TELEWAVE 44D Manual de usuario

44D User Manual

3 Jul 2018

44D Digital/Analog Broadband RF

Wattmeter - User Manual

3 Jul 2018

Firmware Version TiE.01.00

Telewave, Inc.

660 Giguere Court

San Jose, CA 95133

www.telewave.com

Phone 408-929-4400

Toll Free 800-331-3396

[email protected]

[email protected]om

44D User Manual

3 Jul 2018

Table of Contents

COPYRIGHT/DISCLAIMER/WARRANTY...........................................................................................................4

PRECAUTIONS AND SAFETY INSTRUCTIONS.................................................................................................5

NOTES REGARDING LITHIUM BATTERIES...................................................................................................................5

QUICK START GUIDE .............................................................................................................................................6

OPERATION...............................................................................................................................................................7

CHARGING POWER SUPPLY &INTERNATIONAL POWER ADAPTERS...........................................................................7

CHARGING THE BATTERY..........................................................................................................................................7

POWER CONTROL ......................................................................................................................................................8

SLEEP MODE .............................................................................................................................................................8

MENU TREE...............................................................................................................................................................9

HOME SCREEN AND FIELDS DESCRIPTION ...............................................................................................................9

MAIN MENU.............................................................................................................................................................9

Modulation (no Menu) .......................................................................................................................................10

Frequency Range Menu .....................................................................................................................................10

Settings Menu.....................................................................................................................................................10

Info & Help Menu ..............................................................................................................................................10

SPECIFICATIONS...................................................................................................................................................11

FREQUENCY RANGE ................................................................................................................................................11

POWER RANGE (CONSTANT ENV)MODULATION.....................................................................................................11

POWER RANGE (NON-CONSTANT ENV)MODULATION............................................................................................11

RF AND MEASUREMENT..........................................................................................................................................11

USB CONNECTOR,BATTERY AND CHARGING.........................................................................................................12

MECHANICAL ..........................................................................................................................................................12

ENVIRONMENTAL ....................................................................................................................................................12

Operating ...........................................................................................................................................................12

Storage...............................................................................................................................................................12

WIRELESS CONNECTIVITY (FUTURE).......................................................................................................................13

MISCELLANEOUS: ACCESSORIES, OPTIONS, MAINTENANCE................................................................14

INCLUDED ACCESSORIES.........................................................................................................................................14

OPTIONAL LEATHER CASE ......................................................................................................................................14

OPTIONAL CONNECTOR ADAPTER KIT ....................................................................................................................14

OPTIONAL “QC –QUICK CONNECT”THRU-LINE CONNECTORS..............................................................................14

OPTIONAL THRU LINE ADAPTERS ...........................................................................................................................14

MAINTENANCE ........................................................................................................................................................15

STORAGE.................................................................................................................................................................15

CLEANING ...............................................................................................................................................................15

CALIBRATION..........................................................................................................................................................16

APPENDIX: CONNECTING THE METER TO THE CIRCUIT........................................................................17

CONCEPTS ...............................................................................................................................................................17

METER CONNECTION DIAGRAM ..............................................................................................................................17

CALCULATING THE PRIMARY &SECONDARY CABLE CUT LENGTH ........................................................................18

SAMPLE PRIMARY AND SECONDARY CABLE LENGTHS............................................................................................18

Velocity Factor 66% ..........................................................................................................................................18

Velocity Factor 85% ..........................................................................................................................................20

APPENDIX: RF SAMPLE PORT ISOLATION....................................................................................................22

APPENDIX: SUPPORTED MODULATION TYPES...........................................................................................23

APPENDIX: SPECIAL TEST CASES....................................................................................................................26

POSITIVE TRAIN CONTROL (PTC) RADIOS ..............................................................................................................26

44D User Manual

3 Jul 2018

TETRA SUBSCRIBER RADIOS..................................................................................................................................26

MONITORING AN ANTENNA THAT FOLLOWS A TX COMBINER.................................................................................26

APPENDIX: SPECIFICATION VALIDATION....................................................................................................27

MEASURING INSTRUMENTS AND ANCILLARY EQUIPMENT ......................................................................................27

BASELINE TEST SETUP ............................................................................................................................................27

THRU LINE POWER MEASUREMENT VERIFICATION.................................................................................................28

THRU LINE DIRECTIVITY VERIFICATION .................................................................................................................28

THRU LINE MATCH VERIFICATION..........................................................................................................................28

RF SAMPLE PORT MATCH VERIFICATION................................................................................................................28

THRU LINE TO RF SAMPLE PORT ISOLATION VERIFICATION ...................................................................................29

RF SAMPLE PORT TO THRU LINE ISOLATION VERIFICATION ...................................................................................29

44D User Manual

3 Jul 2018

Printed in the United States of America.

