SLLU288–March 2018

TUSB564RNQ Evaluation Module

User's Guide

SLLU288–March 2018

TUSB564RNQ Evaluation Module

This user's guide describes the characteristics and use of the TUSB564RNQ evaluation module. This

document describes how to power up the EVM and also includes schematics that can be used as

reference design for the Alternate mode implementations of the system with the TUSB564 device.

Contents

1 Introduction ................................................................................................................... 2

2 TUSB564RNQ EVM......................................................................................................... 2

3 TUSB564RNQ EVM Configuration........................................................................................ 3

3.1 TUSB564RNQ EVM Default Configuration...................................................................... 3

3.2 TUSB564 Equalization Control.................................................................................... 3

3.3 Power................................................................................................................. 4

4 TUSB564RNQ EVM Schematics and Bill of Materials.................................................................. 5

4.1 Schematics .......................................................................................................... 5

4.2 Bill of Materials...................................................................................................... 9

List of Figures

1 TUSB564RNQ EVM......................................................................................................... 2

2 Test Board Setup............................................................................................................ 2

3 TUSB564RNQ EVM Main Schematic..................................................................................... 5

4 TUSB564RNQ EVM Configuration Pins.................................................................................. 6

5 TPS65986..................................................................................................................... 7

6 TUSB564RNQ EVM Power ................................................................................................ 8

List of Tables

1 TUSB564 Configuration Pins............................................................................................... 3

2 Configuration Pin Level Definitions........................................................................................ 3

3 USB 3.1 EQ Settings........................................................................................................ 3

4 DisplayPort™ EQ Settings ................................................................................................. 4

5 Bill of Materials............................................................................................................... 9

Trademarks

USB Type-C is a trademark of USB Implementers Forum.

DisplayPort is a trademark of Video Electronics Standards Association.

VESA is a registered trademark of Video Electronics Standards Association.

All other trademarks are the property of their respective owners.

DP Source

USB Host TUSB1046EVM

USBDP

USB Type-C

USB Hub / Device

TUSB564RNQEVM

USB DP

USB Type-C

DP-Branch / Sink

Introduction

www.ti.com

2SLLU288–March 2018

Submit Documentation Feedback

TUSB564RNQ Evaluation Module

1 Introduction

The TUSB564 device is a USB Type-C™ / VESA®DisplayPort™ (DP) alternate mode redriving switch

supporting USB data rates up to 5 Gbps for a USB Type-C upstream facing port (UFP).

2 TUSB564RNQ EVM

Figure 1 shows the TUSB564RNQ EVM.

Figure 1. TUSB564RNQ EVM

The TUSB564RNQ EVM can be used with an Alternate mode USB Type-C source such as the TUSB1046

EVM and/or USB or DisplayPort USB Type-C Host system to evaluate the USB Type-C implementation.

Figure 2 shows a typical test setup.

Figure 2. Test Board Setup

The TUSB564RNQ EVM has a legacy Type-A USB receptacle to connect to a USB hub or device and a

DisplayPort receptacle to connect to DisplayPort sink. The EVM uses TI's TPS65986 device for USB

Type-C PD control and to configure the TUSB564.

www.ti.com

TUSB564RNQ EVM Configuration

SLLU288–March 2018

TUSB564RNQ Evaluation Module

3 TUSB564RNQ EVM Configuration

This section provides the configuration options available in the TUSB564RNQ EVM.

3.1 TUSB564RNQ EVM Default Configuration

Table 1 lists the default configuration pins for the TUSB564 device. Configuration settings may need to be

optimized depending on the amount of loss of each channel in the system. The EVM is configured to

GPIO mode by default. If I2C configuration is desired, JMP7 (I2C_EN) shunt must be changed to shunt

pins 2-3 (VCC).

