Cisco 7861 MPP User Guide

Cisco 7861 MPP User Guide 1 23/06/20

Feature Overview

The Cisco 7861 Multiplatform Phone with 16 lines is the ideal handset for Small Businesses or

Administrative staff that manage high call volumes.

Your Phone

1. Incoming call or voicemail indicator

2. LCD display screen

3. Softkeys- Give you access to functions

that are displayed on the screen above

the button. Go to the More

softkey to view further available

functions

4. Line and feature buttons

5. Hold, Transfer and Conference

6. Speaker, Headset and Mute

7. Volume control

8. Voicemail, Settings and Directory

9. Navigation button

Line and Feature Buttons

Use line and feature buttons to view calls on a

line, or access features such as Speed Dial.

Buttons illuminate to indicate line status:

Green-steady: Available line

Red-flashing: Incoming call

Red-steady: Active call

Red-flashing: Held call

Red-flashing: BLF line-Alerting

Red-steady: BLF line-In use

Cisco 7861 MPP User Guide

Cisco 7861 MPP User Guide 2 23/06/20

Placing a Call

You can place a call in a number of ways:

1. Enter a number, then pick up the handset

2. Enter the number, then press the Call softkey

3. Using the hands-free speakerphone

-Enter a number using the keypad

-Press Speakerphone

4. Using the headset

-Enter a number using the keypad

-Press Headset

Answering Calls

You can answer a call either using the handset, headset, or speakerphone. To answer an incoming

call:

1. Lift the handset

-Press the Answer softkey. or

-Press the flashing Red line key

2. If you are using the Headset

-Ensure the Headset

button

is pressed

-Press the Answer softkey, or

3. Press the Speaker

button

Placing a Call on Hold

To place an active call on hold:

•Press the Hold button on the phone or the Hold softkey

To resume a held call:

•Press on the phone or press the Resume softkey.

Placing Multiple Calls

It is possible to make multiple calls however, only one active call can be in progress at any time,

other calls are placed on hold.

To make a new call during an active call:

1. Press the Hold softkey or Hold

button (to place the original call on hold

2. Press the New Call softkey

3. Dial the second number

Both calls will appear on the screen (Active Call ) (Held Call )

Cisco 7861 MPP User Guide

Cisco 7861 MPP User Guide 3 23/06/20

To swap between the two calls:

4. Use the Navigation button to highlight the Held call, then press the Resume softkey

To join both parties into a conference:

5. Use the Navigation button to highlight the Active call, then press Conf line softkey

Call Waiting

The Call Waiting feature enables the user to take two calls simultaneously

1. While on a call, when another call comes in press the Answer softkey (this places the

first call on hold)

To swap between the two calls:

2. Use the Navigation button to highlight the Held call, then press the Resume softkey

Muting a Call

While on a call you can place the call on Mute, this prevents the caller from hearing you, but you can

still hear the caller. To mute a call:

1. Press during an active call.

2. Press again to un-mute the call.

Adjusting the Ringer and Volume

1. Press -/+ to adjust the ring volume when the phone is idle or use to adjust

the volume of the other party while on an active call

Transferring Calls

There are two ways of transferring a call –Blind (direct transfer) and Consult (announced transfer).

Blind Transfer

1. During a call, press the BlindXfer softkey

2. Dial the other destination phone number

3. The call will transfer directly

Consult Transfer

1. During a call, press the Transfer button or the Transfer softkey

2. Enter the destination phone number

3. When the second party answers, announce the call then press the Transfer button

or Transfer softkey to complete the transfer

If the party refuses the call

4. Press the EndCall softkey then the Resume softkey to return to the original call

Cisco 7861 MPP User Guide

Cisco 7861 MPP User Guide 4 23/06/20

Call Pickup

If you are a member of a Call Pickup Group, you can answer a ringing phone of another colleague

within your Call Pick Up Group.

Redirect a call that is ringing on another phone within your Pick Up group:

1. Press the GrPickup soft key

Note: If more than one phone within the Pick Up group is ringing, you will pick up the phone that was

ringing first.