Disclaimer of Liability:

This manual contains Telewave, Inc. proprietary information, which is exempt from disclosure

under the Freedom of Information Act (5 USC 552). No part of this manual may be reproduced

or transmitted in any form or by any means, electronic or mechanical, including photocopying,

recording, or information recording and retrieval systems, for any purpose, without the written

consent of Telewave, Inc.

Warranty:

Products sold by Telewave, Inc. and covered by this Warranty are warranted to be free from defects

in material and workmanship at the time of and for a specified period after delivery to the Buyer.

Seller's entire warranty obligation is limited to making adjustments by repair, replacement, or

refunding the purchase price of any product which is returned to the Seller as provided below within

the specified period from the date of shipment by the Seller. In no event shall Seller be liable for

direct, special, or consequential damages for breach of warranty.

Adjustment will not be allowed for products which have been damaged by lightning, subjected to

abuse, improper application or installation, alteration or accident, or negligence in use, storage,

transportation or handling. Alteration or removal of the serial number or identification markings

voids the Warranty. Seller shall have the right of final determination as to the existence and cause of

a defect, whether adjustment will be allowed, and if allowed, whether adjustment will be by repair,

replacement, or refund. Where adjustment is not allowed, a charge of 5% of the original purchase

price will be made to the Buyer to cover the Seller's cost of inspection and handling.

Shipping and packaging instructions must be obtained from the Seller before products are returned

for adjustment. The Buyer will pay for packing, transportation, and transit insurance costs for

returned products. The Seller reserves the right to discontinue models at any time or change

specifications, design, or price without notice and without incurring any obligation. Products will be

returned to the Buyer with transportation cost collect.

Subject to the provisions of its "Patent Indemnity" clause, the Seller also warrants that it has the right

to sell its products, that the Buyer shall have and enjoy quite possession thereof as against any lawful

claims existing at the time of the sale by the Seller, and that said products are free from any charge of

encumbrance in favor of third persons existing at the time of sale by the Seller.

The foregoing constitutes the Seller's entire warranty, express, implied or statutory with respect to its

products and states the full extent of its liability for breach of Warranty and for damages, whether

direct, special or consequential resulting from any such breach. No change whatsoever thereto shall

be binding upon the seller unless made in writing and signed by a duly authorized representative of

the Seller.

Warranty Periods:

Antennas and antenna mounting hardware - 5 years

All other products - 1 year

44D User Manual

3 Jul 2018

Precautions and Safety Instructions

1. Read the user manual carefully. All Warnings and Cautions should be noted.

Contact Telewave Support with any questions.

Keep the user manual(s) for future reference.

2. Keep the meter away from sources of moisture or excessive humidity.

Never pour any liquid into the openings or connectors.

Do not immerse into any liquid. The meter is water resistant, not water proof

3. Do not store this meter in an unconditioned environment for an extended time. Prolonged

exposure to extreme heat, cold or moisture may cause damage.

4. Check the current capacity of the USB charger/power supply before connecting to the meter.

5. Do not attempt to disassemble the meter, there are no user serviceable parts inside.

6. Inspect the meter if it has been dropped or exposed to excessive vibration.

7. Contact Telewave Support if any of the following conditions arise:

There are any obvious signs of damage –case, display, connectors, switches, or etc.

Any liquid appears to have penetrated into the case.

The meter appears to malfunction or is giving obviously incorrect readings.

The meter has been tampered with, or opened by anyone other than Telewave.

8. Follow all normal Radio Frequency safety rules and High Voltage safety rules.

Double check all connections and configurations before applying power to transmitters

Double check all connections and configurations before keying any transmitters

Be mindful of short and long-term exposure risks to Radio Frequency Radiation

WARNING: This symbol alerts you to the risk of personal injury, hardware damage or

irrevocable loss of data.