Table 1. TUSB564 Configuration Pins

Reference

Designator JMP Control Configuration

JMP1 Downstream EQ1 SHUNT on pin 2-4 (R – 20k to GND)

JMP2 Downstream EQ0 SHUNT on pin 2-4 (R – 20k to GND)

JMP3 Downstream SSEQ1 SHUNT on pin 2-4 (R – 20k to GND)

JMP4 Downstream SSEQ0 SHUNT on pin 2-4 (R – 20k to GND)

JMP5 DP EQ1 SHUNT on pin 2-4 (R – 20k to GND)

JMP6 DP EQ0 SHUNT on pin 2-4 (R – 20k to GND)

JMP7 I2C_EN SHUNT on pin 1-2 (GND)

J1 FLIP No SHUNT

J2 CTL0 No SHUNT

J3 CTL1 No SHUNT

J4 EN SHUNT on pin 1-2 (PU)

3.2 TUSB564 Equalization Control

Equalization (EQ) can be controlled through I2C or pin-strapping (see Table 2). Each TUSB564 receiver

lane has individual controls for receiver equalization. Table 3 and Table 4 detail the gain values for each

available combination for downstream, upstream, and all DisplayPort configurations.

Table 2. Configuration Pin Level Definitions

Level Settings

0Option 1: Tie 1 kΩ5% to GND.

Option 2: Tie directly to GND.

R Tie 20 kΩ5% to GND.

F Float (leave pin open)

1Option 1: Tie 1 kΩ5% to VCC.

Option 2: Tie directly to VCC.

Table 3. USB 3.1 EQ Settings

USB 3.1 Downstream Facing Ports USB 3.1 Upstream Facing Ports

EQ1 Pin Level EQ1 Pin Level EQ Gain at 2.5 GHz

(dB) SSEQ1 Pin

Level SSEQ1 Pin

Level EQ Gain at 2.5 GHz

(dB)

0 0 –2.4 0 0 –0.9

0 R –1.3 0 R 0.2

0 F –0.4 0 F 1.2

0 1 0.7 0 1 2.2

R 0 1.5 R 0 3.1

R R 2.5 R R 4.0

R F 3.2 R F 4.8

R 1 4.0 R 1 5.6

F 0 4.8 F 0 6.3

TUSB564RNQ EVM Configuration

www.ti.com

4SLLU288–March 2018

Submit Documentation Feedback

TUSB564RNQ Evaluation Module

Table 3. USB 3.1 EQ Settings (continued)

USB 3.1 Downstream Facing Ports USB 3.1 Upstream Facing Ports

EQ1 Pin Level EQ1 Pin Level EQ Gain at 2.5 GHz

(dB) SSEQ1 Pin

Level SSEQ1 Pin

Level EQ Gain at 2.5 GHz

(dB)

F R 5.5 F R 7.0

F F 6.0 F F 7.5

F 1 6.6 F 1 8.1

1 0 7.1 1 0 8.5

1 R 7.6 1 R 9.1

1 F 8.0 1 F 9.5

1 1 8.5 1 1 9.9

Table 4. DisplayPort™ EQ Settings

All DisplayPort Lanes

DPEQ1 Pin Level DPEQ0 Pin Level EQ Gain at 5 GHz (dB)

0 0 –0.3

0 R 1.6

0 F 3.0

0 1 4.4

R 0 5.4

R R 6.5

R F 7.3

R 1 8.1

F 0 8.9

F R 9.5

F F 10.0

F 1 10.6

1 0 11.0

1 R 11.4

1 F 11.8

1 1 12.1

3.3 Power

The EVM is designed to operate off of the VBUS from a USB host connected through USB Type-C (P2). A

5-V external power is applied through J8 only if stand-alone operation is desired.

If testing DisplayPort only, or if bypassing VBUS power, the EVM must be powered through J8 (a 5-V, 1-A

input).

