Teltonika FMC13A Guía de instalación
FMC13A
ADVANCED LTE TERMINAL WITH
FLEXIBLE INPUTS CONFIGURATION
Quick Manual v1.5
Quick Manual v1.5 // FMC13A 2
Telematics
CONTENT
Content.................................................................................................................................................................................................................2
Know your device................................................................................................................................................................................................3
Pinout ...................................................................................................................................................................................................................4
Wiring scheme.....................................................................................................................................................................................................5
Set up your device ..............................................................................................................................................................................................6
PC Connection (Windows)..................................................................................................................................................................................7
How to install USB drivers (Windows) ..............................................................................................................................................................7
Conguration.......................................................................................................................................................................................................8
Quick SMS conguration................................................................................................................................................................................. 10
Mounting recommendations.......................................................................................................................................................................... 12
Basic characteristics ........................................................................................................................................................................................ 13
LED indications................................................................................................................................................................................................. 13
Electrical characteristics.................................................................................................................................................................................. 16
Safety information .......................................................................................................................................................................................... 18
Certication .................................................................................................................................................................................................... 19
Warranty ........................................................................................................................................................................................................... 20
Warranty disclaimer ....................................................................................................................................................................................... 20
Quick Manual v1.5 // FMC13A 3
Telematics
KNOW YOUR DEVICE
STATUS
LED
NAVIGATE
LED
MICRO-SIM
SLOT
BATTERY
SOCKET
2x6
SOCKET
GNSS
ANTENA
TOP VIEW TOP VIEW
(WITHOUT COVER)
BOTTOM VIEW
(WITHOUT COVER)
Quick Manual v1.5 // FMC13A 4
Telematics
PINOUT
10
9
8
7
11
12
4
3
2
1
5
6
DOUT2
1WIRE POWER
1WIRE DATA
GND
DOUT1
INPUT 5
DIN3/AIN2
DIN 2-N / AIN 1
DIN1
DOUT3
+10...30 V DC
INPUT 6
FMC13A 2x6 socket pinout
Pin number Pin name Description
1 VCC (10-30) V DC (+) Power supply (10-30
V DC)
2 DOUT 3
Digital output, channel
3. Open collector output.
Max. 0,5 A DC
3 DIN 3 / AIN 2
Analog input, channel 2.
Input range: 0-30 V DC /
Digital input, channel 3
4 DIN 2-N / AIN 1
Digital input, channel 2,
Negative input (ground
sense), Analog input,
channel 1, Input range:
0-30 VDC
5 DIN 1 Digital input, channel 1
6 INPUT 6 TX EXT (LVCAN – TX)
7 GND (-) Ground pin. (10-30) V
DC (―)
8 DOUT 1
Digital output, channel
1. Open collector output.
Max. 0,5 A DC
9 DOUT 2
Digital output, channel
2. Open collector output.
Max. 0,5 A DC
10 1WIRE POWER +3,8 V output for 1–Wire
devices
11 1WIRE DATA Data for 1–Wire devices
12 INPUT 5V RX EXT (LVCAN - RX)
Quick Manual v1.5 // FMC13A 5
Telematics
WIRING SCHEME
BUZZER
30
8586
87a
87
IGNITION
DETECTION
FUEL GAUGE
STARTER
IBUTTON
POWER SUPPLY
10 - 30V DC
ANALOG
LLS SENSOR
CAN-CONTROL
ALARM BUTTON
DOOR SENSOR CENTRAL LOCK
DOUT2
1WIRE POWER
1WIRE DATA
GND
DOUT1
INPUT 5
DIN3/AIN2
DIN2-N/AIN1
DIN1
DOUT3
+10...30 V DC
INPUT 6
AIN2
DIN3
DIN2
DIN2-N
10
9
8
7
11
12
4
3
2
1
5
6
Quick Manual v1.5 // FMC13A 6
Telematics
SET UP YOUR DEVICE
HOW TO INSERT MICRO-SIM CARD AND CONNECT THE BATTERY
4
1COVER REMOVAL 3BATTERY CONNECTION
2MICRO-SIM CARD INSERT ATTACHING COVER BACK
You will receive your device
partly closed. Gently remove
top and bottom covers.
Insert SIM card as shown
with PIN request disabled
or read our Wiki1how to
enter it later in Teltonika
Congurator2. Make sure
that Micro-SIM card cut-o
corner is pointing outward
from slot. SIM slot 1 is closer
to PCB, SIM slot 2 is the top
one.
1 wiki.teltonika-gps.com/view/
FMC13A_Security_info
2 wiki.teltonika-gps.com/view/
Teltonika_Congurator
Connect battery as shown to
device. Position the battery
in place where it does not
obstruct other components.