CAUTION: This symbol denotes situations where instructions must be followed carefully

to avoid personal discomfort or to obtain expected results.

Notes regarding Lithium Batteries

WARNING: The batteries in this meter must be discharged to 1/3 or less capacity before

the unit can be transported by Air. This is a legal and safety requirement for all lithium batteries.

WARNING: The internal batteries are not user serviceable. The meter must be returned

to Telewave for service if the batteries no longer accept or retain a sufficient charge.

Telewave recommends returning the wattmeter to the factory every two years for inspection &

calibration. Calibration must be done at Telewave, contact Telewave sales for a quote.

The inspection includes checking the health of the batteries and creating a battery health report.

To return a meter to Telewave; complete the RMA request form located on our web site

www.telewave.com, or call 408-929-4400 Option 1 if assistance is needed to compete the RMA.

44D User Manual

3 Jul 2018

Quick Start Guide

The complete 44D User Manual is available for download at www.telewave.com.

1. Unpack and inspect the 44D and accessories (USB cable, AC power supply, & AC adapter kit)

a. Check the box and contents for any damage immediately after it arrives

b. In case of any damage or missing item, contact Telewave immediately, 408-929-4400 Opt 1.

2. Charge the Batteries

a. Plug the B side of the USB cable into the meter (the connector is located on the back)

b. Plug the A side of the USB cable into the supplied AC power supply or any other USB power

source capable of supplying at least 2.4 amps of charging current

c. Depleted batteries will require about 8 hours of charging time to reach a full charge.

CAUTION: Fully charge the batteries after long term storage.

3. Build or procure “Primary Cables”(see “Appendix - Connecting the Meter to the Circuit”)

4. Press and hold the power button until the blue power indication in the switch illuminates

5. The meter will be functional in three to five seconds as indicated by:

a. Backlight will be illuminated

b. Frequency, temperature & battery indicators are displayed

6. The menu tree is as follows:

HOME

Soft Key MENU ^MEAS ^CALC

V Measurements Calculations

Freq Range > Set low, medium or high frequency range

Settings > Modify some look & feel parameters

Info & Help > Show Version, Telewave contact

Exit > Return to the HOME screen

7. When in any MENU screen other than the HOME Screen, the

function buttons will be UP, SELECT/EXIT, and DOWN.

a. Press SELECT implements the selection & returns HOME

b. Press EXIT aborts the selection and returns HOME

c. On read only screens EXIT returns HOME

8. Set the Frequency Range before use,all other settings are optional

9. Once the meter has been configured, the cables can be connected

a. Connect the primary cable to the port labeled TX on the left side of the meter (RF input)

b. Connect the cable leading to the antenna to the port on the right side of the meter (RF output)

10. The RF Sample port can be connected to any monitor or source test equipment. The sample

port is bi-directional, with connectivity to both the Thru Line TX and Thru Line ANT port.

Wiring Diagram

Original Circuit ½ WL Increment

Insert test cables 44D

& 44D at the TX ANT

Component output

Primary Cable (1/2 WL increment minus 5”) Secondary Cable (Optional = ½ WL increment)

44D User Manual

3 Jul 2018

Operation

Charging Power Supply & International Power Adapters

The included power supply for charging the batteries supports 90 to 250 volts at 50 or 60 hertz.

The power plug on the power supply is an IEC international “Plug Type A”.

Type A to Type C, G, and I adapters are included with the wattmeter. This AC adapter kit will

allow the power supply to be safely connected to the power sockets in most countries.

Visit the International Electro technical Commission (IEC) website for a complete list of socket

types, and power voltage/frequencies used in various countries: http://www.iec.ch/worldplugs/.

Description


Short list of Areas/Countries where the “Type” is used

Type A

Plug on the

power supply

North and Central America, Japan

Directly compatible with Type B sockets

Type C

Universal to

Euro 2P AC

Power Plug

Europe (except UK), Ireland, Cyprus, Malta

Directly compatable with Type E, F, J, K, & N sockets

Type G

Universal to

UK 3P AC

Power Plug

UK, Ireland, Cyprus, Malta, Malaysia, Singapore,

Hong Kong

Type I

Universal to

AUS 3P AC

Power Plug

Australia, New Zealand, Papua New Guinea, Argentina,

China

Charging the Battery

The battery can be charged when the meter is on or off, and can be charged from any USB

source that supports a 2.4 amp load (laptop USB port, vehicle charging adapter, etc.) Connect

the supplied USB cable between the power source and the meter, charging will begin as soon as

the meter detects voltage on the USB connector.