CC1

CC2

C_USB_TN

C_USB_TP

C_USB_BP

C_USB_BN

SBU2

SBU1

EQ0

EQ1

I2C_EN

USB_N

USB_P

CTL1

TPS_SBU1

TPS_SBU2

TPS_AUX_P

TPS_AUX_N

FLIP/SCL

CTL0/SDA

I2C_SCL

I2C_SDA

SSEQ1

DPEQ1

SSEQ0/A0

DPEQ0/A1

HPD

3P3VCC

VBUS

1064_VCC

VBUS_DS

3P3VCC

USB3 Type A Receptacle

VBUS

USB2_DM

USB2_DP

GND

SS_RX_N

SS_RX_P

GND_Drain

SS_TX_N

SS_TX_P

Shield1 10

Shield2 11

C12 100nF

R6 0

R14

100k DNI

C47

10nF

C22

1uF

C19 220nF

TPD4E05U06

D1+

D1-

GND

D2+

D2-

5NC6 6

NC7 7

GND 8

NC9 9

NC10 10

R16 0 DNI

R8 0

C8 470nF

C48

10nF

TPD4E05U06

D1+

D1-

GND

D2+

D2-

5NC6 6

NC7 7

GND 8

NC9 9

NC10 10

C14 100nF

470nF

R2 0

JAE DX07S024JJ2

GND A1

SSTXP1 A2

SSTXN1 A3

VBUS A4

CC1 A5

DP1 A6

DN1 A7

SBU1 A8

VBUS A9

SSRXN2 A10

SSRXP2 A11

GND A12

GND B1

SSTXP2 B2

SSTXN2 B3

VBUS B4

CC2 B5

DP2 B6

DN2 B7

SBU2 B8

VBUS B9

SSRXN1 B10

SSRXP1 B11

GND B12

CHASSIS

C23

1uF

TPD4E05U06

D1+

D1-

GND

D2+

D2-

5NC6 6

NC7 7

GND 8

NC9 9

NC10 10

C16 100nF

R17 0 DNI

10k DNI

R15 0 DNI

C13 470nF

C24

100nF

C11 470nF

470nF

C18 100nF

C25

100nF

C5 100nF

C4 220nF

Display_Port_Connector_Source

ML_0p

GND1

ML_0n

ML_1p

GND2

ML_1n

ML_2p

GND3

ML_2n

ML_3p

GND4

ML_3n

CAD

GND5

AUX_p

GND6

AUX_n

HPD

RTN

DP_PWR

GND7 21

GND8 22

GND9 23

GND10 24

R18 0 DNI

C15 470nF

R12

1M DNI

C20 100nF

C7 100nF

R3 0 DNI

C1 100nF

R83

C6 220nF

R10

100k DNI

R5 0 DNI

C26

10nF

C10 100nF

R13

1M DNI

R7 0

FB2

26 @ 100MHZ

C21

1uF

TUSB564

NC 1

DPEQ1 2

SSEQ1 3

SSRXp 4

SSRXn 5

VCC 6

SSTXp 7

SSTXn 8

TX1p

TX1n

EQ0

RX1p

RX1n

EQ1

RX2n

RX2p

I2C_EN

TX2n

TX2p

VCC

FLIP/SCL

CTL0/SDA

CTL1

SBU1

SBU2

AUXp

AUXn

VCC

EN 29

DP3N 30

DP3P 31

HPDIN 32

DP2N 33

DP2P 34

DPEQ0/A1 35

DP1N 36

DP1P 37

SSEQ0/A0 38

DP0N 39

DP0P 40

PAD/GND 41

C45

10nF

R84

C17 220nF

TPD4E05U06

D1+

D1-

GND

D2+

D2-

5NC6 6

NC7 7

GND 8

NC9 9

NC10 10

R11 0

C46

10nF

C9 100nF

DP0P

DP0N

DP1P

DP1N

DP2P

DP2N

DP3P

DP3N

AUXp

AUXn

HPD

CC1

CC2

SBU1

SBU2

TX1P

TX1N

RX2P

RX2N

TX2P

TX2N

RX1P

RX1N

TX1P

TX1N

TX2P

TX2N

RX1P

RX1N

RX2N

RX2P

SSRXN

SSRXP

SSTXP

SSTXN

SSRXP

SSRXN

SSTXP

SSTXN

DP0P

DP0N

DP1P

DP1N

DP2P

DP2N

DP3P

DP3N

AUXn

AUXp

TX1P

TX1N

RX1P

RX1N

TX1P

TX1N

RX1P

RX1N

TX2P

TX2N

RX2P

RX2N RX2N

RX2P

TX2N

TX2P

CC1

CC2

SBU1

SBU2

CC1

CC2

SBU1

SBU2

C_USB_BP

C_USB_BN

C_USB_TP

C_USB_TN

C_USB_BP

C_USB_BN

C_USB_TP

C_USB_TN

SBU1

SBU2

AUXp

AUXn

CONFIG1

CONFIG2

SBU1

SBU2

HPDIN HPDIN

www.ti.com

TUSB564RNQ EVM Schematics and Bill of Materials

SLLU288–March 2018

TUSB564RNQ Evaluation Module

4 TUSB564RNQ EVM Schematics and Bill of Materials

4.1 Schematics

The section provides schematics as supporting reference information.

