6
CONFIGURING THE DEVICE:
Configuring notifications and remote monitoring:
The contact details of CMS (Central monitoring station) servers can be added in
the Reporting channels menu. Beyond entering the name at will, you must set
the receiver’s IP address/domain and port number, the communication protocol
you want to use, and the supervision message settings.
The device can also send notification via SMS or voice call. E-mail and Push
notification options are also available in the PRO model. The phone numbers
and e-mail addresses can also be added in the Reporting channels menu.
You can change the default priority of reporting to your CMS receivers in the
Notification templates menu. For advanced reporting options (e.g. to report a
specific event with a different priority or to a different receiver) you can create
a new notification template by clicking on the Add new button. Then you
must select the servers you want to use and set their priority, and then select the
given template in the settings of the event you want to use it for.
Configuring IP cameras:
The Adapter2 PRO can manage access to up to four IP cameras with ONVIF
protocol. They can be added in the IP cameras menu, by entering the URLs of
the cameras. You can enter either stream or snapshot URLs, and the mobile
application will display the camera images accordingly.
For extracting the URL from your IP camera, we suggest using our IP camera
detector software designed for this purpose. You can download the software
from our website under the Software tab on the Adapter2 PRO product page.
Configuring events:
The events of Adapter2 can be classified into three groups that need to be
configured separately.
Inputs and Input events:
The type and sensitivity of the inputs can be set in the Inputs menu. A state
change on a contact input can generate an event, upon which the Adapter2 can
perform different actions. To use this option, you must add the input event you
want to use in the Input events menu by clicking on the Add new button.
Configuring an input event after adding it:
•Enter the Name and select the Type of the event.
•Select the Input.
•Enter the Event code, Partition and Zone.
•Select the Notification template.
