4-Port Dual Monitor DP KVM Switch
DP Dual
USER MANUAL
1
ŸUsing only 1 set of keyboard, mouse and 2 monitors to control 2
computers
ŸSupport 2 monitors to display the desktop of 1 computer or to
display 2 desktops at the same time.
ŸSupport Unix/Windows/Debian/Ubuntu/Fedora/Mac OS X/
Raspbian/Ubuntu for Raspberry Pi and other Linux basic
system
ŸSupport resolution up to 3840*2160@60HZ
ŸSupport hot plug, disconnect or connect devices to the KVM at
any time without turning off PC
ŸSupport front panel button, keyboard hotkeys, IR remote control
and RS232 to control KVM
ŸAvailable to use keyboard and mouse without any delay after
switching input sources
ŸWith extra USB 2.0 port, it is possible to connect bar code
scanner, USB hard device or other USB device
ŸSupport keyboard and mouse pass through mode to improve
KVM compatibility
ŸSupport auto switch to monitor computers in a specified time
interval
ŸSupport DCCI
Features:
Packing List
1 * Dual Monitor DP KVM Switch
1 * IR remote control
1 * IR Receiver cable
1 * DC 12V power adapter
1 * 3 Pins Connector(For RS232)
2 * Rack-eras
1 * AUX Cable
1 * User manual
DP Dual
2
Panel Description:
ID
Name
Description
1
DC 12V
DC 12V power supply
2
RS232 port
Connect this port to any control termination,
then it is able to select the input sources by
sending RS232 commands
3
Ext.IR
For extended IR receiver cable input
4
L/R audio output
Analog audio output, connect to speaker
5
Standard USB 2.0
port
Connect to USB 2.0 devices, printers, USB
drives
6
DCCI port
Used for product cascading to realize
simultaneous display of 4 monitors
DP Dual
15 16 17 184
5
13 14
57
6
1 2
4
8 9 12
8
11
3
810
3
ID
Name
Description
7
Keyboard and
mouse input
Connect to keyboard and mouse
8
DP output ports
Connect to DP displays
9
PC 4 Input
DP input A/B:Connect to the two outputs of
the same computer
USB:Connect to computer by USB Type A to
Type B cable
10
PC 3 Input
DP input A/B:Connect to the two outputs of
the same computer
USB:Connect to computer by USB Type A to
Type B cable
11
PC 2 Input
DP input A/B:Connect to the two outputs of
the same computer
USB:Connect to computer by USB Type A to
Type B cable
12
PC 1 Input
DP input A/B:Connect to the two outputs of
the same computer
USB:Connect to computer by USB Type A to
Type B cable
13
Auto scan time
interval settings
[MIN]: Press [MIN] to loop between 0~59
minutes
[SEC]: Press [SEC] to loop between 0~59
seconds
[Set]: After setting minutes and seconds,
press button [Set] to enter final scan time
interval setting
DP Dual
ID
Name
Description
14
LED display
Display current selected input port
15
Status LED
Red: Turn off auto scanning mode
Green: Turn on auto scanning mode
16
IR receiver
Receive IR remote signal
17
Keypad
[1~4]: Press button[1]~[4] to directly select input
1~4
[Output A]: Keyboard and mouse focus on the
desktop of output A in the display mode 2
[Output B]: Keyboard and mouse focus on the
desktop of output B in the display mode 2
[Output A]+[1~4]: After pressing [Output A],
then press [1~4] to switch input sources of
output A
[Output B]+[1~4]: After pressing [Output B],
then press [1~4] to switch input sources of
output B
[Close]: Press this button to turn on or off the
LED display and monitor
[Scan]: Press this button to start or stop
automatically scanning between input1 to input8.
The interval time can be set by [Set], [MIN],
[SEC] as described above
18
Power switch
Turn on or turn off power supply
4
DP Dual
Connection Diagram :
Step1:Connect the two outputs of the PC1 to the Input A and
Input B of the KVM PC1 inputs.
Connect the USB of the PC to the USB of the KVM PC1
inputs with USB type A to B cable
Note: Both Input A and Input B should be connected to the same computer. If
connect only one of them, then the dual monitor function would not
work properly.
Step 2: Connect keyboard, mouse and monitors to the specified
ports.
5
......
USB Cable DP Cable
USB Cable DP Cable
Keyboard Mouse
Monitor A
Monitor B
DP Cable
DP Dual
Step 3: Connect speakers, USB devices, Ext. IR and RS232 to
the KVM.
6
Step 4：Directly connect the DCCI port of first KVM switch
according to above steps, in order to realize simultaneous
display of 4 monitors
Barcode
Scanner
USB
drive Printer
Console center
Speaker
Speaker
Barcode
Scanner
USB
drive Printer
IR receiver
DP Dual
Console center
Speaker
Barcode
Scanner
USB
drive Printer Keyboard Mouse
Monitor A
Monitor B
(1) (2)
IR receiver
Monitor A
Monitor B
AUX Cable
Cascade Diagram
7
Note： The slave only connects to monitors and computers.
Computers need to connect 4 DP cables simultaneously.
DP Dual
Speaker
Monitor C
Monitor D
Barcode
Scanner
USB
drive Printer Keyboard Mouse
Console center
PC4 PC1
......
IR receiver Monitor A
Monitor B
DC 12V
DCCI
USB 2.0
Output B
Input A
Input B
USB
PC 4
Output A Input A
Input B
USB
PC 3
Input A
Input B
USB
PC 2
Input A
Input B
USB
PC 1
DC 12V
DCCI
USB 2.0
Output B
Input A
Input B
USB
PC 4
Output A Input A
Input B
USB
PC 3
Input A
Input B
USB
PC 2
Input A
Input B
USB
PC 1
AUX Cable
How To Use :
1. Set up the connection according to the connection diagram.
2. After all the PCs are started in step 1, then you can control the
Dual Monitor KVM by keyboard hot keys, IR control or the front-
panel key, the specific control methods are as follows:
Step 5: Turn on the power switch to start the Dual Monitor KVM.
How to use keyboard hot keys :
8
Select port by port number
4
+ +
Turn off auto switching mode
Press [Alt] key twice to change active
selected computer in display mode 2
Note: Display mode 2 means one monitor display one PC.
+
F11 Enable or disable buzzer sound
+ +
Note: Default auto switching time interval is 6 seconds, you are able to
change this value by following hot key commands:
Turn on auto switching mode
+ +
Increase or decrease auto
switching time interval
Note:1 second per step, the time is up to 250 seconds.
+ +