Figure 3. TUSB564RNQ EVM Main Schematic

EQ0EQ1

FLIP/SCL

SSEQ1 SSEQ0/A0

CTL0/SDA

DPEQ1 DPEQ0/A1

CTL1

I2C_EN

1064_VCC1064_VCC1064_VCC

1064_VCC

1064_VCC 1064_VCC

1064_VCC

1064_VCC 1064_VCC

1064_VCC1064_VCC

JMP4

4 Pin-T Berg Jumper

R20 1K

R24 1K

R23 20K

R35

JMP6

4 Pin-T Berg Jumper

R19 1K

R25 1K

HDR3X1 M .1

R29 1K

R26 20K

HDR3X1 M .1

R36 20K

R28

R30 1K

HDR3X1 M .1

R31 20K

R34 1K

R27 20K

R21 20K

JMP2

4 Pin-T Berg Jumper

R32 20K

R22

HDR3X1 M .1

R33

JMP3

4 Pin-T Berg Jumper

JMP1

4 Pin-T Berg Jumper

JMP7

4 Pin-T Berg Jumper

JMP5

4 Pin-T Berg Jumper

TUSB564RNQ EVM Schematics and Bill of Materials

www.ti.com

6SLLU288–March 2018

Submit Documentation Feedback

TUSB564RNQ Evaluation Module

Figure 4. TUSB564RNQ EVM Configuration Pins

SPI Programming Header

SILKSCREEN:

SPI

TPS65982

CC1

CC2

C_USB_TP

C_USB_TN

C_USB_BP

C_USB_BN

USB_P

USB_N

FLIP/SCL

CTL0/SDA

CTL1

HPD

TPS_SBU1

TPS_SBU2

TPS_AUX_P

TPS_AUX_N

I2C_SCL

I2C_SDA

LDO_3P3

VOUT_3P3

LDO_3P3

TPS65986_3P3V

VBUS

VBUS_DS

SYS_PWR

VBUS

TPS65986_3P3V

VDDIO

C27

0.22uF

C36

1uF

R58

3.3k

SW1

4-POS 50-MIL SMT

455

R38 0

C30

10uF

C32

1uF

R60 100k

C39

0.01uF

R64

R72 3.3k

R50

C37

0.1uF

R41 0

R59

3.3k

C50

10uF

R87 100k

C33

1uF

HDR3X2 .1X.1

R45 1M

C51

1uF 25V

C38

0.1uF

R43 0

R46 0 DNI

JMP8

Header 5x2

R73 3.3k

R74 3.3k

R51

R47 1M

Header 5x2 0.1" Shroud RA thru-hole

R66 0

R52 100k DNI

R44 0

C34

1uF

R61

TPS65986

GND

LDO_1V8D

SPI_CLK

SPI_MISO

GND

PP_HV1

PP_HV2

PP_HV3

NC3 A9

SENSEN A10

PP_5V0_2

A11

VDDIO

GPIO0 B2

SPI_SSZ

SPI_MOSI

GND

NC1

PP_HV4

GND

NC2 B9

SENSEP B10

PP_5V0_1

B11

I2C_IRQ1Z

GPIO1 C2

GPIO4

C10

PP_5V0_3

C11

I2C_SDA1

I2C_SCL1

DBG_CTL2

HRESET

GPIO7 D7

GND

GPIO2 D10

PP_5V0_4

D11

LDO_BMC

UART_TX

DBG_CTL1

GND

GPIO5

E10

MRESET E11

I2C_ADDR

UART_RX

SWD_DAT

GND

BUSPOWERZ F10

RESETZ F11

LDO_3V3

R_OSC G2

SWD_CLK

GND

GPIO6 G10

GPIO3 G11

VIN_3V3

VOUT_3V3

GND

GPIO8 H6

SS H7

GND

PP_CABLE

H10

VBUS1 H11

AUX_P

AUX_N

VBUS2 J10

VBUS3 J11

LDO_1V8A

DEBUG2

DEBUG4

NC4

USB_RP_N

C_USB_TP K6

C_USB_BP K7

C_SBU1 K8

RPD_G1 K9

RPD_G2 K10

VBUS4 K11

GND

DEBUG1

DEBUG3

GND

USB_RP_P

C_USB_TN L6

C_USB_BN L7

C_SBU2 L8

C_CC1 L9

C_CC2 L10

NC L11

C49

10uF

R49 1M

R62

R67 3.3k

R40 0

R71 3.3k DNI

R42 0

C28

330pF

R37 0

R48 1M

R70 0

R39 15k 0.1%

HDR2X2 M .1X.1

C35

1uF

R57

10k

R63

C29

330pF

R68 3.3k

W25Q80

/CS

/WP 3

GND 4

VCC 8

CLK

6DI

/HOLD

C31

1uF

R53 100k

GPIO5

I2C_IRQ1Z

I2C_SCL1

LCO_1P8VD

LCO_1P8VA

LDO_BMC

I2C_SCL1

I2C_SDA1

SPI_MISO

SPI_CLK SPI_MOSI

SPI_SSZ

I2C_ADDR

SPI_SSZ

SPI_MISO

SPI_MOSI

SPI_CLK

DBG_CTL2

DBG_CTL1

SPI_SSZ

SPI_MISO

SPI_MOSI

SPI_CLK

SPI_HOLD#

SPI_WP#

CTL0/SDA

FLIP/SCL

HPD

GPIO6

CTL1

GPIO3

GPIO5

GPIO7

GPIO8 GND

GPIO3

GPIO6

GPIO7

GPIO8

I2C_ADDR

DBG_CTL1

DBG_CTL2

CC1

CC2

VBUS

VBUS_DS

SYS_PWR

I2C_SDA1

LCO_1P8VD

www.ti.com

TUSB564RNQ EVM Schematics and Bill of Materials

SLLU288–March 2018

TUSB564RNQ Evaluation Module

Figure 5. TPS65986

3.3V REGULATOR

DOWNSTREAM PORT/PP_5V POWER SWITCH

5V INPUT

+5V / Max 3A Input

SYS_PWR

VBUS_DS

3P3VCC

1064_VCC TPS65986_3P3V

SYS_PWR

VBUS

VDDIO LDO_3P3

R82

0 DNI

2.1mm x 5.5mm

R75

R77

330

FB1

26 @ 100MHZ

R76

R78

330

TPS7A4501

SHDN/

GND

OUT 4

ADJ 5

GND

R80

3.9K

R85 0

C41

10uF

R86 0 DNI

C44

10uF

R81

1.2K

LED Green

R79

0 DNI

C42

10uF

C40

22uF

TPS7A4533

GND

SENSE 5

OUT 4

SHDN/

PMEG3050EP, 115

C43

10uF

TUSB564RNQ EVM Schematics and Bill of Materials

www.ti.com

8SLLU288–March 2018

Submit Documentation Feedback

TUSB564RNQ Evaluation Module

Figure 6. TUSB564RNQ EVM Power

www.ti.com

TUSB564RNQ EVM Schematics and Bill of Materials

SLLU288–March 2018

TUSB564RNQ Evaluation Module

4.2 Bill of Materials

Table 5 lists the bill of materials.

Table 5. Bill of Materials

Item Qty Reference Part Footprint Manufacturer Manufacturer Part Number Description

1 10 C1,C5,C7,C9,C10,C12,C14,

C16,C18,C20 100 nF c0201 Murata GRM033R61A104KE15D CAP CER, 0.1-µF, 10-V X5R 0201

2 6 C2,C3,C8,C11,C13,C15 470 nF c0201 Murata GRM033R60J474KE90D CAP CER, 0.47-µF, 6.3-V X5R 0201

3 4 C4,C6,C17,C19 220 nF c0201 Murata GRM033R60G224ME15D CAP CER, 0.22-µF, 4-V, X5R 0201

