-Q200, Moisture Resistant,

Pulse Withstanding Thick Film

603 SG73S1JTTD101J KOA Speer

Rilim 1 18.2k RES, 18.2 k, 1%, 0.125 W, AEC-Q200 Grade 0, 0805 805 ERJ-6ENF1822V Panasonic

Rsr 1 20.5k RES, 20.5 k, 1%, 0.125 W, AEC-Q200 Grade 0, 0805 805 ERJ-6ENF2052V Panasonic

SH-J1, SH-J2, SH-J3,

SH-J4, SH-J5, SH-J6,

SH-J7

7 Shunt, 100 mil, Gold plated, Black Shunt 2 pos. 100 mil 881545-2 TE Connectivity

T1 1 24 V: 15 V TRANSFORMER SMT_XFRMR_9MM45_8MM50 750319696 Wurth

T1 0 Push-Pull Transformer ER9.5 SMD8 24Vin 1 MHz

Output 15 V/0.5 A

SMT_XFRMR_12MM07_10MM3 TX1-ZB1459-BE Coilcraft

T1 0 XFMR, PUSH-PULL, 10 W, 120 V-USEC, EP7, SMT SMT_XFRMR_10MM3_13MM2 PAG6356.086NLT Pulse Electronics

T1 0 Transformer, Turns Ratio 0.733, 430uH, 2.5kVAC,

13.2x11.8x11.1mm

SMT_XFRMR_13MM2_11MM8 SM91207L Bourns

T1 0 Push Pull Transformer, 10:7, 550uH, 2.5kV,

8.6x9.4x9.1mm

SMT_XFRMR_8MM6_9MM4 B1807127 Bourns

TP1, TP2, TP3, TP4,

TP5, TP6, TP7, TP8,

TP9, TP10

10 Test Point, Miniature, SMT Test Point, Miniature, SMT 5019 Keystone

U1 1 1% Accurate, 1.5 A Adjustable Linear Regulator with

Short Circuit Protection, NDP0003B (TO-252-3)

NDP0003B LM317AMDT/NOPB Texas Instruments

U2 1 Low-Noise 36 V Push-Pull Transformer Driver with

Duty Cycle Control for Isolated Power Supplies

PowerPAD10 SN6507DGQ Texas Instruments

www.ti.com Bill of Materials

SLLU346 – APRIL 2022

Submit Document Feedback

SN6507DGQEVM Low-Emissions 500 mA Push-Pull Transformer Driver for Isolated Power Supplies

Evaluation Module

6 EVM Schematic and PCB

Figure 6-1 shows the schematic diagram for this EVM, and Figure 6-2 and Figure 6-3 show the printed circuit board (PCB) layout.

GND

R11

R10

C11

C12

GND

ISO_GND

GND

2 1

PMEG200G20ELRX

TP7

+VOUT

TP8

GND_OUT

TP9

-VOUT

TP4

GND

J14

EN_High EN_Low

EXT_CLK

CLK_adjust. (RCLK)

GND

ISO_GND

2 1

PMEG200G20ELRX

2 1

PMEG200G20ELRX

2 1

PMEG200G20ELRX

VCC

3SW1 1

SW2 10

CLK

EN/UVLO

SS/ILIM 8

GND 2

GND 9

EP 11

SN6507DGQ

TP1

VIN

TP5

GND

EN/UVLO_IN

CLK_GND (default)

GND

18.2k

Rilim

GND

J11

50.5k

Rdc

10V

2.2uF

Css

Vout = 1.25V x (1+R5/R4) + (50uA x R5)

1751248

GND GND

VIN

Input Power

SN6507 Vcc range 3V-36V

10uF

1µF

3OUT 4

ADJ

LM317AMDT/NOPB

1751248

Output Power

10k

240

VIN

100nF

10uF

C13

VIN

VLDO in 4.25V-40V

1 2

3 4

5 6

J10

TSM-103-01-L-DV

+VOUT_LDO_IN

10uF

C17

1uF

C18

J13

DC_48% (default)

DC Control

GND

ISO_GND

TP2

+VOUT_LDO

TP3

GND_OUT

15V R option

12V R option

R5 = (Vout-1.25) / ([1.25/R4]+50uA)

DNP R option

2.61k

R5A

2.05k

R5B

R5C

1 2

3 4

5 6

TSM-103-01-L-DV

ISO_GND

TP10

CLK_IN

TP6

EN_IN 499k

Ruv1

100k

Ruv2

10uF

ISO_GND

10uF

10k

20.5k

Rsr

Default SR

SR adjust.