CAUTION: When the meter off the display is blank. There is no indication that the meter

is charging, fully charged, or that the USB cable is disconnected or not suppling charge current.

Battery charge indication:

Bars 3 equals >3/4, 6-8 hours awake time remain

Bars 2 equals >1/2, 4-6 hours awake time remain

Bars 1 equals >1/4, 2-4 hours awake time remain

Flashing equals <1/4, 0-2 hours awake time remain

44D User Manual

3 Jul 2018

Though not recommended, the wattmeter can be left connected to the USB power source for an

extended period of time. The internal charging controller can detect when the batteries are fully

charged, and stop charging the batteries until they have been partially discharged.

WARNING: Charge the batteries at least once every six months to prevent battery damage

CAUTION: Fully charge the batteries after removing the meter from long term storage.

Power Control

The meter has a latching push power button in the lower left corner of the front panel.

To turn the meter ON, push the power button until you hear a clicking sound and/or you see that

the power switch rim is illuminated with a blue glow. After a few seconds the display backlight

will illuminate, and the power up sequence will be shown in the display.

The power up sequence, as is seen in the display is:

The screen backlight will illuminate after about two seconds

Then the HOME screen will display

After that the frequency, temperature and battery status indications will be displayed

Once the power up sequence is complete the HOME screen will indicate the settings that were

selected when the meter was previously turned off (units of measurement, backlight level, etc.)

The power switch will remain partially depressed while the meter is turned on.

To turn the meter OFF, push the power button in slightly further, and release. The switch will

return to the flush position, the blue rim light will extinguish, the display backlight will turn off

and the display will become blank. There are no lights or display activity when the unit is off.

Sleep Mode

The meter can be configured to go to “sleep” after few of minutes of inactivity. Inactivity is

defined as no function select buttons have been pushed. If the meter is connected to a transmitter

and is reading power, it will still go to sleep if the sleep timer expires (no buttons were pushed.)

Sleep mode is indicated by the following:

The display backlight will extinguish and the display will be blank/dark

The meter will emit a beep sound as it is going to sleep

The blue ring around power button will remain lit

To wake the meter, turn off the power button and then turn it back on.

The meter will boot back to the previous configuration in a few seconds.

CAUTION: The meter will only go into sleep mode when the HOME screen is displayed.

When any screen other than HOME is displayed and the sleep timer expires, the meter will wait

for the user to complete the pending action; and then go to sleep.

NOTE: RF signals will flow though the through line sensor un-impeded with the wattmeter

power turned on or off. Any live circuits that are monitored with the wattmeter will not be

affected if the wattmeter goes to sleep or is turned off while connected to the circuit.

44D User Manual

3 Jul 2018

Menu Tree

HOME Screen and Fields Description

HOME Screen Description

Battery Status

FWD (measured forward power)

Measured Value

Avg (W/dBm) or Peak (W/dBm)

REFL (measured reflected pwr)

Measured Value

Avg (W/dBm)

Calculated Info

Calculated Value

VSWR / Return Loss / Crest

Measured Frequency MHz

Measured Temperature C or F

^MEAS

^CALC

After the system has completed the power up sequence the default screen configuration is shown.

Top Row indicates the Battery Life

The second and third rows indicate results measured from the main thru line connectors.

These measurements are the primary function of the meter.

The forth row indicates calculated results based on the measurements from rows two and three.

The fifth row indicates the measured frequency of the RF signal, and the ambient temperature of

the critical RF detector circuits. The meter compensates for temperature changes, allowing high

accuracy at any ambient temperature within the specification range.

NOTE: All measured and calculated indications will be zero “0” or dash “---“ until the

average power level detected on the forward through line connector exceeds 1 watt (minimum.)

The bottom row indicates the current function of the three buttons located just below the screen.

The purpose of each of these buttons change as the needed for easy configuration of the meter.