4 9 C21,C22,C23,C31,C32,C33,

C34,C35,C36 1 µF c0402 Murata GRM155R60J105ME19D CAP CER, 1-µF, 6.3-V X5R 0402

5 2 C24,C25 100 nF c0402 Murata GRM155R61A104KA01D CAP CER, 0.1-µF, 10-V X5R 0402

6 5 C26,C45,C46,C47,C48 10 nF c0402 Murata GRM155R71C103KA01D CAP CER, 10000-pF, 16-V X7R 0402

7 1 C27 0.22 µF c0402 Murata GRM152R61A224KE19D CAP CER, 0.22-µF, 10-V X5R 0402

8 2 C28,C29 330 pF c0402 Murata GRM1555C1E331JA01D CAP CER, 330-pF, 25-V C0G/NP0 0402

9 5 C30,C43,C44,C49,C50 10 µF c0603 Murata GRM188R61E106MA73D CAP CER, 10-µF, 25-V X5R 0603

10 2 C37,C38 0.1 µF c0402 Murata GRM155R61A104KA01D CAP CER, 0.1-µF, 10-V X5R 0402

11 1 C39 0.01 c0402 Murata GRM155R71C103KA01D CAP CER, 10000-pF, 16-V X7R 0402

12 1 C40 22 µF c1206 Murata GRT31CR61E226ME01L CAP CER, 22-µF, 25-V X5R 1206

13 2 C41,C42 10 µF c1206 Murata GRM319R61E106KA12D CAP CER, 10-µF, 25-V X5R 1206

14 1 C51 1 µF, 25 V c0603 Murata GRM185R61E105KA12D CAP CER, 1-µF, 25-V X5R 0603

15 1 D1 SCHOTTKY DO-214AA NXP PMEG3050EP,115 DIODE SCHOTTKY 30-V 5-A SOD128

16 1 D2 LED green 805 Lumex LTST-C170KGKT LED GREEN CLEAR 0805 SMD

17 1 D3 TPD1E10B06 DPY0001AA Texas Instruments TPD1E10B06DPYR Schottky

18 1 D4 LED green 0805 805 Lumex LTST-C170KGKT LED GREEN CLEAR 0805 SMD

19 2 FB1,FB2 26 at 100 MHz 603 Murata BLM18SG260TN1D FERRITE BEAD 26 Ω0603 1LN

20 7 JMP1A,JMP2A,JMP3A,JMP

4A,JMP5A,JMP6A,JMP7A 4 Pin-T Berg Jumper BERGSTIK II .100" SR

STRAIGHT AMP 68000-103HLF 3 Positions Header Connector 0.100" (2.54 mm) Through-Hole Gold or Gold,

GXT™

21 7 JMP1B,JMP2B,JMP3B,JMP

4B,JMP5B,JMP6B,JMP7B BERGSTIK II .100" SR

STRAIGHT AMP 68000-101HLF 1 Positions Header Connector 0.100" (2.54 mm) Through-Hole Gold or Gold,

GXT™

22 1 JMP8 Header 5 × 2 HDR_THVT_2x5_100 FCI 68021-210HLF CONN HEADER 10-POS .100 R/A 15AU

23 4 J1,J2,J3,J4 HDR3X1 M .1 HDR_THVT_1x3_100_M 3M 961103-6404-AR CONN HEADER VERT SGL 3-POS GOLD

24 1 J5 HDR3X2 .1X.1 HDR_THVT_2x3_100_M Harwin M20-9980345 DIL VERTICAL PC TAIL PIN HEADER

25 1 J6 HDR2X2 M .1X.1 HDR_THVT_2x2_100 Amphenol FCI 67997-404HLF CONN HEADER 4-POS .100 STR TIN

26 1 J7 Header 5 × 2 0.1"

Shroud RA through-

hole

HDR_THRT_2X5_ 100 Amphenol FCI 67997-410HLF CONN HEADER 10-POS .100 STR TIN

27 1 J8 2.1 mm × 5.5 mm PJ-202AH CUI Inc. PJ-202AH CONN PWR JACK 2-mm × 5.5-mm KINKED PIN

28 2 LB1,LB2 THD-47-478-10 Rectangle Brady THD-47-478-10 LB1 = "HSDC025A-001", LB2 = "TUSB564RNQEVM"

