Texas Instruments CC3100 SimpleLink Manual de usuario

CC3100 SimpleLink™ Wi-Fi®and IoT Solution

Getting Started Guide

User's Guide

Literature Number: SWRU375D

June 2014–Revised May 2018

2SWRU375D–June 2014–Revised May 2018

Submit Documentation Feedback

Table of Contents

Contents

1 Trademarks......................................................................................................................... 4

2 Introduction......................................................................................................................... 4

2.1 Prerequisites.............................................................................................................. 4

3 Getting Started .................................................................................................................... 4

3.1 Download and Install Software......................................................................................... 4

3.2 Update Service Pack .................................................................................................... 4

4 Getting Started with SimpleLink Studio .................................................................................. 5

4.1 Configure Boards......................................................................................................... 5

4.2 Run the Software......................................................................................................... 8

5 Getting Started with the MSP430F5529.................................................................................. 13

5.1 Configure Boards ....................................................................................................... 13

5.2 Run the Software ....................................................................................................... 15

6 Summary........................................................................................................................... 20

7 Acronyms Used.................................................................................................................. 20

Revision History.......................................................................................................................... 21

www.ti.com

SWRU375D–June 2014–Revised May 2018

List of Figures

1 CC3100BOOST.............................................................................................................. 5

2 CC31XXEMUBOOST ....................................................................................................... 6

3 Connect the CC3100BOOST to the CC31XXEMUBOOST ............................................................ 7

4 Device Manager.............................................................................................................. 8

5 MinGW Installation Screen ................................................................................................. 9

6 Import Existing Code....................................................................................................... 10

7 Paths and Symbols ........................................................................................................ 11

8 Eclipse Output Console ................................................................................................... 11

9 CC3100BOOST ............................................................................................................ 13

10 Jumpers on the MSP430F5529 Launchpad ............................................................................ 14

11 Connect the CC3100BOOST to the MSP430F5529 Launchpad .................................................... 15

12 Select CCS Projects to Import............................................................................................ 16

13 Define SSID_Name ........................................................................................................ 17

14 Launch Tera Term ......................................................................................................... 17

15 Tera Term VT............................................................................................................... 18

16 Macro Definition of SSID_Name ......................................................................................... 18

17 Launch Tera Term ......................................................................................................... 19

18 Tera Term VT............................................................................................................... 19

4SWRU375D–June 2014–Revised May 2018

Submit Documentation Feedback

CC3100 SimpleLink™ Wi-Fi®and IoT Solution Getting Started Guide

User's Guide

SWRU375D–June 2014–Revised May 2018

CC3100 SimpleLink™ Wi-Fi®and IoT Solution Getting

Started Guide

ABSTRACT

This guide is intended to assist users in the initial setup and demonstration of the Getting Started with

WLAN Station application. The guide explains how to install an Integrated Development Environment

(IDE), and then compile, download, and debug Getting Started with WLAN Station.

1 Trademarks

SimpleLink is a trademark of Texas Instruments.

Microsoft, Windows are registered trademarks of Microsoft.

Wi-Fi is a registered trademark of Wi-Fi Alliance.

2 Introduction

2.1 Prerequisites

The user should have the following items:

• One CC3100BOOST

• One CC31XXEMUBOOST or MSP430F5529 Launchpad

• An 802.11b/g/n Wireless Access Point (AP)

• A computer running Microsoft®Windows®7 or XP operating systems.

3 Getting Started

3.1 Download and Install Software

Download and install the following software:

• CC3100 SDK package http://www.ti.com/tool/cc3100sdk

– This guide assumes the use of the default installation folder C:\TI\CC3100SDK_<x.x.x>\. .

3.2 Update Service Pack

If the board is not already flashed with the service pack for SDK_<x.x.x>, the latest service pack for

SDK_<x.x.x> must be flashed on the CC3100. The latest service pack can be downloaded from

http://www.ti.com/tool/cc3100sdk. Refer to the UNIFLASH Quick Start guide for details on flashing the

service pack to the CC3100

(http://processors.wiki.ti.com/index.php/CC31xx_%26_CC32xx_UniFlash#Service_Pack_Programming).

Details on setting up the hardware for flashing can be found in Section 4.1 .

www.ti.com

Getting Started with SimpleLink Studio

SWRU375D–June 2014–Revised May 2018

CC3100 SimpleLink™ Wi-Fi®and IoT Solution Getting Started Guide

4 Getting Started with SimpleLink Studio

4.1 Configure Boards

1. The jumpers on the CC3100BOOST should be connected as shown in Figure 1.

Figure 1. CC3100BOOST

Getting Started with SimpleLink Studio

www.ti.com

6SWRU375D–June 2014–Revised May 2018

Submit Documentation Feedback

CC3100 SimpleLink™ Wi-Fi®and IoT Solution Getting Started Guide

2. The jumpers on the CC31XXEMUBOOST should be connected as shown in Figure 2.

Figure 2. CC31XXEMUBOOST

www.ti.com

Getting Started with SimpleLink Studio

SWRU375D–June 2014–Revised May 2018

CC3100 SimpleLink™ Wi-Fi®and IoT Solution Getting Started Guide

3. Connect the CC3100BOOST to the CC31XXEMUBOOST as shown in Figure 3.

Figure 3. Connect the CC3100BOOST to the CC31XXEMUBOOST

4. Connect the J6 port CC31XXEMUBOOST to the PC using the provided micro-USB cable.

5. The CC3100BOOST is now visible in the Device Manager as shown in Figure 4. The user may see

two COM ports instead of four.

