Telegesis

TG-PM-510 ZigBee Communications

Gateway

ZigBee Communications

Gateway

Product Manual 0510

Telegesis ZigBee Communications Gateway

Product Manual

Rev: 1

Date: Aug 2013

ZigBee Communications Gateway

Table of Contents

Abbreviations....................................................................................................................................4

Package Contents.............................................................................................................................5

Specifications....................................................................................................................................6

Order Codes..................................................................................................................................6

Examples ......................................................................................................................................6

Layout...............................................................................................................................................7

Power............................................................................................................................................9

LED Indicators.............................................................................................................................10

Buttons Actions ...........................................................................................................................11

Restore factory defaults...........................................................................................................11

Gateway reboot........................................................................................................................11

Gateway recovery mode..........................................................................................................11

Issue ZigBee command ...........................................................................................................11

Functionality....................................................................................................................................12

Start-up .......................................................................................................................................12

Gateway Discovery......................................................................................................................12

Discovery on a windows-7 PC..................................................................................................12

Discovery on other platforms:...................................................................................................13

Gateway Webserver....................................................................................................................14

Authentication..........................................................................................................................14

Web Pages..............................................................................................................................15

Appendix A .....................................................................................................................................28

Bootloading ETRX3 ZigBee module............................................................................................28

Warranty.........................................................................................................................................31

Caution........................................................................................................................................32

Cleaning......................................................................................................................................32

Compliance with Laws and Regulations..........................................................................................33

Disclaimer.......................................................................................................................................33

Contact Information.........................................................................................................................33

ZigBee Communications Gateway

Table of Figures

Figure 1: Package contents...............................................................................................................5

Figure 2: Gateway front view.............................................................................................................7

Figure 3: Gateway back view............................................................................................................7

Figure 4: Gateway bottom view.........................................................................................................8

Figure 5: Top label............................................................................................................................8

Figure 6: Bottom label.......................................................................................................................9

Figure 7: Device Discovery .............................................................................................................12

Figure 8: Discovery Python Script...................................................................................................13

Figure 9: Discovery Output..............................................................................................................13

Figure 10: HTTP server authentication............................................................................................14

Figure 11: Configurations Page.......................................................................................................15

Figure 12: ZigBee Interface Configurations page............................................................................22

Figure 13: Web Terminal page........................................................................................................23

Figure 14: Firmware Upgrade page.................................................................................................24

Figure 15: Logout page...................................................................................................................27

Figure 16: Dialin socket connection.................................................................................................28

Figure 17: ETRX3 Bootload prompt ................................................................................................29

Figure 18: Ready to receive upgrade image file via XMODEM........................................................30

ZigBee Communications Gateway

Abbreviations

PoE Power over Ethernet

LED Light Emitting Diode

HTTP Hyper Text Transfer Protocol

UPnP Universal Plug and Play

UDP User Datagram Protocol

TCP Transmission Control Protocol

SSL Secure Socket Layer

DNS Domain Name System

SNTP Simple Network Time Protocol

DHCP Dynamic Host Control Protocol

IP Internet Protocol

MAC Media Access Control

ZigBee Communications Gateway

Package Contents

The package contains the following items,

Figure 1: Package contents

a. ZigBee Communications Gateway

b. Micro USB power cable

c. Mounting screws

(a)

(b)

(c)

ZigBee Communications Gateway

Specifications

Model Number

GW357

RF Interface

ZigBee Pro

RF Output Power

+8dBm

Antenna

Half-wave Dipole Antenna 2dBi Gain or Integrated Antenna

Battery

1x 3V 220mAh Sony CR2032 Battery

Power Source

5Volts @ 500mA via USB Micro Connector

Charging source should be current limited

Ethernet

RJ45 10/100Mbps

Power Over Ethernet

(optional)

802.3af Compliant Class 1 Device

Operating Temperature

-20 to 70C

Humidity

95% TH Non-condensing

IP Rating

IP20 (subject to testing)

Net Weight

110g

Order Codes

Examples

GW-357-11-P-W-1-8 Gateway with 2xETRX357 module, Power-over-Ethernet, WiFi,

RS232/RS485 and an 8MB SD Memory Card

GW-357-1 Basic Gateway with 1xETRX357 module

GW-357-30-0-0-1 Gateway with 1xETRX357-LRS and RS232/RS485

GW-

Gateway

GW-357

Core Silabs IC

GW-357-X

1st module

1 = ETRX357

2 = ETRX357HR

3 = ETRX357-LRS

4 = ETRX357-HR-LRS

GW-357-0X

2nd module

GW-357-00-X

Power of Ethernet (P)

GW-357-00-0-X

WiFi or GSM (W or G)

GW-357-00-0-0-X

RS232/RS485 (1=yes 0=No)

GW-357-00-0-0-0-X

SD Memory Card size i.e. 4, 8 etc.

(a)

(b)

ZigBee Communications Gateway

Layout

Figure 2: Gateway front view

Figure 3: Gateway back view

2nd ETRX3 Status LED

Interface Active LED

Gateway Activity LED

Link Status LED

LED1st ETRX3 Status

LED

Ethernet connector RJ45

Micro USB power socket

Button-2 (B2)

ZigBee Communications Gateway

Figure 4: Gateway bottom view

Figure 5: Top label

Mounting holes

Opening for

battery and SD

card holder

Button-1 (B1)

Button-3 (B3)

Anti-slip pads

Power supply

ratings

Gateway MAC

address

ZigBee Communications Gateway

Figure 6: Bottom label

Power

The Gateway can be powered ON by plugging in the micro USB cable in the socket provided as

shown in figure-3 with power source as specified in the Specifications. Selected models of gateway

incorporating Power over Ethernet (PoE) can be powered on using the PoE injector through RJ45

cable.

Manufacture date

Gateway serial number

Gateway model number

ZigBee Communications Gateway

LED Indicators

Sequence

Number

Gateway State

1st

ETRX3

Status

LED

Link

Status

LED

Gateway

Activity LED

Interface

Active

LED

2nd

ETRX3

Status

LED

Power UP Sequence

Red +

Green

Blinking

Amber for

5 sec

OFF

All LEDs will turn ON and then following blink one after

the other twice except for the ETRX3 Status LEDs

which are controlled by ETRX3 ZigBee modules

Ethernet link inactive

Red

Blinking

Amber

Ethernet link active

Green

OFF

Any socket connected to

either ZigBee module

Web Terminal connected

Green

Any communication with

ZigBee modules

Any communications on

Ethernet lines

Blinking

Amber

Table 2: LED Sequence table

1st ETRX3 Status LED

Interface Active LED

Gateway Activity LED

Link Status LED

2nd ETRX3 Status
