Teufel BAMSTER PRO Manual
Technical Description and
Operating Instructions
2.0 Bluetooth speaker
BAMSTERPRO
2• BAMSTER PRO
General Notes and Information
Notice
The information in this document may change
without prior notice and in no way constitutes
any liability on the part of Lautsprecher Teufel
GmbH.
No part of these instructions may be repro-
duced in any form or be broadcasted in any
way electronically, mechanically, by photocopy
or recording without the written permission of
Lautsprecher Teufel GmbH.
© Lautsprecher Teufel GmbH
Version 2.1
September 2020
Trademarks
® All trademarks are the property of their
respective owners.
Bluetooth®and the Bluetooth
symbol are trademarks of Blue-
tooth SIG, Inc.
Contents
General Notes and Information. . . . . . . . . . 2
For Your Safety . . . . . . . . . . . . . . . . . . . . . . . . 4
Product Contents. . . . . . . . . . . . . . . . . . . . . . 9
Control Elements and Connections . . . . . 10
Charging the Rechargeable Battery. . . . . 12
Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Cleaning & Maintenance . . . . . . . . . . . . . . 17
Protecting the Environment . . . . . . . . . . . . 18
Technical Data . . . . . . . . . . . . . . . . . . . . . . . 19
Declaration of Conformity . . . . . . . . . . . . . 20
3• BAMSTER PRO
aptX®and the aptX symbol are
trademarks of CSR plc or affiliated
companies and may be registered
in several countries.
Original packaging
If you wish to exercise your eight-week right of
return, we ask that you be absolutely sure to
hold onto the packaging. We can only accept
the return of the speakers WITH THE ORIGINAL
PACKAGING.
Empty boxes are not available!
Complaints
In case of complaint we will need the following
information to process your enquiry:
1. Invoice number
Can be found on the sales slip (enclosed with
the product) or on the order confirmation re-
ceived as a PDF document, e.g. 4322543
2. Serial number or batch number
Located on the back of the device,
e.g. serial no.: KB20240129A-123.
Thank-you for your support!
Contact
Please contact our customer service with any
questions, suggestions or criticism:
Lautsprecher Teufel GmbH
BIKINI Berlin
Budapester Str. 44
10787 Berlin (Germany)
Phone 00800 - 200 300 40 (toll-free)
Fax: +49 (0)30 / 300 930 930
Service: www.teufelaudio.com/service
Contact: www.teufelaudio.com/contact
4• BAMSTER PRO
For Your Safety
Proper use
The BAMSTER PRO is designed for the play-
back of music and speech from an external
player. The devices can be connected via
Bluetooth or AUX cable
The BAMSTER PRO is protected against
splash water and dust and may be used
outdoors. However, you must protect your
BAMSTER PRO against strong and persistent
rain.
Only use the BAMSTER PRO as described
in this user manual. Any other use will be
deemed as not in accordance with the instruc-
tions and may lead to physical damage or
even injury of persons.
The manufacturer accepts no liability for dam-
age
caused by improper use
.
The BAMSTER PRO is only intended for private
use.
Before operating the BAMSTER PRO,
please first read the safety notes and
user manual carefully. Only in this way,
can you ensure that all functions are used in a
safe and reliable manner. Store the user man-
ual in a safe place and also be sure to pass it
on to any subsequent owner.
Definition of terms
You can find the following signal terms in
these instructions:
WARNING
This signal term indicates a moder-
ate risk, which, if not avoided, may
result in death or severe injury.
5• BAMSTER PRO
CAUTION
This signal term indicates a low risk,
which, if not avoided, may result in
minor or moderate injury.
NOTICE
This signal term warns you of poten-
tial damage.
Safety Notes
Read these instructions.
Follow all instructions.
WARNING
Risk of electric shock:
Improper electrical installation or
excessive mains voltage may result
in an electrical shock.
–Only use attachments/accessories
specified by the manufacturer.