Getting Started with SimpleLink Studio

www.ti.com

8SWRU375D–June 2014–Revised May 2018

Submit Documentation Feedback

CC3100 SimpleLink™ Wi-Fi®and IoT Solution Getting Started Guide

Figure 4. Device Manager

4.2 Run the Software

The Getting Started with WLAN Station example uses SimpleLink Studio. This example performs the

following functions:

1. Program restores WLAN configuration to factory default

2. Prompts the user for the SSID of an AP

3. Prompts the user for the security type

4. Prompts the user for the password to the AP

5. Attempts to acquire an IP address through DHCP

6. Attempts to reach the internet

NOTE: For full compatibility ensure Visual Studio 2010 is used. Newer versions of Visual Studio will

not work with the device. Visual Studio 2012 works with the "getting started" example, but

gives the error code -2003 for the weather example, and error code -2005 for the email app.

Option 1. Microsoft Visual Studio:

1. Download and install Microsoft Visual Studio Express 2010 from http://www.visualstudio.com/en-

us/downloads/download-visual-studio-vs#DownloadFamilies_4.

2. Open Microsoft Visual Studio Express, and select File>Open>Project/Solution.

3. Navigate to C:\TI\CC3100SDK_<x.x.x>\cc3100-

sdk\platform\simplelinkstudio\example_project_vs\getting_started_with_station , and open

getting_started.sln.

4. Select Build>Build Solution from the menu.

5. When building is complete, select Debug>Start Debugging from the menu.

www.ti.com

Getting Started with SimpleLink Studio

SWRU375D–June 2014–Revised May 2018

CC3100 SimpleLink™ Wi-Fi®and IoT Solution Getting Started Guide

Option 2. Eclipse:

1. Download and install the latest version of Java: https://www.java.com/en/download/. Install the correct

version for the system (64-bit or 32-bit).

2. Download and extract Eclipse from http://www.eclipse.org/downloads/. Choose the Eclipse IDE for

C/C++ Developers package. Install the correct version for the system (64-bit or 32-bit).

3. Download and install MinGW from

http://sourceforge.net/projects/mingw/files/latest/download?source=files. During installation, ensure the

following configurations are selected:

a. Set the installation location as C:\MinGW.

b. In the MinGW Installation Screen, select packages for mingw32-base and mingw32-gcc-g++ as

shown in Figure 5.

Figure 5. MinGW Installation Screen

c. After selecting the packages, choose Installation>Apply Changes from the menu, then press Apply.

d. Select Installation>Quit from the menu to quit the installer.

4. After a successful MinGW installation, add the path (c:\MinGW\bin\) to the Windows environment

variable path by going into Control Panel>System>Advanced System Settings>Environment Variables.

Under System Variables, select PATH and press Edit. Append “;C:\MinGW\bin\” to the end of the line

and press Ok.

5. Open Eclipse by running eclipse.exe from the extracted Eclipse folder.

6. In the "Select a workspace," choose your desired workspace directory (for example:

C:\Users\myself\Desktop\eclipse_workspace). This directory should be different from the user's other

versions of Eclipse.

7. From the menu, select File>New>Makefile Project with Existing Code.

8. Enter ‘Getting_started’ as the project name.

9. For Existing Code Location, enter C:\TI\CC3100SDK_<x.x.x.>\cc3100-

sdk\platform\simplelinkstudio\example_project_eclipse\getting_started_with_station .

10. For Toolchain for indexer settings, choose “MinGW GCC” as shown in Figure 6.

Getting Started with SimpleLink Studio

www.ti.com

10 SWRU375D–June 2014–Revised May 2018

Submit Documentation Feedback

CC3100 SimpleLink™ Wi-Fi®and IoT Solution Getting Started Guide

Figure 6. Import Existing Code

11. Press Finish.

12. Select Window>Show View>Project Explorer from the menu.

13. Select the Getting_started project in the Project Explorer, and select File>Properties from the menu.

14. In the Project Explorer window, right click on <Project_Folder_Name>, then select Property.

15. Expand the C/C++ Build menu, and select Tool Chain Editor. Under Current Builder, Select "Gnu

Make Builder", then click Apply.

16. Click the C/C++ Build menu and do the following:

a. Uncheck 'Use the default build command.'

b. Type mingw32-make -f Makefile in the Build command.

c. Uncheck 'Generate Makefiles automatically.'

d. Set the Build Directory as: ${workspace_loc:/Getting_started}

17. Select Environment in the C/C++ Build menu. Ensure the value of MSYS_HOME is empty, then click

Apply.

18. Click the C/C++ General menu, and select Paths and Symbols. Under the Includes tab, in the