Chose which ringing phone within your Pick Up group that you want to redirect to your phone:

1. Press the Group Pick Up softkey

2. Enter the extension of the phone you want to redirect

3. Press the Call softkey

Note: Call Pick Up Groups will only be available if set up by your Group Administrator

Conference Calls

To create an ad hoc conference call with up to 8 parties (you and up to 7 other parties)

While on a call

1. Press the Conference button or Conf softkey

2. Dial the next participant

3. Press the Conference button again or the Conf softkey to connect all parties

Repeat the instructions above to add more parties to your conference call

Call Forward

Set Forwarding on your desk phone to redirect incoming calls to an alternative number or your

voicemail.

To enable Forwarding to an alternate number:

1. Press the Forward softkey

2. Enter the destination number

A forward icon and the destination number is displayed on your phone

To enable Forwarding to your voicemail:

3. Press the Forward softkey

4. Press the Voicemail button or dial *62

A forward icon and *62 is displayed on your phone

To disable Forwarding:

5. Press the Clr fwd softkey

Cisco 7861 MPP User Guide

Cisco 7861 MPP User Guide 5 23/06/20

DND (Do Not Disturb)

Use DND to silence your phone and ignore incoming call notifications. When turned on, incoming

calls will forward directly to your voicemail.

1. Press the DND softkey to activate

“Do not disturb” will be displayed on your phone screen when this feature is on

2. Press Clr DND softkey to turn the DND feature off

Redial

You can call back your most recently dialed numbers:

1. Press the Redial softkey

2. Use the Navigation button to scroll to the required number

3. Press Call softkey

Press the Option softkey to view further actions:

•Delete Entry

•Delete list

•Add Contact to directory

Call Return

To call back the last call activity form your phone:

1. Press Call rtn softkey

Recent Call List

Your phone maintains Call History of Placed calls, Received calls and Missed Calls. Your Recent list

holds up to the last 150 calls.

To view your recent calls list:

1. Press the Recents softkey

2. Press Settings > Recents

3. Use the Navigation button to scroll to the required number

4. Press Call softkey to call back

Press the Option softkey to view further actions:

•Delete Entry

•Delete list

•Add Contact to directory

Cisco 7861 MPP User Guide

Cisco 7861 MPP User Guide 6 23/06/20

Directories

To access your phone directories, press the Directory button

Enterprise Directory –Search for and call your colleagues from the directory

Personal Address Book –Add personal contacts to your Address book:

1. From Directory, go to Personal address book

2. Press the Add softkey

3. Enter the contact name and phone number/s

4. Press the Save softkey

Call from the Directory

1. Scroll to the required directory

2. Press Select softkey

3. Enter search criteria, then press Search softkey to find matches

4. Highlight the number to call

5. Press Call softkey

IM&P contacts–Instant Message and Presence directory is integrated with your Business Connect

soft phone Contact list.

Contacts that have been added to the contact list on your Business Connect soft phone App, will be

available to view in the IM&P directory on your Cisco 7861MPP phone.

The Business Connect Presence will also display on your phone

•✓indicates the contact is available

•Indicates the contact is on another call

•Indicates the contact is offline

1. Press the navigation button while highlighted on a contact to toggle

between their available calling numbers

2. Press Call to dial the contact

Speed Dials

From your handset you can manually set 8 speed dials.

To add a contact to a Speed dial

1. Press Settings button

2. Scroll to Speed Dials and press Select

3. Scroll to a vacant entry (2-8) and press Edit softkey

4. Enter the name and phone number

5. Press Save softkey

To call a speed dial contact:

1. From the dial pad, enter the contacts speed dial number (i.e. 2)

2. Press Call softkey

Cisco 7861 MPP User Guide

Cisco 7861 MPP User Guide 7 23/06/20

BLF (Busy Lamp Field)

BLF lines are assigned to the line buttons on the right side of your screen. They allow you to speed

dial or monitor the status of other users within your organisation. Ideal for Managers, Receptionists

or users who are monitoring other team members.

