TeleEye III+ Manual de usuario
Video Recording Transmitter
Installation Guide
Notice:
reserves the right to make improvements to the
product described in this manual at any time and without notice.
This manual is copyrighted. All rights are reserved. This manual may not be copied,
reproduced or translated in whole or part without prior consent from
.
Eye is a trademark of Signal Communications Limited and is registered in China, Hong
Kong, US and other countries.
All other trademarks are the property of their respective owners.
Copyright (c) 2005 !"
Eye
# ! $ %. All rights reserved.
Version 1.01
Limits of Liability and Disclaimer of Warranty
have taken care in preparation of this manual, but
makes no expressed or implied warranty of any kind and assume no responsibility for errors
or omissions. No liability is assumed for incidental or consequential damages in connection
with or arising out of the use of the information or accessories contained herein.
Features and specifications are subject to change without prior notice.
Table of Contents
SECTION 1
INTRODUCTION 1
•Features 2
SECTION 2
INTERFACE DESCRIPTION
•Model: VRB-4041 3
•Model: VRB-8082 3
•Model: VRB-16164 4
•Functional Description 4
Alarm Port Definition
• Model: VRB-4041 6
•Model: VRB-8082 6
•Model: VRB-16164 7
Support BS8418
• Model: VRB-4041 8
•Model: VRB-8082 8
•Model: VRB-16164 9
•Install
Eye
III+
VRB with Tamper Circuit and External Resistors 10
SECTION 3
GENERAL TERMS DISCUSSION
• Registration Checking 13
• Video Mode 13
• Built-in Web Server 13
• Site Monitoring Method 14
SECTION 4
sureLINK TECHNOLOGY
• sureLINK Address 15
• How to apply 16
• Transmitter Modification 17
SECTION 5
SYSTEM CONFIGURATION AND INSTALLATION
A. For Dial-up and Leased Line Connection
• What you need 19
• Transmitter Configuration 21
• Transmitter Installation 24
B1. For Internal LAN Access
• What you need 26
• Transmitter Configuration 27
• Transmitter Installation 31
B2. For Broadband Internet Connection with Static IP 32
C1. For Broadband Internet Connection with Dynamic IP using Router
• What you need 33
• Transmitter Configuration 35
• Router Configuration 39
• Transmitter Installation 40
C2. For Broadband Internet Connection with Dynamic IP using Broadband
Dialer
• What you need 41
• Transmitter Configuration 43
•
Eye Proxy Server Configuration 48
• Transmitter Installation 49
SECTION 6
USING BUILT-IN WEB SERVER 51
SECTION 7
SCAN AND FORMAT THE HARD DRIVE
• Scan 53
• Complete Scan 55
• Format 56
• Complete Format 57
APPENDIX A
IP SETUP
• IP Address Setup for Window 98/ME 58
• IP Address Setup for Window NT/2000 61
• Router Configuration 62
APPENDIX B
ADVANCED CONFIGURATION - MODIFYING SETTINGS
• Through Serial Port 64
• Through Internet/Intranet 65
• Through Modem 66
APPENDIX C
GLOSSARY 67
APPENDIX D
SPECIFICATIONS 69
Support BS8418
SPECIFICATIONS 70
Eye
III+
Video Recording Transmitter I
nstallation Guide Page 1
Introduction
1
INTRODUCTION
The revolutionary
Eye
III+
Video Recording Transmitter (VRB)
is a one-plug
module on LAN and the Internet for remote video monitoring and recording.
The powerful
VRB
works on broadband Internet economically and gives you
exceptionally well real time video transmission at speed up to 25/30 fps. Its
“sureLINK” technology allows low cost dynamic IP broadband Internet connection.
Say goodbye to expensive static IP requirement!
Powered by its proprietary video compression technology and remote accessibility,
VRB
provides simultaneous remote monitoring, recording and playback. Users can keep track
of live video and play back recorded video from any remote locations.
The
Eye
III+
VRB
is designed to comply with the recognized British Code of
Practice BS 8418:2003 for Detector Activated CCTV Systems. When partnered with
Eye CMS01 software, the system becomes a professional video alarm verification
solution with comprehensive visual management and reporting capabilities required for
the highest level of police response.
VRB
is not only designed for connectivity but a total solution for video monitoring and
recording!
SECTION
Eye
III+
Video Recording Transmitter I
nstallation Guide Page 2
Introduction
Features
Flexible connections – Internet, LAN, PSTN, ISDN, ADSL cable modem, mobile
network…
Built-in web server
Support static and dynamic IP
Real time video transmission
Up to 30fps over LAN for NTSC
Up to 25fps over LAN for PAL
Up to 20fps on PSTN
Excellent picture resolution up to 640 x 480 pixels
4, 8, & 16 video & alarm inputs
Web-based video monitoring
Mobile video on Pocket PC
Triplex Operation: Simultaneous video monitoring, recording & playback
Video motion detection
Event-driven recording
Programmable video recording
Auto alarm dial-back
Pre- & post-alarm video recording
Compatibility with popular telemetry systems
Single- & multi-site monitoring
Audio transmission with
EAR
Video back-up function
4 relay switches
Eye
III+
Video Recording Transmitter I
nstallation Guide Page 3
Interface Description
INTERFACE
DESCRIPTION
Eye
III+
Video Recording Transmitter I
nstallation Guide Page 4
Interface Description
Functional Descriptions
VIDEO INPUT Connectors
-VRB-4041: CH1 – CH4
-VRB-8082: CH1 – CH8
-VRB-16164: CH1 – CH16
-Standard BNC connectors for color and black&white video sources
-A composite video signal should be supplied to these connectors
-“Line lock” camera(s) is(are) recommended to be used.
ALARM & SWITCH Port
-4 remote control switches are available for all the models.
-VRB-4041: 4 alarm input ports
-VRB-8082: 8 alarm input ports
-VRB-16164: 16 alarm input ports
-All alarm channels have the same priority.
Ethernet Socket (10/100 Base-T)
-This socket is used for connecting VRB to the corporate computer network (e.g. LAN)
Collision & Link LED Status
-COL LED, when on, indicates that collision is occurring on the network.
-LINK LED, when on, indicates that VRB is connecting to the network and ready to function.
Eye
III+
Video Recording Transmitter I
nstallation Guide Page 5
Interface Description
AUX Port
-A DB-9 female connector of DCE format, capable of connecting to DTE such as remote
Pan/Tilt/Zoom operation
-Used for configuring the VRB ’s internal settings
Pin number
Definition Direction
1 CD Output
2 RXD Output
3 TXD Input
4 DTR Input
5 GND –––
6 DSR Output
7 RTS Input
8 CTS Output
9 N/A
MODEM Port
-A DB-9 male connector of DTE format, capable for connecting to DCE such as modem,
ISDN terminal adaptor
Pin number
Definition Direction
1 CD Input
2 RXD Input
3 TXD Output
4 DTR Output
5 GND –––
6 DSR Input
7 RTS Output
8 CTS Input
9 N/A
Power Jack
-A 2.1mm D.C. power jack for the connection to the power supply (12V D.C.)