–Use only the supplied mains adapt-
er. Make sure that the mains voltage
is correct. More detailed information
is available directly on the mains
adapter.
–Check the mains adapter regularly
for damage. Never use the mains
adapter, if its casing is defective or
exhibits other visible damage.
–Only use the BAMSTER PRO and the
mains adapter in indoor areas, do
not use it in moist areas and pro-
tect it from drops of water or splash
water.
6• BAMSTER PRO
–Never open the unit’s hous-
ing of the mains adapter or the
BAMSTER PRO.
–Unplug this mains adapter during
lightning storms or when unused for
long periods of time.
Risk of explosion:
Batteries (particularly lithium batter-
ies) can explode if used improperly.
–Do not install the BAMSTER PRO
near any heat sources such as
radiators, heat registers, stoves, or
other apparatus (including amplifi-
ers) that produce heat.
Do not expose the BAMSTER PRO to
direct sunlight and do not dispose of
it in a fire.
–Only use the accessories/tools of
outfit (e.g. battery pack) indicated
offering from producer.
–Battery pack shall not be exposed
to excessive heat such as sunshine,
fire or the like.
–No naked flame sources, such as
lighted candles, should be placed on
the apparatus.
–Do not use this BAMSTER PRO near
water.
–If the housing is defective, stop us-
ing the device and store it in an area
that is not accessible for children.
–Refer all servicing to qualified ser-
vice personnel. Servicing is required
when the BAMSTER PRO has been
damaged in any way, such as pow-
7• BAMSTER PRO
er-supply cord or plug is damaged,
liquid has been spilled or objects
have fallen into the apparatus, the
apparatus has been exposed to rain,
does not operate normally, or has
been dropped.
–Only use the BAMSTER PRO under
the following conditions:
• Ambient temperature: max. 40 °C
• Maximum height above sea level:
2000 m
Risk of injury:
The BAMSTER PRO permanently
generates magnetic fields that may
interfere with pacemakers and im-
planted defibrillators.
–Make sure that the BAMSTER PRO
and pacemaker/defibrillator are
always at a minimum distance of
10cm apart.
–Please contact your physician if you
have any questions on whether this
might affect the operation of your
implantable medical device.
CAUTION
An unsuitable location could lead to
damage.
–Do not use the BAMSTER PRO in en-
vironments with a risk of explosion.
–Only use Bluetooth in locations
where wireless transmission is per-
mitted.
8• BAMSTER PRO
Extended listening at high vol-
umes may lead to hearing loss.
–To avoid damage to health, avoid
extended listening at high volumes.
–When the volume is set high, always
keep a certain distance from the
device and never place your ear
directly on the speaker.
–If the signal source device is set to
full volume, it may produce very high
sound pressure. This may have psy-
chological consequences and also
cause physical injury. Children and
pets are particularly at risk. Set your
signal source device volume control
to a low setting before turning on the
power.
Explanation of symbols
Safety class II
Dual insulation
May only be used indoors.
9• BAMSTER PRO
Product Contents
1 × BAMSTER PRO
1 × Docking pad with mains adapter
DC 12 V/2 A
• Check that all items have been delivered
and that nothing is damaged. Should the
delivery be incomplete or damaged in any
way, please contact our customer service
department (see “Contact”).
• Do not operate a damaged device.
10 • BAMSTER PRO
Control Elements and
Connections
Control panel:
⑦⑧⑥⑤⑨
②①③④
①Show battery status (see ⑨).
②Activate Bluetooth pairing or disconnect
the Bluetooth connection (press and
hold for 3 s).
③Widening sound on/off.
④In Bluetooth-mode only: Pause ( ) and
play (►).
Answer / end a call.
⑤Volume up (+) / volume down (–).
⑥In Bluetooth-mode only:
Press: next track.
Press and hold: fast forward.
⑦Switch device on/off.
⑧In Bluetooth-mode only:
Press: previous track.
Press and hold: rewind.
⑨LED ring display for volume and charging
(see ①).