SR Control

100nF

C14

100nF

C10

100nF

C19

750319696

36V

4 5

ZB1459-BE

J12

ISO_GND

XP5

XP6

XP4XP3

XP2

XP1

VIN

XP1

XP2

XP3 XP4

XP5

XP6

XP1

XP2

XP3

XP6

XP5

XP4

PAG6356.086NLT

Extra Transformer Footprints

SN6507 Circuit

36V

3 6

SM91207L

XP1

XP2

XP3

XP6

XP5

XP4

2 5

B1807127

5GND 1

GND 2

6GND 3

PAD 7

TVS3300DRVR

XP1

XP2

XP3

XP6

XP5

XP4

GND

Rclk

DC adjust.

100nF

+VOUT

GND_OUT

-VOUT

GND_OUT

R15

GND_OUT

R14

ISO_GND

GND

R16

+VOUT_LDO_IN

62pF

C15

62pF

C16

100

R13

100

R12

Rclk, Rsr, Rdc, Rilim, Css can be adjusted per

SN6507 datasheet

Populate D1 and D4 for -Viso

output

J4 jumper:

populated = +Vout LDO ON

DNP = LDO bypassed

J7 jumper:

populated = L1 bypassed no DC CTRL

DNP = L1 for DC CTRL

J12 jumper:

populated = L1 bypassed no DC CTRL

DNP = L1 for DC CTRL

Figure 6-1. SN6507DGQEVM Schematic

Bill of Materials www.ti.com

10 SN6507DGQEVM Low-Emissions 500 mA Push-Pull Transformer Driver for Isolated Power Supplies

Evaluation Module

SLLU346 – APRIL 2022

Submit Document Feedback

Tabla de contenidos

Otros manuales de Placa madre de Texas Instruments

Texas Instruments

Texas Instruments TPS61193EVM Manual de usuario

Texas Instruments

Texas Instruments ADS7881 Manual de usuario

Texas Instruments

Texas Instruments LMK5B33216EVM Manual de usuario

Texas Instruments

Texas Instruments BOOSTXL-DRV8323Rx Manual de usuario

Texas Instruments

Texas Instruments TPS566235EVM-036 Manual de usuario

Texas Instruments

Texas Instruments CC85-CC2590EM Series Manual de usuario

Texas Instruments

Texas Instruments bq30z554EVM Manual de usuario

Texas Instruments

Texas Instruments TPS7H3014EVM-CVAL Manual de usuario

Texas Instruments

Texas Instruments LMP91300SWIFEVM Manual de usuario

Texas Instruments

Texas Instruments TPS40074EVM-001 Manual de usuario

Texas Instruments

Texas Instruments INA4290 Manual de usuario

Texas Instruments

Texas Instruments TPS563203 Manual de usuario

Texas Instruments

Texas Instruments TMS320C66 Series Manual de usuario

Texas Instruments

Texas Instruments TSW12D1620 Manual de usuario

Texas Instruments

Texas Instruments LMQ61460EVM-400K Manual de usuario

Texas Instruments

Texas Instruments LM5013-Q1EVM Manual de usuario

Texas Instruments

Texas Instruments INA210-215EVM Manual de usuario

Texas Instruments

Texas Instruments MSP430FR57 Series Manual de usuario

Texas Instruments

Texas Instruments TPL5010EVM Manual de usuario

Texas Instruments

Texas Instruments TPA0232 Manual de usuario

Texas Instruments

Texas Instruments TPS65680 Manual de usuario

Texas Instruments

Texas Instruments TPS650937 Manual de usuario

Texas Instruments

Texas Instruments TPS61194xEVM Manual de usuario

Texas Instruments

Texas Instruments UCC25230EVM-662 Manual de usuario

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

ASROCK

ASROCK ROMED8-2T Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Gigabyte

Gigabyte GA-9IVDT Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manual de usuario