After conguration, see
“PC Connection (Windows)”,
attach device top and
bottom cover back and
press them twice to the
full closure. Make sure that
product casing is closed
correctly.
Quick Manual v1.5 // FMC13A 7
Telematics
PC CONNECTION (WINDOWS)
HOW TO INSTALL USB DRIVERS (WINDOWS)
1. Power-up FMC13A with DC voltage (10 – 30 V) power supply using supplied power cable. LED’s should start blinking, see “LED
indications”.
2. Connect device to computer using Micro-USB cable or Bluetooth connection:
• Using Micro-USB cable
• You will need to install USB drivers, see “How to install USB drivers (Windows)”
• Using Bluetooth
• FMC13A Bluetooth is enabled by default. Turn on Bluetooth on your PC, then select Add Bluetooth or other device >
Bluetooth. Choose your device named – “FMC13A_last_7_imei_digits”, without LE in the end. Enter default password 5555,
press Connect and then select Done.
3. You are now ready to use the device on your computer.
1. Please download COM port drivers from here.
2. Extract and run TeltonikaCOMDriver.exe.
3. Click Next in driver installation window.
4. In the following window click Install button.
5. Setup will continue installing the driver and eventually the conrmation window will appear. Click Finish to complete the
setup.
Quick Manual v1.5 // FMC13A 8
Telematics
At rst FMC13A device will have default factory settings set. These settings should be changed according to the users needs. Main
conguration can be performed via Teltonika Congurator1software. Get the latest Congurator version from here2. Congurator
operates on Microsoft Windows OS and uses prerequisite MS .NET Framework. Make sure you have the correct version installed.
1 wiki.teltonika-gps.com/view/Teltonika_Congurator
2 wiki.teltonika-gps.com/view/Teltonika_Congurator_versions
CONFIGURATION
MS .Net requirements
Operating system MS .NET Framework version Version Links
Windows Vista
Windows 7
Windows 8.1
Windows 10
MS .NET Framework 4.6.2 32 and 64 bit www.microsoft.com1
1 https://dotnet.microsoft.com/en-us/download/dotnet-framework/net462
Quick Manual v1.5 // FMC13A 9
Telematics
Downloaded Congurator will be in compressed archive.
Extract it and launch Congurator.exe. After launch software
language can be changed by clicking 🌐in the right bottom
corner.
Conguration process begins by pressing on connected device.
FMC13A
Various Status window1 tabs display information about GNSS2,
GSM3, I/O4, Maintenance5and etc. FMC13A has one user
editable prole, which can be loaded and saved to the device.
After any modication of conguration the changes need to
be saved to device using Save to device button. Main buttons
oer following functionality:
Load from device – loads conguration from device.
Save to device – saves conguration to device.
Load from le – loads conguration from le.
Save to le – saves conguration to le.
Update rmware – updates rmware on device.
Read records – reads records from the device.
Reboot device – restarts device.
Reset conguration – sets device conguration to
default.
Most important congurator section is GPRS – where all
your server and GPRS settings6 can be congured and Data
Acquisition7– where data acquiring parameters can be
congured. More details about FMC13A conguration using
Congurator can be found in our Wiki8.
After connection to Congurator Status window will be
displayed.
FMC13A
1 wiki.teltonika-gps.com/view/FMC13A_Status_info
2 wiki.teltonika-gps.com/view/FMC13A_Status_info#GNSS_Info
3wiki.teltonika-gps.com/view/FMC13A_Status_info#GSM_Info
4wiki.teltonika-gps.com/view/FMC13A_Status_info#I.2FO_Info
5wiki.teltonika-gps.com/view/FMC13A_Status_info#Maintenance
6 wiki.teltonika-gps.com/view/FMC13A_GPRS_settings
7 wiki.teltonika-gps.com/view/FMC13A_Data_acquisition_settings
8 wiki.teltonika-gps.com/view/FMC13A_Congurationn
Quick Manual v1.5 // FMC13A 10
Telematics
QUICK SMS CONFIGURATION
Default conguration has optimal parameters present to ensure best performance of track quality and data usage.
Quickly set up your device by sending this SMS command to it:
Note: Before SMS text, two space symbols should be inserted.
GPRS SETTINGS:
2001 – APN
2002 – APN username (if there are no APN username,
empty eld should be left)
2003 – APN password (if there are no APN password,
empty eld should be left)
SERVER SETTINGS:
2004 – Domain
2005 – Port
2006 – Data sending protocol (0 – TCP, 1 – UDP)
« setparam 2001:APN;2002:APN_username;2003:APN_password;2004:Domain;2005:Port;2006:0»
1 2 3 4 5 6
1
2
3
4
5
6