29 1 P1 JAE DX07S024JJ2 USB-C_SMRT_DX07S024JJ2 JAE DX07B024JJ2 CONN RCPT USB 3.1 USB Type-C BRD EDGE

30 1 P2 USB3 Type-A

receptacle USB3_TYPEA AMP GSB4111312HR USB 3.1 Type-A Connector

31 1 P3 Display_Port_

Connector_Source CON_DP_SD-47272-001 Molex Inc. 472720001 CONN RCPT 20-POS UDI R/A SMD

TUSB564RNQ EVM Schematics and Bill of Materials

www.ti.com

10 SLLU288–March 2018

Submit Documentation Feedback

TUSB564RNQ Evaluation Module

Table 5. Bill of Materials (continued)

Item Qty Reference Part Footprint Manufacturer Manufacturer Part Number Description

32 0 R1 10k DNI r0402 Panasonic Electronic

Components ERJ-2GEJ103X RES SMD 10 kΩ5% 1/10W 0402

33 11 R2,R6,R7,R8,R11,R41,R43,

R44,R66,R70,R85 0 r0402 Panasonic Electronic

Components ERJ-2GE0R00X RES SMD 0-ΩJUMPER 1/10W 0402

34 0 R3,R5,R15,R16,R17,R18,R

46,R86 0 DNI r0402 Panasonic Electronic

Components ERJ-2GE0R00X RES SMD 0-ΩJUMPER 1/10W 0402

35 0 R4,R14,R52 100k DNI r0402 Panasonic Electronic

Components ERJ-2GEJ104X RES SMD 100 kΩ5% 1/10W 0402

36 7 R9,R45,R47,R48,R49,R50,

R51 1M r0402 Panasonic Electronic

Components ERJ-2GEJ105X RES SMD 1 MΩ5% 1/10W 0402

37 1 R10 5M r0402 Ohmite HVC0402T5004JET RES SMD 5 MΩ5% 1/20W 0402

38 0 R12,R13 1M DNI r0402 Panasonic Electronic

Components ERJ-2GEJ105X RES SMD 1-MΩ5% 1/10W 0402

39 15 R19,R20,R22,R24,R25,R28,

R29,R30,R33,R34,R35,R61,

R62,R63,R64

1k r0402 Panasonic Electronic

Components ERJ-2GEJ102X RES SMD 1 kΩ5% 1/10W 0402

40 7 R21,R23,R26,R27,R31,R32,

R36 20K r0402 Panasonic Electronic

Components ERJ-2RKF2001X RES SMD 20 kΩ1% 1/10W 0402

41 2 R37,R38 0 r0201 Panasonic Electronic

Components ERJ-1GN0R00C RES SMD 0-ΩJUMPER 1/20W 0201

42 1 R39 15k 0.1% r0402 Panasonic Electronic

Components ERA-2AEB153X RES SMD 15 kΩ0.1% 1/16W 0402

43 2 R40,R42 0 r0402 Panasonic Electronic

Components ERJ-2GE0R00X RES SMD 0-ΩJUMPER 1/10W 0402

44 3 R53,R60,R87 100k r0402 Panasonic Electronic

Components ERJ-2GEJ104X RES SMD 100 kΩ5% 1/10W 0402

45 1 R57 10k r0402 Panasonic Electronic

Components ERJ-2GEJ103X RES SMD 10 kΩ5% 1/10W 0402

46 7 R58,R59,R67,R68,R72,R73,

R74 3.3k r0402 Panasonic Electronic

Components ERJ-2GEJ332X RES SMD 3.3 kΩ5% 1/10W 0402

47 0 R71 3.3k DNI r0402 Panasonic Electronic

Components ERJ-2GEJ332X RES SMD 3.3 kΩ5% 1/10W 0402

48 2 R75,R76 0 r1206 Panasonic Electronic

Components ERJ-8GEY0R00V RES SMD 0-ΩJUMPER 1/4W 1206

49 2 R77,R78 330 r0402 Panasonic Electronic

Components ERJ-2GEJ331X RES SMD 330 Ω5% 1/10W 0402

50 0 R79,R82 0 DNI r0805 Panasonic Electronic

Components ERJ-6GEY0R00V RES SMD 0-ΩJUMPER 1/8W 0805

51 1 R80 3.9K r0402 Panasonic Electronic

Components ERA-2AEB392X RES SMD 3.9 kΩ0.1% 1/16W 0402

52 1 R81 1.2K r0402 Panasonic Electronic

Components ERA-2AEB122X RES SMD 1.2 kΩ0.1% 1/16W 0402

53 2 R83,R84 2M r0402 Panasonic Electronic

Components ERJ-2GEJ205X RES SMD 2 MΩ5% 1/10W 0402

54 4 SCRW1,SCRW2,SCRW3,S

CRW4 NY PMS 440 005

PH Screw B&F Fastener NY PMS 440 005 PH 40 × .5-inch nylon

