TempSen ITAG 4 Manual de usuario
USER MANUAL
EN
ITAG®4 / ITAG®4 Bio/ ITAG®4 TH DATA LOGGER
UM-ITAG4-160217 REV.B
Updated@ 03/02/2016
UM-ITAG4-160217 REV.B
CONTENTS
Product Overview .............................................................................................................................................. 3
Logger ........................................................................................................................................................ 3
LCD ............................................................................................................................................................ 4
Technical Specifications..................................................................................................................................... 5
TEMPCENTRE SOFTWARE............................................................................................................................. 6
How to download TempCentre software?................................................................................................... 6
Installing and using TempCentre software ................................................................................................. 6
Data Logger Configuration ................................................................................................................................ 7
Configuring Logger with TempCentre......................................................................................................... 7
Configuring Loggers Online........................................................................................................................ 7
Applying Configuration ............................................................................................................................... 8
Configuration Options................................................................................................................................. 8
Recording .........................................................................................................................................................11
Start Recording..........................................................................................................................................11
In Recording ............................................................................................................................................. 12
Stopping recording ................................................................................................................................... 14
Downloading Data ........................................................................................................................................... 15
Downloading Data by Obtaining PDF Report........................................................................................... 15
Downloading Data via TempCentre.......................................................................................................... 16
Data Results Explanation ................................................................................................................................ 16
Device Information.................................................................................................................................... 16
Logging Summary .................................................................................................................................... 16
Alarms ...................................................................................................................................................... 16
Battery.............................................................................................................................................................. 18
Shelf Life / Expiry Date............................................................................................................................. 18
Error Codes ..................................................................................................................................................... 19
MKT ................................................................................................................................................................. 19
Why is MKT important in the life of pharmaceuticals and perishable goods?.......................................... 19
Additional Information...................................................................................................................................... 20
Glossary........................................................................................................................................................... 21
Warranty .......................................................................................................................................................... 22
Revision History............................................................................................................................................... 23
UM-ITAG4-160217 REV.B
PRODUCT OVERVIEW
1. USB Plug
2. Start and Stop Button
3. View Button
4. LCD
5. *Humidity sensor window, only available on ITAG4 TH
UM-ITAG4-160217 REV.B
1. Overall alarm status
2. Relative humidity unit*
3. Temperature unit (Celsius and Fahrenheit)
4. Maximum, minimum, average
5. Power active indicator
6. Start timer and limit violation duration indicators
7. Recording indicator
8. Time units
9. Readings
10. Low alarm zone status (temperature sensor)
11. High alarm zone (temperature sensor)
12. Limit violation indicator
13. Number of limit violation events
14. High alarm zone (humidity sensor)*
15. Low alarm zone status (humidity sensor)*
*Applicable on ITAG4 TH
UM-ITAG4-160217 REV.B
TECHNICAL SPECIFICATIONS
Product
ITAG4
ITAG4 Bio
ITAG4 TH
Type
Single Use
Sensor
Internal NTC
Internal NTC
Internal temperature and humidity Sensor
Memory Capacity
7200 readings
Measurement Range
-30°C...70°C (-22°F...158°F)
-30°C...70°C (-22°F...158°F)
-30°C...70°C, 0% RH...100% RH
Accuracy
±0.5°C/0.9°F
±0.5°C/0.9°F
± 0.5°C (0°C…60°), ± 1°C (rest range)
±4% RH (20% RH...80% RH)
Resolution
0.1°C /°F
Logging Interval
1 minute...2 hours
Alarm Range
High and low alarm
High and low alarm/5 alarm ranges
High and low alarm
Battery
CR2032 lithium battery
Typical Run Time
60 days max
Shelf Life
2 years (1 year if power activated)
Automatic Data File
Encrypted PDF report with embedded raw data
Dimensions
93mm L x 45mm W x 7mm H
Weight
Approx. 25g
Protection Class
IP65
UM-ITAG4-160217 REV.B
TEMPCENTRE SOFTWARE
Please download and install the latest version of TempCentre software from www.tempsen.com.
If it’s your first time to download software from www.tempsen.com, please sign up with the information
required prior to downloading, then an email containing download link would be sent to the mail address
you left in couple of minutes.
If you want to download the software from www.tempsen.com again after your successful registration
last time, please click “I already signed up, download now” button in dialog box, then software would
begin to download in couple of minutes.
Please refer to TempCentre User Manual for installation and operation instructions of TempCentre software.
UM-ITAG4-160217 REV.B
DATA LOGGER CONFIGURATION
Connect ITAG4 data logger to USB port of PC, open TempCentre software, select Configure Device in tool
bar, software would automatically start searching and connecting devices, then user could start programming
of this data logger.
Connect ITAG4 logger to USB port of PC, open Internet Browser, go to www.itag4.com, input and select
configuration parameters you need, then download the configuration profile (.cfg format file), save it into the
logger created removable storage device “TempSenDisk”.
LCD displays “USB”when logger connected to PC.
IMPORTANT
Please only apply configuration profile the same product model on which configuration
file is created based.
Do not alter the configuration profile downloaded to avoid configuration error.
Configuration profile contains time zone information, so please do not use this file in
areas of different time zones, or it will result in incorrect time base.
UM-ITAG4-160217 REV.B
LCD displays “ConF”for configuration success when connection with PC
remains. (Only applicable to non-software configuration).
LCD displays “Err” for configuration failure, please re-configure device with
correct parameters.
Trip Number
A unique 10 digits alphanumeric number automatically created for identifying each monitoring task.
Trip Description
A brief note entered by user for describing monitoring task and showing on data report.
Logging Interval
The recording and sampling interval for data logger, optional from 1 minute to 2 hours.
Startup Mode
Manual Start
Device needs to be started by pressing Start/Stop button for 3seconds
Start Delay
The time device needs to wait before recording starts after manually activated, optional from 1
minute to 10 days.
IMPORTANT
Configuration to data logger would erase all data recorded, so please make sure you have
save the data before configuration.
Do not remove data logger from PC before you are prompted of configuration success.
UM-ITAG4-160217 REV.B
Auto Start
Device automatically starts recording on the specific date/time preset, no need to press Start/Stop
button after configuration.
Button Settings
Disable Stop Button
This option is used to avoid mistaken Stop Button action, once enabled, device could not be
stopped by pressing Start/Stop button, recording stops when logging cycle completes, however,
you are still allowed to stop recording through TempCentre.
Alarm Settings
Alarm Mode
No alarm setting
High & Low alarm, 2 alarm ranges determined by 2 alarm limits.
Multiple Alarm ranges, 5 alarm ranges determined by 5 alarm limits.
High alarm zones: A1, A2, A3
Ideal range: A4 (No alarm will be triggered when data falls within this range )
Low alarm zone: A5, A6
▪
Only ITAG4 Bio supports multiple alarm ranges.
Alarm Type
Single Event
Alarm could only be triggered when data over high limit (or under low limit) not less than an alarm
delay continuously.
Cumulative Alarm
Alarm could be triggered once the cumulative total time data over high limit (or under low limit) is
not less than an alarm delay.
UM-ITAG4-160217 REV.B
PDF Report Settings
PDF Report Title
This report title would be used for PDF report created automatically by data logger.
Time Base
Select Time Zone and enable/disable Day Light Saving time (DST) for PDF report.
Language
Select language for PDF report.
LCD Screens after Configuration
Start Delay
LCD displays “Stby” after configuration.
Auto Start
LCD displays “Stby”and a Clock after configuration indicating logger is
waiting for Auto Start on pre-set time.
