PT-110/PT-110 F
Operation and Maintenance Manual
Compact Track Loader
Version: EN
Edition: 2013-02
Part Number: 2095-479 (US)
Valid From Serial No: 00101 (PT-110)
00101 (PT-110F)
Original Instructions
CONTENTS
Introduction...................................................... 2
Safety ................................................................. 5
Technical Data.................................................. 29
Machine Description / Controls................. 35
Operation........................................................... 59
Transportation.................................................. 69
Maintenance..................................................... 75
California Proposition 65.............................. 96
Service Log ........................................................ 97
1
Page
The operator must read and understand all the instructions in this
manual before operating the machine.
PT-110/PT-110F US O&M
2095-479 2013-02
1 INTRODUCTION
2
1.1 Product Identification (PIN)
The machine PIN is located on the identifi-
cation plate, on the front surface of the
operator enclosure.
Please state the model of the machine and
PIN when making inquiries in regards to
parts, service, or warranty.
1.2 Introduction
Thank you for purchasing a Terex Compact Track Loader. We are confident
that the machine you have chosen will provide excellent performance and effi-
cient operation.
The information contained in this manual is intended to provide the operator with
all necessary information for the proper use of the machine.
It is imperative that this manual be provided to the end user at the time of pur-
chase, prior to operation and kept with the machine at all times. If lost or dam-
aged, contact your dealer immediately to obtain a replacement prior to resuming
operation.
It is very important that the operator read and understand the information in
this manual prior to operating the machine or performing maintenance or
service.
During operation, it is very important that the operator obey the instructions
in this manual to ensure safe and efficient operation.
Should you need clarification or further explanation of the topics in this manual,
please contact your dealer immediately for assistance.
Information describing special equipment or attachments and their operation are
not included in this manual.
This manual should be stored in the black plastic manual box located inside the
cab enclosure.
1.3 Safety Alert Symbol
The safety alert symbol is used to alert you to potential personal injury
hazards. Obey all safety messages that follow this symbol to avoid
possible injury or death.
1.4 Intended Use
The machine with standard dirt bucket is intended to be used solely for work con-
sistent with its design. Such work includes loosening, collecting, transporting, and
distributing soil, rock, or similar materials as well as loading these materials onto
trucks, conveyors, or other methods of transport.
PT-110/PT-110F US O&M
2095-479 2013-02
1 INTRODUCTION
3
After installation of compatible (see section 4.13) special working attachments,
the equipment can be used for corresponding applications.
The operator must follow the enclosed operating instructions (manuals) for any
externally supplied components or attachments.
This machine can also be used for towing provided the specific operating
instructions found in the “towing” section of this manual are followed.
Any use varying from that described here or any lack of adherence to the operat-
ing instructions, maintenance procedures, or replacement intervals described in
this manual shall be regarded as unintended or improper use. The supplier cannot
be held responsible for any damage resulting from improper use. This risk is
borne solely by the user.
Note: Mulching type brush cutting attachments commonly used on this type of
machine may become unbalanced due to worn, damaged, or missing “teeth”,
causing vibration. If the attachment is operated in this condition, it can cause
metal fatigue and / or cracking in both the host machine and the attachment
itself. Vibration can also cause hydraulic component failure (ex: relief valves).
Mulching type brush cutters also generate more dust and flying debris than other
attachments. The increased particles can plug coolers, radiators, and air cleaners
much faster causing overheat or even engine failure if left unattended. The debris
can also be introduced into many high temperature areas and can become a fire
hazard. Debris should be cleaned frequently from these areas.
Although these mulching type heads work extremely well on Terex machines with
high flow hydraulics, educate yourself on the increased maintenance and operat-
ing costs before using this type of attachment.
1.5 Bulletin Compliance
It is very important to comply with all safety related bulletins. Bulletins are tied to
the most current owner on record. Therefore, it is important that any new owner
contact their local dealer to register the machine in their name. This will ensure
that they will be notified in the event of a safety related bulletin affecting their
machine.
1.6 Contacting the Manufacturer
If you have questions relating to ownership including, but not limited to: accident
reporting, current owner updates, product applications and safety, standards and
regulations compliance, product modifications, transfer of ownership, please
consult your local dealer as the first point of contact.