The HOME screen function buttons are:

MENU Open the MAIN menu

^MEAS Rotate the Measured results display between Average or Peak Power

in Watts or dBm.

^CALC Rotate the Calculated results display between VSWR / Return Loss,

and Crest Factor (indicated in dB in place of PAPR, no linear indication)

The meter is auto ranging for any power or frequency within the ranges indicated in the specs.

MAIN Menu

The main MENU allows access to these categories:

FREQ RANGE Configure the meter to High freq (>100 MHz) or Low freq range

SETTINGS Adjust meter display parameters

INFO & HELP Read only meter attributes and Telewave contact information

EXIT Return to the HOME screen

For the main MENU and all Sub-Menus

Scroll up and down in the options by pressing the UP and DOWN buttons.

Pressing the SELECT key will select the currently highlighted item.

Selecting EXIT will return to the HOME screen without making any changes.

44D User Manual

3 Jul 2018

Modulation (no Menu)

There is no menu for selecting the modulation to be measured. The currently supported

modulation types are all accurately measured without any special meter configuration.

A complete listing of the modulation types supported as of the publication of this version of the

User Manual is listed in “Appendix –Supported Modulation Types”.

Frequency Range Menu

The menu will list all modulation types supported by the current hardware & firmware version

88-100 MHz Select for measuring frequencies between 88 and 101 MHz

101-700 Mz Select for measuring frequencies between 101 and 701 MHz

701-1000 M Select for measuring frequencies between 701 and 1000 MHz (1 GHz)

EXIT Return to the HOME screen

CAUTION: The Frequency Range is the only mandatory setting. The meter will not be

able to accurately measure the absolute power of the signal if the range is not set correctly.

Settings Menu

This menu is for setting the units of measurements and other behavioral parameters of the meter:

Power Units Select forward and reverse power display in Watts or dBm

Temperature Select temperature display in Fahrenheit or Celsius

Backlight Select the backlight intensity: Low, Medium, High

Power Saving Select duration of sleep initiation timer

WLAN Select the WLAN radio on or off (future use –leave off)

EXIT Return to the HOME screen

Power saving selections:

OFF Select never sleep

30 Minutes Select sleep after 30 minutes of inactivity

15 Minutes Select sleep after 15 minutes of inactivity

5 Minutes Select sleep after 5 minutes of inactivity

EXIT Return to the HOME screen

Info & Help Menu

This menu is for query of the attributes of the meter:

About Display the hardware and firmware version of the meter

Help Display the phone number and email address of Telewave support

LAN IP Display the IPv4 Address of the internal WLAN Radio (future use)

MAC Add Display the MAC Address of the internal WLAN Radio (future use)

EXIT Return to the HOME screen

Otros manuales para 44D

Tabla de contenidos

Otros manuales de Instrumento de medición de TELEWAVE

TELEWAVE

TELEWAVE io 44DL Manual de usuario

TELEWAVE

TELEWAVE 44D Manual de usuario

TELEWAVE

TELEWAVE 44A Manual de usuario

TELEWAVE

TELEWAVE 44 Manual de usuario

TELEWAVE

TELEWAVE 44L1 Manual de usuario

TELEWAVE

TELEWAVE 44DL Manual de usuario

Manuales populares de Instrumento de medición de otras marcas

Suaoki

Suaoki D40 Manual de usuario

Elster

Elster BK-G1.6 Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manual

Duratool

Duratool D03128 Manual de usuario

Vega

Vega VEGAPULS 65 Manual de usuario

Tonghui

Tonghui TH2618B Manual de usuario

Tenmars

Tenmars TM-801 Manual de usuario

MSR

MSR 145 Manual de usuario

TPS

TPS WP-82 Manual de usuario

ELMETRON

ELMETRON CP-511 Manual de usuario

PCB Piezotronics

PCB Piezotronics 003C30 Manual de usuario

Tenma

Tenma 72-10465 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag 50 Especificaciones técnicas

Siemens

Siemens SITRANS F Coriolis FCT030 Manual de lista de piezas

KLINGER

KLINGER CMF V Series Manual de usuario

EXFO

EXFO FTB-2 Manual de operación y mantenimiento

Keysight

Keysight M8290A Manual de usuario

ADTEK

ADTEK MW-5 Manual de usuario