Directory Card

Remove the Directory card from your phone to manually write the

name of the BLF line contact in the corresponding field

Green light: Monitored line is available

Blinking Red light: The monitored line is ringing

Red light: The monitored line is busy

1. Press a BLF line to speed dial the contact

2. Press a flashing BLF line to pick up an incoming call to that line

3. When transferring a call to a BLF line –

a. While on an active call, press Transfer button or Transfer softkey

b. Press the BLF line button of the party you are transferring to

Park a call on to a BLF contact:

1. While on an active call, press the Park softkey

2. Press the BLF line where you want to park the call

3. Your screen will display *68 followed by the extension where the call is parked

(e.g.: *686543)

4. You will also hear the following greeting

“Your call has been parked, thank you”

To unpark the call:

1. Press the Unpark soft key, then press the BLF line where the call was parked

To unpark the call from another phone:

1. Dial *88 followed by the extension where the call was parked (e.g.: *886543)

If a Parked call is not retrieved by a pre-set time, it will recall back to your phone (default is 45

seconds)

Note: Park groups are set up by your Administrator

Cisco 7861 MPP User Guide

Cisco 7861 MPP User Guide 8 23/06/20

Voicemail

You can access your voice messages directly from your phone.

Note: Your administrator may have set your service up to access voice messages via email.

To Setup Voicemail:

2. Press on your phone

3. When prompted enter your 4digit Voicemail passcode

(This will be provided to you by your administrator).

For first time login

4. When prompted, change the passcode to a new passcode

5. Follow the prompts to record you name

6. You can then setup two greetings, your No Answer and/or Busy greeting. Follow the

prompts to setup greetings.

7. Press 1to access your mailbox.

8. Press 2to record Busy greeting

9. Press 3to record No Answer greeting

10. Press *to repeat menu options

To listen to Voicemails:

1. When the phone screen displays you have a new voicemail and the handset LED

flashes red, press the Message

button to access voicemail

2. Enter your Voicemail passcode

3. Press 1to access your Voicemail box

4. Press 1to listen to your messages

5. Press #to save the message; 2to pause/resume the message; 7to Delete the

message.

To access your Voicemail Remotely

1. Dial your phone number, when you hear your mailbox greeting being played, press *

2. Enter your 4digit Voicemail password.

3. Press 1to access your Voicemail box.

4. Press 1to listen to your messages.

Tabla de contenidos

Otros manuales de Teléfono de Telstra

Telstra

Telstra Slimline 25 Manual de usuario

Telstra

Telstra VVX 1500 Manual de usuario

Telstra

Telstra Easy Control TEC-D Instrucciones de montaje

Telstra

Telstra T1000C SMS Manual de usuario

Telstra

Telstra Priority Assist Phone Manual de usuario

Telstra

Telstra 8950 Manual de usuario

Telstra

Telstra T800 Manual de usuario

Telstra

Telstra T1000S Manual de usuario

Telstra

Telstra VVX410 Manual de usuario

Telstra

Telstra SP817BB Manual de usuario

Telstra

Telstra TSH-D Instrucciones de montaje

Telstra

Telstra S60 Manual de usuario

Telstra

Telstra T1000S Manual de usuario

Telstra

Telstra VVX300 Manual de usuario

Telstra

Telstra T310 Manual de usuario

Telstra

Telstra Touchfone 400 Manual de usuario

Telstra

Telstra 13450 Manual de usuario

Telstra

Telstra VVX500 Hoja de especificaciones

Telstra

Telstra T1000S Manual de usuario

Telstra

Telstra T1000S Manual de usuario

Telstra

Telstra customnet Manual de usuario

Telstra

Telstra T1000S Manual de usuario

Telstra

Telstra T1000C SMS Manual de usuario

Telstra

Telstra A248 Manual de usuario

Manuales populares de Teléfono de otras marcas

GE 2-9480 Manual de usuario

Geemarc

Geemarc PHOTOPHONE 155 Manual de usuario

D-Link

D-Link DWR-720/PW Manual de usuario

Interquartz

Interquartz Gemini IQ333 Manual de usuario

SSS Siedle

SSS Siedle HT 840-0 Manual de usuario

Motorola

Motorola TITANIUM Manual de usuario

Panasonic

Panasonic ICX Manual de usuario

LG H870DS Manual de usuario

Samsung

Samsung GT-I9500 Manual de usuario

AT&T

AT&T Trimline 205 Manual de usuario

Selta

Selta zenyth 600 Manual de usuario

Doro

Doro AFTI 20 Manual de usuario

UNIQCELL

UNIQCELL A1 Manual de usuario

Panasonic

Panasonic KX Series Manual de usuario

Jabra

Jabra SP5050 - Bluetooth hands-free Speakerphone Manual de usuario

BT Decor 425 Manual de usuario

NEC

NEC SV8500 Manual de usuario

Teledex

Teledex PEARL Manual de usuario