PT-110/PT-110F US O&M
2095-479 2013-02
4
1.7 Copyright
This manual is intended for use by personnel responsible for operation, mainte-
nance, repair, and supervision activities involving the machine described within.
This manual is copyrighted. It shall not, either in whole or in part, be reproduced,
transmitted, or used for the purpose of competition without our prior written con-
sent.
1.8 Warranty
Your Terex PT-110 is warranted under the Terex Compact Track Loader and Utility
Vehicle Standard Limited New Product Warranty (“Warranty”). A copy of the
Warranty certificate is included with this manual and is also available from your
Authorized Terex Distributor.
1 INTRODUCTION
PT-110/PT-110F US O&M
2095-479 2013-02
2.1 Safety Alert System ................................. 7
2.2 Graphical Symbols................................... 8
2.3 Safety Signs (ANSI) .................................. 12
2.4 General Notes............................................ 14
2.5 Personal Protection Equipment ......... 15
2.6 Hazard Zone............................................... 15
2.7 Operation.................................................... 16
2.8 Stability........................................................ 17
2.9 Transport of Persons ............................... 17
2.10 Fire Prevention ....................................... 18
2.11 Crush / Burn Avoidance ...................... 19
2.12 Placing Into Operation ........................ 20
2.13 Starting the Machine ........................... 20
2.14 Jobsite Safety.......................................... 21
2.15 Parking the Machine ............................ 22
2.16 Towing / Retrieving............................... 22
2.17 Transporting............................................ 23
2.18 Maintenance ........................................... 24
2.19 Battery ....................................................... 26
2.20 Hydraulic Lines / Hoses....................... 27
Page
5
2 SAFETY
PT-110/PT-110F US O&M
2095-479 2013-02
6
PT-110/PT-110F US O&M
2095-479 2013-02
2.1 Safety Alert System
Safety Alert Symbol
This symbol means: Attention! Be alert! Your safety
is involved!
The safety alert symbol is used to alert you to potential
personal injury hazards. Obey all safety messages
that follow this symbol to avoid possible injury or
death.
This symbol is used as an attention-getting device throughout this manual as well
as on decals and labels fixed to the machinery to assist in potential hazard recog-
nition and prevention.
NOTICE
indicates a property damage
message.
Hazard Classification (applies only to ANSI safety signs)
The following signal words used with the safety alert symbol indicate a specific
level of severity of the potential hazard. Signal words used without the safety alert
symbol relate to property damage and protection only. Warnings in this publication
and on the product labels are identified by these symbols.
2 SAFETY
7PT-110/PT-110F US O&M
2095-479 2013-02
DANGER indicates a hazardous situ-
ation which, if not avoided, will
result in death or serious injury.
WARNING indicates a hazardous sit-
uation which, if not avoided, could
result in death or serious injury.
CAUTION, used with the safety alert
symbol, indicates a hazardous situ-
ation which, if not avoided, could
result in minor or moderate injury.
2.2 Graphical Symbols
Hazard Avoidance
Pictorial Pictorial Description
Hazard: Skin/Oil Injection
Avoidance:
• Relieve internal pressure before
disconnecting any line or fitting.
• Keep away from leaks or pin-
holes.
• Use cardboard to check for leaks.
Fluid injected into skin must be
surgically removed within a few
hours by a doctor familiar with this
type of injury or gangrene will
result.
Hazard: Corrosive
Avoidance: Read and understand
the operator’s manual.
Hazard: Entanglement
Avoidance: Stop machine and
remove key before servicing.
Hazard: Burn/Scald
Avoidance: Allow to cool before
opening.
8
2 SAFETY
PT-110/PT-110F US O&M
2095-479 2013-02
Hazard Avoidance
Pictorial Pictorial Description
Hazard: Explosion/Burn
Avoidance:
• Keep all flames/sparks away!
• No Smoking!
• Read and understand all
manuals.
Hazard: Fall
Avoidance: Use the provided
access system when entering or
exiting the machine.
Hazard: Fall
Avoidance: No Riders.
Hazard: Burn
Avoidance: Do not touch hot
surfaces.
Hazard: Crush
Avoidance: Fasten seat belt.
9
2 SAFETY
PT-110/PT-110F US O&M
2095-479 2013-02