55 8 SHNT1,SHNT2,SHNT3,SHN

T4,SHNT5,SHNT6,SHNT7,S

HNT8

QPC02SXGN-RC 0.1 Sullins Connector Solutions QPC02SXGN-RC CONN JUMPER SHORTING .100" GOLD

Tabla de contenidos

Otros manuales de Unidad de control de Texas Instruments

Texas Instruments

Texas Instruments TMS320C6A816 Series Manual del producto

Texas Instruments

Texas Instruments bq2023EVM-001 Manual de usuario

Texas Instruments

Texas Instruments DAC8574 Manual de usuario

Texas Instruments

Texas Instruments TAS5514B Manual de usuario

Texas Instruments

Texas Instruments TMS320C3 Series Manual de usuario

Texas Instruments

Texas Instruments TPS54383 Manual de usuario

Texas Instruments

Texas Instruments TPS54232EVM-415 Manual de usuario

Texas Instruments

Texas Instruments ADS7042EVM-PDK Manual de usuario

Texas Instruments

Texas Instruments PCM4222EVM Manual de usuario

Texas Instruments

Texas Instruments UCC25600EVM Manual de usuario

Texas Instruments

Texas Instruments BOOSTXL-SENSORS BoosterPack Manual de usuario

Texas Instruments

Texas Instruments USB-C-PD-TKT-EVM Manual de usuario

Texas Instruments

Texas Instruments TCA5405EVM Manual de usuario

Texas Instruments

Texas Instruments DAC90 EVM Series Manual de usuario

Texas Instruments

Texas Instruments LMZ35003EVM-001 Manual de usuario

Texas Instruments

Texas Instruments TPS544 20 Series Manual de usuario

Texas Instruments

Texas Instruments MCT8316ZTEVM Manual de usuario

Texas Instruments

Texas Instruments OPT3004EVM Manual de usuario

Texas Instruments

Texas Instruments TDC7200EVM Manual de usuario

Texas Instruments

Texas Instruments TA 5 1 Q15B5EVM-K Series Manual de usuario

Texas Instruments

Texas Instruments bq27 10EVM Series Manual de usuario

Texas Instruments

Texas Instruments TMCS1101EVM Manual de usuario

Texas Instruments

Texas Instruments BoosterPack Educational Plug-in Module Mark II... Manual de usuario

Texas Instruments

Texas Instruments TPS55165Q1-EVM Manual de usuario

Manuales populares de Unidad de control de otras marcas

Festo

Festo Compact Performance CP-FB6-E Manual de lista de piezas

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manual de usuario

JS Automation

JS Automation MPC3034A Manual de usuario

JAUDT

JAUDT SW GII 6406 Series Guía rápida

Spektrum

Spektrum Air Module System Manual de usuario

BOC Edwards

BOC Edwards Q Series Manual de usuario

KHADAS

KHADAS BT Magic Manual de usuario

Etherma

Etherma eNEXHO-IL Manual de usuario

PMFoundations

PMFoundations Attenuverter Manual de usuario

GEA

GEA VARIVENT Manual de usuario

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manual de usuario

Altronix

Altronix LINQ8PD Instrucciones de montaje

Eaton

Eaton Powerware Series Manual de usuario

WAGO

WAGO 750-407/040-000 Manual de usuario

Sony

Sony CCU-590 Manual de usuario

Graco

Graco 25D614 Manual de usuario

Task Force Tips

Task Force Tips YE-RF-900 Manual de programación

Shini

Shini SPV-U Series Manual de usuario
